Smart UPS On Line provides high density, double conversion online power protection for servers, voice/data networks, medical labs, and light industrial applications.
The Smart UPS On Line is capable of supporting loads from 1 kVA to 10 kVA in a rack/tower convertible chassis. The 6 kVA, 8 kVA, and 10 kVA models feature unity output power factor enabling them to support power hungry blade servers or heavily loaded equipment racks. When business critical systems require runtime in hours, not minutes, Smart UPS On Line can be configured with multiple battery packs to meet aggressive runtime demands.
The included PowerChute Network Shutdown management software provides unattended graceful shutdown of network operating systems. Models 5 kVA to 10 kVA include an integrated network management card for remote management. The entire Smart UPS On Line family helps to provide value to customers with demanding power conditions, including a very wide input voltage window, extremely tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.
Key Features:
2200VA/1980W double-conversion on-line pure sine wave 2U rackmount UPS
Ideal for servers, storage, voice/data networks, medical labs, and light industrial applications
Rack/Tower convertible (rail kit included)
Delivers clean power with zero transfer time for critical or sensitive devices
Add up to 10 external battery packs (SRT72RMBP) for extended runtime
Standard features
Best in class power density: More real power in watts, 0.82 to 0.9 pf on the 1, 1.5, 2.2 and 3 kVA models. 0.85 pf on 5 kVA and Unity on 6 kVA – 10 kVA units.
High efficiency "Green Mode": Achieves 98% efficiency, which helps save utility and cooling costs without compromising performance or reliability.
Graphical LCD display with multicolor backlight: Intuitive interface provides detailed and accurate information with ability to configure locally.
Intelligent battery management: Temperature compensated charging extends life and advanced algorithms recommend replacement date. The UPS can inform the user which batteries need to be replaced and auto detect when additional battery packs are added.
Built in energy meter: Measures energy use and displays UPS efficiency in various modes of operation for easy energy tracking.
Operate without battery: Ability to immediately protect equipment when power returns after a complete discharge of the battery.
Three year warranty on electronics: Additional year of warranty protection for electronics provides peace of mind.
LCD graphics display - Text and mimic diagrams that display modes of operation, system parameters and alarms.
ECO Mode - Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
Battery failure notification - Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Rack/Tower convertible - Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
Additional features
Embedded network management card with environmental monitoring (5 kVA – 10 kVA models): Remote monitoring and control of the UPS and the environment via Ethernet connection while freeing up the SmartSlot so customers can add accessories for additional communication options.
Switched outlet group(s): Ability to control a group of output load receptacles independent from the main UPS.
Enables:
Rebooting hung device without cycling the entire UPS
Sequenced turn on/off
Shedding of noncritical loads based on a variety of parameters (battery time, runtime remaining, and overload)
Scheduled time off to conserve energy
Emergency power off (EPO): Remote UPS shutoff in the event of an emergency. The UPS can accept normally open (NO) or normally closed (NC) contacts.
Communication ports: Serial, USB, Ethernet, and SmartSlot for network accessory cards.
Communication protocols: Modbus Serial, USB PowerSummary, HTTP, SNMP, and Telnet.
1:1, 3:1 input hard-wire options: Product can be wired for 3-PH or 1-PH input (230 V, 8 kVA, and 10 kVA models only).
Dual input: Enables second input source to be connected to UPS bypass (230 V, 8 kVA, and 10 kVA models only).
APC UPS Network Management Card 2
APC UPS network management cards allow for secure monitoring and control of an individual APC UPS via web browser, command line interface or SNMP. Embedded technology provides exceptional reliability with notification features that inform you of problems as they occur.
Main Features
Command line interface - Offers simultaneous remote management access through Telnet and SSH.
Compatible with SmartSlot enabled UPS - Compatible with all SmartSlot UPS
IPv6 Support - Capable of operating on a network using IPv6 protocol.
Standard UPS RFC 1628 MIB Compatible - Make UPS information available to your preferred network, server or enterprise management system by forwarding SNMP traps (events) using RFC 1628 MIB.
Device Encryption - Securely connect via HTTPS/SSL, SSH (up to 2048-bit encryption), SNMPv3.
Multiple language support - Web browser interface available in English, German, Russian, Simplified Chinese & Japanese.
Multiple user access - Supports simultaneous web browser access for up to 8 users and network command line interface access for up to 3 users.
UPS Firmware Update - User friendly mechanism to remotely and seamlessly update UPS firmware via the web browser interface (SMX, SMT and SRT Smart-UPS only).
Smart Battery Management Support - Detailed battery information including battery cartridge parameters provides early-warning fault analysis to simplify management of the entire battery system (SRT Smart-UPS only).
Modbus TCP Support - Supports reporting UPS information to Building Management Systems or other third party management systems via Modbus TCP.
APC Warranties available for this UPS
APC Service Pack Warranty Extension
(New Product Purchases)
APC Service Pack Warranty Extension
(Renewal or High Volume)
FEWBEXTWAR1YR-SP-04 FEWBEXTWAR3YR-SP-04 FEWEXTWAR1YR-SP-04 FEWEXTWAR3YR-SP-04
Protection for your system, peace of mind for you - With the APC Extended Warranty program, you will have peace of mind knowing that in the unlikely event of a failure, your product will be repaired or replaced quickly, minimizing downtime.
Our warranty guarantees free next business day delivery of parts or unit to ensure you get what you need as soon as you need it.
Replacement Battery Options for this UPS
APC Replacement Battery Cartridge - FEAPCRBC141
This APC Replacement Battery Cartridge fits selected APC Smart-UPS and Back-UPS, restoring power back-up capacity for home offices, small businesses and IT departments.
This replacement battery cartridge (RBC) has a lifetime of three to five years, offers safe and reliable support to the UPS, and extends the useful life of your UPS. The APC RBC comes fully assembled and includes easy-to-follow replacement instructions, making hot-swap installation simple.
APC UPS External Battery Pack - FESRT72RMBP
The APC Extended Run Battery Pack is the ideal companion for the APC Back-UPS Pro UPS (uninterruptible power supply).
The battery pack increases the duration of time that you can protect your electronic devices from damage and disconnect due to unexpected blackouts, voltage fluctuations, and other power disruptions.
