D-Link Network Switches

D-Link’s DGS-1210-28P Gigabit PoE Smart+ Switch with 4 Fibre Uplinks integrates advanced management as well as security functions that provide performance and scalability. Management options for the switch include SNMP, Web Management, D-Link Network Assistant Utility,

The DGS-1210-28P uses Auto Voice VLAN, ensuring bandwidth is prioritised for a smoother voice performance. The DGS-1210-28P features a smart fan design that powers on after the switch reaches a certain temperature, saving energy and cutting costs without sacrificing performance.

The DGS-1210-28P is a high power budget PoE-enabled switch for businesses looking to power VoIP phones, wireless access points or network cameras. The DGS- 1210-28P is a Smart PoE+ switch with power budgets of 193W that provides 24 PoE-enabled ports with 4 ports that support up to 30W of power output following IEEE 802.3at standard. The design allows more flexibility in power allocation for a variety of powered devices with affordable installation costs.

DGS-1210-28P: 20 x 1000Base-T 802.3af PoE 4 x 1000Base-T 802.3at PoE 4 x 1GbE SFP 193W PoE budget Green Technology

Power saving via the following features: Link Status detection
LED Shut-Off
Port Shut-Off
System Hibernation
Time-based PoE

Security Features
Access Control List secures network
D-Link Safeguard Engine protects CPU from Broadcast/Multicast/Unicast Flooding
Port Security supports 64 MACs per port
ARP Spoofing Prevention
Intuitive Management
D-Link Network Assistant Utility or Web-based GUI
Built-in SNMP MIB for remote NMS (D-View 6.0)
Compact CLI through Telnet
Advanced Features
Auto Surveillance VLAN
Loopback Detection automatically disables a port when a loop is detected
Cable Diagnostics allows administrators to determine cable status
SFP ports for flexibility
Auto MDI/MDIX
Energy saving DGS-1210 switch is capable of conserving power without sacrificing operational performance or functionality by using D-Link Green 3.0 technology. Using the Energy Efficient Ethernet standard, the network will automatically decrease the power usage when traffic is low with no setup required. For environments not fully supporting the standard, DGS-1210 switch offers advanced power-saving settings including port shutoff and standby, LED shutoff, and system hibernation based on custom scheduling profiles. The profiles can also be applied to the PoE switch so that there is no unnecessary power consumption during off hours. The DGS-1210 series switch can also detect the length of connected cables to automatically reduce power usage on shorter cable connections.


Auto Surveillance VLAN and Voice VLAN The process of setting up IP surveillance and VoIP on a network is automated with the D-Link Smart switch. Auto Surveillance VLAN (ASV) consolidates data and surveillance video transmission through the network, sparing businesses the expense of maintaining dedicated facilities. ASV also protects the quality of real-time video by grouping IP surveillance devices on a single high priority VLAN. This ensures that surveillance video streams will not be affected when ordinary data traffic is at their high levels. Similarly, the Auto Voice VLAN guarantees clear audio quality and efficient transmission for all voice communication.


Exclusive Layer 2 features Equipped with a complete lineup of L2 features, the DGS-1210 series switch includes IGMP Snooping, Port Mirroring, Spanning Tree, and Link Aggregation Control Protocol (LACP). The IEEE 802.3x flow control function allows servers to directly connect to the switch for fast, reliable data transfer. At 2000 Mbps full duplex, the Gigabit ports provide high-speed data pipes to servers with minimum data transfer loss. Network maintenance features include loopback detection and cable diagnostics. Loopback detection is used to detect loops created by a specific port and automatically shut down the affected port. The cable diagnostic feature is designed primarily for administrators and customer service representatives, and can rapidly discover the type of error and determine the cable quality.


Secure your network D-Link's safeguard engine protects the switch against traffic flooding caused by virus attacks. The switch also supports 802.1x port-based authentication, allowing the network clients to be authenticated through external RADIUS servers. In addition, the Access Control List (ACL) feature enhances network security and protects the network by screening traffic from illegal MAC or IP addresses. ARP spoofing prevention prevents malicious intruders from sending massive fake ARP messages through a manipulated source. This protects important data from being stolen by man-in-the-middle attacks, and prevents wasting CPU cycles on these packets. For added security, the DHCP server screening feature blocks rogue DHCP server packets from user ports to prevent unauthorised IP assignment.


DGS-1210-24 DGS-1210-24P DGS-1210-28 DGS-1210-28P DGS-1210-28MP Form Factor Rackmount Rackmount Rackmount Rackmount Rackmount Switching Capacity 56 Gbps 56 Gbps 56 Gbps 56 Gbps 56 Gbps 100M/1G Copper  (RJ-45) Ports 24 24 24 24 24 1G SFP Fibre Ports 4 4 4 4 4 PoE/PoE+ Ports N/A 12 N/A 24 24 PoE Standard N/A 802.3af/ 802.3at  N/A 802.3af/ 802.3at  802.3at PoE Budget N/A 85 W N/A 193 W 370 W PoE Capable Ports N/A Ports 1 to 12: Up to 30 W N/A Ports 1 to 4: 802.3at.
Ports 5 to 24: 802.3af Ports 1 to 24: Up to 30 W Dimensions 441 x 209.9 x 44 mm 441 x 209.9 x 44 mm 440 x 140 x 44 mm 444 x 210 x 44 mm 440 x 250 x 44 mm

The D-Link DGS-1026MP 26-Port Gigabit Max PoE Switch enables users to easily connect and power PoE-capable devices such as wireless access points (APs), IP cameras, and IP phones. Each of the 24 PoE ports can supply up to 30 W, with a total PoE budget of 370 W.

Features

24 x Gigabit Ethernet ports (4x PoE+ ports)
2 Gigabit Combo Uplink Ports
370W power budget
52 Gbps switching fabric capacity
Plug & play simplicity for easy installation
Hassle-Free Setup

The DGS-1026MP is a plug-and-play device that requires no configuration, so setup is simple and hassle-free. Simply connect the switch to the network and then connect multiple computers, share files and make VoIP calls across the network.



Energy Efficient

To help small businesses save on operating costs, the DGS-1026MP supports IEEE 802.3az Energy Efficient Ethernet (EEE). This feature actively monitors network traffic and automatically puts ports that are not being used into hibernation, powering them on only when they are required.



Power Over Ethernet+

The DGS-1026MP features 24 10/100/1000BASE-T ports that support the IEEE 802.3at PoE+ standard. Each of the 24 PoE ports can supply up to 30 W, with a total PoE budget of 370 W. The PoE usage LEDs further provide real-time feedback on the current PoE power usage on the network and helps plan out the PoE network budget, preventing PoE overloading problems..





Expand Your Network

With 2 x Gigabit combo uplink ports, businesses have additional flexibility their network deployment, offering a choice for upstream or downstream server connections via a fibre or copper interface.

The DGS-1210-48 48-Port Gigabit Smart Managed Switches with Four Fibre Uplinks is the latest generation of D-Link Smart Managed Switches. With D-Link Green 3.0 technology, the series offers a high level of energy saving and efficiency, as well as compliance with IEEE 802.3az Energy Efficient Ethernet standard.

Features:

48-Port Gigabit Smart Managed Switch
4 combo 1000BASE-T/SFP ports
Fanless
Easily manage your entire network with the Web GUI or D-Link Network Assistant using features like automatic switch discovery, batch operations, and more
Innovative Safeguard Engine, ACL, and ARP Spoofing Prevention protect your network from malicious attacks and illegal access
Range of D-Link Green Technology features help save energy usage automatically and reduce costs, without sacrificing performance
DGS-1210-48: 44 x 1000Base-T  4 Combo 1000 Mbps Base-T /1000 Mbps SFP
  D-Link green The DGS-1210-48 implements D-Link Green, an innovative concept that provides energy savings without sacrificing operational performance or functionality. The switch reacts when devices attached to it are turned off, by placing the corresponding port in a standby mode that requires less power. It also automatically detects the length of connected cables, which allows it to cut power usage on shorter cable connections up to 20 m.



Seamless integration The DGS-1210-48 includes 48 10/100/1000 Mbps ports capable of connecting to existing Cat. 5 twisted-pair cables. Additionally, the last four ports of the DGS-1210-48 combine SFP and copper connectivity into one port and therefore provide a flexible solution for server connections via fibre interface. Using the default presets, the administrator can quickly set up the switch without worrying about reconfiguring any settings and providing easy access for the user.


Extensive layer 2 features Equipped with a complete lineup of L2 features, these switches include IGMP snooping, port mirroring, spanning tree and Link Aggregation Control Protocol (LACP). The IEEE 802.3x flow control function allows servers to directly connect to the switch for fast, reliable data transfer. At 2000Mbps full duplex, the gigabit ports provide high-speed data pipes to servers with minimum data transfer loss. Network maintenance features include Loopback detection and cable diagnostics. Loopback detection is used to detect loops created by a specific port and automatically shut down the affected port. Cable diagnostics is designed for network administrators to quickly examine the quality of the copper cables and also determine the type of cable error.


QoS, bandwidth control The switches are perfect for deployment in a VoIP environment, as they support Auto Voice VLAN and Differentiated Services Code Point (DSCP) QoS for VoIP application. Auto Voice VLAN will automatically place voice traffic from an IP phone to an assigned VLAN and by doing so enhance the VoIP service. With a higher priority and individual VLAN, this feature guarantees the quality and security of VoIP traffic. DSCP marks parts of an IP packet, enabling different levels of service to be assigned for network traffic. With Bandwidth Control, the network administrator can reserve bandwidth for important functions that require a larger bandwidth or might have high priority.


Secure your network D-Link's innovative safeguard engine function protects the switches against traffic flooding caused by virus attacks. The switches also support 802.1X port-based authentication, allowing the network to be authenticated through external RADIUS servers. In addition, the Access Control List (ACL) feature enhances network security and helps to protect the internal IT network. The DGS-1210 series includes ARP spoofing prevention, which protects from attacks on the Ethernet network that may allow an intruder to sniff data frames on a LAN, modify traffic, or bring traffic to a halt altogether by sending fake ARP messages to the network. To prevent ARP spoofing attacks, the switch uses packet control ACLs to block invalid packets that contain fake ARP messages. For added security, the DHCP Server Screening feature screens rogue DHCP server packets from user ports to prevent unauthorised IP assignment.

D-Link’s DGS-1210-08P Gigabit PoE Smart+ Switch with 2 Fibre Uplinks integrates advanced management as well as security functions that provide performance and scalability. Management options for the switch include SNMP, Web Management, D-Link Network Assistant Utility.

The DGS-1210-08P uses Auto Voice VLAN, ensuring bandwidth is prioritised for a smoother voice performance and features a fanless design that allows for quieter operation and helps to extend the device’s lifetime.

The DGS-1210-08P is a PoE-enabled switch for businesses looking to power VoIP phones, wireless access points or network cameras. The DGS- 1210-08P is a Smart PoE switch with a power budget of 45W that provides 8 PoE-enabled ports power of up to 15.4 W each. The design allows more flexibility in power allocation for a variety of powered devices with affordable installation costs.

Features:

Easily manage your entire network with the Web GUI or D-Link Network Assistantusing features like automatic switch discovery, batch operations, and more
Innovative Safeguard Engine, ACL, and ARP Spoofing Prevention protect your network from malicious attacks and illegal access
Range of D-Link Green Technology features help save energy usage automatically and reduce costs, without sacrificing performance
DGS-1210-08P: 8 x 1000Base-T 802.3af PoE 2 x 1GbE SFP
Fanless 45W PoE budget
Energy saving DGS-1210 switch is capable of conserving power without sacrificing operational performance or functionality by using D-Link Green 3.0 technology. Using the Energy Efficient Ethernet standard, the network will automatically decrease the power usage when traffic is low with no setup required. For environments not fully supporting the standard, DGS-1210 switch offers advanced power-saving settings including port shutoff and standby, LED shutoff, and system hibernation based on custom scheduling profiles. The profiles can also be applied to the PoE switch so that there is no unnecessary power consumption during off hours. The DGS-1210 series switch can also detect the length of connected cables to automatically reduce power usage on shorter cable connections.


Auto Surveillance VLAN and Voice VLAN The process of setting up IP surveillance and VoIP on a network is automated with the D-Link Smart switch. Auto Surveillance VLAN (ASV) consolidates data and surveillance video transmission through the network, sparing businesses the expense of maintaining dedicated facilities. ASV also protects the quality of real-time video by grouping IP surveillance devices on a single high priority VLAN. This ensures that surveillance video streams will not be affected when ordinary data traffic is at their high levels. Similarly, the Auto Voice VLAN guarantees clear audio quality and efficient transmission for all voice communication.


Exclusive Layer 2 features Equipped with a complete lineup of L2 features, the DGS-1210 series switch includes IGMP Snooping, Port Mirroring, Spanning Tree, and Link Aggregation Control Protocol (LACP). The IEEE 802.3x flow control function allows servers to directly connect to the switch for fast, reliable data transfer. At 2000 Mbps full duplex, the Gigabit ports provide high-speed data pipes to servers with minimum data transfer loss. Network maintenance features include loopback detection and cable diagnostics. Loopback detection is used to detect loops created by a specific port and automatically shut down the affected port. The cable diagnostic feature is designed primarily for administrators and customer service representatives, and can rapidly discover the type of error and determine the cable quality.


Secure your network D-Link's safeguard engine protects the switch against traffic flooding caused by virus attacks. The switch also supports 802.1x port-based authentication, allowing the network clients to be authenticated through external RADIUS servers. In addition, the Access Control List (ACL) feature enhances network security and protects the network by screening traffic from illegal MAC or IP addresses. ARP spoofing prevention prevents malicious intruders from sending massive fake ARP messages through a manipulated source. This protects important data from being stolen by man-in-the-middle attacks, and prevents wasting CPU cycles on these packets. For added security, the DHCP server screening feature blocks rogue DHCP server packets from user ports to prevent unauthorised IP assignment.



DGS-1210-08P DGS-1210-10 DGS-1210-10P DGS-1210-16 Form Factor Desktop/ Rackmount Desktop/ Rackmount Desktop/ Rackmount Desktop/ Rackmount Switching Capacity 20 Gbps 40 Gbps 40 Gbps 40 Gbps 100M/1G Copper  (RJ-45) Ports 8 8 8 16 1G SFP Fibre Ports  2 2 2 4 PoE/PoE+ Ports 8 N/A 8 N/A PoE Standard 802.3af N/A 802.3af/ 802.3at  N/A PoE Budget 45 W N/A 78 W N/A PoE Capable Ports Ports 1 to 8: Up to 15.4 W N/A Port 1 to 8 (30 W max. per PoE port) N/A Dimensions 280 x 180 x 44 mm 280 x 126 x 44 mm 280 x 180 x 44 mm 280 x 180 x 44 mm

D-Link DGS-1210-24P Gigabit Smart Switch with Fibre Uplinks is the latest generation of D-Link Smart Switches featuring D-Link Green 3.0 technology. offering a high level of energy saving and efficiency, as it also complies with the IEEE 802.3az Energy Efficient Ethernet standard. Support for IPv6 management and configurations ensure your network remains protected after the upgrade from IPv4 to IPv61. By offering multiple management options, the Smart Switches allows quick deployment, infrastructure expansion, and seamless function upgrades. Built for small and medium-sized businesses, the DGS-1210-24P Smart Switch provides functionality, security and manageability for a fraction of the standard cost of ownership.

The DGS-1210-24P is an affordable PoE-enabled switch for businesses looking to power VoIP phones, wireless access points or network cameras. The DGS-1210-24P is a 24-port Smart PoE Switch that provides 24 PoE-enabled ports that can support up to 30 W of power output following IEEE 802.3at standard. The design allows more flexibility in power allocation for a variety of powered devices with affordable installation costs.

Features:

Easily manage your entire network with the Web GUI or D-Link Network Assistant using features like automatic switch discovery, batch operations, and more
Innovative Safeguard Engine, ACL, and ARP Spoofing Prevention protect your network from malicious attacks and illegal access
Range of D-Link Green Technology features help save energy usage automatically and reduce costs, without sacrificing performance


DGS-1210-24P:

24 x 1000Base-T / 802.3af PoE

4 x 1GbE SFP


193W PoE budget


Energy saving DGS-1210 switch is capable of conserving power without sacrificing operational performance or functionality by using D-Link Green 3.0 technology. Using the Energy Efficient Ethernet standard, the network will automatically decrease the power usage when traffic is low with no setup required. For environments not fully supporting the standard, DGS-1210 switch offers advanced power-saving settings including port shutoff and standby, LED shutoff, and system hibernation based on custom scheduling profiles. The profiles can also be applied to the PoE switch so that there is no unnecessary power consumption during off hours. The DGS-1210 series switch can also detect the length of connected cables to automatically reduce power usage on shorter cable connections.



Auto Surveillance VLAN and Voice VLAN The process of setting up IP surveillance and VoIP on a network is automated with the D-Link Smart switch. Auto Surveillance VLAN (ASV) consolidates data and surveillance video transmission through the network, sparing businesses the expense of maintaining dedicated facilities. ASV also protects the quality of real-time video by grouping IP surveillance devices on a single high priority VLAN. This ensures that surveillance video streams will not be affected when ordinary data traffic is at their high levels. Similarly, the Auto Voice VLAN guarantees clear audio quality and efficient transmission for all voice communication.


Exclusive Layer 2 features Equipped with a complete lineup of L2 features, the DGS-1210 series switch includes IGMP Snooping, Port Mirroring, Spanning Tree, and Link Aggregation Control Protocol (LACP). The IEEE 802.3x flow control function allows servers to directly connect to the switch for fast, reliable data transfer. At 2000 Mbps full duplex, the Gigabit ports provide high-speed data pipes to servers with minimum data transfer loss. Network maintenance features include loopback detection and cable diagnostics. Loopback detection is used to detect loops created by a specific port and automatically shut down the affected port. The cable diagnostic feature is designed primarily for administrators and customer service representatives, and can rapidly discover the type of error and determine the cable quality.


Secure your network D-Link's safeguard engine protects the switch against traffic flooding caused by virus attacks. The switch also supports 802.1x port-based authentication, allowing the network clients to be authenticated through external RADIUS servers. In addition, the Access Control List (ACL) feature enhances network security and protects the network by screening traffic from illegal MAC or IP addresses. ARP spoofing prevention prevents malicious intruders from sending massive fake ARP messages through a manipulated source. This protects important data from being stolen by man-in-the-middle attacks, and prevents wasting CPU cycles on these packets. For added security, the DHCP server screening feature blocks rogue DHCP server packets from user ports to prevent unauthorized IP assignment.






DGS-1210-24 DGS-1210-24P DGS-1210-28 DGS-1210-28P DGS-1210-28MP Form Factor Rackmount Rackmount Rackmount Rackmount Rackmount Switching Capacity 56 Gbps 56 Gbps 56 Gbps 56 Gbps 56 Gbps 100M/1G Copper  (RJ-45) Ports 24 24 24 24 24 1G SFP Fibre Ports 4 4 4 4 4 PoE/PoE+ Ports N/A 24 N/A 24 24 PoE Standard N/A 802.3af/ 802.3at  N/A 802.3af/ 802.3at  802.3at PoE Budget N/A 193 W N/A 193 W 370 W PoE Capable Ports N/A Ports 1 to 24: Up to 30 W
(Max 193 W) N/A Ports 1 to 4: 802.3at.
Ports 5 to 24: 802.3af Ports 1 to 24: Up to 30 W Dimensions 441 x 209.9 x 44 mm 441 x 209.9 x 44 mm 440 x 140 x 44 mm 444 x 210 x 44 mm 440 x 250 x 44 mm

The DGS-1510-28X is the next generation of SmartPro switch. It contains 24 10/100/1000 Mbps ports plus 4 10G SFP+ ports.With its 10G SFP+ ports, the DGS-1510-28X is ideal for deployments in the SME/SMB core with its 10G uplinks connecting with servers equipped with 10G port connectivity. For medium to large scale enterprise deployment, it can serve as a good interconnection between the core switch and edge switch Features:

24 10/100/1000 Mbps Ports
Four 10G SFP+ stacking/uplink ports
Extensive Layer 2 features
QoS, bandwidth control
Secure your network
IPv6 ready
Versatile management
Layer 3 traffic management
Energy saving

DGS-1510-28X: 24 x 1000Base-T 4 x 10GbE SFP+
Smart Fan Featuring D-Link Green 3.0 technology, the DGS-1510 series offers a high level of energy saving and efficiency, as it also complies with the IEEE 802.3az Energy Efficient Ethernet standard. Support for IPv6 management and configurations ensures your network remains protected after the upgrade from IPv4 to IPv6. By offering multiple management options, the DGS-1510 Series allows quick deployment, infrastructure expansion, and seamless function upgrades. Built for small and medium-sized businesses, the DGS-1510 Series provide functionality, security, and manageability for a fraction of the standard cost of ownership.

Depending on whether linear or fault-tolerant ring stacking is implemented, users can use one or two 10-Gigabit SFP+ ports to create a physical stack. 6 units or 288 Gigabit ports can be configured for a stack using optional direct attach cables to provide high bandwidth on the DGS-1510 Series with cost efficiency. Users can mix any models from the DGS-1510 SmartPro series in a single stack to allow simultaneous and easy configuration, management and troubleshooting.

DGS-1510 series supports virtual stacking via D-Link's Single IP Management (SIM), allowing up to 32 devices to be managed via a single IP. This simplifies management of small workgroups or wiring closets while allowing the network to be scaled to handle increased bandwidth demand. SIM not only reduces the number of IP address needed in your network but also allow switches to be stacked together over Ethernet instead of using physical uplink or stacking ports. This eliminates the need for any specialised stacking cables while at the same time removing the distance barriers that typically limit your topology options when using other stacking technology.

These switches are equipped with a complete lineup of Layer 2 features including IGMP Snooping, Port Mirroring, Spanning Tree, and Link Layer Discovery Protocol (LLDP). The IEEE 802.3x Flow Control function allows servers to directly connect to the switch for fast, reliable data transfer. At 2000 Mbps Full Duplex, the Gigabit ports provide high-speed data pipes to servers with minimum data transfer loss. Network maintenance features include Loopback Detection and Cable Diagnostics. Loopback Detection is used to detect loops created by a specific port or VLAN and automatically shut down the affected port or VLAN. The Cable Diagnostics feature, designed primarily for administrators and customer service representatives, can quickly discover the type of error on cables and determine the cable quality.

The DGS-1510 Series supports Auto Surveillance VLAN (ASV) and Auto Voice VLAN, which are best suited to VoIP and video surveillance deployments. Auto Surveillance VLAN is a new, industry-leading technology built into D-Link Smart Switches.

Depending on whether linear or fault-tolerant ring stacking is implemented, users can use one or two 10-Gigabit SFP+ ports to create a physical stack. Six units or 288 Gigabit ports can be configured as a stack using optional direct attach cables to provide high bandwidth on the DGS-1510 series with cost efficiency. Users can mix from any of the DGS-1510 SmartPro series in a single stack to allow simultaneous and easy configuration, management and troubleshooting.

Flexibility and scalability

The DGS-1510 series supports virtual stacking via D-Link's Single IP Management (SIM), allowing up to 32 devices to be managed via a single IP. This simplifies management of small workgroups or wiring closets while allowing the network to be scaled to handle increased bandwidth demand. SIM reduces the number of IP address needed in the network and allows switches to be stacked together over Ethernet instead of using physical uplink or stacking ports. This eliminates the need for specialised stacking cables and removes distance barriers that can limit topology options when using other stacking technology.


Extensive Layer 2 features

The DGS-1510 series switches are equipped with a complete lineup of Layer 2 features including IGMP Snooping, Port Mirroring, Spanning Tree, and Link Layer Discovery Protocol (LLDP). The IEEE 802.3x Flow Control function allows servers to directly connect to the switch for fast, reliable data transfer. At 2000 Mbps Full Duplex, the Gigabit ports provide high-speed data pipes to servers with minimum data transfer loss. Network maintenance features include Loopback Detection and Cable Diagnostics. Loopback Detection is used to detect loops created by a specific port or VLAN and automatically shut down the affected port or VLAN. The Cable Diagnostics feature, designed primarily for administrators and customer service representatives, can quickly discover the type of error on cables and determine the cable quality.


QoS, bandwidth control

The DGS-1510 series supports Auto Surveillance VLAN (ASV) and Auto Voice VLAN, which are best suited for VoIP and video surveillance deployments. Auto Surveillance VLAN is a new, industry-leading technology built into D-Link Smart Switches. This technology consolidates data and surveillance video transmission through a single SmartPro switch, sparing businesses the expense of maintaining expensive dedicated hardware and facilities. ASV also ensures the quality of real-time video for monitoring and control without compromising the transmission of conventional network data. The Auto Voice VLAN technology enhances VoIP service by automatically placing voice traffic from an IP phone to an assigned VLAN. With higher priority and an individual VLAN, these features guarantee the quality and security of VoIP traffic. Furthermore, the DSCP markings on Ethernet packets enable different levels of service to be assigned to network traffic. As a result, these voice and video packets take precedence over other packets. In addition, with Bandwidth Control, network administrators can reserve bandwidth for important functions that require more bandwidth or might require high priority.


Secure your network

D-Link's innovative safeguard engine protects the switches against traffic flooding caused by virus attacks. The switches also support 802.1X port-based authentication, allowing the network to be authenticated through external RADIUS servers. In addition, the Access Control List (ACL) feature enhances network security and helps to protect the internal IT network by screening ingress traffic based on MAC or IP addresses. The DGS-1510 series includes ARP Spoofing Prevention, which protects from attacks on the Ethernet network that may allow an intruder to sniff data frames, modify traffic, or bring traffic to a halt altogether by sending fake ARP messages to the network. To prevent ARP Spoofing attacks, the switch uses Packet Control ACLs to block invalid packets that contain fake ARP messages. For added security, the DHCP Server Screening feature screens rogue DHCP server packets from user ports to prevent unauthorised IP assignment.


IPv6 ready

The DGS-1510 series is IPv6 ready and supports various IPv6 functions such as MLD Snooping, IPv6 ACL/QoS, and IMPBv6 to ensure seamless integration of next generation networks. The DGS-1510 series also supports a IPv4/v6 dual stack function that allows the switch to act as a bridge between IPv4 and IPv6 networks. Finally, all DGS-1510 series are certified to be IPv6 Ready Logo Phase 2, which guarantees interoperability for IPv6 environments.


Versatile management

The DGS-1510 series provides a D-Link Network Assistant Utility and a web based management interface that enables administrators to remotely control their network down to the port level. The D-Link Network Assistant Utility allows customers to easily discover multiple D-Link SmartPro Switches within the same L2 network segment. With this utility, users do not need to change the IP address of their PC. It also simplifies the initial setup of the SmartPro Switches. Switches within the same L2 network segment that are connected to the user's PC are displayed on screen for instant access. This allows extensive switch configuration and basic setup of discovered devices including password changes and firmware upgrades. The DGS-1510 Series also supports D-View 6.0 and a fully featured Command Line Interface (CLI) via dedicated out-of-band console port. D-View 6.0 is a Network Management System that allows for the central management of critical network characteristics such as availability, reliability, resilience, and security. CLI management of the switches is possible via console port and Telnet interfaces. This makes it possible to adjust basic settings, passwords, configuration files, and firmware with ease.


Layer 3 traffic management

The DGS-1510 series supports advanced traffic management features, including static routing. In static routing, IP routes are manually entered into a routing table, which allows for communication between different user groups in different VLAN segments in a network. The switch can directly handle inter VLAN routing using multiple interfaces, making the network run faster and more efficiently. Because the switches can manage internal routing, the network router can be assigned to handle external traffic routing only.


Energy saving

DGS-1510 switches are capable of conserving power without sacrificing operational performance or functionality by using D-Link Green 3.0 technology. Using the 802.3az Energy Efficient Ethernet standard, the network will automatically decrease the power usage when traffic is low with no setup required. For environments not fully supporting the standard, DGS-1510 switches offer advanced power-saving settings including port shutoff, LED shutoff, and system hibernation based on custom scheduling profiles.






DGS-1510-20 DGS-1510-28 DGS-1510-28X DGS-1510-28P DGS-1510-28XMP Form Factor Rackmount Rackmount Rackmount Rackmount Rackmount Switching Capacity 76 Gbps 92 Gbps 128 Gbps 92 Gbps 128 Gbps 100M/1G Copper  (RJ-45) Ports 16 24 24 24 24 1G/10G SFP/SFP+ Fibre Ports 2/2 2/2 0/4 2/2 0/4 PoE/PoE+ Ports N/A N/A N/A 24 24 PoE Standard N/A N/A N/A  802.3at  802.3at PoE Budget N/A N/A N/A 193 W 370 W PoE Capable Ports N/A N/A N/A Ports 1 to 24: Up to 30 W Ports 1 to 24: Up to 30 W Dimensions 280 x 180 x 44 mm 440 x 210 x 44 mm 440 x 210 x 44 mm 444 x 210 x 44 mm 440 x 308 x 44 mm

D-Link’s DGS-1210-28MP Gigabit PoE Smart+ Switch with 4 Fibre Uplinks integrates advanced management as well as security functions that provide performance and scalability. Management options for the switch include SNMP, Web Management, D-Link Network Assistant Utility,

The DGS-1210-28MP uses Auto Voice VLAN, ensuring bandwidth is prioritised for a smoother voice performance. The DGS-1210-28MP features a smart fan design that powers on after the switch reaches a certain temperature, saving energy and cutting costs without sacrificing performance.

The DGS-1210-28MP is a high power budget PoE-enabled switch for businesses looking to power VoIP phones, wireless access points or network cameras. The DGS- 1210-28MP is a Smart PoE+ switch with power budgets of 370W that provides 24 PoE-enabled ports that support up to 30W of power output following IEEE 802.3at standard. The design allows more flexibility in power allocation for a variety of powered devices with affordable installation costs.

DGS-1210-28MP: 24 x 1000Base-T 802.3at PoE 4 x 1GbE SFP 370W PoE budget Green Technology

Power saving via the following features: Link Status detection
LED Shut-Off
Port Shut-Off
System Hibernation
Time-based PoE

Security Features
Access Control List secures network
D-Link Safeguard Engine protects CPU from Broadcast/Multicast/Unicast Flooding
Port Security supports 64 MACs per port
ARP Spoofing Prevention
Intuitive Management
D-Link Network Assistant Utility or Web-based GUI
Built-in SNMP MIB for remote NMS (D-View 6.0)
Compact CLI through Telnet
Advanced Features
Auto Surveillance VLAN
Loopback Detection automatically disables a port when a loop is detected
Cable Diagnostics allows administrators to determine cable status
SFP ports for flexibility
Auto MDI/MDIX
Energy saving DGS-1210 switch is capable of conserving power without sacrificing operational performance or functionality by using D-Link Green 3.0 technology. Using the Energy Efficient Ethernet standard, the network will automatically decrease the power usage when traffic is low with no setup required. For environments not fully supporting the standard, DGS-1210 switch offers advanced power-saving settings including port shutoff and standby, LED shutoff, and system hibernation based on custom scheduling profiles. The profiles can also be applied to the PoE switch so that there is no unnecessary power consumption during off hours. The DGS-1210 series switch can also detect the length of connected cables to automatically reduce power usage on shorter cable connections.


Auto Surveillance VLAN and Voice VLAN The process of setting up IP surveillance and VoIP on a network is automated with the D-Link Smart switch. Auto Surveillance VLAN (ASV) consolidates data and surveillance video transmission through the network, sparing businesses the expense of maintaining dedicated facilities. ASV also protects the quality of real-time video by grouping IP surveillance devices on a single high priority VLAN. This ensures that surveillance video streams will not be affected when ordinary data traffic is at their high levels. Similarly, the Auto Voice VLAN guarantees clear audio quality and efficient transmission for all voice communication.


Exclusive Layer 2 features Equipped with a complete lineup of L2 features, the DGS-1210 series switch includes IGMP Snooping, Port Mirroring, Spanning Tree, and Link Aggregation Control Protocol (LACP). The IEEE 802.3x flow control function allows servers to directly connect to the switch for fast, reliable data transfer. At 2000 Mbps full duplex, the Gigabit ports provide high-speed data pipes to servers with minimum data transfer loss. Network maintenance features include loopback detection and cable diagnostics. Loopback detection is used to detect loops created by a specific port and automatically shut down the affected port. The cable diagnostic feature is designed primarily for administrators and customer service representatives, and can rapidly discover the type of error and determine the cable quality.


Secure your network D-Link's safeguard engine protects the switch against traffic flooding caused by virus attacks. The switch also supports 802.1x port-based authentication, allowing the network clients to be authenticated through external RADIUS servers. In addition, the Access Control List (ACL) feature enhances network security and protects the network by screening traffic from illegal MAC or IP addresses. ARP spoofing prevention prevents malicious intruders from sending massive fake ARP messages through a manipulated source. This protects important data from being stolen by man-in-the-middle attacks, and prevents wasting CPU cycles on these packets. For added security, the DHCP server screening feature blocks rogue DHCP server packets from user ports to prevent unauthorised IP assignment.


DGS-1210-24 DGS-1210-24P DGS-1210-28 DGS-1210-28P DGS-1210-28MP Form Factor Rackmount Rackmount Rackmount Rackmount Rackmount Switching Capacity 56 Gbps 56 Gbps 56 Gbps 56 Gbps 56 Gbps 100M/1G Copper  (RJ-45) Ports 24 24 24 24 24 1G SFP Fibre Ports 4 4 4 4 4 PoE/PoE+ Ports N/A 12 N/A 24 24 PoE Standard N/A 802.3af/ 802.3at  N/A 802.3af/ 802.3at  802.3at PoE Budget N/A 85 W N/A 193 W 370 W PoE Capable Ports N/A Ports 1 to 12: Up to 30 W N/A Ports 1 to 4: 802.3at.
Ports 5 to 24: 802.3af Ports 1 to 24: Up to 30 W Dimensions 441 x 209.9 x 44 mm 441 x 209.9 x 44 mm 440 x 140 x 44 mm 444 x 210 x 44 mm 440 x 250 x 44 mm

The all-new DGS-3130 Series Gigabit Layer 3 Stackable Managed Switches are designed to address the needs of small to medium-sized business networks. A unified software image incorporates L2 and L3 features enabling the family to be deployed in a variety of environments and topologies. Together the hardware and software enhancements combine to create a family of powerful, flexible and cost-effective switches.

The DGS-3130-30S switch has 24 gigabit SFP ports with six embedded 10G uplink/stacking ports. Two 10GBASE-T ports and four 10G SFP+ ports.

Features:

Reliability Redundant power supply (RPS) support
Ethernet Ring Protection Switching (ERPS) for single ring topologies
Embedded 6 kV surge protection on all Gigabit Ethernet ports
IEEE 802.3D/802.1s Spanning Tree
Loopback Detection (LBD)
L3 Features Static Route
RIP
RIPng


DGS-3130-30S: 24 x SFP Ports
2 x 10GBASE-T
4 x 10G SFP+



Optional Accessories

DEM-310GT

1000BASE-LX, Single-mode, 10 km

DEM-312GT2

1000BASE-SX Multi-mode,2 km

DEM-431XT

SFP+ 10GBASE-SR Multi-Mode Fibre Transceiver (300m)

DEM-432XT

SFP+ 10GBASE-LR Multi-Mode Fibre Transceiver (10 km)

DEM-CB100S

1mt 10G SFP+ Direct Attach Cable (DAC)

DEM-CB300S

3mt 10G SFP+ Direct Attach Cable (DAC)

DPS-500A

AC Redundant Power Supply



Highights:

2 x 10GBASE-T, 4x SFP+ 10G ports Physical Stacking Layer 2 Features Layer 3 Features   Connect to areas of your network at 10G speeds, and reach even further distances with fibre optic cabling.   Up to 9 units per stack1, with a maximum of 324 ports, and up to 80GB of bandwidth.   Such as flow control, link aggregation, Ethernet Ring Protection Switching (ERPS), Spanning Tree Protocols, Loopback Detection, IGMP/MLD Snooping.   Including up to 16 IP Interfaces, IGMP Filtering, Neighbor Discovery Protocol (ND), ARP Proxy, VRRP. RIPv1/v2/ng Static Routing Industry Standard CLI Dual Image   Determines the best route to a destination in the network.   Route Layer 3 traffic between switches, even if they're segmented in VLANs.   Supports a full industry standard Command-Line Interface for system management.   Risk-free configuration testing. Greater port density. Powerful Layer 3 features.

Designed for small to medium-sized business networks, the unified software incorporates Layer 2 and Layer 3 features, with 10-Gigabit ports, greater port density thanks to physical stacking, all of which enables the DGS-3130 Series to be deployed in a variety of environments and topologies, including Metro Ethernet deployments. World-class reliability

Advanced L2 and L3 features including port security, Storm Control, Spanning Tree Protocols, IGMP/MLD Snooping, and IPv6 ND. Management options like a multilingual web-UI, and industry standard CLI support, with support for multiple images and multiple configurations.

6x 10-Gigabit ports, physical stacking for more ports, and they have built-in G.8032 Ethernet Ring Protection Switching (ERPS) to help minimise recovery times to 50 ms. An USB 2.0 interface to store config files, boot images, and syslog. As well as support for an additional external redundant power supply on all models to ensure maximum uptime.

Comprehensive security.

Includes the latest security such as Multi-layer and Packet Content Access Control Lists (ACL), and Storm Control. And our exclusive D-Link Safeguard Engine has been designed to guard against traffic flooding caused by malicious attacks and protect your business network uptime.

IP-MAC-Port Binding allows you to bind a source IP address with an associated MAC and define the port number to enhance user access control. And DHCP Snooping makes the switch learn IP/MAC pairs by snooping DHCP packets and saving them to the IMPB whitelist, giving you extra control.

Easy Access Control policies.

They feature multiple authentication mechanisms such as 802.1X, Web-based Access Control (WAC), and MAC-based Access Control (MAC) for strict access control and an easy deployment. After authentication, individual policies such as VLAN membership, Quality of Service (QoS) policies, and ACL rules can be assigned to each host.

Support for the Microsoft® NAP policy enforcement allows you to protect network assets from compromised computers by enforcing compliance with network health policies.

Versatile traffic management.

A rich set of multi-layer QoS/CoS features ensure that critical network services such as VoIP, video conferences, IPTV, and IP surveillance are always given high priority, and 10-Gigabit ports deliver the speed you need. Traffic Shaping features guarantee bandwidth for these services even when the network is busy. L2 Multicast support enables the DGS-3130 Series to handle growing IPTV applications.

Host-based IGMP/MLD Snooping allows multiple multicast subscribers per physical interface while ISM VLAN allows the switches to send multicast streams in a multicast VLAN to save bandwidth, and to provide better security to the backbone network. The ISM VLAN profiles allow you to bind or replace the pre-defined multicast registration information to subscriber ports quickly and easily. Selective Q-in-Q enables you to be selective over VLAN traffic.

1 When stacking the DGS-3130-30TS/30S/30PS models, the stacking cost is 1 per unit so the maximum units per stack is 9. When stacking the DGS-3130-54TS/54S/54PS models, the stacking cost is 2 per unit so the maximum units per stack is 6. When stacking different models in the same stack, switches can be stacked up to a maximum of 12 stacking cost per stack. For example: 2 x DGS-3130-30TS (2 stacking cost) + 2 x DGS-3130-30S (2 stacking cost) + 4 x DGS-3130-54TS (8 stacking cost) consumes a total stacking cost of 12 (2+2+8).

D-Link’s DGS-1210-10MP Gigabit PoE Smart+ Switch with 2 Fibre Uplinks integrates advanced management as well as security functions that provide performance and scalability. Management options for the switch include SNMP, Web Management, D-Link Network Assistant Utility.

The DGS-1210-10MP uses Auto Voice VLAN, ensuring bandwidth is prioritised for a smoother voice performance and features a fanless design that allows for quieter operation and helps to extend the device’s lifetime.

The DGS-1210-10MP is a high power budget PoE-enabled switch for businesses looking to power VoIP phones, wireless access points or network cameras. The DGS- 1210-10MP is a Smart PoE+ switch with a power budget of 130W that provides 8 PoE-enabled ports power of up to 30 W each. The design allows more flexibility in power allocation for a variety of powered devices with affordable installation costs.

DGS-1210-10MP: 8 x 1000Base-T 802.3at PoE+ 2 x 1GbE SFP
Fanless 130W PoE budget Green Technology

Power saving via the following features: Link Status detection
LED Shut-Off
Port Shut-Off
System Hibernation
Time-based PoE

Security Features
Access Control List secures network
D-Link Safeguard Engine protects CPU from Broadcast/Multicast/Unicast Flooding
Port Security supports 64 MACs per port
ARP Spoofing Prevention
Intuitive Management
D-Link Network Assistant Utility or Web-based GUI
Built-in SNMP MIB for remote NMS (D-View 6.0)
Compact CLI through Telnet
Advanced Features
Auto Surveillance VLAN
Loopback Detection automatically disables a port when a loop is detected
Cable Diagnostics allows administrators to determine cable status
SFP ports for flexibility
Auto MDI/MDIX

DGS-1210-08P DGS-1210-10 DGS-1210-10MP DGS-1210-10P Form Factor Desktop/ Rackmount Desktop/ Rackmount Desktop/ Rackmount Desktop/ Rackmount Switching Capacity 20 Gbps 20 Gbps 20 Gbps 20 Gbps 100M/1G Copper  (RJ-45) Ports 8 8 8 8 1G SFP Fibre Ports  2 2 2 2 PoE/PoE+ Ports 8 N/A 8 8 PoE Standard 802.3af N/A 802.3af/ 802.3at  802.3af/ 802.3at  PoE Budget 45 W N/A 130 W 65 W PoE Capable Ports Ports 1 to 8: Up to 15.4 W N/A Port 1 to 8 (30 W max. per PoE port) Port 1 to 8 (30 W max. per PoE port) Dimensions 280 x 180 x 44 mm 280 x 126 x 44 mm 330 x 180 x 44 mm 280 x 126 x 44 mm

Gigabit Smart Managed Switches - DGS-1100-24PV2

The DGS-1100 (V2) Series is a range of highly affordable smart-managed switches designed to meet the requirements of small, medium, and enterprise businesses. Advanced management features, bandwidth management, PoE option, diagnostic and troubleshooting tools, and energy-efficient technologies provide a flexible solution to meet your networking requirements

The DGS-1100 (V2) Series is equipped with advanced security features such as Static MAC, Storm Control, and IGMP Snooping to help businesses protect their network. The switches are also ideal for IP surveillance deployment with the Surveillance VLAN support that gives high priority surveillance traffic to mitigate disruption and guarantee the quality of video recording







Product Highlights: Simple Layer 2 Management
Web-based User Interface
PoE options up to 370W power budget
Limited-Lifetime Warranty after registration











Simple. Easy. Smart. DGS-1100 Smart Switch Series provides an affordable solution for environments that require simple network management.






Smart Web UI The DGS-1100's web user interface is an easy way to manage Layer 2 features, such as VLANs, Spanning Tree Protocol (STP), link aggregation (static). With powerful security features like IGMP snooping, Static MAC, and Storm Control, the DGS-1100 Smart family is a versatile solution for environments that require easy to deploy and easy to configure solutions without added complexities.




Easy to Deploy and Manage D-Link’s free Network Assistant (DNA) displays all connected devices and speeds up the first time configuration. The free D-View 7 Network Management System comes with a license for 25 nodes and 2 probes and full access to the management tools. Optional upgrade licenses allow you to broaden your network and analysis.





PoE and Poe+, with budgets up to 370W The DGS-1100 Smart Series includes a range of high power budget PoE-enabled switches for businesses looking to power larger deployments of VoIP phones, wireless access points or network cameras.




Easy Troubleshooting The DGS-1100 Series features Loopback Detection and Cable Diagnostics to help network administrators find and solve network problems quickly and easily. Loopback Detection is used to detect loops created by a specific port and automatically shut down the affected port. The Cable Diagnostics feature is designed for network administrators to quickly examine the quality of the copper cables, recognise the cable type, and detect cable errors.

















PhysicalAvailable in multiple configurations, with or without PoE and fibre support
Fanless design for silent operation





Green Technology Link status detection
IEEE 802.3az Energy-Efficient Ethernet compliant
Time-based PoE (PoE models excluding DGS1100-08PV2)





Advanced Features IGMP Snooping
Bandwidth Control
IEEE 802.1Q VLAN traffic segregation
Port-based VLAN
IEEE 802.1p Quality of Service
Surveillance VLAN
Voice VLAN





Management Features Client-based utility or web-based GUI
Built-in SNMP MIB












Physical Power Input • 100 to 240 V AC / 50 to 60 Hz Internal Power Supply MTBF 406,887 hours Operating Temperature -10 to 50 °C / 14 to 122 °F Temperature (Storage) -40 to 70 °C / -40 to 158 °F Humidity (Operating) 0% to 95% non-condensing Humidity (Storage) 0% to 95% non-condensing Dimensions 280 x 180 x 44 mm Weight 1.5 kg An installation guide be found in the
