4 Port Dual DVI USB KVM Switch with Audio & USB 2.0 Hub
Share a keyboard, mouse and dual DVI displays/monitors between 4 multimedia computers
The SV431DD2DUA 4-port Dual DVI USB KVM Switch allows up to four PCs, each with dual DVI video outputs, to share two monitors, one microphone and set of speakers, one keyboard and one mouse as well as two other USB peripherals.
An ideal solution for graphic designers, CAD/CAM designers or educational and financial institutions, the dual view KVM Switch allows you to instantly switch back and forth between dual DVI display PCs at the touch of a button, while maintaining professional level video quality on both monitors. The dual DVI switch also features an integrated USB hub port that allows USB 2.0 peripherals such as thumb drives, external hard drives or web cams to be shared between attached systems - eliminating duplicate peripheral costs.
Please Note: While both DVI-I (analog mode) and DVI-D (digital only) are supported by the KVM, both source PCs should output the same signal type for proper switching. It is recommended wherever possible to use DVI-D cables across all PC to KVM and KVM to Console connections. Please contact technical support if you require assistance identifying your source.
This product is TAA compliant and backed by a Startech.com 3 year warranty with free lifetime technical support.
If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.
| Technical details | |
| Product colour | Black |
| Number of users | 1 user(s) |
| LED indicators | Power |
| IP control | No |
| Sustainability certificates | RoHS |
| Video | |
| Maximum resolution | 2048 x 1536 pixels |
| Maximum digital resolution | 1920 x 1200 pixels |
| Maximum analog resolution | 2048 x 1536 pixels |
| Ports & interfaces | |
| Console ports | 3.5 mm headphone, 3.5 mm mic, DVI-I, USB A |
| USB connector type | USB Type-A |
| Number of microphone inputs | 1 |
| Number of computers controlled | 4 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DVI-I |
| Audio connections | Yes |
| USB 2.0 ports quantity | 4 |
| DC-in jack | Yes |
| Network | |
| Ethernet LAN | No |
| Performance | |
| Daisy chain | No |
| Maximum resolution | 2048 x 1536 pixels |
| Number of users | 1 user(s) |
| Maximum digital resolution | 1920 x 1200 pixels |
| Maximum analog resolution | 2048 x 1536 pixels |
| Design | |
| Product colour | Black |
| LED indicators | Power |
| Certification | CE, FCC, UL |
| Housing material | Steel |
| Power | |
| Input current | 0.8 A |
| Output current | 1.5 A |
| Compatible power plug types | AU, EU, UK, US |
| Output voltage | 12 V |
| AC input voltage | 100 - 240 V |
| Operating conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | - 20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Weight & dimensions | |
| Width | 220 mm |
| Depth | 130 mm |
| Height | 60 mm |
| Weight | 1.25 kg |
| Packaging content | |
| Rubber feet | Yes |
| Manual | Yes |
| AC adapter included | Yes |
| Other features | |
| IP control | No |
Full specification and details can be found in the PDF file
A user manual can be found in the PDF file
