| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | FESV231DDVDUA |
| Manufacturer No: | SV231DDVDUA |
| Delivery: | In Stock: Next Day |
 |
2 Port DVI VGA Dual Monitor KVM Switch USB with Audio & USB 2.0 Hub
Share a keyboard and mouse as well as 1 VGA and 1 DVI displays/monitors between 2 multimedia computers
The SV231DDVDUA 2-port Dual Monitor KVM Switch (DVI+VGA) offers a complete multimedia switching solution, letting users control two Dual Display computers using a single USB mouse and keyboard peripheral set.
With support for high-resolution video interfaces, this dual view KVM switch provides one VGA (analog) and one DVI-I port per computer connection, as well as audio switching capability between connected computers.
Delivering versatility for virtually any application, the DVI/VGA KVM switch features an integrated 2-port USB hub that allows connected USB 2.0 peripherals to be shared between connected computers, eliminating the need to purchase duplicate peripherals.
Suitable for any workspace, the dual monitor KVM switch offers a compact desktop KVM design and features a rugged metal chassis that helps ensure durable performance.
This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.
| Technical details | |
| Product colour | Black |
| Rack mounting | No |
| Number of users | 1 user(s) |
| LED indicators | Power |
| IP control | No |
| Audio support | Yes |
| Sustainability certificates | RoHS |
| Performance | |
| HDCP | Yes |
| DDC2B support | Yes |
| Daisy chain | No |
| HD type | WUXGA |
| Maximum resolution | 1920 x 1200 pixels |
| Number of users | 1 user(s) |
| Maximum digital resolution | 1920 x 1200 pixels |
| Video | |
| HD type | WUXGA |
| Maximum resolution | 1920 x 1200 pixels |
| Maximum digital resolution | 1920 x 1200 pixels |
| Ports & interfaces | |
| Console ports | 3.5mm headphone, DVI-I, VGA (D-Sub) |
| HDCP | Yes |
| USB connector type | USB Type-A |
| Number of microphone inputs | 3 |
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | VGA/DVI-I |
| Audio connections | Yes |
| USB 2.0 ports quantity | 4 |
| Headphone outputs | 3 |
| Design | |
| Mean time between failures (MTBF) | 64691 h |
| Product colour | Black |
| Rack mounting | No |
| LED indicators | Power |
| Certification | CE, FCC |
| Housing material | Steel |
| Display | |
| Built-in display | No |
| Power | |
| Input current | 0.8 A |
| Output current | 1.5 A |
| Power plug type | Type M |
| Compatible power plug types | AU, EU, UK, US |
| Output voltage | 12 V |
| AC input voltage | 100 - 240 V |
| Power consumption (typical) | 18 W |
| External power adapter | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Width | 160 mm |
| Depth | 163 mm |
| Height | 57 mm |
| Weight | 750 g |
| Packaging content | |
| Rubber feet | Yes |
| Manual | Yes |
| AC adapter included | Yes |
| Other features | |
| IP control | No |
| Audio support | Yes |
Full specification and details can be found in the PDF file
A user manual can be found in the PDF file
2 Port DVI VGA Dual Monitor KVM Switch USB with Audio & USB 2.0 Hub
Share a keyboard and mouse as well as 1 VGA and 1 DVI displays/monitors between 2 multimedia computers
The SV231DDVDUA 2-port Dual Monitor KVM Switch (DVI+VGA) offers a complete multimedia switching solution, letting users control two Dual Display computers using a single USB mouse and keyboard peripheral set.
With support for high-resolution video interfaces, this dual view KVM switch provides one VGA (analog) and one DVI-I port per computer connection, as well as audio switching capability between connected computers.
Delivering versatility for virtually any application, the DVI/VGA KVM switch features an integrated 2-port USB hub that allows connected USB 2.0 peripherals to be shared between connected computers, eliminating the need to purchase duplicate peripherals.
Suitable for any workspace, the dual monitor KVM switch offers a compact desktop KVM design and features a rugged metal chassis that helps ensure durable performance.
This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.
| Technical details | |
| Product colour | Black |
| Rack mounting | No |
| Number of users | 1 user(s) |
| LED indicators | Power |
| IP control | No |
| Audio support | Yes |
| Sustainability certificates | RoHS |
| Performance | |
| HDCP | Yes |
| DDC2B support | Yes |
| Daisy chain | No |
| HD type | WUXGA |
| Maximum resolution | 1920 x 1200 pixels |
| Number of users | 1 user(s) |
| Maximum digital resolution | 1920 x 1200 pixels |
| Video | |
| HD type | WUXGA |
| Maximum resolution | 1920 x 1200 pixels |
| Maximum digital resolution | 1920 x 1200 pixels |
| Ports & interfaces | |
| Console ports | 3.5mm headphone, DVI-I, VGA (D-Sub) |
| HDCP | Yes |
| USB connector type | USB Type-A |
| Number of microphone inputs | 3 |
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | VGA/DVI-I |
| Audio connections | Yes |
| USB 2.0 ports quantity | 4 |
| Headphone outputs | 3 |
| Design | |
| Mean time between failures (MTBF) | 64691 h |
| Product colour | Black |
| Rack mounting | No |
| LED indicators | Power |
| Certification | CE, FCC |
| Housing material | Steel |
| Display | |
| Built-in display | No |
| Power | |
| Input current | 0.8 A |
| Output current | 1.5 A |
| Power plug type | Type M |
| Compatible power plug types | AU, EU, UK, US |
| Output voltage | 12 V |
| AC input voltage | 100 - 240 V |
| Power consumption (typical) | 18 W |
| External power adapter | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Width | 160 mm |
| Depth | 163 mm |
| Height | 57 mm |
| Weight | 750 g |
| Packaging content | |
| Rubber feet | Yes |
| Manual | Yes |
| AC adapter included | Yes |
| Other features | |
| IP control | No |
| Audio support | Yes |
Full specification and details can be found in the PDF file
A user manual can be found in the PDF file
Product data is provided by Icecat, we do not warrant the accuracy of the material above.
