APC's SMX1500RMI2UNC is part of the award winning Smart-UPS family which is the most popular UPS in the world for servers, storage and networks. The 1200W 1500VA extended runtime UPS is trusted to protect critical data and equipment from power problems, and supplies clean and reliable network-grade power. In addition to legendary reliability and manageability, Smart-UPS units have extremely high efficiency at low, medium and high load levels, making them ideal for today’s multi-core or virtualized servers that have varying load consumption.
With Pre-installed Network Management Card 2 allowing for secure monitoring and control of an individual UPS via Web browser,
CLI, or
SNMP.
Product Features:1. Alphanumeric LCD (Liquid Crystal Display) - Intuitive interface provides detailed and accurate information with the ability to configure locally.
2. Preinstalled Network Management Card -
Remote monitoring and control of an individual UPS by connecting it directly to the network
3. Communication Ports - Serial, USB, and SmartSlot™ for accessory cards.
4. 8 IEC320 C13 Outlets in 3 Groups5. Emergency Power Off (EPO) - Provides for remote UPS shut-off in the event of a fire or other emergency
6. Push Button Circuit Breaker - enables quick recovery from overloads.
7. Network-Grade Power - Provides most stable power conditions by filtering noise, automatic voltage regulation (AVR), and surge protection.
8. High Efficiency Green Mode - Saves utility costs and reduces heat promoting longer component life.
9. Advanced Battery Management - Temperature-compensated charging extends life and advanced algorithms recommend replacement date.
Additional Features:
1. Slim 2U Rack/Tower Convertible Form: Display rotates easily for use in or out of a rack.
2. High-frequency Design: Reduces size of (or eliminates) bulky transformers making installation even easier.
3. Smart External Battery Connector: Accept external batteries and increases runtime automatically to increase availability.
4. Switched Outlet Groups: Reboot hung devices, shed non-critical loads to conserve runtime, and sequence start-up/turn off.
Smart-UPS Display Intuitive, easy-to-use LCD interface
LCD Display Screen - Clear, consistent, and detailed information in your choice of basic or advanced menus.
Power Status:
- Operating mode and efficiency
- Load VA/Watts/Amps
- Input/Output voltage and frequency
- Battery capacity and runtime
- Energy meter and more
Control - UPS and outlet group settings
Language
Power quality settings
Alarm, delay and threshold settings
Test and Diagnostics - Initiate battery and runtime calibration tests
Logs - See explanation of last 10 transfers and faults
About - UPS and replacement battery part numbers, serial numbers, battery install, and suggested replacement dates
Online Status Indicators - Online, on battery, fault, and replace battery LEDs for quick status identification.
Escape - Exits to the previous menu or screen.
Return - Used to enter or confirm settings.
Navigation Arrows - Allow for quick adjustment of settings.
|
|
APC Warranties available for this UPS |
|
|
APC Service Pack Warranty Extension (New Product Purchases)
|
APC Service Pack Warranty Extension (Renewal or High Volume)
|
FEWBEXTWAR1YR-SP-04 FEWBEXTWAR3YR-SP-04 FEWEXTWAR1YR-SP-04 FEWEXTWAR3YR-SP-04
Protection for your system, peace of mind for you - With the APC Extended Warranty program, you will have peace of mind knowing that in the unlikely event of a failure, your product will be repaired or replaced quickly, minimizing downtime.
Our warranty guarantees free next business day delivery of parts or unit to ensure you get what you need as soon as you need it. |
Replacement Battery Options for this UPS |
|
APC Replacement Battery Cartridge - FEAPCRBC133
This APC Replacement Battery Cartridge fits selected APC Smart-UPS and Back-UPS, restoring power back-up capacity for home offices, small businesses and IT departments.
This replacement battery cartridge (RBC) has a lifetime of three to five years, offers safe and reliable support to the UPS, and extends the useful life of your UPS. The APC RBC comes fully assembled and includes easy-to-follow replacement instructions, making hot-swap installation simple.
|
Product Features:
1. Alphanumeric LCD (Liquid Crystal Display) Intuitive interface provides detailed and accurate information with the ability to configure locally.
2. Communication Ports: Serial, USB, and SmartSlot™ for accessory cards.
3. 8 IEC320 C13 Outlets in 3 Groups
4. Push Button Circuit Breaker enables quick recovery from overloads.
5. Emergency Power Off (EPO): Provides for remote UPS shut-off in the event of a fire or other emergency
6. Network-grade Power: Provides the most stable power conditions by filtering noise, automatic voltage regulation (AVR), and surge protection.
7. High Efficiency Green Mode: Saves utility costs and reduces heat promoting longer component life.
8. Advanced Battery Management: Temperature-compensated charging extends life and advanced algorithms recommend replacement date
Additional Features:
1. Slim 2U Rack/Tower Convertible Form: Display rotates easily for use in or out of a rack.
2. High-frequency Design: Reduces size of (or eliminates) bulky transformers making installation even easier.
3. Smart External Battery Connector: Accept external batteries and increases runtime automatically to increase availability.
4. Switched Outlet Groups: Reboot hung devices, shed non-critical loads to conserve runtime, and sequence start-up/turn off.
APC Smart-UPS Display
Intuitive, easy-to-use LCD interface - Clear, consistent, and detailed information in your choice of basic or advanced menus
Power Status
- Operating mode and efficiency
- Load VA/Watts/Amps
- Input/Output voltage and frequency
- Battery capacity and runtime
- Energy meter and more
Control - UPS and outlet group settings
Language
Power quality settings
Alarm, delay and threshold settings
Test and Diagnostics - Initiate battery and runtime calibration tests
Logs - See explanation of last 10 transfers and faults
About - UPS and replacement battery part numbers, serial numbers, battery install, and suggested replacement dates
Online Status Indicators - Online, on battery, fault, and replace battery LEDs for quick status identification
Escape - Exits to the previous menu or screen
Return - Used to enter or confirm settings.
Navigation Arrows - Allow for quick adjustment of settings.
Supplied With:
APC UPS Network Management Card with Environmental Monitoring
APC UPS network management cards allow for secure monitoring and control of an individual APC UPS via web browser, command line interface or SNMP. Embedded technology provides exceptional reliability with notification features that inform you of problems as they occur.
Main Features
- Command line interface - Offers simultaneous remote management access through Telnet and SSH.
- Compatible with SmartSlot enabled UPS - Compatible with all SmartSlot UPS
- IPv6 Support - Capable of operating on a network using IPv6 protocol.
- Standard UPS RFC 1628 MIB Compatible - Make UPS information available to your preferred network, server or enterprise management system by forwarding SNMP traps (events) using RFC 1628 MIB.
- Device Encryption - Securely connect via HTTPS/SSL, SSH (up to 2048-bit encryption), SNMPv3.
- Multiple user access - Supports simultaneous web browser access for up to 8 users and network command line interface access for up to 3 users.
- UPS Firmware Update - User friendly mechanism to remotely and seamlessly update UPS firmware via the web browser interface (SMX, SMT and SRT Smart-UPS only).
- Smart Battery Management Support - Detailed battery information including battery cartridge parameters provides early-warning fault analysis to simplify management of the entire battery system (SRT Smart-UPS only).
- Modbus TCP Support - Supports reporting UPS information to Building Management Systems or other third party management systems via Modbus TCP.
Battery Options
APC Replacement Battery Cartridge - RBC115
This APC Replacement Battery Cartridge fits selected APC Smart-UPS and Back-UPS, restoring power back-up capacity for home offices, small businesses and IT departments.
This replacement battery cartridge (RBC) has a lifetime of three to five years, offers safe and reliable support to the UPS, and extends the useful life of your UPS. The APC RBC comes fully assembled and includes easy-to-follow replacement instructions, making hot-swap installation simple.
APC UPS External Battery Pack - SMX48RMBP2U
The APC Extended Run Battery Pack is the ideal companion for the APC Back-UPS Pro UPS (uninterruptible power supply).
The battery pack increases the duration of time that you can protect your electronic devices from damage and disconnect due to unexpected blackouts, voltage fluctuations, and other power disruptions.
APC Warranties available for this UPS
APC Service Pack Warranty Extension
(New Product Purchases)
APC Service Pack Warranty Extension
(Renewal or High Volume)
Protection for your system, peace of mind for you - With the APC Extended Warranty program, you will have peace of mind knowing that in the unlikely event of a failure, your product will be repaired or replaced quickly, minimising downtime.
APC's warranty guarantees free next business day delivery of parts or unit to ensure you get what you need as soon as you need it.
