10 Gigabit Smart Managed Fiber Switch
Cost-e?ective, flexible 10 Gigabit switch for Small-to-Medium-Businesses (SMBs).
Product Highlights:
10 x 10G SFP+ ports
2 x 10GBASE-T/SFP+ combo ports
Advanced security features to help protect your network
Supports a wide variety of management tools and utilities for efficient operation
Seamless Integration
The DXS-1210 Series is available in RJ-45 and SFP+ models, capable of connecting to Cat.6 and fiber cabling for reliable and fast 10 Gigabit connectivity, offering a flexibile solution for upstream or downstream server connections, simplifying network administration.
Energy Saving
Incorporating D-Link Green technology, these switches are capable of powersaving without sacrificing operational performance or functionality. They feature built-in smart fans with internal heat sensors that monitor and detect temperature changes and react accordingly by utilizing different fan speeds for different temperatures.
Extensive Layer 2 Features
The DXS-1210 Series comes with a complete lineup of L2 features, including port mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). Network maintenance features include loopback detection and cable diagnostics.
QoS, Bandwidth Control
The DXS-1210 Series supports Auto Surveillance VLAN (ASV) and Auto Voice VLAN, which are best suited for video surveillance and VoIP deployments. Auto Surveillance VLAN consolidates data and surveillance video transmission through a single switch, thus sparing businesses the expense of dedicated hardware and facilities.
Advanced Security Features
D-Link’s innovative Safeguard Engine™ helps protect the switches against traffic flooding caused by malicious attacks. The DXS-1210 Series supports 802.1X port-based and host-based authentication, allowing the network to be authenticated through external RADIUS servers.
Versatile Management
The DXS-1210 Series supports a variety of management options including D-Link Network Assistant (DNA), SNMP, industry-standard CLI, and D-View 7, a network management platform that allows for centralized management of the core network. This extensive toolset enables administrators to easily set up and remotely manage their networks, greatly reducing switch deployment time.
Green Technology
Power saving via the following features: Link Status detection, LED Shut-Off, Port Shut-Off, System Hibernation
Security Features
Access Control List
IP-MAC-Port Binding
Clientless MAC/Web access control
D-Link Safeguard Engine
Port Security
ARP Spoofing Prevention
Intuitive Management
full CLI through console and Telnet
Web-based GUI
D-Link Network Assistant Utility
Built-in SNMP MIB for remote NMS (D-View 7)
Advanced Features
Auto Surveillane VLAN
Auto Voice VLAN
Loopback Detection
Cable Diagnostics
Static Route
LLDP/LLDP-MED
Physical
Standby Power Consumption
25.22 watts
AC Input
100 to 240 VAC
Operating Temperature
-5 to 50 °C / 23 to 122 °F
Temperature (Storage)
-40 to 70 °C / -40 to 158 °F
Humidity (Operating)
0% to 95% non-condensing
Humidity (Storage)
0% to 95% non-condensing
Dimensions
440 x 210 x 44 mm / 17.36 x 8.26 x 1.73 in
Weight
2.73 kg / 6.02 lbs
General
Interfaces
10 x 10G SFP+ optical ports, 2 x 10GBASE-T/SFP+ combo ports
Port Standard & Functions
IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabtit Ethernet, IEEE 802.3z compliance, IEEE 802.3an 10GBASE-T 10GbE over copper, IEEE 802.3ae 10GbE over fiber, IEEE 802.3z 1000BASE-X, Auto MDI/MDIX support for 1000/10GBASE-T
An installation guide be found in the
