APC BGM2200B-UK Back-UPS Pro 230V 2200VA Gaming UPS

This APC Back-UPS Pro offers premium power protection for high performance gaming consoles and PC, routers/modems, and gaming accessories. The 2200VA/1320W tower UPS has 4 total outlets, 4 of which are battery back up and surge protection.

It has a surge energy rating of 1080 Joules. It features Automatic Voltage Regulation to correct voltage dips and surges to proper levels. It comes with PowerChute Serial Shutdown, an easy-to-use safe system shutdown software with power and energy management features.

This UPS has a 3-year warranty and a $150,000 connected equipment protection policy. It has 3 USB ports (Type A + C) for smart charging of personal devices.

Features

Specification

Main

• Main Input Voltage: 230 V AC 1 phase
• Other Input Voltage: 230 V
• Main Output Voltage: 230 V 1 phase
• Rated Power in W: 1320 W
• Rated Power in VA: 2200 VA
• Output Connection Type: 2 UK Standard, 2 IEC 60320 C13
• Number of Rack Unit: 0U
• Cable Length: 1.52 m
• Number of Cables: 1

Batteries and Runtime

• Battery Type: Lead-acid battery
• Run Time: 23s - 43m (Dependent on load)
• Battery Recharge Time: 16 h
• Battery Voltage: 24 V
• Overcurrent Protection: 13 A
• Battery Charger Power: 12 W rated
• Battery Life: 3-5 year(s)

General

• Provided Equipment: Safety guide, USB cable
• Product Web Sub-family: Gaming performance
• USB Compatible: Yes
• Color: Black
• Dimensions (H x W x D): 292.10 x 104.14 x 408.94 mm
• Net Weight: 12.32 kg
• Mounting Support: Floor
• Mounting Preference: No preference
• Mounting Mode: Not rack-mountable, Two post mountable

Input

• Network Frequency: 50/60 Hz +/- 3 Hz
• Plug Standard: UK
• Input Voltage Limits: 168-302 V
• Maximum Input Current: 12 A
• Switching Current Capacity: 15 A
• Input Harmonic Distortion: Less than 3% for full load
• Input Protection Type: Circuit breaker and fuse

Output

• Maximum Configurable Power in W: 1320 W
• Output Frequency: 50/60 Hz +/- 3 Hz sync to mains
• UPS Type: Line interactive
• Wave Type: Sine wave
• Maximum Configurable Power in VA: 2200 VA
• Transfer Time: 8 ms typical : 10 ms maximum

Conformance

• Product Certifications: IEC 62040-1-1, IEC 62040-2

Environmental

• Ambient Air Temperature for Operation: 0-40 °C
• Relative Humidity for Operation: 0-95 %
• Operating Altitude: 0-10000 ft
• Ambient Air Temperature for Storage: -15-40 °C
• Relative Humidity for Storage: 0-95 %
• Storage Altitude: 0.00-3048.00 m
• Acoustic Level: 45 dBA
• IP Degree of Protection: IP20

Communications & Management

• Free Slots: 0
• Control Panel: Multifunction LCD status and control console
• Alarm: Alarm when on battery, distinctive low battery alarm, overload continuous tone alarm

Surge Protection and Filtering

• Surge Energy Rate: 1080 J
• Noise Suppression: Full time multi-pole noise filtering, 5% of IEEE surge let-through, zero clamping response time: instantaneous

Packing Units

• Unit Type of Package 1: PCE
• Package 1 Dimensions (H x L x W): 15.5 x 35.5 x 48 cm
• Package 1 Weight: 14.46 kg

Logistical Information

• Contractual Warranty: Warranty - 2 years repair or replace, 3 years repair or replace for European Union countries
