| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | DLDMS-106XT |
| Manufacturer No: | DMS-106XT |
| Delivery: | In Stock: 1-2 Weeks |
 |
6-Port Multi-Gigabit Unmanaged Switch
Turbocharged multi-gig for work or play
The DMS-106XT multi-gig switch features a 10-Gigabit port for high-bandwidth network uplink or access to a Network-Attached Storage (NAS) device, it's perfect for the multimedia design workplace or advanced home networking setup.
Fast enough to handle your large multimedia file transfers to and from the storage server with the 10-Gigabit port, and versatile enough to keep your Wi-Fi 6 router and AP communications unrestricted with 5 multi-Gigabit (2.5 Gbps) ports. What's more - the sleek aluminum alloy design and multi-colored LED light bar make the DMS-106XT a great addition to any modern home or workplace.
The DMS-106XT multi-gig switch features a 10-Gigabit port for high-bandwidth network uplink or access to a Network-Attached Storage (NAS) device, it's perfect for the multimedia design workplace or advanced home networking setup.
When you're ready for a turbo-charged network experience, simply activate Turbo Mode to keep your online gaming and 4K streaming running at maximum network speeds. Perfect for uninterrupted online entertainment every time.
| Network | |
| Copper ethernet cabling technology | 10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T |
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x |
| Flow control support | Yes |
| Ports & interfaces | |
| Copper ethernet cabling technology | 10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| 10G Ethernet (copper) ports quantity | 1 |
| Data transmission | |
| MAC address table | 4000 entries |
| Switching capacity | 45 Gbit/s |
| Store-and-forward | Yes |
| Design | |
| Product colour | Black |
| LED indicators | Activity, Link, Power |
| Housing material | Aluminium |
| Certification | CE, FCC, RCM, BSMI, VCCI, RoHS |
| Power | |
| Power consumption (max) | 10.6 W |
| AC input voltage | 100 - 240 V |
| Input current | 1.5 A |
| DC input voltage | 12 V |
| Operational conditions | |
| Storage temperature (T-T) | -10 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Weight & Dimensions | |
| Width | 217 mm |
| Depth | 163 mm |
| Height | 33 mm |
| Weight | 608 g |
Full specification and details can be found in the PDF file
6-Port Multi-Gigabit Unmanaged Switch
Turbocharged multi-gig for work or play
The DMS-106XT multi-gig switch features a 10-Gigabit port for high-bandwidth network uplink or access to a Network-Attached Storage (NAS) device, it's perfect for the multimedia design workplace or advanced home networking setup.
Fast enough to handle your large multimedia file transfers to and from the storage server with the 10-Gigabit port, and versatile enough to keep your Wi-Fi 6 router and AP communications unrestricted with 5 multi-Gigabit (2.5 Gbps) ports. What's more - the sleek aluminum alloy design and multi-colored LED light bar make the DMS-106XT a great addition to any modern home or workplace.
The DMS-106XT multi-gig switch features a 10-Gigabit port for high-bandwidth network uplink or access to a Network-Attached Storage (NAS) device, it's perfect for the multimedia design workplace or advanced home networking setup.
When you're ready for a turbo-charged network experience, simply activate Turbo Mode to keep your online gaming and 4K streaming running at maximum network speeds. Perfect for uninterrupted online entertainment every time.
| Network | |
| Copper ethernet cabling technology | 10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T |
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x |
| Flow control support | Yes |
| Ports & interfaces | |
| Copper ethernet cabling technology | 10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| 10G Ethernet (copper) ports quantity | 1 |
| Data transmission | |
| MAC address table | 4000 entries |
| Switching capacity | 45 Gbit/s |
| Store-and-forward | Yes |
| Design | |
| Product colour | Black |
| LED indicators | Activity, Link, Power |
| Housing material | Aluminium |
| Certification | CE, FCC, RCM, BSMI, VCCI, RoHS |
| Power | |
| Power consumption (max) | 10.6 W |
| AC input voltage | 100 - 240 V |
| Input current | 1.5 A |
| DC input voltage | 12 V |
| Operational conditions | |
| Storage temperature (T-T) | -10 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Weight & Dimensions | |
| Width | 217 mm |
| Depth | 163 mm |
| Height | 33 mm |
| Weight | 608 g |
Full specification and details can be found in the PDF file
