StarTech 4-Port KVM Switches

4 Port Black USB KVM Switch Kit with Cables and Audio

Control 4 USB enabled computers with this complete KVM kit including cables










The SV411KUSB 4 Port USB KVM Switch Kit with Audio and Cables lets you control up to four USB-enabled computers using a single keyboard, mouse and VGA monitor and offers both hotkey and top panel push-button operation for simple switching between connected computers.


Designed to integrate seamlessly into any environment, the USB KVM switch offers a small footprint design (roughly the size of a deck of playing cards) and draws power from the connected computers, so it doesn't require an external power supply.


A suitable solution for virtually any application, the USB KVM switch supports video resolutions of up to 2048 x 1536 as well as audio switching. The USB KVM switch includes four, 4ft 4-in-1 VGA and USB Host Cables, providing everything needed for quick installation to provide a complete, out-of-the-box KVM solution.


Delivering dependable and convenient control of multiple computers from a single peripheral station, the KVM switch is backed by a StarTech.com 2-year warranty and free lifetime technical support.





Applications:

Control 4 USB-enabled computers using a single keyboard, mouse, and VGA monitor
Applicable for call centers, help desks, education environments, home gamers, video editing, and PC enthusiasts
Great for PC test/burn-in computer control saving the desk space required for multiple monitors, keyboards and mice
Multiple system control for single user workstations, increasing user productivity in the office









Features:

Cables (4 ft.) included
Includes audio support for a complete switching solution
Maximum resolution: 2048 x 1536
Switching type: Hotkey, push-button









The StarTech.com Advantage:

Power-free operation – KVM draws power from attached computers and requires no power adapters
Compact, small footprint design fits easily into almost any environment saving desk space and reducing clutter
Included all-in-one KVM plus audio cables provide a complete out of the box KVM solution









Ports & interfaces Cable length 1.2 m Console USB ports quantity 2 Console ports 3.5 mm headphone, 3.5 mm mix, USB A, VGA (D-Sub) Number of microphone inputs 4 Number of computers controlled 4 Keyboard port type USB Video port type VGA VGA (D-Sub) ports quantity 5 Headphone outputs 4 DC-in jack Yes

Technical details Product colour Black Rack mounting No On Screen Display (OSD) No Number of users 1 user(s) Hot keys Yes IP control No Sustainability certificates RoHS

Video HD type 2K Ultra HD Maximum resolution 2048 x 1536 pixels

Performance HD type 2K Ultra HD Maximum resolution 2048 x 1536 pixels Number of users 1 user(s)

Design Product colour Black Cable length 1.2 m Rack mounting No Hot keys Yes Certification CE, FCC, REACH Housing material Plastic

Display Built-in display No On Screen Display (OSD) No

Weight & dimensions Width 95 mm Depth 61 mm Height 25 mm Weight 189 g

Packaging content Drivers included Yes Cables included Audio (3.5 mm), KVM Manual Yes

Other features Hot keys Yes IP control No Full specification and details can be found in the

4 Port Professional VGA USB KVM Switch with Hub

Control up to 4 PC or Mac® computers from a single keyboard, mouse and monitor and share any USB device between all connected computers










The SV431USB 4 Port rack mountable VGA USB KVM Switch with Hub offers simple control of up to four computers from a single monitor/display and USB peripheral set (keyboard, mouse).


The USB KVM switch features an integrated 4 port USB hub, allowing you to share connected USB peripherals between the four controlled PC/Mac computers as though the devices were connected directly.


Offering convenient placement and installation options, the KVM switch features a 1U rack-mountable form factor and rear port connection to master and slave computers, allowing you to make the necessary device connections without disrupting your workspace.


A cross-platform solution, the KVM switch supports high resolution applications at up to 1920x1440 and provides a smooth operating experience when controlling mixed (Windows/Mac OS/Linux) environments.


This product is TAA compliant and backed by a Startech.com 3 year warranty with free lifetime technical support.





Rackmount your KVM switch If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.



Product diagram:









Applications: Sharing computers and USB devices in the home/SOHO/multimedia environment
Perfect for manufacturing line computer control, simplifying access to multiple systems
Great for PC test/burn-in computer control saving the desk space required for two monitors, keyboards and mice
Dual system control for single user workstations increasing user productivity in the office









Features: Supports hot-plug and disconnect – computers can be added or removed without the need to reboot other connected systems
Front panel push-buttons for quick and easy switching
High 1920x1440 resolution capability
OS independent - No driver or software installation required
USB 2.0 hub for peripheral sharing
USB self-power operation









The StarTech.com Advantage: Integrated USB 2.0 hub allows the user to share USB peripherals eliminating the expense of duplicate devices
Absolutely no software or drivers required providing a completely OS independent KVM solution









Technical details Product colour Black Rack mounting Yes Scan interval 3, 8, 15, 30 s On Screen Display (OSD) No Number of users 1 user(s) Hot keys No IP control No Sustainability certificates RoHS

Performance Maximum cable length 5 m Daisy chain No Maximum resolution 1920 x 1440 pixels Scan interval 3, 8, 15, 30 s Number of users 1 user(s)

Video Maximum resolution 1920 x 1440 pixels

Ports & interfaces Console USB ports quantity 4 Console ports USB A, VGA (D-Sub) USB connector type USB Type-A Number of computers controlled 4 Keyboard port type USB Mouse port type USB Video port type VGA Audio connections No DC-in jack Yes

Design Mean time between failure (MTBF) 82506 h Maximum cable length 5 m Product colour Black Rack mounting Yes Hot keys No Certification CE, FCC, REACH, TAA, cUR Rack capacity 1U Housing material Steel

Display Built-in display No On Screen Display (OSD) No

Power Input current 0.4 A Output current 2 A Power plug type Type N Output voltage 5 V AC input voltage 110 - 240 V

Weight & dimensions Width 130 mm Depth 220 mm Height 44 mm Weight 988 g

Packaging content Rubber feet Yes Manual Yes

Other features Hot keys No IP control No Full specification and details can be found in the

4 Port Rack Mountable USB KVM Switch with Audio & USB Hub

Share keyboard, mouse, speakers and a VGA display between four multimedia computers










This Rack Mountable USB KVM Switch supports high resolution video applications (up to 1920x1440 pixels supported) and audio switching between connected computers, and provides an integrated USB 2.0 hub that lets the selected computer have access shared high speed USB peripherals.


Providing control of up to four computers from a single USB keyboard and mouse peripheral set, the switch features a sturdy all metal chassis and can be rackmounted in a server rack/cabinet using an optional Rackmount Bracket kit (SV431RACK) - minimizing clutter and saving space.


This product is TAA compliant and is backed by a Startech.com 3 year warranty with lifetine technical support.





Console Connection Before installation, please ensure that all devices and computers to be connected to the KVM Switch have been turned off. 1. Connect the monitor that will be used to the Console VGA port on the rear panel of SV431USBAE. 2. Connect a USB keyboard and a USB mouse to any two of the Console USB ports as shown below:






Connecting Slave Computers 1. Connect the VGA port located on the rear panel of SV431USBAE to the VGA port provided by the video connection on the desired computer, using an HDB15 male to female cable. Please note the PC Port number, for steps 2 and 3. 2. Using a USB A-B Cable, connect the USB port that corresponds with the PC port used in step 1, to the USB port on the corresponding computer, as shown below 3. Optional: Using an audio cable (Speaker and Mic), connect the Speaker and Mic ports provided by the PC port used in step 1 on SV431USBAE to the Speaker and Mic ports located on the computer. 4. Repeat steps 1-4 as necessary for each computer you wish to connect. Once all computers have been connected, you can turn on all devices and computers.






Applications: Control up to four computers, sharing a single keyboard, mouse, monitor and speakers.
Integrated USB 2.0 hub allows you to share up to three USB peripherals between the four computers.









Features: Designed for high-resolution applications: up to 1920x1440 pixels supported
All metal chassis for long-term durability
Integrated USB 2.0 hub allows you to share up to three high-speed USB devices between computers
Audio switching with microphone and speaker connectivity
Auto-scan function automatically selects computer sequentially
Compatible with all USB supported Operating Systems
Front panel push button computer selection









The StarTech.com Advantage: High-resolution: up to 1920x1440 pixels supported
Optional rack-mountable bracket (SV431RACK)
Powerful features that increase usability
Share USB peripherals between multiple computers
Full control of both audio and video









Technical details Product colour Black Rack mounting Yes Number of users 1 user(s)

Performance Maximum resolution 1920 x 1440 pixels Number of users 1 user(s)

Video Maximum resolution 1920 x 1440 pixels

Ports & interfaces Number of microphone inputs 1 Number of computers controlled 4 Keyboard port type USB Mouse port type USB Video port type VGA Headphone outputs 1

Design Product colour Black Rack mounting Yes Rack capacity 1U

Power External power adapter Yes

Weight & dimensions Package width 90 mm Package depth 410 mm Package height 215 mm Package weight 1.66 kg Weight 1.03 kg

Other features Connectivity technology Wired Ports quantity 4 Dimensions (W x D x H) 130 x 220 x 44.5 mm I/O ports 4 x USB B / 4 x USB A / 8 x 3.5 mm Mini-Jack / 4 x VGA Full specification and details can be found in the

4 Port 1U Rackmount USB KVM Switch with OSD

Control up to 4 VGA and USB computers from a single keyboard, mouse and monitor










The SV431DUSBU 4 Port 1U Rack Mountable USB KVM Switch with OSD lets you control multiple USB based computers from a single console (USB keyboard, USB mouse, monitor).


Convenient push-button and hot-key controls provide quick, reliable switching between connected computers while manual and auto-scan switching modes and an On Screen Display (OSD) offer additional control options.


Designed to ensure maximum space efficiency, the USB KVM switch features a slim 1U design that fits neatly into a server equipment rack/cabinet (with optional mounting bracket SV431RACK) and offers rear cable connections to eliminate cable tangles and minimize workspace disruption.


This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.





Rackmount your KVM switch If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM. The SV431DUSBU only works with specific 2-in-1 VGA and USB cables (sold separately), a list of StarTech.com approved cables are below: 6 ft Ultra Thin USB VGA 2-in-1 KVM Cable 6 ft Ultra Thin USB VGA 2-in-1 KVM Cable 10 ft Ultra Thin USB VGA 2-in-1 KVM Cable 15 ft Ultra Thin USB VGA 2-in-1 KVM Cable





Applications: Add single console administration to your Co-location/ISP facility saving you time and money
Perfect for manufacturing line computer control, simplifying access to multiple systems
Create a scalable, streamlined access solution in your Datacenter or Server Farm
Great for PC test/burn-in computer control saving the desk space required for multiple monitors, keyboards and mice
Ideal for control of multiple PCs in a QA testing environment









Features: OS Independent – No drivers or software required
Auto-scan function automatically selects computer sequentially
Front panel push-button and Hotkey switching allow easy computer access
Identifies and selects computers by the names assigned using the OSD
USB console connections
Rename connected computers for easy identification
OSD security allows each PC to be password protected
Plug-and-play system configuration
Supported Wide Screen Resolutions: 1920x1200, 1920x1080, 1680x1050, 1400x1050, 1440x900, 1360x768
Supported 4 : 3 Resolutions: 1920x1440, 1600x1200, 1280x1024, 1024x768









The StarTech.com Advantage: Extracting the keyboard strokes from the USB connection this KVM enables hot key support for wireless keyboard and mouse combo kits that use a single USB receiver
On Screen Display adds the ability to rename connected computers for easy identification and provides per-port password security
Absolutely no software or drivers required providing a completely OS independent KVM solution









Technical details Product colour Black Rack mounting Yes Plug and Play Yes On Screen Display (OSD) Yes LED indicators Power Hot keys Yes IP control No Audio support No Sustainability certificates RoHS

Video Maximum resolution 1920 x 1440 pixels Maximum digital resolution 1920 x 1440 pixels

Ports & interfaces Console USB ports quantity 2 Console ports USB A, VGA (D-Sub) Number of computers controlled 4 Keyboard port type No Mouse port type No Video port type VGA Audio connections No USB 2.0 ports quantity 2 VGA (D-Sub) ports quantity 5 DC-in jack Yes

Performance Daisy chain Yes Plug and Play Yes Maximum resolution 1920 x 1440 pixels Maximum analog resolution 1920 x 1440 pixels

Design Mean time between failures (MTBF) 143000 h Product colour Black Rack mounting Yes LED indicators Power Hot keys Yes Certification CE, FCC, UL, TAA, REACH Rack capacity 1U Housing material Steel

Display Built-in display No On Screen Display (OSD) Yes

Power Input current 0.2 A Output current 0.6 A Power plug type Type M Compatible power plug types AU, EU, UK, US Output voltage 9 V AC input voltage 100 - 240 V Power consumption (typical) 5.4 W External power adapter Yes

Operating conditions Operating temperature (T-T) 5 - 40 °C Storage temperature (T-T) -20 - 60 °C Operating relative humidity (H-H) 0 - 80 %

Weight & dimensions Width 220 mm Depth 130 mm Height 43 mm Weight 957 g

Packaging content Rubber feet Yes Manual Yes AC adapter included Yes

Other features Hot keys Yes IP control No Audio support No Full specification and details can be found in the

4 Port USB DisplayPort KVM Switch with Audio

Share keyboard, mouse, and DisplayPort display between four HD multimedia systems










The SV431DPUA 4 Port USB DisplayPort KVM Switch with Audio combines next generation display standards with seamless KVM control of up to 4 connected PC or Mac computers.


Featuring DisplayPort resolutions of 2560x1600 @60Hz, as well as offering both 7.1 HD digital audio (with supporting displays and sources) and separate 3.5mm stereo audio support. An integrated USB 2.0 hub allows you to share 2 additional peripherals among attached computers as if they were directly connected.


Suitable for high quality static imaging applications such as health care (MRI, X-ray diagnostics, etc.), a maximum resolution of 3840x2400 is supported at reduced refresh rates.


A simple yet comprehensive solution, the 4-port KVM features both front-panel push-button and hotkey switching, and offers a small form factor with rear connection ports, to minimize workspace disruptions.


This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.





Rackmount your KVM switch If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.





Applications: Dual system control for a single workstation increasing productivity in the office
High resolution medical imaging and Health care display, such as MRI and X-Ray display
Perfect for high-res Digital Signage server control, simplifying access to multiple systems
Multimedia design, multimedia post-production and video editing
Great for PC test/burn-in computer control saving the desk space required for multiple monitors, keyboards and mice
Leverage DisplayPort’s high resolution capabilities for Satellite Topography equipment









Features: 7.1 Channel High Definition Audio support plus dual channel Analog Stereo and Microphone
Full plug-and-play support with USB keyboards, mice, and connected peripherals
Hotkey and push-button switching
Native DisplayPort resolution of 2560x1600 @60Hz; beyond 1080p
OS independent - No driver or software required
Supports a maximum resolution of 3840x2400 at lower refresh rates
Supports DDC2B for monitor detection
Supports hot-plug, un-plug and link status-failure detection
Integrated 2 port USB 2.0 hub
User-defined scan time intervals
VESA and CEA compliant
Fully compatible with Mini-DisplayPort, HDMI, and DVI adapters









The StarTech.com Advantage: USB peripheral sharing using the integrated hub eliminates the expense of duplicate devices (printers, scanners, etc.)
Compatible with Mini-DisplayPort adapters, making it suitable for Apple Macbook connectivity
Support for digital DisplayPort 7.1 HD audio or separate 3.5mm analog audio connections for added versatility









Technical details Product colour Black Hot-Plug support Yes Plug and Play Yes Push button Yes On Screen Display (OSD) No Number of users 1 user(s) LED indicators Yes Hot keys Yes IP control No Audio support Yes USB hub Yes Sustainability certificates RoHS

Video Maximum resolution 3840 x 2400 pixels Maximum digital resolution 2560 x 1600 pixels

Ports & interfaces Console USB ports quantity 4 Console ports DisplayPort, 3.5 mm headphone, 3.5 mm mic, USB A Number of microphone inputs 5 Number of computers controlled 4 Keyboard port type USB Mouse port type USB Video port type DisplayPort Audio connections Yes Headphone outputs 5 DC-in jack Yes USB hub Yes

Performance DDC2B support Yes Daisy chain No Hot-Plug support Yes Plug and Play Yes Maximum resolution 3840 x 2400 pixels Number of users 1 user(s) Maximum digital resolution 2560 x 1600 pixels Audio channels 7.1

Design Mean time between failures (MTBF) 136000 h Product colour Black Push button Yes LED indicators Yes Hot keys Yes Certification CE, FCC, UL, TAA, REACH Housing display Steel

Display Built-in display No On Screen Display (OSD) No

Power Input current 0.8 A Output current 1.5 A Power plug type Type M Compatible power plug types AU, EU, UK, US Output voltage 12 V AC input voltage 100 - 240 V External power adapter Yes

Operating conditions Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -20 - 60 °C Operating relative humidity (H-H) 0 - 80 %

Weight & dimensions Width 221 mm Depth 130.6 mm Height 44 mm Weight 1 kg

Packaging content Rubber feet Yes Manual Yes AC adapter included Yes

Other features Push button Yes Hot keys Yes IP control No Audio support Yes Full specification and details can be found in the

4 Port High Resolution USB DVI Dual Link KVM Switch with Audio

Control up to 4 high resolution multimedia computers from a single console










The SV431DVIUAHR 4 Port High Resolution USB DVI Dual Link KVM Switch with Audio provides simple, yet comprehensive KVM control of up to 4 directly connected computers with dual link DVI output and USB keyboard and mouse connections.


Audio switching capability and support for high resolution dual link DVI applications up to 2560x1600 @ 60Hz (up to 3840x2400 at lower refresh rates), make this KVM a superior switching solution that integrates perfectly into multimedia environments.


The DVI USB KVM Switch is compatible with all USB supported operating systems with no software or drivers to install, and features a built-in USB 2.0 hub that allows you to share up to 3 high speed USB devices between computers.


This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.




Rackmount your KVM switch If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.





Applications: Ideal for switching between desktops, workstations and servers requiring Ultra High resolution displays
Sharing computers and USB devices in the home/SOHO/multimedia environment
Switching USB peripherals between connected PC's
Designed for large and high resolution displays such as Multimedia Display, Apple Cinema Displays, Stock trading setups, and Medical Displays









Features: All metal chassis for long-term durability
Supports dual link DVI resolutions up to 2560x1600 @ 60Hz
Higher resolutions up to 3840x2400 supported at lower refresh rates
Integrated USB 2.0 hub allows you to share up to 3 high-speed USB devices between computers
Compatible with all USB supported Operating Systems
Front panel push button computer selection
HDCP Compliant









The StarTech.com Advantage: Dual Link DVI interface supports higher resolution applications, allowing you to take full advantage of your larger high resolution monitor’s workspace
Integrated USB 2.0 hub allows the user to have full multimedia control and share USB peripherals eliminating the expense of duplicate devices
Supports even higher resolutions (exceeding 2560x1600) by using a lower refresh rate. Example 3840x2400 @30Hz









Technical details Product colour Black Number of users 1 user(s) IP control No Audio support Yes Sustainability certificates RoHS

Performance HDCP Yes Daisy chain No Maximum resolution 3840 x 2400 pixels Number of users 1 user(s) Maximum digital resolution 2560 x 1600 pixels

Video Maximum resolution 3840 x 2400 pixels Maximum digital resolution 2560 x 1600 pixels

Ports & interfaces Console ports 3.5 mm headphone, 3.5 mm mic, DVI-I, USB A HDCP Yes Number of computers controlled 4 Keyboard port type USB Mouse port type USB Video port type DVI-I Audio connections Yes USB 2.0 ports quantity 4 DVI-I ports quantity 5 DC-in jack Yes

Design Mean time between failures (MTBF) 64000 h Product colour Black Certification CE, FCC

Display Built-in display No

Power Input current 0.4 A Output current 2 A Power plug type Type M Output voltage 5 V AC input voltage 110 - 240 V

Operational conditions Operating temperature (T-T) 0 - 40 °C Storage conditions -20 - 60 °C Operating relative humidity (H-H) 0 - 80%

Weight & dimensions Width 220 mm Depth 130 mm Height 44 mm Weight 1.75 kg

Packaging content Rubber feet Yes Manual Yes AC adapter included Yes

Other features IP control No Audio support Yes Full specification and details can be found in the

4 Port DisplayPort KVM Switch - 4K 60Hz - Single Display - Dual Port UHD DP 1.2 USB KVM Switch with Integrated USB 2.0 Hub & Audio - Dell, HP, Apple, Lenovo - TAA Compliant

DisplayPort 1.2?KVM | TAA Compliant | USB 2.0 Hub | 7.1 HD Digital Audio










This 4-port KVM switch combines 4K (60Hz) digital display capabilities with control of up to four connected computers.




4K60 Picture and Full Audio Support The DisplayPort KVM switch supports resolutions up to 4K at 60Hz and can drive one large DP display with ease, maximizing viewing space. With support for 7.1 HD digital audio (with supporting displays and sources) and separate 3.5 mm stereo audio, the DisplayPort 1.2 KVM switch delivers full audio compatibility.




Integrated USB Hub The integrated USB 2.0 hub shares two additional peripherals (in addition to keyboard and mouse) among attached computers as if they were directly connected, eliminating the cost of duplicate devices such as printers and scanners.




PC and Mac Compatible While supporting PCs, this DP KVM switch is also compatible with Mac computers using a Mini DisplayPort adapter, including laptops, notebooks, and tablets.




Simple to Operate The front-panel pushbuttons make it easy to switch between systems and activate the auto scan. The hotkey functionality makes accessing each system quick while a buzzer sound confirms the switch. StarTech.com offers a wide selection of high-quality KVM switches and KVM-related products to help you access your systems more efficiently without the expense and clutter of extra keyboards, mice and monitors. This USB KVM switch is backed by a 3-year warranty and free lifetime technical support.



Front view:





Rear view:









Applications: High-res medical imaging
High-res digital signage server control
Multimedia design and production









Features: IMPROVE EFFICIENCY: 4 Port DisplayPort KVM Switch with hotkey and manual switching to access 4 computers with DP video and USB hub; works with major brands including Dell, HP, and Lenovo
4K VIDEO QUALITY: DisplayPort KVM switch supports up to 4K at 60Hz on one large monitor Supports MST Passthrough for multiple displays
TECH SPECS: 4 Port DP 1.2 KVM 3840 x 2160 60Hz 4K UHD MST Passthrough 2 Port USB 2.0 Hub HDCP 3.5mm Analog Audio Switching: Hotkey & Push Button OS Independent TAA
USER-FRIENDLY: KVM switch with compact & durable steel housing features large buttons & integrated USB 2.0 Hub for sharing USB drives & devices between connected computers
THE STARTECH.COM ADVANTAGE: This KVM is TAA compliant, and StarTech.com offers a 3-year warranty and free lifetime 24/5 multilingual technical support based in North America









Technical details Product colour Black Rack mounting Yes Plug and Play Yes Scan intervals 3, 8, 15, 30 s On Screen Display (OSD) Yes Number of users 1 user(s) LED indicators Yes Hot keys Yes IP control No Audio support Yes Sustainability certificates RoHS

Video HD type 4K Ultra HD Maximum resolution 3840 x 2160 pixels

Ports & interfaces Console USB ports quantity 4 Console ports 3.5 mm headphone, 3.5 mm mix, DisplayPort, USB A Number of microphone inuts 5 DisplayPorts quantity 5 Number of computers controlled 4 Keyboard port type USB Mouse port type USB Video port type DisplayPort Audio connections Yes Headphone outputs 5 DC-in jack Yes USB 2.0 Type-B ports quantity 4

Network Ethernet LAN No

Performance Daisy chain No Data transfer rate (max) 0.48 Gbit/s HD type 4K Ultra HD Plug and Play Yes Maximum resolution 3840 x 2160 pixels Scan interval 3, 8, 15, 30 s Number of users 1 user(s)

Design Mean time between failures (MTBF) 138327 h Product colour Black Rack mounting Yes LED indicators Yes Hot keys Yes Certification CE, FCC, TAA, REACH Rack capacity 1U Housing material Steel

Power Input current 0.6 A Output current 1.5 A Power plug type Type M Compatible power plug types AU, EU, JP, UK, US Output voltage 12 V AC input voltage 100 - 240 V Power consumption (typical) 18 W External power adapter Yes

Operational conditions Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -10 - 60 °C Operating relative humidity (H-H) 0 - 40%

Weight & dimensions Width 131 mm Depth 220 mm Height 45 mm Weight 1 kg

Packaging content Rubber feet Yes Quick installation guide Yes AC adapter included Yes

Logistics data Master (outer) case width 43.3 cm Master (outer) case length 54.5 cm Master (outer) case height 25.8 cm Quantity per master (outer) case 6 pc(s)

Other features Hot keys Yes IP control No Audio support Yes Full specification and details can be found in the

4 Port Dual DVI USB KVM Switch with Audio & USB 2.0 Hub

Share a keyboard, mouse and dual DVI displays/monitors between 4 multimedia computers










The SV431DD2DUA 4-port Dual DVI USB KVM Switch allows up to four PCs, each with dual DVI video outputs, to share two monitors, one microphone and set of speakers, one keyboard and one mouse as well as two other USB peripherals.


An ideal solution for graphic designers, CAD/CAM designers or educational and financial institutions, the dual view KVM Switch allows you to instantly switch back and forth between dual DVI display PCs at the touch of a button, while maintaining professional level video quality on both monitors. The dual DVI switch also features an integrated USB hub port that allows USB 2.0 peripherals such as thumb drives, external hard drives or web cams to be shared between attached systems - eliminating duplicate peripheral costs.


Please Note: While both DVI-I (analog mode) and DVI-D (digital only) are supported by the KVM, both source PCs should output the same signal type for proper switching. It is recommended wherever possible to use DVI-D cables across all PC to KVM and KVM to Console connections. Please contact technical support if you require assistance identifying your source.


This product is TAA compliant and backed by a Startech.com 3 year warranty with free lifetime technical support.





Rackmount your KVM switch If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.





Applications: Four system control for single user workstations with dual head video cards, increasing user productivity in the office
Control up to four dual display multimedia computers with a single set of console peripherals (Keyboard, Mouse, and two Monitors)
Ideal for financial/banking industries, graphic designers, multi-media applications and industries using CAD/CAM applications, and multiple screens
Integrated USB 2.0 hub and Mic/Audio ports allow the user to have full multimedia control of two computers and share USB peripherals









Features: Front panel push-buttons and Hot-key functions for easy switching
Supports resolutions up to 2048x1536 (Analog) and 1920x1200 (digital)
USB 2.0 hub for peripheral sharing (Thumb drives, external hard drives, web cams, etc.)
Audible tone confirms port switching
Combined or independent switching of audio ports
EDID retention - eliminates hassle when switching between computers as the KVM "remembers" monitor settings
Supports all USB-capable operating systems (Windows 98e/SE/ME/2000/XP/Vista/7, Linux, Mac OS, etc.)
TMDS compliant to support DDC2B emulation and HDCP for digital contents protection
Status LED display for easy port status monitoring









The StarTech.com Advantage: Integrated USB 2.0 hub and Mic/Audio ports allow the user to have full multimedia control of two computers and share USB peripherals eliminating the expense of duplicate devices
Take full advantage of Dual head video cards by switching up to four machines across two high resolution DVI monitors
Absolutely no software or drivers required providing a completely OS independent KVM solution









Technical details Product colour Black Number of users 1 user(s) LED indicators Power IP control No Sustainability certificates RoHS

Video Maximum resolution 2048 x 1536 pixels Maximum digital resolution 1920 x 1200 pixels Maximum analog resolution 2048 x 1536 pixels

Ports & interfaces Console ports 3.5 mm headphone, 3.5 mm mic, DVI-I, USB A USB connector type USB Type-A Number of microphone inputs 1 Number of computers controlled 4 Keyboard port type USB Mouse port type USB Video port type DVI-I Audio connections Yes USB 2.0 ports quantity 4 DC-in jack Yes

Network Ethernet LAN No

Performance Daisy chain No Maximum resolution 2048 x 1536 pixels Number of users 1 user(s) Maximum digital resolution 1920 x 1200 pixels Maximum analog resolution 2048 x 1536 pixels

Design Product colour Black LED indicators Power Certification CE, FCC, UL Housing material Steel

Power Input current 0.8 A Output current 1.5 A Compatible power plug types AU, EU, UK, US Output voltage 12 V AC input voltage 100 - 240 V

Operating conditions Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) - 20 - 60 °C Operating relative humidity (H-H) 0 - 90%

Weight & dimensions Width 220 mm Depth 130 mm Height 60 mm Weight 1.25 kg

Packaging content Rubber feet Yes Manual Yes AC adapter included Yes

Other features IP control No Full specification and details can be found in the

4-Port HDMI KVM Switch - USB 3.0 - 1080p

Control four HDMI computers using a single console, with a built-in USB 3.0 hub for sharing additional peripheral devices



This 4-Port USB 3.0 HDMI® KVM switch lets you control four HDMI computers with a single monitor, keyboard and mouse. The KVM also features 3.5 mm audio and a built-in 3-port USB 3.0 hub.




Convenient and cost-effective USB 3.0 peripheral sharing This KVM switch offers a built-in 3-port USB 3.0 hub that's separate from your HID keyboard and mouse, so you can share USB peripheral devices between each connected computer and avoid the expense of separate equipment. The USB 3.0 hub automatically switches your connected USB devices to the selected computer, saving you the hassle of disconnecting and reconnecting peripherals. With support for USB 3.0, you can achieve data transfer rates up to 5Gbps, to ensure flawless performance for your USB peripherals - great for quickly transferring data to external USB 3.0 drives.




HD picture quality Offering support for high-definition 1080p resolutions, this 4-port HDMI KVM switch has the ability to drive HDMI displays with crystal clarity, making it ideal for graphical applications that require 1920 x 1080 video resolutions.




Complete multimedia control The KVM switch features auxiliary 3.5 mm audio ports that enable you to share independent analog audio, from each of your connected computers, with your desktop speaker set. Independent audio, along with 1080p HDMI video, gives you full multimedia control between different computers, making this KVM perfect for creative professional applications such as video and sound design or editing. The SV431HDU3A2 is TAA compliant and backed by a StarTech.com 2-year warranty with free lifetime technical support.




Rackmount your KVM switch If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.



Front view:






Back view:







Applications: Control four HDMI USB computers with a single set of console peripherals (keyboard, mouse and monitor)
Perform HD 1080p multimedia applications such as graphic design or CAD and CAM creations
Share USB 3.0 peripherals between four computers









Features: Easily share peripheral devices with built-in USB 3.0 hub
High definition video quality with support for resolutions up to 1080p
Full multimedia control with separate 3.5 mm auxiliary support
No software or drivers required
Independent HID keyboard and mouse ports









Technical details Product colour Black Rack mounting Yes Plug and Play Yes On Screen Display (OSD) No LED indicators Link, Power Hot keys Yes IP control No Audio support Yes Sustainability certificates RoHS

Performance Maximum cable length 10000 m Daisy chain No Plug and Play Yes Maximum resolution 1920 x 1080 pixels Audio channels 2.0

Video Maximum resolution 1920 x 1080 pixels

Ports & interfaces Console USB ports quantity 4 Console ports 3.5 mm headphone, HDMI, USB A USB connector type USB Type-A Number of computers controlled 4 Keyboard port type USB Mouse port type USB Video port type HDMI Audio connections Yes Headphone outputs 4 DC-in jack Yes USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity 3

Network Ethernet LAN No

Design Mean time between failure (MTBF) 142000 h Maximum cable length 10000 m Product colour Black Rack mounting Yes LED indicators Link, Power Hot keys Yes Certification CE, FCC, UL, PSE

Display Built-in display No On Screen Display (OSD) No

Power Input current 0.6 A Output current 1.5 A Power plug type Type M Compatible power plug types AU, EU, UK, US Output voltage 12 V AC input voltage 100 - 240 V

Operational conditions Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -10 - 60 °C Operating relative humidity (H-H) 0 - 80 %

Weight & dimensions Width 130 mm Depth 220 mm Height 43 mm Weight 1.1 kg

Packaging content Rubber feet Yes Quick installation guide Yes

Other features Hot keys Yes IP control No Audio support Yes Full specification and details can be found in the

4-Port DisplayPort KVM Switch - USB 3.0 - 4K 30Hz

Control four DP computers using a single console with a built-in USB 3.0 hub for sharing additional peripheral devices










This 4-Port USB 3.0 DisplayPort KVM switch lets you control four DisplayPort (DP) computers with a single monitor, keyboard and mouse. The KVM also features 3.5 mm audio and a built-in 3-port USB 3.0 hub.




Convenient and cost-effective USB 3.0 peripheral sharing This KVM switch offers a built-in 3-port USB 3.0 hub that's separate from your HID keyboard and mouse, so you can share USB peripheral devices between each connected computer and avoid the expense of separate equipment. The USB 3.0 hub automatically switches your connected USB devices to the selected computer, saving you the hassle of disconnecting and reconnecting your peripherals. With support for USB 3.0, you can achieve data transfer rates up to 5Gbps, to ensure flawless performance for your USB peripherals - great for quickly transferring data to external USB 3.0 drives.




Astonishing picture quality Offering support for resolutions up to Ultra HD 4K at 30 Hz, this 4-port DisplayPort KVM switch has the ability to drive large DP displays with ease, making it ideal for graphical applications that require high-resolution video support.




Complete multimedia control The KVM switch features auxiliary 3.5 mm audio ports that enable you to share independent analog audio, from each of your connected computers, with your desktop speaker set. Independent audio, along with 4K DP video, gives you full multimedia control between different computers, making this KVM perfect for creative professional applications such as video and sound design or editing. The SV431DPU3A2 is TAA compliant and backed by a StarTech.com 2-year warranty with free lifetime technical support.




Rackmount your KVM switch If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.





Applications: Control four DisplayPort USB computers with a single set of console peripherals (keyboard, mouse and monitor)
Perform Ultra HD multimedia applications such as graphic design or CAD and CAM creations
Share USB 3.0 peripherals between four computers









Features: Easily share peripheral devices using the built-in USB 3.0 hub
Astonishing picture quality with support for Ultra HD 4K resolutions
Full multimedia control with separate 3.5 mm auxiliary support
No software or drivers required
Independent HID keyboard and mouse ports









Technical details Product colour Black Rack mounting Yes Plug and Play Yes Maximum operating distance 10 m LED indicators Link, Power Hot keys Yes IP control No Audio support Yes USB version 3.2 Gen 1 (3.1 Gen 1) Sustainability certificates RoHS

Performance HDCP Yes Daisy chain No HD type 4K Ultra HD Plug and Play Yes Maximum resolution 3840 x 2160 pixels Maximum operating distance 10 m Audio channels 2.0

Video HD type 4K Ultra HD Maximum resolution 3840 x 2160 pixels

Ports & interfaces Console USB ports quantity 4 Console ports 3.5 mm headphone, DisplayPort, USB A HDCP Yes USB version 3.2 Gen 1 (3.1 Gen 1) USB connector type USB Type-A Number of computers controlled 4 Keyboard port type USB Mouse port type USB Video port type DisplayPort Audio connections Yes Headphone outputs 4 DC-in jack Yes USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity 3

Network Ethernet LAN No

Design Product colour Black Rack mounting Yes LED indicators Link, Power Hot keys Yes Certification CE, FCC, UL, PSE

Display Built-in display No

Power Output current 1.5 A Power plug type Type M Compatible power plug types AU, EU, UK, US Output voltage 12 V AC input voltage 100 - 240 V Power consumption (typical) 18 W

Operating conditions Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -10 - 60 °C Operating relative humidity (H-H) 0 - 80 %

Weight & dimensions Width 130 mm Depth 220 mm Height 43 mm Weight 1.06 kg

Packaging content Rubber feet Yes Quick installation guide Yes

Other features Maximum operating distance 10 m Hot keys Yes IP control No Audio support Yes Full specification and details can be found in the

4 Port HDMI KVM Switch - 4K 30Hz - Dual Display

This 4K HDMI KVM with dual monitor support lets you control four HDMI computers with a single mouse, keyboard and dual monitors up to 4K at 30Hz

This 4-port HDMI KVM switch lets you control four HDMI computers with a single mouse, keyboard and monitor up to 4K 30Hz. The KVM also features 3.5 mm audio and a built-in 2-port USB 3.0 hub.




4K at 30Hz UHD dual display With support for ultra-high-definition 4K 30Hz resolutions, this 4-port KVM switch can drive dual HDMI displays with crystal clarity, making it ideal for graphical applications that require UHD capability




Convenient and cost-effective USB 3.0 peripheral sharing This 4-port KVM switch offers two USB 3.0 ports, as well as four HID keyboard and mouse ports, so you can share peripheral devices between each computer and avoid the cost of separate equipment. The USB 3.0 hub automatically switches your connected devices to the selected computer, saving you the hassle of disconnecting and reconnecting peripherals.




Complete multimedia capability Along with dual UHD video capability, this KVM switch features auxiliary 3.5 mm dual-channel bi-directional audio ports. This independent analog audio lets you share your analog audio devices such as speakers or a microphone between each of your connected computers, giving you complete multimedia control of your systems. The SV431DHD4KU is TAA compliant and backed by a StarTech.com 2-year warranty with free lifetime technical support.





Applications: Ideal for applications that require two displays at high resolutions such as graphic design, medical imaging, digital signage, multimedia design across four computers
Great for those who need to share high-speed storage between up to four systems
Perfect for creative professional applications such as video and sound design or editing









Features: High-definition video quality with support for dual 4K at 30Hz displays
Two built-in USB 3.0 ports and independent HID keyboard/mouse ports
No software or drivers required
Separate 3.5 mm auxiliary support
Supports push-button and hotkey switching









Technical details Product colour Black Rack mounting Yes Scan interval 3, 8, 15, 30 s LED indicators Power, Status Hot keys Yes IP control No Sustainability certificates RoHS

Video HD type 4K Ultra HD Maximum resolution 3840 x 2160 pixels

Ports & interfaces Console USB ports quantity 6 Console ports 3.5 mm headphone, HDMI, USB A USB connector type USB Type-A Number of computers controlled 4 Keyboard port type USB Mouse port type USB Video port type HDMI Headphone outputs 4 HDMI ports quantity 10

Performance Data transfer rate (max) 5 Gbit/s HD type 4K Ultra HD Maximum resolution 3840 x 2160 pixels Scan interval 3, 8, 15, 30 s

Design Mean time between failure (MTBF) 168000 h Product colour Black Rack mounting Yes LED indicators Power, Status Hot keys Yes Certification CE, FCC, TAA, REACH Housing material Steel

Display Built-in display No

Power Input current 0.6 A Output current 1.5 A Compatible power plug types AU, EU, JP, UK, US Output voltage 12 V AC input voltage 100 - 240 V Power consumption (typical) 18 W External power adapter Yes

Operating conditions Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -10 - 60 °C Operating relative humidity (H-H) 0 - 80 %

Weight & dimensions Width 130 mm Depth 220 mm Height 63 mm Weight 1.2 kg

Packaging content Rubber feet Yes Quick installation guide Yes

Other features Hot keys Yes IP control No Full specification and details can be found in the

4-Port Dual DisplayPort KVM Switch - 4K 60Hz

This 4-port Dual DP KVM switch combines dual 4K 60Hz displays with KVM switch control of four connected PC and MAC computers










This 4-port dual DP KVM switch combines dual 4K 60Hz displays with KVM switch control of four connected PC and Mac computers. It features audio and USB peripheral support along with dual-display capability, which makes it easy to create a multimedia workstation that can switch between two dual-head DP systems.




Maximize productivity with dual video With two DP video inputs and control of four different computers, this Ultra HD KVM switch helps maximize productivity by giving you the freedom to multitask. Each of the DP ports supports resolutions up to 4K 60Hz, for maximum screen viewing space.




Astonishing picture quality The dual DisplayPort KVM switch supports resolutions up to 4K at 60Hz, and can drive two large DP displays with ease. An ideal solution for creating workstations where high-quality imaging is critical, such as for graphic design.




Convenient multimedia and peripheral sharing The KVM switch features full multimedia control with separate 3.5 mm microphone and speaker ports and two USB ports separate from the HID keyboard and mouse. The independent audio support lets you share independent analog audio from each of your connected computers, while the 2-port USB hub enables you to share USB peripherals between each connected computer. The SV431DPDDUA2 is TAA compliant and backed by a 2-year StarTech.com warranty.





Applications: Ideal in environments where high-quality imaging and computing bandwidth are critical, such as graphic design, video editing, medical, CAD drawing
Operate multiple computers in manufacturing lines or install the KVM switch in your server room, for multi-computer access









Features: Maximum productivity with dual-display, multi-computer access
Full multimedia control with separate 3.5 mm microphone and speaker support
Astonishing picture quality with support for Ultra HD 4K resolutions at 60Hz
Share your USB peripheral devices with built-in 2-port USB hub
Access computers easily with hotkey and push-button switching









Technical details Product colour Black Rack mounting Yes Scan interval 3, 8, 15, 30 s LED indicators Power Hot keys Yes IP control No Audio support Yes USB hub Yes Sustainability certificates RoHS

Video HD type 4K Ultra HD Maximum resolution 3840 x 2160 pixels

Ports & interfaces Console USB ports quantity 4 Console ports 3.5 mm headphone, 3.5 mm mic, DisplayPort, USB A USB connector type USB Type-A DisplayPorts quantity 10 Number of computers controlled 4 Keyboard port type USB Mouse port type USB Video port type DisplayPort Audio connections Yes DC-in jack Yes USB hub Yes

Performance Daisy chain No Data transfer rate (max) 0.5 Gbit/s HD type 4K Ultra HD Maximum resolution 3840 x 2160 pixels Scan interval 3, 8, 15, 30 s

Design Mean time between failure (MTBF) 142000 h Product colour Black Rack mounting Yes LED indicators Power Hot keys Yes Certification CE, FCC, TAA, REACH Rack capacity 2U Housing material Steel

Display Built-in display No

Power Input current 0.6 A Output current 1.5 A Power plug type Type M Compatible power plug types AU, EU, JP, UK, US Output voltage 12 V Power source AC AC input voltage 100 - 240 V Power consumption (typical) 18 W External power adapter Yes

Operating conditions Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -10 - 60 °C Operating relative humidity (H-H) 0 - 80 %

Weight & dimensions Width 216 mm Depth 127 mm Height 63 mm Weight 1.2 kg

Packaging content Rubber feet Yes Quick installation guide Yes

Other features Hot keys Yes IP control No Audio support Yes Full specification and details can be found in the
