APC Back-UPS CS 325VA, 230V, without auto shutdown software, 4 IEC outlets (1 surge)
Battery Backup & Surge Protector for Electronics and Computers
Includes: (2) Detachable IEC C13 to IEC C14 power cords, User manual
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Battery-protected and surge-only outlets
Reserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only protection for less critical equipment.
Surge only outlets
Protect secondary electronics from surges and spikes without reducing battery power used to run primary electronics during an outage.
Battery and surge protected outlets
Back up and protect your hardware and data during power outages, surges and spikes.
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance.
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
LED status display
Quickly understand unit and power status with visual indicators.
Audible alarms
Provides notification of changing utility power and UPS power conditions.
Battery and surge protected outlets
Back up and protect your hardware and data during power outages, surges and spikes.
Installation:
1. Placement / Power
Avoid placing the Back-UPS in: Direct sunlight, Excessive heat, Excessive humidity or in contact with fluids of any type
Plug the Back-UPS into a wall outlet, as show
2. Connect Equipment to the Back-UPS
The rear panel of the Back-UPS consists of the following elements:
Battery Back Up Outlets (qty. of 3). These outlets provide battery back-up, surge protection, and Electro-magnetic Interference (EMI) filtering. In case of power outage, battery power is automatically provided to these outlets. Power (utility or battery) is not supplied to these outlets when the Back-UPS is switched Off. Connect a computer, monitor, and external disk or CD-ROM drive to these outlets.
Surge Only Outlet. This outlet is always On (when utility power is available) and is not controlled by the On/Off switch. This outlet does not provide power during a power outage. Connect a printer, fax machine or scanner to this outlet.
3. Switch on the Back-UPS
Press the push-button on Back-UPS front panel.
Observe that the following events occur after pressing and releasing the push-button:
The green On-Line indicator flashes.
The yellow On Battery indicator lights while the Self-Test is being performed.
When Self-Test has successfully completed, only the green On Line indicator will be lit.
If the internal battery is not connected, (see Step 1 above) the green On Line indicator and red Replace Battery indicator will light. The BackUPS will also emit a chirping sound.
Additional information can be found in the Brochure PDF file
