Axis Conduit and Back Box

AXIS 3/4" Conduit Locknut A

For flexible ceiling installations



• 3/4" nuts

• Sold in packs of four


AXIS 3/4" Conduit Locknut A is a conduit locknut for AXIS T91B53 Telescopic Ceiling Mount to be used with Axis pendant kits.

AXIS ACI Conduit Bracket B

For ½" conduits, M20 pipes, and ACI adapters



• Part of the Axis Conduit Interface (ACI)

• Anti-loss screws included


AXIS ACI Conduit Bracket B is a cable protection attachment bracket compatible with ½? conduits, M20 pipes, and ACI adapters.

AXIS ACI Conduit Adapter 1/2" U-Shape 20 mm

For U-shape cable protection



• U-shaped cable entry

• Sold in packs of five


Mechanical adapter providing a U-shaped 20 mm wide cable entry for use when U-shape cable protection is required.

AXIS ACI Conduit Cover A

Cover for several Axis mounts



• Cover for conduit entrance

• Spare part for several Axis mounts

• Sold in packs of 10


The cover is sold in 10-piece pack, and it is a spare part to cover the conduit entrance in several Axis mounts.

AXIS ACI Conduit Adapter 3/4" U-Shape 30 mm

For U-shape cable protection



• U-shaped cable entry

• Sold in packs of five


Mechanical adapter providing a U-shaped 30 mm wide cable entry for use when U-shape cable protection is required.

For ½" conduits and M20 pipes with UNC thread

Integrated female UNC thread
Part of the Axis Conduit Interface (ACI)
AXIS T94B01P Conduit Back Box has an ½? ACI interface to enable the use of ACI adapters. The back box has an integrated female UNC thread for use of standard camera stands or holders.

Stainless steel adapter used for mounting 3/4" NPS or NPT pipes to AXIS P33XX-VE cameras for cable protection.

AXIS T94F01P Conduit Back Box

For ½" conduits and M20 pipes



• Part of the Axis Conduit Interface (ACI)

• Compatible with selected AXIS M30 and P14 Cameras


AXIS T94F01P Conduit Back Box enables safe cabling through ½" conduits and M20 pipes. It is also compatible with ACI ½" conduit adapters.

AXIS T94G01P Conduit Back Box

Vandal-resistant for ¾" conduits and M25 pips



• Flexible mounting

• Vandal-resistant

• AXIS ACI Conduit Adapter 3/4? U-shape 30mm included

• Aluminum


AXIS T94G01P Conduit Back Box enables safe cabling through ¾" conduits and M25 pipes. It can be mounted directly on a wall, hard ceiling, or junction box. Includes AXIS ACI Conduit Adapter 3/4" U-shape 30mm.

AXIS TP1601 Adapter Plate

For installations with AXIS P14/M42 Series



• Adapter plate for AXIS TP3606/T94S01P

• For aesthetically pleasing installations

• Compatible with AXIS P14/M42 Series


AXIS TP1601 Adapter Plate is mounted on AXIS TP3603 Conduit Back Box when installing products in AXIS P14/M42 Series for a more aesthetically pleasing installation. AXIS TP1601 is also compatible with AXIS T94S01P Conduit Back Box (outdoor-ready).

AXIS TP3601 3/4" Conduit Adapter

For selected AXIS M32 and P32 Cameras



• Part of the Axis Conduit Interface (ACI)

• Anti-loss screws included

• Sold in packs of four


AXIS TP3601 3/4? Conduit Adapter is used for protected cable routing in ¾? conduits and M25 pipes.

AXIS TP3602 1/2" Conduit Adapter

For selected AXIS M32 and P32 Cameras



• Part of the Axis Conduit Interface (ACI)

• Anti-loss screws included

• Sold in packs of four


AXIS TP3602 1/2" Conduit Adapter is used for protected cable routing in ½" conduits and M20 pipes.

AXIS ACI Conduit Adapter 1/2"-3/4" A

Step-up ACI adapter



• Part of the Axis Conduit Interface (ACI)

• Anti-loss screws and spring clip included

• Compatible with selected AXIS P37 and Q35 Cameras


Step-up adapter for attaching ¾" conduits or M25 pipes to Axis products with a ½" conduit Interface.

Aluminum cable cover with stainless steel adapter used for mounting 3/4" NPS or NPT pipes to AXIS P33XX-VE cameras for cable protection.

AXIS TI8603 Conduit Adapter 3/4" NPS

Cable protection for video intercom installations



• Compatible with AXIS I8016-LVE Network Video Intercom

• For use with AXIS TI8602 Wall Mount

• Compatible with ¾" conduits


AXIS TI8603 Conduit Adapter 3/4" NPS is a cable protection attachment bracket for Axis network video intercoms.

AXIS TQ1601-E Conduit Back Box

Aluminum conduit back box for increased mounting possibilities



• Aluminum

• Coating in corrosion resilient material

• Designed to dissipate vibrations

• Conduit entries for easy installation

• Compatible with AXIS ACI Adapters ¾"


AXIS TQ1601-E Conduit Back Box is an aluminum mount with a coating that alleviates corrosion. Its design with long screws and a washer helps dissipate vibrations, and the top/bottom and side conduit entries make installation easier. When used together with AXIS T94Q01A Wall Mount, the Ethernet cable can be routed through or along the wall (from left or right). The side and top/bottom holes are compatible with 3/4" conduits, M25 cable protection products, and with AXIS Conduit Interface (ACI) adapter range (NPS/U-shape). AXIS TQ1601-E can also be used to cover a single gang junction box.

Aluminum Camera cable cover (pack of 4) - for AXIS P3343, P3344, P3346, P3363-VE 12, P3363-VE 6mm, P3364-VE

AXIS TP3603 Conduit Back Box

For flexible indoor installations



• Room for connectivity devices

• Flexible conduit entries

• Adapted for mounting on strut-channels

• Compatible with several Axis products


AXIS TP3603 Conduit Back Box is suitable in large indoor installations to facilitate and shorten installation time, as well as providing space for connectors, termination jacks etc. It has two separate conduit entries (1/2" and 3/4") creating flexibility for the installer. AXIS TP3603 is compatible with a wide range of Axis products.

AXIS ACI Conduit Adapter 1/2"-3/4" NPS

Threaded ACI adapter



• Compatible with Axis ¾" NPS (M25) conduits

• Spring clip included

• Stainless steel


AXIS ACI Conduit Adapter 3/4" NPS is used for attaching ¾" NPS conduits to Axis products with a ¾" conduit interface.

AXIS ACI Conduit Adapter 3/4" NPS

Threaded ACI adapter



• Compatible with Axis ¾" NPS (M25) conduits

• Spring clip included

• Stainless steel


AXIS ACI Conduit Adapter 3/4" NPS is used for attaching ¾" NPS conduits to Axis products with a ¾" conduit interface.

AXIS TQ9601 Conduit Top Box

Vandal-resistant corner mount



• Easy to install

• Space for PoE over coax or other connectivity devices

• Aluminum


AXIS TQ9601 Conduit Top Box is a vandal-resistant corner-mounted top box for safe cabling through ¾" conduits.

Aluminum cable cover with stainless steel adapter used for mounting 3/4" NPS or NPT pipes to AXIS P33XX-VE cameras for cable protection. Four complete units.

AXIS TQ1602-E Conduit Back Box

IP66/IP67 rated outdoor back box with conduit entrance



• IP66/IP67 storage compartment for connectivity devices

• Impact resistant (IK10+) against vandalism attempts

• ¾" / M25 conduit interface from both side and back

• Designed for various Axis bullet cameras


Specifically designed for a several Axis bullet cameras, AXIS TQ1602-E Conduit Back Box is outdoor-ready and impact resistant (IK10+) with an ingress-protected compartment for secure storage of connectivity devices.

AXIS TQ1602-E enables both camera and connectivity device to be safely mounted at the same point, without need for extra cabinet installation (even directly onto junction boxes). The finished installation is specifically designed to be both aesthetically pleasing mounted together with bullet cameras within AXIS Q17/Q19/P14 Camera Series and able to withstand challenging outdoor conditions. It’s carefully designed to store for example an IP-over-COAX adapter to re-use legacy cabling or a network cable coupler to bridge between rigid and flexible network cables.

AXIS T93C Wall-Pole Conduit Back Box

Mounting on walls or poles



• Space for power supply and electrical connection boxes

• Screws and nuts included

• Aluminum


AXIS T93C Wall-Pole Conduit Back Box is used to install AXIS Q1649 Camera with AXIS T93C10 Outdoor Housing on a pole. The back box can also be installed directly on the wall.

Installation with three steel straps (sold separately) is recommended.

AXIS TP3905 ACI Conduit Adapter 1"



• Compatible with Axis 1" NPS (M25) conduits

• Spring clip included

• Plastic, for indoor installations


AXIS TP3905 ACI Conduit Adapter 1" is used for attaching 1" NPS conduits to Axis products with a 1" conduit interface.
