A complete ceiling 360° AI Theta system designed to discreetly provide a panoramic view of large, busy spaces.
Features
A complete ceiling 360° AI Theta system designed to discreetly provide a panoramic view of large, busy spaces.
Kit includes (1) AI Theta Hub, (1) Pro 360 Lens, (1) Standard Flush Mount, and (1) Pro Flush Mount
4K (8MP) resolution with ultra-wide 360° view
Exceptional image quality with superb low-light performance and enhanced dynamic range
Advanced AI: Detect people, read license plates, and more*
Minimal footprint with lens separated from the camera body
Included Pro Flush Mount allows for mounting lens without access to the rear of a ceiling or wall
PoE-powered hub that connects to lens with included cable
Supports optional AI Theta Audio module for two-way audio
Specifications
Mechanical
Material: UVC-AI-Theta-Hub: aluminum alloy, UVC-AI-Theta-ProLens360: aluminum alloy, polycarbonate
Mount Material: UVC-AI-Theta-Hub: aluminum alloy, UVC-AI-Theta-ProLens360 Flush Mount: polycarbonate
Dimensions:
UVC-AI-Theta-Hub: 140 x 70 x 38 mm (5.5 x 2.8 x 1.5”)
UVC-AI-Theta-ProLens360: Ø36.6 x 58.9 mm (Ø1.4 x 2.3”)
UVC-AI-Theta-ProLens360 Flush Mount: Ø54.6 x 60.4 mm (Ø2.2 x 2.4”)
Cable length: 1 m (3.3 ft)
Weight:
UVC-AI-Theta-Hub: 330 g (11.6 oz)
UVC-AI-Theta-Hub Mount: 35 g (1.2 oz)
UVC-AI-Theta-ProLens360: 58 g (2 oz)
UVC-AI-Theta-ProLens360 Flush Mount: 24 g (0.8 oz)
Optic
Sensor: 8MP 1/1.8" CMOS
Lens: Fixed focal length
View Angle: H: 180°, V: 180°, D: 180°
Video and Audio
Video compression: H.264
Resolution: 4MP 2160 x 2160 (1:1)
Max. frame rate: 24 FPS
Image settings: Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay
Microphone: No
Speaker: No
System
Processor: Quad-core Arm® Cortex®-A53 based chip
Networking interface: GbE RJ45 port
Max. power consumption: 12.5W
Power Supply: 5V DC, 0.5A
Power method: PoE
Supported voltage range: 37—57V DC
Output power: 5V DC, 1A per port
Mounting: Wall, ceiling mount
Ambient operating temperature: -20 to 40° C (-4 to 104° F)
Ambient operating humidity: 10 to 90% noncondensing
