Multi-Gigabit Switches

The HPE Aruba Networking JL320A 2930M 24G PoE+ 1-slot Switch is designed for digital workplaces optimized for mobile users. These Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager, Aruba AirWave and cloud-based Aruba Central. Modular stacking, uplinks and power provide scalability and simplicity for enterprise edge, SMB and branch offices. The 2930M delivers performance and value with support for static, RIP and Access OSPF routing, 10GbE and 40GbE uplinks, models with 24 ports of HPE Smart Rate multi-gigabit Ethernet, up to 740W of PoE+, robust QoS, SDN and requires no software licensing.

Key Features: Aruba Layer 3 Switch with 10 chassis backplane stacking, static, RIP and access OSPF routing, Tunnel Node, ACLs, SDN, and robust QoS
Advanced security and network management tools like Aruba ClearPass Policy Manager, Aruba AirWave and Aruba Central
Modular 10GbE or 40GbE uplinks and HPE Smart Rate (IEEE 802.3bz), up to 740W PoE+
Ready for the software defined network with REST APIs and OpenFlow support
Simple deployment with Zero Touch Provisioning

HPE Aruba 2930M 24G PoE+: 20 Autosensing 10/100/1000 PoE+ ports
Dual Personality 10/100/1000 BASE-T PoE+ or 100/1000 Mbps SFP Ports
Features:

The Aruba 2930M Switch Series provides performance, security, and ease of use for enterprise edge, SMB, and branch office networks.
The Aruba 2930M Switch Series is designed with a powerful Aruba ProVision ASIC, to enable the mobile campus with low latency, increased packet buffering, and adaptive power consumption.
The Aruba 2930M Switch Series includes security and quality of services (QoS) features to build a network that meets ever-changing corporate policies and compliance's while protecting your data from both inside and outside attacks.
The Aruba 2930M Switch Series supports Aruba ClearPass Policy Manager for unified and consistent policy between wired and wireless users and simplifies implementation and management of guest login, user onboarding, network access, security, QoS, and other network policies.


Option of dual
Power Supplies Stacking Module
Slot Uplink Slot Additional Ports and Slots

1 Dual Personality (RJ-45 or USB Micro-B) serial console port
1 USB B port for uploading/ downloading files
1 100BASE-T Out of Band Management Port
1 Uplink Slot
1 Stacking Module Slot
2 Power Supply Slots (power supplies not included)




JL319A
2930M 24G
JL320A
2930M 24G PoE+  JL324A
2930M 24 HPE Smart Rate PoE
Ports 20 Autosensing 10/100/1000 ports 20 Autosensing 10/100/1000 ports 24 Autosensing 1/2.5/5GBaseT ports Switching Capacity 128 Gbps 128 Gbps 320 Gbps Switching Capacity (Including Stacking 128 Gbps 228 Gbps 420 Gbps Throughput 95.2 Gbps 95.2 Gbps 112 Gbps Predominant Port Type 1 GbE Gigabit Copper 1 GbE Gigabit Copper 1/2.5/5GBaseT Port Count 24 24 24 Uplink Speed/Media 4 Combo 10/100/1000BASE-T or 100/1000 Mbps SFP Ports Dual Personality 10/100/1000 BASE-T PoE+ or 100/1000 Mbps SFP Ports N/A PoE/PoE+ Ports N/A 24 PoE+ 24 PoE+ PoE Power (Max Possible) N/A 740 Watts 860 Watts Management Managed Functionality Layer 3 Dynamic Dimensions 44.25(w) x 32.43(d) x 4.39(h) cm

The 4000 Series are ExtremeCloud IQ managed* Layer 2 switches that streamline network management while providing the power and flexibility of a standard business access switch. As a fully cloud-managed solution, the 4000 Series is suitable for businesses looking for easy-to-manage, cost-effective Ethernet connectivity for their campus, branch, or remote sites..

4000 Series cloud management combines instant actions along with centralized visibility that simplify switch deployment, provisioning, and troubleshooting. Machine learning tools help quickly isolate issues, continuous cloud-delivery ensures latest management feature updates, and zero-touch provisioning allows rapid deployment across sites.

With 90W PoE, multi-gigabit access, stacking and policy services, the 4000 Series is a switch platform capable of addressing the evolving connectivity requirements of today’s and tomorrow’s wired networks.

The 4000 Series consists of 4120 and 4220 model families: 4120 Family The 4120 family includes a 24-port and a 48-port model, with multi-gigabit (1/2.5Gb) and 90W PoE support across all access ports, and high-speed 4 x 10/25Gb uplink plus 2 x 100Gb uplink/stack ports, making it ideal as a wired concentrator for high-density Wi-Fi/IoT environments.

4220 Family The 4220 family includes 8, 12, 24, and 48-port models with gigabit and multi-gigabit (1/2.5/5Gb) access ports, up to 90W PoE, and 4 x SFP+ uplink/stack ports and is a highly flexible enterprise Layer 2 wired access solution.

*The 4000 Series is solely managed by ExtremeCloud IQ and/or ExtremeCloud IQ Site Engine and each switch requires an ExtremeCloud IQ Pilot SaaS Subscription.

Highlights Cloud-managed switching* that simplifies deployment, operation, and management
Automate and streamline switch provisioning and day-to-day operations with cloud-based instant actions
Mobile app to easily onboard, provision, and troubleshoot your switches
Automated, maintenance-free feature and security updates delivered via the cloud
ExtremeCloud IQ and/or ExtremeCloud IQ Site Engine for powerful and secure public cloud or on-premises management
Switch Features 12-port, 24-port, and 48-port models with Gigabit and multi-Gigabit Ethernet access port options
4 x 1/10Gb uplink/stacking ports on all 4220 models
4 x 1/10/25Gb uplink ports plus 2 x 100Gb uplink/stacking ports on 4120 models
30W, 60W, 90W PoE options for powered connection of edge devices
8-port 1/10Gb SFP+ fiber model (4220)
Silent operation up to 35°C on 12-port PoE, multi-gigabit and non-PoE models (4220)
Non-blocking, wire-speed design
360° Views Cloud-based 360° network topology and switch views enable drill down to the 4000 Series switch, port and connected clients for quick status, including historical trends. Aggregated 4000 Switch Health scores further offer a way to easily monitor an individual 4000 Series switch or all 4000 Series switches in the network, to quickly isolate and troubleshoot issues. Furthermore, unified views of the entire Extreme wired/wireless infrastructure are also available within ExtremeCloud IQ.

4000 Series Cloud Management The 4000 Series has been designed for easy-to-use cloud management that simplifies deployment, provisioning and troubleshooting. 4000 Series switches can be managed either by ExtremeCloud IQ or ExtremeCloud IQ Site Engine for comprehensive, unified management with a consolidated view of users, devices, and applications across wired and wireless networks. As a wholly cloud-managed solution, 4000 Series switches avoid the need for complex on-switch provisioning via direct console interface, making it easier for users to set up and manage their entire 4000 Series wired network.

Continuous Cloud Feature Delivery The 4000 Series benefits from continuous feature delivery with each new ExtremeCloud IQ update. It’s an automated way to get maintenance-free cloud-feature and security updates delivered to every 4000 Series switch in the network. And if there is a need to update 4000 Series firmware, this can also be centrally done from the cloud.

ExtremeCloud IQ for the 4000 Series ExtremeCloud IQ provides a native cloud management option for the 4000 Series. With a rich set of automated onboarding, provisioning and visibility features, ExtremeCloud IQ eases the day-to-day task of managing the 4000 Series through the following unique cloud-native features.

ExtremeCloud IQ Site Engine for the 4000 Series 4000 Series switches can also be managed from ExtremeCloud IQ Site Engine as an on-premises cloud management option. ExtremeCloud IQ Site Engine supports complete end-to-end management and monitoring of wired, wireless and 3rd-party devices, with in-depth visibility and control of users, devices and applications. 4000 Series management features available using ExtremeCloud IQ Site Engine include zero-touch provisioning, device configuration, alarms and events, scripts and workflows, as well as inventory management including backup and restore functions. Also available are ExtremeAnalytics for 4000 Series telemetry reporting and ExtremeControl for OnePolicy configuration/support.

Fabric Attach Services Fabric Attach services provide zero-touch edge provisioning and allow the 4000 Series to take advantage of the virtualized services and inherent security capabilities of the Extreme Fabric infrastructure.

Flexible PoE The 4000 Series offers models that include standards-based IEEE 802.3at 30W on 1 gigabit access ports and IEEE 802.3bt 30/60/90W on multi-gigabit ports. This includes 90W PoE support across all 24 or 48 ports of the 4120 hardware. PoE eliminates the need for additional electrical cabling and circuits otherwise needed to power edge devices, such as IP phones or wireless APs.

High-Performance Stacking 4120 models support 200Gb stacking via two built-in QSFP28 ports. Up to eight systems can be stacked using qualified direct-attach cables and optical transceivers.

4220 models support 40Gb stacking via two built-in SFP+ uplink ports. Up to eight systems can be stacked using qualified 10Gb direct attach-cables and optical transceivers.

Note: Cross-stacking between 4120 and 4220 models is not supported.

Instant Onboarding 4000 Series onboarding to the cloud is a hands-off operation using zero-touch provisioning. Simply unpack the 4000 Series switch, connect it to the network, and it automatically finds its connection to the cloud, ready to be provisioned. The ExtremeCloud Companion mobile app makes onboarding even easier with on-site cloud set-up and switch troubleshooting capabilities.

Instant Port Instant Port automates adds, moves or changes across 4000 Series switch ports, eliminating the need for manual port configuration. The 4000 Series automatically detects the connected device type and applies the correct port parameters. The result is significant time savings when adding or moving devices across the 4000 Series wired network. A simple cloud interface allows Instant Port definitions of customer designated device types which can then be applied across a single switch, a stack, or even all 4000 Series switches in the network.

Instant Secure Port Instant Secure Port leverages ExtremeCloud Universal ZTNA (UZTNA) for authentication and zero-trust policy enforcement across 4000 Series switch ports, while providing the same add, move, and change automation features of Instant Port. It simplifies 4000 Series security by using UZTNA’s cloud-based security capabilities, including RADIUS authentication, unified visibility and reporting, as well as policy enforced locally on 4000 Series ports. In doing so, it delivers a consistent and frictionless security experience for any user or device connecting through the 4000 Series switch. (NOTE: ExtremeCloud UZTNA requires a separate license.)

Instant Stack Instant Stack simplifies cloud-based stack provisioning, enabling the entire switch stack to be set-up through a single push-button operation. Real-world stack information, including each switch model and their stack order, is captured and replicated in the cloud. Once set up, the entire stack is then ready to be cloud-provisioned.

Multi-Gigabit Support The 4120 supports 1/2.5Gb multi-gigabit operation across all its access ports. This includes 24 x 1/2.5Gb ports on the 4120-24MW-4Y and 48 x 1/2.5Gb ports on the 4120-48MW-4Y.

The 4220 includes multi-gigabit PoE models with ports that operate at 1/2.5/5Gb. The 4220-4MW-8P-4X and 4220-4MW-20P-4X models support 4 multi-gigabit ports and the 4220-8MW-40P-4X supports 8 multi-gigabit ports. This enables the connection of APs or other powered devices requiring more than 1 Gigabit of bandwidth.

Quiet (Fan-Off) Operation Quiet (fan-off) mode operation at temperatures up to 35°C is supported on 4220 12-port PoE, non-PoE, and multi-gigabit models. This makes these models ideal for classrooms, hospitality suites, retail sites, or other noise-sensitive environments, especially outside of the wiring closet environment.

*Images are for Illustrative Purposes Only; Image is to Showcase Cloud Capabilities

HPE Aruba Networking JL324A 2930M 24 Smart Rate PoE+ 1-slot Switch is designed for digital workplaces optimized for mobile users. These Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager, Aruba AirWave and cloud-based Aruba Central. Modular stacking, uplinks and power provide scalability and simplicity for enterprise edge, SMB and branch offices. The 2930M delivers performance and value with support for static, RIP and Access OSPF routing, 10GbE and 40GbE uplinks, models with 24 ports of HPE Smart Rate multi-gigabit Ethernet, up to 860W of PoE+, robust QoS, SDN and requires no software licensing. Key Features: Aruba Layer 3 Switch with 10 chassis backplane stacking, static, RIP and access OSPF routing, Tunnel Node, ACLs, SDN, and robust QoS
Advanced security and network management tools like Aruba ClearPass Policy Manager, Aruba AirWave and Aruba Central
Modular 10GbE or 40GbE uplinks and HPE Smart Rate (IEEE 802.3bz), up to 860W PoE+
24 ports of HPE Smart Rate with IEEE 802.3bz
Ready for the software defined network with REST APIs and OpenFlow support
Simple deployment with Zero Touch Provisioning

24 HPE Smart Rate PoE+ 1-slot Switch:
24 Autosensing 1/2.5/5GBaseT ports PoE+


Features:

The Aruba 2930M Switch Series provides performance, security, and ease of use for enterprise edge, SMB, and branch office networks.
The Aruba 2930M Switch Series is designed with a powerful Aruba ProVision ASIC, to enable the mobile campus with low latency, increased packet buffering, and adaptive power consumption.
The Aruba 2930M Switch Series includes security and quality of services (QoS) features to build a network that meets ever-changing corporate policies and compliance's while protecting your data from both inside and outside attacks.
The Aruba 2930M Switch Series supports Aruba ClearPass Policy Manager for unified and consistent policy between wired and wireless users and simplifies implementation and management of guest login, user onboarding, network access, security, QoS, and other network policies.
Option of dual
Power Supplies Stacking Module
Slot Uplink Slot
Additional Ports and Slots

1 Dual Personality (RJ-45 or USB Micro-B) serial console port
1 USB B port for uploading/ downloading files
1 100BASE-T Out of Band Management Port
1 Uplink Slot
1 Stacking Module Slot
2 Power Supply Slots (power supplies not included)


JL319A
2930M 24G
JL320A
2930M 24G PoE+  JL324A
2930M 24 HPE Smart Rate PoE
Ports 20 Autosensing 10/100/1000 ports 20 Autosensing 10/100/1000 ports 24 Autosensing 1/2.5/5GBaseT ports Switching Capacity 128 Gbps 128 Gbps 320 Gbps Switching Capacity (Including Stacking 128 Gbps 228 Gbps 420 Gbps Throughput 95.2 Gbps 95.2 Gbps 112 Gbps Predominant Port Type 1 GbE Gigabit Copper 1 GbE Gigabit Copper 1/2.5/5GBaseT Port Count 24 24 24 Uplink Speed/Media 4 Combo 10/100/1000BASE-T or 100/1000 Mbps SFP Ports Dual Personality 10/100/1000 BASE-T PoE+ or 100/1000 Mbps SFP Ports N/A PoE/PoE+ Ports N/A 24 PoE+ 24 PoE+ PoE Power (Max Possible) N/A 740 Watts 860 Watts Management Managed Functionality Layer 3 Dynamic Dimensions 44.25(w) x 32.43(d) x 4.39(h) cm

The 4000 Series are ExtremeCloud IQ managed* Layer 2 switches that streamline network management while providing the power and flexibility of a standard business access switch. As a fully cloud-managed solution, the 4000 Series is suitable for businesses looking for easy-to-manage, cost-effective Ethernet connectivity for their campus, branch, or remote sites..

4000 Series cloud management combines instant actions along with centralized visibility that simplify switch deployment, provisioning, and troubleshooting. Machine learning tools help quickly isolate issues, continuous cloud-delivery ensures latest management feature updates, and zero-touch provisioning allows rapid deployment across sites.

With 90W PoE, multi-gigabit access, stacking and policy services, the 4000 Series is a switch platform capable of addressing the evolving connectivity requirements of today’s and tomorrow’s wired networks.

The 4000 Series consists of 4120 and 4220 model families: 4120 Family The 4120 family includes a 24-port and a 48-port model, with multi-gigabit (1/2.5Gb) and 90W PoE support across all access ports, and high-speed 4 x 10/25Gb uplink plus 2 x 100Gb uplink/stack ports, making it ideal as a wired concentrator for high-density Wi-Fi/IoT environments.

4220 Family The 4220 family includes 8, 12, 24, and 48-port models with gigabit and multi-gigabit (1/2.5/5Gb) access ports, up to 90W PoE, and 4 x SFP+ uplink/stack ports and is a highly flexible enterprise Layer 2 wired access solution.

*The 4000 Series is solely managed by ExtremeCloud IQ and/or ExtremeCloud IQ Site Engine and each switch requires an ExtremeCloud IQ Pilot SaaS Subscription.

Highlights Cloud-managed switching* that simplifies deployment, operation, and management
Automate and streamline switch provisioning and day-to-day operations with cloud-based instant actions
Mobile app to easily onboard, provision, and troubleshoot your switches
Automated, maintenance-free feature and security updates delivered via the cloud
ExtremeCloud IQ and/or ExtremeCloud IQ Site Engine for powerful and secure public cloud or on-premises management
Switch Features 12-port, 24-port, and 48-port models with Gigabit and multi-Gigabit Ethernet access port options
4 x 1/10Gb uplink/stacking ports on all 4220 models
4 x 1/10/25Gb uplink ports plus 2 x 100Gb uplink/stacking ports on 4120 models
30W, 60W, 90W PoE options for powered connection of edge devices
8-port 1/10Gb SFP+ fiber model (4220)
Silent operation up to 35°C on 12-port PoE, multi-gigabit and non-PoE models (4220)
Non-blocking, wire-speed design
360° Views Cloud-based 360° network topology and switch views enable drill down to the 4000 Series switch, port and connected clients for quick status, including historical trends. Aggregated 4000 Switch Health scores further offer a way to easily monitor an individual 4000 Series switch or all 4000 Series switches in the network, to quickly isolate and troubleshoot issues. Furthermore, unified views of the entire Extreme wired/wireless infrastructure are also available within ExtremeCloud IQ.

4000 Series Cloud Management The 4000 Series has been designed for easy-to-use cloud management that simplifies deployment, provisioning and troubleshooting. 4000 Series switches can be managed either by ExtremeCloud IQ or ExtremeCloud IQ Site Engine for comprehensive, unified management with a consolidated view of users, devices, and applications across wired and wireless networks. As a wholly cloud-managed solution, 4000 Series switches avoid the need for complex on-switch provisioning via direct console interface, making it easier for users to set up and manage their entire 4000 Series wired network.

Continuous Cloud Feature Delivery The 4000 Series benefits from continuous feature delivery with each new ExtremeCloud IQ update. It’s an automated way to get maintenance-free cloud-feature and security updates delivered to every 4000 Series switch in the network. And if there is a need to update 4000 Series firmware, this can also be centrally done from the cloud.

ExtremeCloud IQ for the 4000 Series ExtremeCloud IQ provides a native cloud management option for the 4000 Series. With a rich set of automated onboarding, provisioning and visibility features, ExtremeCloud IQ eases the day-to-day task of managing the 4000 Series through the following unique cloud-native features.

ExtremeCloud IQ Site Engine for the 4000 Series 4000 Series switches can also be managed from ExtremeCloud IQ Site Engine as an on-premises cloud management option. ExtremeCloud IQ Site Engine supports complete end-to-end management and monitoring of wired, wireless and 3rd-party devices, with in-depth visibility and control of users, devices and applications. 4000 Series management features available using ExtremeCloud IQ Site Engine include zero-touch provisioning, device configuration, alarms and events, scripts and workflows, as well as inventory management including backup and restore functions. Also available are ExtremeAnalytics for 4000 Series telemetry reporting and ExtremeControl for OnePolicy configuration/support.

Fabric Attach Services Fabric Attach services provide zero-touch edge provisioning and allow the 4000 Series to take advantage of the virtualized services and inherent security capabilities of the Extreme Fabric infrastructure.

Flexible PoE The 4000 Series offers models that include standards-based IEEE 802.3at 30W on 1 gigabit access ports and IEEE 802.3bt 30/60/90W on multi-gigabit ports. This includes 90W PoE support across all 24 or 48 ports of the 4120 hardware. PoE eliminates the need for additional electrical cabling and circuits otherwise needed to power edge devices, such as IP phones or wireless APs.

High-Performance Stacking 4120 models support 200Gb stacking via two built-in QSFP28 ports. Up to eight systems can be stacked using qualified direct-attach cables and optical transceivers.

4220 models support 40Gb stacking via two built-in SFP+ uplink ports. Up to eight systems can be stacked using qualified 10Gb direct attach-cables and optical transceivers.

Note: Cross-stacking between 4120 and 4220 models is not supported.

Instant Onboarding 4000 Series onboarding to the cloud is a hands-off operation using zero-touch provisioning. Simply unpack the 4000 Series switch, connect it to the network, and it automatically finds its connection to the cloud, ready to be provisioned. The ExtremeCloud Companion mobile app makes onboarding even easier with on-site cloud set-up and switch troubleshooting capabilities.

Instant Port Instant Port automates adds, moves or changes across 4000 Series switch ports, eliminating the need for manual port configuration. The 4000 Series automatically detects the connected device type and applies the correct port parameters. The result is significant time savings when adding or moving devices across the 4000 Series wired network. A simple cloud interface allows Instant Port definitions of customer designated device types which can then be applied across a single switch, a stack, or even all 4000 Series switches in the network.

Instant Secure Port Instant Secure Port leverages ExtremeCloud Universal ZTNA (UZTNA) for authentication and zero-trust policy enforcement across 4000 Series switch ports, while providing the same add, move, and change automation features of Instant Port. It simplifies 4000 Series security by using UZTNA’s cloud-based security capabilities, including RADIUS authentication, unified visibility and reporting, as well as policy enforced locally on 4000 Series ports. In doing so, it delivers a consistent and frictionless security experience for any user or device connecting through the 4000 Series switch. (NOTE: ExtremeCloud UZTNA requires a separate license.)

Instant Stack Instant Stack simplifies cloud-based stack provisioning, enabling the entire switch stack to be set-up through a single push-button operation. Real-world stack information, including each switch model and their stack order, is captured and replicated in the cloud. Once set up, the entire stack is then ready to be cloud-provisioned.

Multi-Gigabit Support The 4120 supports 1/2.5Gb multi-gigabit operation across all its access ports. This includes 24 x 1/2.5Gb ports on the 4120-24MW-4Y and 48 x 1/2.5Gb ports on the 4120-48MW-4Y.

The 4220 includes multi-gigabit PoE models with ports that operate at 1/2.5/5Gb. The 4220-4MW-8P-4X and 4220-4MW-20P-4X models support 4 multi-gigabit ports and the 4220-8MW-40P-4X supports 8 multi-gigabit ports. This enables the connection of APs or other powered devices requiring more than 1 Gigabit of bandwidth.

Quiet (Fan-Off) Operation Quiet (fan-off) mode operation at temperatures up to 35°C is supported on 4220 12-port PoE, non-PoE, and multi-gigabit models. This makes these models ideal for classrooms, hospitality suites, retail sites, or other noise-sensitive environments, especially outside of the wiring closet environment.

*Images are for Illustrative Purposes Only; Image is to Showcase Cloud Capabilities

HPE Aruba Networking JL322A 2930M 48G PoE+ 1-slot Switch: High-Performance and Scalable NetworkingThe HPE Aruba Networking JL322A 2930M 48G PoE+ 1-slot Switch is a powerful and versatile network switch designed to meet the demands of modern enterprise environments. With its advanced features and high power output, this switch ensures reliable and efficient network performance.

Key Features:Device Type: Managed L3 switch with 48 ports, stackable for scalability.
Ports:44 x 10/100/1000 (PoE+) ports for versatile connectivity.
4 x combo Gigabit SFP ports for high-speed uplinks.

Power Over Ethernet (PoE+): Provides up to 1440 W of power, ideal for powering access points, IP phones, and other PoE-enabled devices.
Enclosure: Rack-mountable design for efficient space utilization.
Performance and Capacity:High Performance: Designed to handle bandwidth-intensive applications with ease.
Scalability: Stackable design allows for easy expansion as your network grows.
Advanced Management: Managed switch with Layer 3 capabilities for robust network management.
Technical Specifications:Power Output: 1440 W PoE+ power budget.
Form Factor: Rack-mountable, ensuring efficient use of space in your data center or network closet.
The HPE Aruba 2930M 48G PoE+ 1-slot Switch is an excellent choice for businesses looking to enhance their network infrastructure with a reliable, high-performance, and scalable solution.

30-port Lite Layer 3 Stackable Managed Gigabit PoE Switch

The DGS-3130 Series is a range of Lite Layer 3 Stackable Managed Switches designed to connect end-users in a secure enterprise or metro Ethernet access network. With multicast support and enhanced security, they form the ideal Gigabit access layer solution.

Designed For Secure Enterprise And Metro Ethernet Networks

Feature-Rich Unified Image

with powerful L2 and L3 features

6 Embedded 10G Ports

for super versatile network deployment

Scalable and Highly Available

with physical stacking and fault tolerant topologies

Key Features

16 x 100M/1/2.5GBASE-T PoE+ ports + 8 x 100M/1/2.5/5GBASE-T PoE++ ports
2 x 100M/1/2.5/5/10GBASE-T ports and 4 x 10/25G SFP28 ports provide all the uplink capacity your network needs
PoE budget of 740W allows powering of numerous external devices (Up to 960W with dual powers)
Premium L2 and L3 features effortlessly improve network efficiency and reduce unnecessary data transfer
RIP/RIPngand OSFPv2/v3 dynamically map out your network, aiding data to get to its destination via the fastest route possible
Expand capacity in a flash with physical stacking up to 9 units
Smart Fan self-adjusts accordingly to maintain optimal operating temperatures
Support ERPS, Q-in-Q and 6 KV surge protection
Support 60W PoE compliancewith IEEE 802.3bt
Perpetual PoE and Fast PoE support delivers faster and uninterrupted power to connected devices even when the switch is booting
Enhanced Network Reliability

The DGS-3130 Series targets enterprises and metro Ethernet applications, and customers who require a high level of network security and maximum uptime. Ethernet Ring Protection Switching (ERPS), low-latency ERPS recovery for high-speed metro Ethernet ring resilience, and Loopback Detection for network maintenance provide reliable network access for non-stop service.

Comprehensive Security

The DGS-3130 Series provides users with the latest security features such as Multi-layer and Packet Content Access Control Lists (ACL), Storm Control, and IP-MAC-Port Binding (IMPB) with DHCP Snooping. In addition, the DGS-3130 Series supports authentication mechanisms such as 802.1X, Web-based Access Control (WAC), and MAC-based Access Control (MAC) for strict access control and easy deployment.

Scalable Flexibility

The DGS-3130 Series allows multiple switches to be combined via two 10G RJ-45 and four 10G SFP+ ports to form a single physical or virtual stack to meet the needs of growing enterprises. This increases redundancy over multiple physical units and simplifies management by allowing all members in the stack to be managed using a single IP address.

Versatile Traffic Management

The DGS-3130 Series implements a rich set of multi-layer QoS/CoS features to ensure that critical network services such as VoIP, video conferences, IPTV, and IP surveillance are always given high priority. This optimizes network data, and video and voice transmissions to ensure that sensitive data is always transmitted quickly and reliably.

The HPE Aruba Networking 2930M 48G 1-slot Switch (JL321A) is a versatile and high-performance switch designed for enterprise, SMB, and branch access networks. Here are some key features:

Layer 3 Switch: Supports static, RIP, and Access OSPF routing.
High Port Density: 48 Gigabit Ethernet ports.
Modular Uplinks: Supports 10GbE and 40GbE uplinks for flexible connectivity.
Power over Ethernet (PoE): Delivers up to 1440W of PoE, with up to 60W per port.
Stackable: Allows stacking of up to 10 chassis for scalability and redundancy.
Advanced Security: Includes features like ACLs, Dynamic Segmentation, and sFlow.
Management: Supports Zero Touch Provisioning and cloud-based management with HPE Aruba Central.
This switch is designed to provide robust performance, scalability, and ease of management, making it ideal for modern digital workplaces.



JL321A
2930M 48G
JL322A
2930M 48G PoE+
JL323A
2930M 48G PoE+
Ports 44 Autosensing 10/100/1000 ports 44 Autosensing 10/100/1000 ports 36 Autosensing 10/100/1000 ports
8 802.3bz 1/2.5/5 and 10GbaseT copper ports

Switching Capacity 176 Gbps 176 Gbps 320 Gbps Switching Capacity (Including Stacking 276 Gbps 276 Gbps 420 Gbps Throughput 112 Gbps 112 Gbps 112 Gbps Predominant Port Type 1 GbE Gigabit Copper 1 GbE Gigabit Copper 1 GbE Gigabit Copper Port Count 48 48 48 Uplink Speed/Media 4 Combo 10/100/1000BASE-T or 100/1000 Mbps SFP Ports 4 Combo 10/100/1000BASE-T or 100/1000 Mbps SFP Ports 4 Combo 10/100/1000BASE-T or 100/1000 Mbps SFP Ports PoE/PoE+ Ports N/A 48 PoE+ 48 PoE+ PoE Power (Max Possible) N/A 1440 Watts 1440 Watts Management Managed Functionality Layer 3 Dynamic Dimensions 44.25(w) x 32.43(d) x 4.39(h) cm

The 4000 Series are ExtremeCloud IQ managed* Layer 2 switches that streamline network management while providing the power and flexibility of a standard business access switch. As a fully cloud-managed solution, the 4000 Series is suitable for businesses looking for easy-to-manage, cost-effective Ethernet connectivity for their campus, branch, or remote sites..

4000 Series cloud management combines instant actions along with centralized visibility that simplify switch deployment, provisioning, and troubleshooting. Machine learning tools help quickly isolate issues, continuous cloud-delivery ensures latest management feature updates, and zero-touch provisioning allows rapid deployment across sites.

With 90W PoE, multi-gigabit access, stacking and policy services, the 4000 Series is a switch platform capable of addressing the evolving connectivity requirements of today’s and tomorrow’s wired networks.

The 4000 Series consists of 4120 and 4220 model families: 4120 Family The 4120 family includes a 24-port and a 48-port model, with multi-gigabit (1/2.5Gb) and 90W PoE support across all access ports, and high-speed 4 x 10/25Gb uplink plus 2 x 100Gb uplink/stack ports, making it ideal as a wired concentrator for high-density Wi-Fi/IoT environments.

4220 Family The 4220 family includes 8, 12, 24, and 48-port models with gigabit and multi-gigabit (1/2.5/5Gb) access ports, up to 90W PoE, and 4 x SFP+ uplink/stack ports and is a highly flexible enterprise Layer 2 wired access solution.

*The 4000 Series is solely managed by ExtremeCloud IQ and/or ExtremeCloud IQ Site Engine and each switch requires an ExtremeCloud IQ Pilot SaaS Subscription.

Highlights Cloud-managed switching* that simplifies deployment, operation, and management
Automate and streamline switch provisioning and day-to-day operations with cloud-based instant actions
Mobile app to easily onboard, provision, and troubleshoot your switches
Automated, maintenance-free feature and security updates delivered via the cloud
ExtremeCloud IQ and/or ExtremeCloud IQ Site Engine for powerful and secure public cloud or on-premises management
Switch Features 12-port, 24-port, and 48-port models with Gigabit and multi-Gigabit Ethernet access port options
4 x 1/10Gb uplink/stacking ports on all 4220 models
4 x 1/10/25Gb uplink ports plus 2 x 100Gb uplink/stacking ports on 4120 models
30W, 60W, 90W PoE options for powered connection of edge devices
8-port 1/10Gb SFP+ fiber model (4220)
Silent operation up to 35°C on 12-port PoE, multi-gigabit and non-PoE models (4220)
Non-blocking, wire-speed design
360° Views Cloud-based 360° network topology and switch views enable drill down to the 4000 Series switch, port and connected clients for quick status, including historical trends. Aggregated 4000 Switch Health scores further offer a way to easily monitor an individual 4000 Series switch or all 4000 Series switches in the network, to quickly isolate and troubleshoot issues. Furthermore, unified views of the entire Extreme wired/wireless infrastructure are also available within ExtremeCloud IQ.

4000 Series Cloud Management The 4000 Series has been designed for easy-to-use cloud management that simplifies deployment, provisioning and troubleshooting. 4000 Series switches can be managed either by ExtremeCloud IQ or ExtremeCloud IQ Site Engine for comprehensive, unified management with a consolidated view of users, devices, and applications across wired and wireless networks. As a wholly cloud-managed solution, 4000 Series switches avoid the need for complex on-switch provisioning via direct console interface, making it easier for users to set up and manage their entire 4000 Series wired network.

Continuous Cloud Feature Delivery The 4000 Series benefits from continuous feature delivery with each new ExtremeCloud IQ update. It’s an automated way to get maintenance-free cloud-feature and security updates delivered to every 4000 Series switch in the network. And if there is a need to update 4000 Series firmware, this can also be centrally done from the cloud.

ExtremeCloud IQ for the 4000 Series ExtremeCloud IQ provides a native cloud management option for the 4000 Series. With a rich set of automated onboarding, provisioning and visibility features, ExtremeCloud IQ eases the day-to-day task of managing the 4000 Series through the following unique cloud-native features.

ExtremeCloud IQ Site Engine for the 4000 Series 4000 Series switches can also be managed from ExtremeCloud IQ Site Engine as an on-premises cloud management option. ExtremeCloud IQ Site Engine supports complete end-to-end management and monitoring of wired, wireless and 3rd-party devices, with in-depth visibility and control of users, devices and applications. 4000 Series management features available using ExtremeCloud IQ Site Engine include zero-touch provisioning, device configuration, alarms and events, scripts and workflows, as well as inventory management including backup and restore functions. Also available are ExtremeAnalytics for 4000 Series telemetry reporting and ExtremeControl for OnePolicy configuration/support.

Fabric Attach Services Fabric Attach services provide zero-touch edge provisioning and allow the 4000 Series to take advantage of the virtualized services and inherent security capabilities of the Extreme Fabric infrastructure.

Flexible PoE The 4000 Series offers models that include standards-based IEEE 802.3at 30W on 1 gigabit access ports and IEEE 802.3bt 30/60/90W on multi-gigabit ports. This includes 90W PoE support across all 24 or 48 ports of the 4120 hardware. PoE eliminates the need for additional electrical cabling and circuits otherwise needed to power edge devices, such as IP phones or wireless APs.

High-Performance Stacking 4120 models support 200Gb stacking via two built-in QSFP28 ports. Up to eight systems can be stacked using qualified direct-attach cables and optical transceivers.

4220 models support 40Gb stacking via two built-in SFP+ uplink ports. Up to eight systems can be stacked using qualified 10Gb direct attach-cables and optical transceivers.

Note: Cross-stacking between 4120 and 4220 models is not supported.

Instant Onboarding 4000 Series onboarding to the cloud is a hands-off operation using zero-touch provisioning. Simply unpack the 4000 Series switch, connect it to the network, and it automatically finds its connection to the cloud, ready to be provisioned. The ExtremeCloud Companion mobile app makes onboarding even easier with on-site cloud set-up and switch troubleshooting capabilities.

Instant Port Instant Port automates adds, moves or changes across 4000 Series switch ports, eliminating the need for manual port configuration. The 4000 Series automatically detects the connected device type and applies the correct port parameters. The result is significant time savings when adding or moving devices across the 4000 Series wired network. A simple cloud interface allows Instant Port definitions of customer designated device types which can then be applied across a single switch, a stack, or even all 4000 Series switches in the network.

Instant Secure Port Instant Secure Port leverages ExtremeCloud Universal ZTNA (UZTNA) for authentication and zero-trust policy enforcement across 4000 Series switch ports, while providing the same add, move, and change automation features of Instant Port. It simplifies 4000 Series security by using UZTNA’s cloud-based security capabilities, including RADIUS authentication, unified visibility and reporting, as well as policy enforced locally on 4000 Series ports. In doing so, it delivers a consistent and frictionless security experience for any user or device connecting through the 4000 Series switch. (NOTE: ExtremeCloud UZTNA requires a separate license.)

Instant Stack Instant Stack simplifies cloud-based stack provisioning, enabling the entire switch stack to be set-up through a single push-button operation. Real-world stack information, including each switch model and their stack order, is captured and replicated in the cloud. Once set up, the entire stack is then ready to be cloud-provisioned.

Multi-Gigabit Support The 4120 supports 1/2.5Gb multi-gigabit operation across all its access ports. This includes 24 x 1/2.5Gb ports on the 4120-24MW-4Y and 48 x 1/2.5Gb ports on the 4120-48MW-4Y.

The 4220 includes multi-gigabit PoE models with ports that operate at 1/2.5/5Gb. The 4220-4MW-8P-4X and 4220-4MW-20P-4X models support 4 multi-gigabit ports and the 4220-8MW-40P-4X supports 8 multi-gigabit ports. This enables the connection of APs or other powered devices requiring more than 1 Gigabit of bandwidth.

Quiet (Fan-Off) Operation Quiet (fan-off) mode operation at temperatures up to 35°C is supported on 4220 12-port PoE, non-PoE, and multi-gigabit models. This makes these models ideal for classrooms, hospitality suites, retail sites, or other noise-sensitive environments, especially outside of the wiring closet environment.

*Images are for Illustrative Purposes Only; Image is to Showcase Cloud Capabilities

30-port Lite Layer 3 Stackable Managed Gigabit Switch

The DGS-3130 Series is a range of Lite Layer 3 Stackable Managed Switches designed to connect end-users in a secure enterprise or metro Ethernet access network. With multicast support and enhanced security, they form the ideal Gigabit access layer solution.

Designed For Secure Enterprise And Metro Ethernet Networks

Feature-Rich Unified Image

with powerful L2 and L3 features

6 Embedded 10G Ports

for super versatile network deployment

Scalable and Highly Available

with physical stacking and fault tolerant topologies

Key Features

24 x 100M/1/2.5GBASE-T ports
2 x 100M/1/2.5/5/10GBASE-T ports and 4 x 10/25G SFP28 ports provide all the uplink capacity your network needs
Premium L2 and L3 features effortlessly improve network efficiency and reduce unnecessary data transfer
RIP/RIPngand OSFPv2/v3 dynamically map out your network, aiding data to get to its destination via the fastest route possible
Expand capacity in a flash with physical stacking up to 9 units
Smart Fan self-adjusts accordingly to maintain optimal operating temperatures
Support ERPS, Q-in-Q and 6 KV surge protection
Support 60W PoE compliancewith IEEE 802.3bt
Enhanced Network Reliability

The DGS-3130 Series targets enterprises and metro Ethernet applications, and customers who require a high level of network security and maximum uptime. Ethernet Ring Protection Switching (ERPS), low-latency ERPS recovery for high-speed metro Ethernet ring resilience, and Loopback Detection for network maintenance provide reliable network access for non-stop service.

Comprehensive Security

The DGS-3130 Series provides users with the latest security features such as Multi-layer and Packet Content Access Control Lists (ACL), Storm Control, and IP-MAC-Port Binding (IMPB) with DHCP Snooping. In addition, the DGS-3130 Series supports authentication mechanisms such as 802.1X, Web-based Access Control (WAC), and MAC-based Access Control (MAC) for strict access control and easy deployment.

Scalable Flexibility

The DGS-3130 Series allows multiple switches to be combined via two 10G RJ-45 and four 10G SFP+ ports to form a single physical or virtual stack to meet the needs of growing enterprises. This increases redundancy over multiple physical units and simplifies management by allowing all members in the stack to be managed using a single IP address.

Versatile Traffic Management

The DGS-3130 Series implements a rich set of multi-layer QoS/CoS features to ensure that critical network services such as VoIP, video conferences, IPTV, and IP surveillance are always given high priority. This optimizes network data, and video and voice transmissions to ensure that sensitive data is always transmitted quickly and reliably.

The HPE Aruba Networking JL323A 2930M 40G 8 HPE Smart Rate PoE+ 1-slot Switch is designed to provide high-performance and flexible networking capabilities for modern enterprise environments. This switch is equipped with advanced features to support a wide range of applications and devices.

Key Features:36 Autosensing Ports: 10/100/1000 PoE+ ports for versatile device connectivity.
4 Combo Ports: 10/100/1000BASE-T PoE+ or 100/1000Mbps SFP ports for flexible uplink options.
8 HPE Smart Rate Ports: 802.3bz 100M, 1/2.5/5GBaseT, and 10GbaseT copper PoE+ ports for high-speed connections.
Dual Personality Serial Console Port: RJ-45 or USB Micro-B for easy management.
USB A Port: For uploading and downloading files.
Out of Band Management Port: 100BASE-T for dedicated management access.
Uplink Slot: For additional connectivity options.
Stacking Module Slot: Allows for easy expansion and scalability.
Power Supply Slots: Two slots for power supplies (not included) to ensure redundancy and reliability.
Warranty: Limited lifetime warranty for peace of mind.
The HPE Aruba 2930M 40G 8 HPE Smart Rate PoE+ 1-slot Switch is an ideal choice for businesses looking to enhance their network infrastructure with a reliable, high-performance, and scalable solution. Its advanced features and flexible connectivity options make it suitable for a wide range of applications and environments.

The 4000 Series are ExtremeCloud IQ managed* Layer 2 switches that streamline network management while providing the power and flexibility of a standard business access switch. As a fully cloud-managed solution, the 4000 Series is suitable for businesses looking for easy-to-manage, cost-effective Ethernet connectivity for their campus, branch, or remote sites..

4000 Series cloud management combines instant actions along with centralized visibility that simplify switch deployment, provisioning, and troubleshooting. Machine learning tools help quickly isolate issues, continuous cloud-delivery ensures latest management feature updates, and zero-touch provisioning allows rapid deployment across sites.

With 90W PoE, multi-gigabit access, stacking and policy services, the 4000 Series is a switch platform capable of addressing the evolving connectivity requirements of today’s and tomorrow’s wired networks.

The 4000 Series consists of 4120 and 4220 model families: 4120 Family The 4120 family includes a 24-port and a 48-port model, with multi-gigabit (1/2.5Gb) and 90W PoE support across all access ports, and high-speed 4 x 10/25Gb uplink plus 2 x 100Gb uplink/stack ports, making it ideal as a wired concentrator for high-density Wi-Fi/IoT environments.

4220 Family The 4220 family includes 8, 12, 24, and 48-port models with gigabit and multi-gigabit (1/2.5/5Gb) access ports, up to 90W PoE, and 4 x SFP+ uplink/stack ports and is a highly flexible enterprise Layer 2 wired access solution.

*The 4000 Series is solely managed by ExtremeCloud IQ and/or ExtremeCloud IQ Site Engine and each switch requires an ExtremeCloud IQ Pilot SaaS Subscription.

Highlights Cloud-managed switching* that simplifies deployment, operation, and management
Automate and streamline switch provisioning and day-to-day operations with cloud-based instant actions
Mobile app to easily onboard, provision, and troubleshoot your switches
Automated, maintenance-free feature and security updates delivered via the cloud
ExtremeCloud IQ and/or ExtremeCloud IQ Site Engine for powerful and secure public cloud or on-premises management
Switch Features 12-port, 24-port, and 48-port models with Gigabit and multi-Gigabit Ethernet access port options
4 x 1/10Gb uplink/stacking ports on all 4220 models
4 x 1/10/25Gb uplink ports plus 2 x 100Gb uplink/stacking ports on 4120 models
30W, 60W, 90W PoE options for powered connection of edge devices
8-port 1/10Gb SFP+ fiber model (4220)
Silent operation up to 35°C on 12-port PoE, multi-gigabit and non-PoE models (4220)
Non-blocking, wire-speed design
360° Views Cloud-based 360° network topology and switch views enable drill down to the 4000 Series switch, port and connected clients for quick status, including historical trends. Aggregated 4000 Switch Health scores further offer a way to easily monitor an individual 4000 Series switch or all 4000 Series switches in the network, to quickly isolate and troubleshoot issues. Furthermore, unified views of the entire Extreme wired/wireless infrastructure are also available within ExtremeCloud IQ.

4000 Series Cloud Management The 4000 Series has been designed for easy-to-use cloud management that simplifies deployment, provisioning and troubleshooting. 4000 Series switches can be managed either by ExtremeCloud IQ or ExtremeCloud IQ Site Engine for comprehensive, unified management with a consolidated view of users, devices, and applications across wired and wireless networks. As a wholly cloud-managed solution, 4000 Series switches avoid the need for complex on-switch provisioning via direct console interface, making it easier for users to set up and manage their entire 4000 Series wired network.

Continuous Cloud Feature Delivery The 4000 Series benefits from continuous feature delivery with each new ExtremeCloud IQ update. It’s an automated way to get maintenance-free cloud-feature and security updates delivered to every 4000 Series switch in the network. And if there is a need to update 4000 Series firmware, this can also be centrally done from the cloud.

ExtremeCloud IQ for the 4000 Series ExtremeCloud IQ provides a native cloud management option for the 4000 Series. With a rich set of automated onboarding, provisioning and visibility features, ExtremeCloud IQ eases the day-to-day task of managing the 4000 Series through the following unique cloud-native features.

ExtremeCloud IQ Site Engine for the 4000 Series 4000 Series switches can also be managed from ExtremeCloud IQ Site Engine as an on-premises cloud management option. ExtremeCloud IQ Site Engine supports complete end-to-end management and monitoring of wired, wireless and 3rd-party devices, with in-depth visibility and control of users, devices and applications. 4000 Series management features available using ExtremeCloud IQ Site Engine include zero-touch provisioning, device configuration, alarms and events, scripts and workflows, as well as inventory management including backup and restore functions. Also available are ExtremeAnalytics for 4000 Series telemetry reporting and ExtremeControl for OnePolicy configuration/support.

Fabric Attach Services Fabric Attach services provide zero-touch edge provisioning and allow the 4000 Series to take advantage of the virtualized services and inherent security capabilities of the Extreme Fabric infrastructure.

Flexible PoE The 4000 Series offers models that include standards-based IEEE 802.3at 30W on 1 gigabit access ports and IEEE 802.3bt 30/60/90W on multi-gigabit ports. This includes 90W PoE support across all 24 or 48 ports of the 4120 hardware. PoE eliminates the need for additional electrical cabling and circuits otherwise needed to power edge devices, such as IP phones or wireless APs.

High-Performance Stacking 4120 models support 200Gb stacking via two built-in QSFP28 ports. Up to eight systems can be stacked using qualified direct-attach cables and optical transceivers.

4220 models support 40Gb stacking via two built-in SFP+ uplink ports. Up to eight systems can be stacked using qualified 10Gb direct attach-cables and optical transceivers.

Note: Cross-stacking between 4120 and 4220 models is not supported.

Instant Onboarding 4000 Series onboarding to the cloud is a hands-off operation using zero-touch provisioning. Simply unpack the 4000 Series switch, connect it to the network, and it automatically finds its connection to the cloud, ready to be provisioned. The ExtremeCloud Companion mobile app makes onboarding even easier with on-site cloud set-up and switch troubleshooting capabilities.

Instant Port Instant Port automates adds, moves or changes across 4000 Series switch ports, eliminating the need for manual port configuration. The 4000 Series automatically detects the connected device type and applies the correct port parameters. The result is significant time savings when adding or moving devices across the 4000 Series wired network. A simple cloud interface allows Instant Port definitions of customer designated device types which can then be applied across a single switch, a stack, or even all 4000 Series switches in the network.

Instant Secure Port Instant Secure Port leverages ExtremeCloud Universal ZTNA (UZTNA) for authentication and zero-trust policy enforcement across 4000 Series switch ports, while providing the same add, move, and change automation features of Instant Port. It simplifies 4000 Series security by using UZTNA’s cloud-based security capabilities, including RADIUS authentication, unified visibility and reporting, as well as policy enforced locally on 4000 Series ports. In doing so, it delivers a consistent and frictionless security experience for any user or device connecting through the 4000 Series switch. (NOTE: ExtremeCloud UZTNA requires a separate license.)

Instant Stack Instant Stack simplifies cloud-based stack provisioning, enabling the entire switch stack to be set-up through a single push-button operation. Real-world stack information, including each switch model and their stack order, is captured and replicated in the cloud. Once set up, the entire stack is then ready to be cloud-provisioned.

Multi-Gigabit Support The 4120 supports 1/2.5Gb multi-gigabit operation across all its access ports. This includes 24 x 1/2.5Gb ports on the 4120-24MW-4Y and 48 x 1/2.5Gb ports on the 4120-48MW-4Y.

The 4220 includes multi-gigabit PoE models with ports that operate at 1/2.5/5Gb. The 4220-4MW-8P-4X and 4220-4MW-20P-4X models support 4 multi-gigabit ports and the 4220-8MW-40P-4X supports 8 multi-gigabit ports. This enables the connection of APs or other powered devices requiring more than 1 Gigabit of bandwidth.

Quiet (Fan-Off) Operation Quiet (fan-off) mode operation at temperatures up to 35°C is supported on 4220 12-port PoE, non-PoE, and multi-gigabit models. This makes these models ideal for classrooms, hospitality suites, retail sites, or other noise-sensitive environments, especially outside of the wiring closet environment.

*Images are for Illustrative Purposes Only; Image is to Showcase Cloud Capabilities

The HPE Aruba Networking 2930M R0M67A is a robust 48-port PoE+ Gigabit Ethernet switch designed for high-performance and scalability. Ideal for enterprise campus access networks, this switch supports advanced Layer 3 features, including static, RIP, and Access OSPF routingThe Aruba 2930M Switch Series is designed for digital workplaces optimized for mobile users. These Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager, Aruba AirWave and cloud-based Aruba Central. Modular stacking, uplinks and power provide scalability and simplicity for enterprise edge, SMB and branch offices. The 2930M delivers performance and value with support for static, RIP and Access OSPF routing, 10GbE and 40GbE uplinks, HPE Smart Rate, PoE+, robust QoS, SDN and requires no software licensing.

What's new

Aruba Layer 3 switch series that is easy to deploy and manage with Aruba ClearPass Policy Manager and on-premise with Aruba Airwave. Simplify with Zero Touch Provisioning and cloud-based Aruba Central support. Scale with modular 10 chassis stacking and up to 1440W PoE+. Modular 10GbE and 40GbE uplinks and HPE Smart Rate multi-gigabit support. Optimized for innovative SDN applications with OpenFlow.

Features

High-Performance Layer 3 Access Switches

The Aruba 2930M Switch Series provides performance, security, and ease of use for enterprise edge, SMB, and branch office networks. Optimized for the digital workplace with unified management tools such as Aruba ClearPass Policy Manager, Aruba Airwave and Aruba Central. Provides optimal configuration automatically when connected to Aruba access points for PoE priority, VLAN configuration, and rogue AP containment.

Pay as you grow modular stacking (10 chassis) and modular 10GbE (SFP+) and 40GbE (QSFP+) uplinks. HPE Smart Rate multi-gigabit Ethernet support for high speed APs over existing cabling and upgradeable power supplies allow your network to quickly scale when more PoE+ is needed. Robust Layer 3 feature set includes Access OSPF, static and RIP routing, ACLs, Tunnel Node, sFlow, IPv6 with no software licensing required. Designed with a power ProVision ASIC and support for OpenFlow, the Aruba 2930M is ready to take advantage of SDN applications such as HPE Network Visualizer, Optimizer, and Protector Software products.

Performance and Power at the Edge

The Aruba 2930M Switch Series is designed with a powerful Aruba ProVision ASIC, to enable the mobile campus with SDN optimizations, low latency, increased packet buffering, and adaptive power consumption. Increase performance with selectable queue configurations and associated memory buffering that meets your specific network application requirements. Plug and play with up to 10 chassis stacking allowing automated failover enhances network resiliency and RPS support delivers power redundancy. Supports up to 740W of internal PoE+ power for wireless access points, cameras and phones and can easily scale to 1440W.

Security and Quality of Service You Can Rely On

The Aruba 2930M Switch Series includes security and quality of services (QoS) features to build a network that meets ever-changing corporate policies and compliances while protecting your data from both inside and outside attacks. Flexible authentication options include standards based security protocols such as 802.1X, MAC and Web Authentication, to enhance security and policy-driven application authentication. Powerful multilevel-access security controls include source-port filtering, RADIUS/TACACS+, SSL, port security, and MAC address lockout. Tunneled Node to transport network traffic on a per-port basis to the Aruba controller delivering authentication and network policies applied and enforced at the controller.

Simplify with Integrated Wired/Wireless Management

The Aruba 2930M Switch Series supports Aruba ClearPass Policy Manager for unified and consistent policy between wired and wireless users and simplifies implementation and management of guest login, user onboarding, network access, security, QoS, and other network policies. Aruba Airwave Network Management software provides an on-premise network management platform for wired and wireless network devices. Cloud-based management with Zero Touch Provisioning supported by Aruba Central. RMON and sFlow provide advanced monitoring and reporting capabilities for statistics, history, alarms and events. Out-of-band Ethernet management port keeps management traffic segmented from your network data traffic.

Specifications

Switch type: Managed
Switch layer: L3
Processor model: ARM Cortex-A9
Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity: 36
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Combo SFP ports quantity: 4
Data transmission

Throughput: 112 Mpps
Latency (1 Gbps): 3.1 µs
Latency (10 Gbps): 3.4 µs
Switching capacity: 320 Gbit/s

The HPE Aruba Networking 2930M 24 Port Multi-Gig PoE+ Ethernet Switch is a powerful and versatile solution designed for modern network environments. This Layer 3 managed switch is ideal for enterprise campuses, SMB networks, and branch offices.Key features include:

24 Multi-Gigabit Ethernet ports with PoE+ support, delivering up to 60W per port.
Modular design for flexible configurations and scalability.
Advanced Layer 3 capabilities including static and dynamic routing.
High-speed uplinks with modular 10 GbE and 40 GbE options.
Enhanced security with support for ACLs and robust QoS.
Zero Touch Provisioning and cloud-based management via Aruba Central.
The HPE Aruba 2930M Switch ensures reliable and efficient network performance, making it an excellent choice for creating smart digital workplaces

Features

The HPE Aruba Networking 2930M layer 3 switch series that is easy to deploy and manage with HPE Aruba Networking ClearPass Policy Manager and on-premise with HPE Aruba Networking Airwave.

Simplify with Zero Touch Provisioning and cloud-based HPE Aruba Networking Central support.

Scale with modular 10 chassis stacking and up to 1440W PoE.

Modular 10GbE and 40GbE uplinks and HPE Smart Rate multi-gigabit support.

Models with 24 ports of HPE Smart Rate with IEEE 802.3bz.

High Power PoE models deliver up to 60W of PoE per port.

High-Performance Layer 3 Access Switches

The HPE Aruba Networking 2930M Switch Series provides performance, security, and ease of use for enterprise edge, SMB, and branch office networks.

Optimized for the digital workplace with unified management tools such as HPE Aruba Networking ClearPass Policy Manager, Airwave and Central. Provides optimal configuration automatically when connected to HPE Aruba Networking APs for PoE priority, VLAN configuration, and rogue AP containment.

Pay as you grow modular stacking (10 chassis) and modular 10GbE (SFP+) and 40GbE (QSFP+) uplinks. HPE Smart Rate multi-gigabit Ethernet models support high speed APs over existing cabling and upgradeable power supplies allow your network to quickly scale when more PoE is needed.

Robust Layer 3 feature set includes Access OSPF, static and RIP routing, ACLs, Dynamic Segmentation, sFlow, IPv6 with no software licensing required.

Designed with a power ProVision ASIC, the HPE Aruba Networking 2930M supports multiple programmatic interfaces, including REST APIs and Openflow 1.0 and 1.3, to enable automation of network operations, monitoring, and troubleshooting.

Performance and Power at the Edge

The HPE Aruba Networking 2930M Switch Series is designed with a powerful HPE Aruba Networking ProVision ASIC, to enable the mobile campus with low latency, increased packet buffering, and adaptive power consumption.

Increase performance with selectable queue configurations and associated memory buffering that meets your specific network application requirements.

Plug and play with up to 10 chassis stacking allowing automated failover enhances network resiliency and RPS support delivers power redundancy.

Supports hot swappable and redundant PoE power for wireless access points, cameras and phones and can easily scale to 1440W with choice of power supplies. High power PoE models deliver up to 60W of PoE per port.

Security and Quality of Service You Can Rely On

The HPE Aruba Networking 2930M Switch Series includes security and quality of services (QoS) features to build a network that meets ever-changing corporate policies and compliances while protecting your data from both inside and outside attacks.

Flexible authentication options include standards based security protocols such as 802.1X, MAC and Web Authentication, to enhance security and policy-driven application authentication.

Powerful multilevel-access security controls include source-port filtering, RADIUS/TACACS+, SSL, port security, and MAC address lockout.

Dynamic Segmentation provides user and port-based traffic tunneling to an HPE Aruba Networking Mobility Controller or Branch Gateway so that policies can be applied, advanced services can be extended to users and IoT devices, and traffic can be encrypted to protect the network.

Simplify with Integrated Wired/Wireless Management

The HPE Aruba Networking 2930M Series supports HPE Aruba Networking ClearPass Policy Manager for unified and consistent policy between wired and wireless users and simplifies implementation and management of guest login, user onboarding, network access, security, QoS, and other network policies.

HPE Aruba Networking Airwave Network Management software provides an on-premise network management platform for wired and wireless network devices. Cloud-based management with Zero Touch Provisioning supported by HPE Aruba Networking Central.

Supports both cloud-based HPE Aruba Networking Central and on-premise HPE Aruba Networking AirWave with the same hardware ensuring change of management platform without ripping and replacing switching infrastructure.

RMON and sFlow provide advanced monitoring and reporting capabilities for statistics, history, alarms and events.

Out-of-band Ethernet management port keeps management traffic segmented from your network data traffic.

Specifications

Dual Core ARM Coretex A9 @ 1016 MHz
1 GB DDR3 SDRAM
Packet buffer size: 12.38 MB and 4.5MB Ingress, 7.785 Egress
4 GB eMMC
Ports & interfaces

(24) RJ-45 autosensing 1/2.5/5GBASE-T PoE Class 6 ports
(1) Uplink module slot, (1) stacking module slot
Data transmission

Latency: 1000 Mb Latency: < 3.1 µs
Latency: 10 Gbps Latency: < 3.4 µs
Throughput: Up to 112 Mpps
Switching capacity: 320 Gbps
Differentiator

Powerful and flexible high density 1U PoE access switch packed with 24 HPE Smart Rate PoE ports supporting high power IEEE 802.3bt Class 6 (up to 60W) per port. Ideal for advanced Wi-Fi deployments. This model has 24x 802.3bz 1/2.5/5GBase-T copper PoE Class 6 ports. This model supports up to 1440W of PoE budget based on selected power supplies (max 2), with power supplies ordered separately.

Provides 8 ports 1G/2.5G with 4 PoE+ ports and 4 Ultra60 PoE++ ports making it a perfect switch for WiFi 6 AP connectivity, IP surveillance and more.


Key Features



Multi-Gigabit Ethernet - 8 ports provide up to 2.5 Gbps of dedicated, non-blocking bandwidth each.
PoE Support - 4 Ultra60 PoE++ and 4 PoE+ ports provide a total of 230W of power so you can power and connect your devices with a single wire.
Advanced PoE Controls - Manage PoE prioritization, PoE power limit per port, PoE scheduling and more for simple control over all PoE-powered devices.
Non-Blocking Switching - 40Gbps (10/100/1000 Mbps) line rate fabric ensures congestion-free connectivity to your devices.
Versatile Mounting Options - Install your switch on your desktop or mount it to your wall with the hardware provided in the box
Fanless Design - Silent operation makes this switch perfect for noise-sensitive environments




New and improved Plus switches Along with the already great Plus features, MS108EUP enhances your business networking experience even more with exciting new features: advanced PoE controls with uninterrupted PoE and more, business-friendly GUI, simplified VLAN and QoS set-up, and multi-language support.



Room to Move Auto-adapting 1G/2.5G ports ensure your devices are operating at their peak performance allowing you to realize faster speeds.



230W PoE Convenience With 8 uninterrupted PoE ports, deploy PoE-based VoIP phones, IP cameras, AV-over-IP endpoints and wireless access points simply and securely.



Easy Management Setup is simple - just plug and play. Configure your network using a user-friendly web GUI.

Whisper quiet with a port-mix ready for anything. Only one cord for both data and power

Key Features



Advanced VLAN support for better network segmentation
L2/L3/L4 access control lists (ACLs) for granular network access control including 802.1x port authentication
Advanced per port PoE controls for remote power management of PoE powered devices including operation scheduling
Advanced QoS (Quality of Service) for traffic prioritization including portbased, 802.1p and L2/L3/L4 DSCPbased
Auto “denial-of-service” (DoS) prevention
IGMP Snooping and Querier for multicast optimizations
Egress Rate limiting and priority queuing for better bandwidth allocation
Port mirroring for network monitoring
Energy Efficient Ethernet (IEEE 802.3az) for maximum power savings
IPv6 management: IPv6 QoS, IPv6 ACL, IPv6 Multicast, and static and dynamic IPv6 address assignment
Cable test to troubleshoot connection issues
Easy-to-use Web browser-based management GUI available in English, German and Japanese
SNMP v1, v2c, v3 and RMON remote monitoring




Whisper Quiet A maximum of 27.3dB (GS716TP) even at full power and 25°C (77°F) ambient.



Room to Move 5 different ports available: 1G, 2.5G, 5G, 10G; SFP+ and Copper.



180W PoE Convenience With 8 PoE ports, Deploy PoE-based VoIP phones, IP cameras, video-over-IP endpoints and Wireless access points simply and securely.

The NETGEAR MS510TXUP 8-Port Smart Managed Rackmount 10 Gigabit PoE++ Switch adds multi-gigabit/10G speed, a high PoE budget for all PoE/PoE+ devices, and Ultra60 PoE++ support for deploying devices with multi-gig capabilities and speed, such as WiFi 6 Access Points or multi-gig/10G NAS. Includes 1-year of Insight Premium or Pro subscription.




Key Features

Advanced VLAN support for better network segmentation
L2/L3/L4 access control lists (ACLs) for granular network access control including 802.1x port authentication
Advanced per port PoE controls for remote power management of PoE powered devices including operation scheduling
Advanced QoS (Quality of Service) for traffic prioritization including portbased, 802.1p and L2/L3/L4 DSCPbased
Auto “denial-of-service” (DoS) prevention
IGMP Snooping and Querier for multicast optimizations
Egress Rate limiting and priority queuing for better bandwidth allocation
Port mirroring for network monitoring
Energy Efficient Ethernet (IEEE 802.3az) for maximum power savings
IPv6 management: IPv6 QoS, IPv6 ACL, IPv6 Multicast, and static and dynamic IPv6 address assignment
Cable test to troubleshoot connection issues
Easy-to-use Web browser-based management GUI available in English, German and Japanese
SNMP v1, v2c, v3 and RMON remote monitoring







NETGEAR IP Camera and WiFi Automation

Simplify the onboarding process of IP cameras and wireless access points to provide better Quality of Service (QoS) and auto-enabling multicast with the Auto-Camera and Auto-WiFi feature

Provides classification for digital camera and wireless access point packets

Automatically placed in a camera and wireless access point VLAN and then be prioritized above other packets





Room to Move

5 different ports available: 1G, 2.5G, 5G, 10G; SFP+ and Copper.





295W PoE Convenience

With 8 uninterrupted PoE ports, deploy PoE-based VoIP phones, IP cameras, AV-over-IP endpoints and wireless access points simply and securely.





Cloud Management

Optional remote access for configuration, management, and monitoring through the NETGEAR Insight Cloud Portals.

Small switch. Multi-Gigabit Ethernet.

Maximise network throughput with 2.5Gbps Multi-Gigabit Ethernet on each port of this compact 5-port switch. Whether it's to connect to your core or create a network between devices, now you can easily start sharing an internet connection, files, music, and video, or for gaming without bottlenecks.

Key Features

x5 2.5Gbps Ethernet ports
25 Gbps switching capacity
IGMP Snooping
QoS & Flow Control
Durable metal housing
Energy efficient, fanless
Plug & play installation
Ideal for Wi-Fi 6

2.5 Gigabit Ethernet

Save time transferring large files and improve sharing and productivity

Effortless multi-Gigabit networking

Easily upgrade or extend your home or small business network

Compact Metal Housing

Sturdy, compact metal housing with fanless design for silent operation

Energy Efficient Design

Automatic power saving features to reduce power usage

Ready for Wi-Fi 6

You can add a Wi-Fi 6 Access Point to your network to any of the 2.5 Gbps ports to maximise throughput and speed. Multi-Gigabit Ethernet eliminates potential bottlenecks with Wi-Fi 6 Access Points, allowing your network to take full advantage of the efficiency and speeds provided by Wi-Fi 6.

Effortless traffic optimisation

With 2.5 Gigabit transfer speeds from every port, you can rapidly transfer files between connected servers and network attached storage (NAS) to computers. The Quality of Service (QoS), and Flow Control features automatically prioritises important data for efficient delivery. And the IGMP Snooping function reduces unwanted multicast traffic so you can enjoy seamless video streaming and IPTV viewing experiences.

Plug-and-play convenience

The DMS-105 is a plug-and-play device that requires no configuration to get started. Plug-and-play makes it easy to instantly create a network without any technical knowledge.

Designed for life, built to last

The DMS-105 has a sturdy and compact metal housing to ensure the product can withstand wider operating temperatures by helping to dissipate heat and reduce stress on internal components.

Energy Saving

The DMS-105 is designed with energy efficiency in mind. The fanless design eliminates a common point of failure and means the switch can be placed virtually anywhere and operate silently. The Link Status detection feature of the switch saves power by automatically powering down ports that are inactive or not connected, and it supports the IEEE 802.3az Energy-Efficient Ethernet standard.

Experience multi-Gigabit Ethernet speeds

The DMS-107 is a multi-Gigabit Ethernet plug-and-play switch that provides ultra-fast connectivity to your network core or network-attached storage (NAS) device. You can easily connect multiple computers within minutes, and start sharing an internet connection, files, music, and video across your small office or home network.

Key Features

x5 Gigabit Ethernet ports
x2 2.5Gbps Ethernet Ports
Durable metal housing
Energy efficient, fanless
QoS support on Gigabit ports
Ideal for Wi-Fi 6

2.5 Gigabit Ethernet

Save time transferring large files and improve sharing and productivity

Effortless multi-Gigabit networking

Easily upgrade or extend your home or small business network

Compact Metal Housing

Sturdy, compact metal housing with fanless design for silent operation

Energy Efficient Design

Automatic power saving features to reduce power usage

Ready for Wi-Fi 6

It comes with multi-Gigabit ports for maximum throughput and performance - ideal for enjoying unrestricted Wi-Fi 6 devices, high-end gaming computers and workstations. The multi-Gigabit ports eliminate potential bottlenecks with Wi-Fi 6 Access Points, allowing your network to take full advantage of the efficiency and speeds provided by Wi-Fi 6.

Effortless traffic optimisation

With 2.5 Gigabit transfer speeds on uplink ports, you can rapidly transfer files between connected servers and network attached storage (NAS) to computers. The switch's 802.1p Quality of Service (QoS) functionality on Gigabit ports automatically organises and prioritises time-sensitive and critical data for efficient delivery, allowing for buffer-free video streaming as well as smooth video and voice calls.

Plug-and-play convenience

The DMS-107 is a plug-and-play device that requires no advanced technical configuration. Plug-and-play makes it easy to instantly create a network connected to the internet.

Designed for life, built to last

The DMS-107 features a fanless design for silent operation, reduced energy consumption, and increased reliability by eliminating a common point of failure. Its sturdy compact metal housing ensures the product can withstand wider operating temperatures by helping to dissipate heat and reduce stress on internal components.

Energy Saving

The compact, metal housing and fanless design mean the switches can be placed virtually anywhere and operate silently. The DMS-107 is designed with energy efficiency in mind. The switches automatically reduce power to ports that are inactive or not connected, and support the IEEE 802.3az Energy-Efficient Ethernet standard.

More ports. Multi-Gigabit Ethernet.

Maximise network throughput with 2.5Gbps Multi-Gigabit Ethernet on each port of this compact 8-port switch. Whether it's to connect to your core or create a network between devices, now you can easily start sharing an internet connection, files, music, and video, or for gaming without bottlenecks.

Key Features

x8 2.5Gbps Ethernet ports
40 Gbps switching capacity
IGMP Snooping
QoS & Flow Control
Durable metal housing
Energy efficient, fanless
Plug & play installation
Ideal for Wi-Fi 6

2.5 Gigabit Ethernet

Save time transferring large files and improve sharing and productivity

Effortless multi-Gigabit networking

Easily upgrade or extend your home or small business network

Compact Metal Housing

Sturdy, compact metal housing with fanless design for silent operation

Energy Efficient Design

Automatic power saving features to reduce power usage

Ready for Wi-Fi 6

You can add a Wi-Fi 6 Access Point to your network to any of the 2.5 Gbps ports to maximise throughput and speed. Multi-Gigabit Ethernet eliminates potential bottlenecks with Wi-Fi 6 Access Points, allowing your network to take full advantage of the efficiency and speeds provided by Wi-Fi 6.

Effortless traffic optimisation

With 2.5 Gigabit transfer speeds from every port, you can rapidly transfer files between connected servers and network attached storage (NAS) to computers. The Quality of Service (QoS), and Flow Control features automatically prioritises important data for efficient delivery. And the IGMP Snooping function reduces unwanted multicast traffic so you can enjoy seamless video streaming and IPTV viewing experiences.

Plug-and-play convenience

The DMS-108 is a plug-and-play device that requires no configuration to get started. Plug-and-play makes it easy to instantly create a network without any technical knowledge.

Designed for life, built to last

The DMS-108 has a sturdy and compact metal housing to ensure the product can withstand wider operating temperatures by helping to dissipate heat and reduce stress on internal components.

Energy Saving

The DMS-108 is designed with energy efficiency in mind. The fanless design eliminates a common point of failure and means the switch can be placed virtually anywhere and operate silently. The Link Status detection feature of the switch saves power by automatically powering down ports that are inactive or not connected, and it supports the IEEE 802.3az Energy-Efficient Ethernet standard.
