5 Port 10-Gigabit Switches

CRS305-1G-4S+IN - Five-port desktop switch with one Gigabit Ethernet port and four SFP+ 10Gbps ports

The CRS305 is a compact yet very powerful switch, featuring four SFP+ ports, for up to 10 Gbit per port. The device has a 1 Gbit copper ethernet port for management access or regular traffic forwarding and two DC jacks for power redundancy.

The device has a “Dual boot” feature that allows you to choose between two operating systems:

RouterOS or SwOS:

If you prefer to have a simplified operating system with only switch specific features, use SwOS
If you would like the ability to use routing and other Layer 3 features in your CRS, use RouterOS
You can select the desired operating system from RouterOS, from SwOS or from the RouterBOOT loader settings.


Amazingly, all these features come with an incredible disruptive price, providing the best price/performance on the market.

The device is a very sleek and compact metallic case without any fans, for silent operation.

The device has an operating system preinstalled and Licenced. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase...


CRS305-1G-4S+IN Specifications:

10/100/1000 Ethernet ports: 1
Architecture: ARM 32bit
CPU: 98DX3236
CPU core count: 1
CPU nominal frequency: 800 MHz
DC jack input Voltage: 12-57 V
Dimensions: 141 x 115 x 28 mm
Ethernet Combo ports: 0
Licence level: 5
Max Power consumption without attachments: 10 W
Max power consumption: 18 W
Number of DC inputs: 3 (DC jack)
Number of SIM slots: 0
Number of USB ports: 0
Operating System: RouterOS / SwitchOS
Tested ambient temperature -40°C to 70°C
PoE in: 802.3af/at
PoE in input Voltage: 12-57 V
SFP ports: None
SFP+ ports: 4
Size of RAM: 512 MB
Storage size: 16 MB
Wireless 1 Number of chains: 0
CPU temperature monitor Yes

6-Port Multi-Gigabit Unmanaged Switch

Turbocharged multi-gig for work or play






Product features: 5 x 2.5 Gbps Ethernet Ports for unrestricted Wi-Fi 6 router or AP connections
1 x 10 Gbps Ethernet port for uplink or NAS server connection
Smart Turbo Mode delivers Quality of Service (QoS) and port-based priority for uninterrupted online gaming and 4K streaming
Power efficiency design for low power consumption
LED conveniently indicates port speed status
Durable matte gray aluminum alloy casing
Fanless operation for enhanced reliability and soundless performance










Why You Want It:









Ultra-Fast 10-Gigabit Connection for Home or Office Applications The DMS-106XT multi-gig switch features a 10-Gigabit port for high-bandwidth network uplink or access to a Network-Attached Storage (NAS) device, it's perfect for the multimedia design workplace or advanced home networking setup.


Designed for Advanced Home or Small Office Networks Fast enough to handle your large multimedia file transfers to and from the storage server with the 10-Gigabit port, and versatile enough to keep your Wi-Fi 6 router and AP communications unrestricted with 5 multi-Gigabit (2.5 Gbps) ports. What's more - the sleek aluminum alloy design and multi-colored LED light bar make the DMS-106XT a great addition to any modern home or workplace.



Ultra-Fast 10-Gigabit Connection for Home or Office Applications The DMS-106XT multi-gig switch features a 10-Gigabit port for high-bandwidth network uplink or access to a Network-Attached Storage (NAS) device, it's perfect for the multimedia design workplace or advanced home networking setup.


























Perfect For:










Turbocharge Your Network for Optimized Performance When you're ready for a turbo-charged network experience, simply activate Turbo Mode to keep your online gaming and 4K streaming running at maximum network speeds. Perfect for uninterrupted online entertainment every time.







Network Copper ethernet cabling technology 10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T Networking standards IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x Flow control support Yes

Ports & interfaces Copper ethernet cabling technology 10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T Basic switching RJ-45 Ethernet ports quantity 5 Basic switching RJ-45 Ethernet ports type 2.5G Ethernet (100/1000/2500) 10G Ethernet (copper) ports quantity 1

Data transmission MAC address table 4000 entries Switching capacity 45 Gbit/s Store-and-forward Yes

Design Product colour Black LED indicators Activity, Link, Power Housing material Aluminium Certification CE, FCC, RCM, BSMI, VCCI, RoHS

Power Power consumption (max) 10.6 W AC input voltage 100 - 240 V Input current 1.5 A DC input voltage 12 V

Operational conditions Storage temperature (T-T) -10 - 70 °C Storage relative humidity (H-H) 5 - 95% Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 10 - 95%

Weight & Dimensions Width 217 mm Depth 163 mm Height 33 mm Weight 608 g Full specification and details can be found in the
