| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | FETSW202 |
| Manufacturer No: | TSW202 |
| Delivery: | In Stock: Next Day |
 |
The Teltonika TSW202 is a managed PoE+ Ethernet switch that combines eight Gigabit Ethernet ports with two SFP ports for flexible copper and fibre connectivity. It provides Layer 2 management with additional Layer 3 features, allowing network administrators to control VLANs, port settings, traffic priorities and routing functions. All eight Ethernet ports support PoE+ with up to 30 W per port and a total PoE power budget of 240 W, while support for PROFINET, EtherNet/IP and MRP makes the switch suitable for industrial networking applications.
The switch provides eight 10/100/1000 Mbps RJ45 Ethernet ports alongside two SFP interfaces for fibre optic connections. The combination allows copper-connected equipment and longer-distance fibre links to operate through the same managed switching platform, with support for IEEE 802.3i, 802.3u, 802.3ab, 802.3x and 802.3z standards.
The switch provides Layer 2 management features including VLAN configuration, STP/RSTP, loop protection, port isolation, port mirroring and link speed control. Additional Layer 3 functionality includes static IPv4 and IPv6 routing, DHCPv6 client support and static IPv6 addressing.
All eight Gigabit Ethernet ports provide PoE+ output using IEEE 802.3af and IEEE 802.3at standards. Each port can deliver up to 30 W at the power sourcing equipment, with a total PoE power budget of 240 W. This allows compatible cameras, wireless access points, sensors and other network devices to receive power and data through their Ethernet connections.
Support for industrial networking protocols includes EtherNet/IP, PROFINET and MRP. The switch also supports SNMP v2 and v3, LLDP and 802.1X port-based network access control, providing additional options for integrating the switch into managed industrial networks.
QoS features include port priority, DSCP priority, 802.1p priority and TOS, while scheduling methods include SP, WFQ and WRR. Bandwidth controls provide rate limiting and storm control. The switch offers 20 Gbps of non-blocking bandwidth, a 512 KB packet buffer, an 8K-entry MAC address table and jumbo frame support up to 10,000 bytes.
The anodised aluminium housing measures 132 x 44.2 x 122.2 mm and weighs 610 g. An integrated DIN rail bracket supports cabinet installation, while wall mounting and flat-surface placement are also available with an additional mounting kit. The switch accepts 7-57 VDC, with PoE operation requiring an input voltage of 44 VDC or higher. It operates from -40 °C to 75 °C and has an IP30 ingress protection rating.
The Teltonika TSW202 is a managed PoE+ Ethernet switch that combines eight Gigabit Ethernet ports with two SFP ports for flexible copper and fibre connectivity. It provides Layer 2 management with additional Layer 3 features, allowing network administrators to control VLANs, port settings, traffic priorities and routing functions. All eight Ethernet ports support PoE+ with up to 30 W per port and a total PoE power budget of 240 W, while support for PROFINET, EtherNet/IP and MRP makes the switch suitable for industrial networking applications.
The switch provides eight 10/100/1000 Mbps RJ45 Ethernet ports alongside two SFP interfaces for fibre optic connections. The combination allows copper-connected equipment and longer-distance fibre links to operate through the same managed switching platform, with support for IEEE 802.3i, 802.3u, 802.3ab, 802.3x and 802.3z standards.
The switch provides Layer 2 management features including VLAN configuration, STP/RSTP, loop protection, port isolation, port mirroring and link speed control. Additional Layer 3 functionality includes static IPv4 and IPv6 routing, DHCPv6 client support and static IPv6 addressing.
All eight Gigabit Ethernet ports provide PoE+ output using IEEE 802.3af and IEEE 802.3at standards. Each port can deliver up to 30 W at the power sourcing equipment, with a total PoE power budget of 240 W. This allows compatible cameras, wireless access points, sensors and other network devices to receive power and data through their Ethernet connections.
Support for industrial networking protocols includes EtherNet/IP, PROFINET and MRP. The switch also supports SNMP v2 and v3, LLDP and 802.1X port-based network access control, providing additional options for integrating the switch into managed industrial networks.
QoS features include port priority, DSCP priority, 802.1p priority and TOS, while scheduling methods include SP, WFQ and WRR. Bandwidth controls provide rate limiting and storm control. The switch offers 20 Gbps of non-blocking bandwidth, a 512 KB packet buffer, an 8K-entry MAC address table and jumbo frame support up to 10,000 bytes.
The anodised aluminium housing measures 132 x 44.2 x 122.2 mm and weighs 610 g. An integrated DIN rail bracket supports cabinet installation, while wall mounting and flat-surface placement are also available with an additional mounting kit. The switch accepts 7-57 VDC, with PoE operation requiring an input voltage of 44 VDC or higher. It operates from -40 °C to 75 °C and has an IP30 ingress protection rating.
