Teltonika Switches

Teltonika TSW110 L2 Unmanaged x5 Port Switch


TSW110 is a layer 2 unmanaged switch, which is a simplified version of our earlier product – TSW100.

Possible to power up through the first LAN port.

It has five 10/100/1000 Mbps Ethernet ports for an economical high-bandwidth solution.

It offers a wide range of supported power supply voltages (9-30 V).

Ideal for professional high bandwidth applications to provide reliable data connection.




Front View:







Back View:








Plug-n-play No additional configuration needed




Mounting DIN rail and surface mounting options




9-30 V Wide range of supported power supply voltages




Durability Rugged aluminium housing




Status LEDs 1 x Power, 10 x Ethernet




Gigabit ETH 5 x Gigabit Ethernet with speeds up to 1000 Mbps




Quick start guide:



Ethernet LAN 5 x LAN ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover Performance specifications Bandwidth (Non-blocking) 10 Gbps Packet buffer 128 KB MAC address table size 2K entries Connector 4 pin industrial DC power socket Input voltage range 9 - 30 VDC, reverse polarity protection, voltage surge/transient protection PoE (passive) Passive PoE. Possibility to power up through LAN port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards Power consumption (idle/max) < 0.4 W/ <1.8 W Physical interfaces (ports, LEDs) Ethernet 5 x RJ45 ports, 10/100/1000 Mbps Status LEDs 1 x Power LED, 10 x LAN status LED’s Power 1 x 4 pin DC connector Ground 1 x Grounding screw Physical specification Casing material Full aluminum housing Dimensions (W x H x D) 100 x 30 x 85 mm Weight 227 g Mounting options DIN rail or wall mounting (additional kit needed), flat surface placement Operating environment Operating temperature -40 C to 75 C Operating humidity 10 % to 90 % non-condensing Hardware Ethernet 5 x LAN ports 10/100/1000 Mbps Power supply 9 - 30 V, 4 pin DC connector Power consumption idle: < 0.4 W, max: < 1.8 W PoE input (passive) Passive PoE over 4,5 (power) and 7,8 (ground) pins. Possibility to power up through first LAN port, not compatible with IEEE802.3af and 802.3at standards Connectors 1 x 4 pin DC, 5 x Ethernet Status LEDs 1 x Power, 10 x Ethernet Ingress protection rating IP30 Operating temperature -40 °C to 75 °C Housing Aluminium housing with wall or DIN rail mounting option and grounding capability Dimensions 100 x 30 x 85 mm Weight 227 g Installation Desktop, wall or DIN Rail mountable (additional kit needed) Full specification and details can be found in the Product Datasheet PDF file

A quick start guide can be found in the Quick Start Guide PDF file

A product flyer can be found in the Product Flyer PDF file

L2 Unmanaged Switch TSW110 is a layer 2 unmanaged switch, which is a simplified version of our earlier product - TSW100. Possible to power up through the first LAN port. It has five 10/100/1000 Mbps Ethernet ports for an economical high-bandwidth solution. It offers a wide range of supported power supply voltages (9-30 V). Ideal for professional high bandwidth applications to provide reliable data connection.

Plug-N-Play
No additional configuration needed

Durability
Rugged aluminium housing

  Mounting
DIN rail and surface mounting options

Status LEDs
1 x Power, 10 x Ethernet

  9-30 V
Wide range of supported power supply voltages

Gigabit Ethernet
5 x Gigabit Ethernet with speeds up to 1000 Mbps

  RUTX14 Diagram

Front View

Rear View

Teltonika TSW200 PoE+ Gigabit Ethernet x8 Port Switch


TSW200 is industrial unmanaged switch from Teltonika Networks.

TSW200 is equipped with 2 SFP ports for long-range Fiber-optic communication and 8 Gigabit Ethernet ports which support IEEE802.3af and IEE802.3at Power-over-Ethernet standards.

Classified as power source equipment (PSE), it enables centralization of the power supply, providing up to 30 watts per port and reducing the effort for installing power. It has 10/100/1000 Mbps Ethernet ports to provide an economical high-bandwidth solution for your industrial Ethernet network.

This rugged unmanaged industrial switch is ideal for professional high bandwidth applications where it is necessary to provide both: reliable data connection and power supply.




Front View:







Back View:








POE+ 8x PoE ports with 802.3af and 802.3at support




Power budget Total power budget at PSE up to 240 W




SFP 2 x SFP ports for long-range Fiber-optic communication voltages




Durability Rugged aluminium housing




Ethernet 8 x Gigabit Ethernet with speeds up to 1000 Mbps




Mounting DIN rail and surface mounting options




Quick start guide:



Ethernet LAN 8 x LAN ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover Fiber 2 x SFP ports POE PoE ports Port 1 - 8 PoE standards 802.3af and 802.3at PoE Max Power per Port (at PSE) 30 W Total PoE Power Budget (at PSE) 240 W Performance specifications Bandwidth (Non-blocking) 20 Gbps Packet buffer 128 KB MAC address table size 2K entries Jumbo frame support 9216 bytes Power Connector 2 pin industrial DC power socket Input voltage range 7 - 57 VDC Input voltage range for PoE 44 - 57 VDC Power consumption (idle/max no PoE/max) 1,81 W/5.5 W/245.5 W Physical interfaces (ports, LEDs) Ethernet 8 x RJ45 ports, 10/100/1000 Mbps Status LEDs 1 x Power LED, 16 x LAN status LED’s 2 x SFP status LED’s Power 1 x 2 pin industrial DC power socket Ground 1 x Grounding screw Fiber 2 x SFP ports Physical specification Casing material Full aluminum housing Dimensions (W x H x D) 132 x 44.2 x 95.1 mm Weight 456 g Mounting options DIN rail or wall mounting (additional kit needed), flat surface placement Operating environment Operating temperature -40 °C to +75 °C Operating humidity 10 % to 90 % non-condensing Ingress Protection Rating IP30 Hardware Power connector 2 pin industrial DC power socket Input voltage range 7-57 VDC Input voltage range for PoE 44-57 VDC Power consumption Idle: 1.81W, Max: 5.5W (no PoE device connected) PoE standard 802.3af/at (up to 30 W per port, total power budget - 240 W) Ethernet 8 x 10/100/1000 Mbps Ethernet ports SFP 2 x SFP ports for Optical interfaces Status LEDs 16 x Ethernet, 1 x Power, 2 x SFP activity Ingress protection rating IP30 Operating temperature -40 °C to 75 °C Housing Aluminium housing with wall or DIN rail mounting option and grounding capability Dimensions 132 x 44.2 x 95.1 mm Weight 456 g Installation Desktop, wall or DIN Rail mountable (additional kit needed) Full specification and details can be found in the Product Datasheet PDF file

A quick start guide can be found in the Quick Start Guide PDF file

A product flyer can be found in the Product Flyer PDF file

Overview

AUTOMOTIVE SWITCH Ideal for in-vehicle solutions

POE+ 4 x PoE+ ports with 802.3af and 802.3at support

GIGABIT ETHERNET 5 x Gigabit Ethernet ports with speeds of up to 1000 Mbps

INDUSTRIAL DESIGN Rugged aluminum housing

LOW INPUT VOLTAGE 9-30 V power range for PoE

PLUG-N-PLAY No configuration needed



Product Features TSW101 is Teltonika Networks’ first automotive-dedicated unmanaged switch.

Equipped with five Gigabit Ethernet ports, four of which support IEEE802.3af and IEEE802.3at PoE+ standards.

A wide range of supported power supply voltages (9-30 VDC), and a compact size allow it to slot into many automotive applications.

Classified as a power source equipment (PSE), this device enables power supply centralization - providing up to 30 watts per single port and maximum output power of 60 watts.

10/100/1000 Mbps Ethernet ports for streamlined, high-bandwidth solutions.

Ideal for providing both: in-vehicle power and an Ethernet data connection simultaneously.
