StarTech Dual Monitor KVM Switches

2 Port DVI VGA Dual Monitor KVM Switch USB with Audio & USB 2.0 Hub

Share a keyboard and mouse as well as 1 VGA and 1 DVI displays/monitors between 2 multimedia computers












The SV231DDVDUA 2-port Dual Monitor KVM Switch (DVI+VGA) offers a complete multimedia switching solution, letting users control two Dual Display computers using a single USB mouse and keyboard peripheral set.


With support for high-resolution video interfaces, this dual view KVM switch provides one VGA (analog) and one DVI-I port per computer connection, as well as audio switching capability between connected computers.


Delivering versatility for virtually any application, the DVI/VGA KVM switch features an integrated 2-port USB hub that allows connected USB 2.0 peripherals to be shared between connected computers, eliminating the need to purchase duplicate peripherals.


Suitable for any workspace, the dual monitor KVM switch offers a compact desktop KVM design and features a rugged metal chassis that helps ensure durable performance.


This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.





Applications: Perfect solution for desktops, workstations and servers with both VGA and DVI-digital ports, allowing a user to take advantage of dual monitor configurations
Ideal for financial/banking industries, graphic designers, engineers, multi-media designers, and industries using CAD/CAM applications, where high resolution dual monitor units are needed
Suitable for use in environments with electromagnetic interference, based on sturdy metal design
Versatile support for setups where one machine is DVI & VGA, and the other is VGA & VGA (with available adapters)









Features: Direct channel selection and operation using front panel push-button or keyboard hotkeys
Supports a maximum resolution of 1920 x 1200
Independent or simultaneous audio switching
OS independent (no drivers or software required)
Full support for plug-n-play peripherals
Status LED display for easy port status monitoring
USB style keyboard and mouse, plus two other USB peripherals can be shared between up to two computers
Tone indicator for computer switching
Selectable time intervals for auto scan
Rear function key to adjust video strength
HDCP compliant
Support DDC2B emulation and EDID pass through, which allows the display adapter to recognize and auto configure the display resolution to match the display capabilities
Supports Dual Monitor/Flat Panel Displays [1 x DVI + 1 x VGA]









The StarTech.com Advantage: High-resolution DVI and VGA ports support almost any dual display scenario; even with one DVI + VGA PC, and one dual DVI PC, an adapter can be used with this KVM to support your configuration
Integrated USB 2.0 hub and Mic/Audio ports allow the user to have full multimedia control of two computers and share USB peripherals eliminating the expense of duplicate devices
Absolutely no software or drivers required providing a completely OS independent KVM solution









Technical details Product colour Black Rack mounting No Number of users 1 user(s) LED indicators Power IP control No Audio support Yes Sustainability certificates RoHS

Performance HDCP Yes DDC2B support Yes Daisy chain No HD type WUXGA Maximum resolution 1920 x 1200 pixels Number of users 1 user(s) Maximum digital resolution 1920 x 1200 pixels

Video HD type WUXGA Maximum resolution 1920 x 1200 pixels Maximum digital resolution 1920 x 1200 pixels

Ports & interfaces Console ports 3.5mm headphone, DVI-I, VGA (D-Sub) HDCP Yes USB connector type USB Type-A Number of microphone inputs 3 Number of computers controlled 2 Keyboard port type USB Mouse port type USB Video port type VGA/DVI-I Audio connections Yes USB 2.0 ports quantity 4 Headphone outputs 3

Design Mean time between failures (MTBF) 64691 h Product colour Black Rack mounting No LED indicators Power Certification CE, FCC Housing material Steel

Display Built-in display No

Power Input current 0.8 A Output current 1.5 A Power plug type Type M Compatible power plug types AU, EU, UK, US Output voltage 12 V AC input voltage 100 - 240 V Power consumption (typical) 18 W External power adapter Yes

Operational conditions Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -20 - 60 °C Operating relative humidity (H-H) 0 - 80%

Weight & dimensions Width 160 mm Depth 163 mm Height 57 mm Weight 750 g

Packaging content Rubber feet Yes Manual Yes AC adapter included Yes

Other features IP control No Audio support Yes Full specification and details can be found in the

4 Port DVI VGA Dual Monitor KVM Switch USB with Audio & USB 2.0 Hub

Share a keyboard and mouse as well as 1 VGA and 1 DVI displays/monitors between 4 multimedia computers










The SV431DDVDUA 4-port DVI VGA dual monitor KVM switch lets you control 4 Dual Display computers using a single USB mouse and keyboard peripheral set.


This dual view KVM switch provides 1 VGA and 1 DVI-I port per computer connection for high-resolution video, as well as audio switching capability between connected computers.


The DVI/VGA KVM switch features an integrated 2-port USB hub that allows USB 2.0 peripherals to be shared between connected computers, and offers a compact design with a rugged metal chassis for durable performance.


NOTE: While both DVI-I (analog) and DVI-D (digital) are supported by the KVM, source PCs must output the same signal for proper switching. It is recommended wherever possible to use DVI-D cables across all PC to KVM and KVM to Console connections. If necessary, please contact technical support for assistance identifying your source.


This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.




Rackmount your KVM switch If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.





Applications: Perfect solution for desktops, workstations and servers with both VGA and DVI-digital ports, allowing a user to take advantage of dual monitor configurations
Ideal for financial/banking industries, graphic designers, engineers, multi-media designers, and industries using CAD/CAM applications, where high resolution dual monitor units are needed
Suitable for use in environments with electromagnetic interference, based on sturdy metal design
Versatile support for setups where one machine is DVI & VGA, and the other is VGA & VGA (with available adapters)









Features: Direct channel selection and operation using front panel push-button or keyboard hotkeys
Supports a maximum digital resolution of 1920 x 1200 and analog of 1920 x 1440; Recommended resolution is 1920 x 1200
OS independent (no drivers or software required)
Independent or simultaneous audio switching
Full support for plug-n-play peripherals
Rugged, all-metal chassis for use in harsh environments
Status LED display for easy port status monitoring
USB style keyboard and mouse, plus two other USB 2.0 peripherals can be shared between up to two computers
Tone indicator for computer switching
Selectable time intervals for auto scan
Rear function key to adjust video strength
HDCP compliant
Support DDC2B emulation and EDID pass through, which allows the display adapter to recognize and auto configure screens to match the display capabilities
Supports Dual Monitor/Flat Panel Displays [1 x DVI + 1 x VGA]









Technical details Product colour Black On Screen Display (OSD) No Number of users 1 user(s) LED indicators Yes Hot keys Yes IP control No Sustainability certificates RoHS

Video Maximum resolution 1920 x 1200 pixels

Ports & interfaces Console USB ports quantity 4 Console ports 3.5mm headphone, 3.5mm mic, DVI-I, USB A, VGA (D-Sub) USB connector type USB Type-A Number of microphone inputs 1 Number of computers controlled 4 Keyboard port type USB Mouse port type USB Video port type VGA / DVI-I Audio connections Yes VGA (D-Sub) ports quantity 5 Headphone outputs 1 DVI-I ports quantity 5 DC-in jack Yes

Performance Daisy chain No Maximum resolution 1920 x 1200 pixels Number of users 1 user(s)

Design Mean time between failures (MTBF) 140000 h Product colour Black LED indicators Yes Hot keys Yes Certification CE, FCC, UL, REACH Housing material Steel

Display Built-in display No On Screen Display (OSD) No

Power Input current 0.8 A Output current 1.5 A Power plug type Type M Compatible power plug types AU, EU, UK, US Output voltage 12 V AC input voltage 100 - 240 V Power consumption (typical) 18 W External power adapter Yes

Operational conditions Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -20 - 60 °C Operating relative humidity (H-H) 0 - 80%

Weight & dimensions Width 220 mm Depth 163 mm Height 60 mm Weight 1.3 kg

Packaging content Rubber feet Yes Manual Yes AC adapter included Yes

Other features Hot keys Yes IP control No Full specification and details can be found in the

2-Port DisplayPort Dual-Monitor KVM Switch - 4K 60Hz

Access two dual-monitor computers and two shared USB peripherals from a single workstation



This dual DisplayPort KVM switch combines next-generation digital display standards with seamless KVM control. The 2-port KVM switch features audio and USB peripheral support along with dual-display capability, which makes it easy to create a multimedia workstation that can switch between two dual-head or twin DisplayPort systems.




Maximize productivity with dual video With support for two DisplayPort video inputs and two different computers, this KVM switch helps maximize productivity.You can access multiple computers, giving you the freedom to multitask and increase your productivity. Each of the DP ports supports resolutions up to 4K for maximum screen viewing space. You can also use low-cost adapters to achieve a dual-monitor setup using your computer's secondary HDMI or DVI port.




Astonishing picture quality The dual DisplayPort KVM switch supports resolutions up to Ultra HD 4K at 60Hz, and can drive two large DP displays with ease. This makes it the ideal solution for creating workstations where high-quality imaging is critical, such as for graphic design.




Complete multimedia control The KVM switch features auxiliary 3.5 mm audio ports that let you share independent analog audio, from each of your connected computers, with your desktop speaker set. With independent audio support, along with dual 4K DP video, you get full multimedia control between different computers which makes this the perfect KVM switch for creative professional applications such as video and sound design or editing.




Convenient peripheral sharing This KVM switch offers a built-in 2-port USB hub that's separate from your HID keyboard and mouse. This enables you to share USB peripherals between each connected computer and avoid the expense of separate equipment. The USB hub automatically switches your connected USB devices to the selected computer, saving you the hassle and cost of outfitting each of your computers with their own peripherals. The SV231DPDDUA2 is TAA compliant and backed by a 2-year StarTech.com warranty with free lifetime technical support.












Applications: Control two computers, each with dual-head video cards, from a single workstation
Work with multimedia applications such as 4K video and photo editing
Operate multiple computers in manufacturing lines
Install in your server room, for multi-computer access
Perform high-resolution tasks such as graphic design or CAD drawing









Features: Maximum productivity with dual-display, multi-computer access
Full multimedia control with separate 3.5 mm auxiliary support
Astonishing picture quality with support for Ultra HD 4K resolutions at 60Hz
Share your USB peripheral devices with built-in 2-port USB hub









Technical details Product colour Black Push button Yes LED indicators Yes Hot keys Yes IP control No Audio support Yes Sustainability certificates RoHS

Video HD type 4K Ultra HD Maximum resolution 3840 x 2160 pixels

Ports & interfaces Console USB ports quantity 4 Console ports 3.5mm headphone, 3.5mm mic, DisplayPort, USB A USB connector type USB Type-A Number of microphone inputs 3 Number of computers controlled 2 Keyboard port type USB Mouse port type USB Video port type DisplayPort Audio connections Yes Headphone outputs 3 DC-in jack Yes

Network Ethernet LAN No

Performance Daisy chain No HD type 4K Ultra HD Maximum resolution 3840 x 2160 pixels

Design Product colour Black Push button Yes LED indicators Yes Hot keys Yes Certification CE, FCC, REACH, TAA

Display Built-in display No

Power Input current 1.5 A Output current 0.6 A Compatible power plug types AU, EU, UK, US Output voltage 12 V AC input voltage 100 - 240 V External power adapter Yes

Operational conditions Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -20 - 60 °C Operating relative humidity (H-H) 0 - 80%

Weight & dimensions Width 161 mm Depth 58 mm Height 100 mm Weight 734 g

Packaging content Rubber feet Yes Manual Yes

Other features Push button Yes Hot keys Yes IP control No Audio support Yes Full specification and details can be found in the
