2.5 Gigabit Ethernet Smart Managed Switches
The DMS-1100-10TP is a great value range of 2.5 Gigabit switches capable of servicing a range of business needs. Featuring eight 2.5 Gigabit PoE access ports and two 10 Gigabit SFP+ uplinks, it's ideal for deploying multiple high-performance access points or surveillance equipment. Take advantage of Power over Ethernet (PoE) for highly flexible deployments.
Product Highlights:
Equipped with 8 x 100/1000/2.5G Base-T PoE ports
Equipped with 2 x SFP+ ports
Quality of Service (QoS) prioritizes time-sensitive traffic for a smoother network experience
IEEE 802.3az Energy Efficient Ethernet is not just good for the planet, but for your budget as well
Cut the power cable clutter with 802.3af/at Power over Ethernet (PoE)
A wide variety of L2 features to improve switch efficiency, making for a better, faster network
Web-based GUI makes network management as easy as it should be
Easily configure and deploy your equipment with D-Link Network Assistant
Built-in SNMP MIB allows convenient remote management for when you can’t be on premises
Auto-surveillance VLAN allocates bandwidth to surveillance related traffic, guaranteeing seamless footage
Auto-voice VLAN allocates bandwidth to voice related traffic, guaranteeing smooth voice calls
Support for LLDP/LLDP-MED
Loopback detection and cable diagnostics help you troubleshoot network issues
Your Switch in Numbers
The DMS-1100 Series feature eight 2.5 Gigabit PoE ports and two dedicated SFP+ ports, altogether offering an impressive 80 Gbps switching capacity. It is perfect for a deployment of Wave 2 access points, while the uplinks provide more than enough bandwidth when accessing the larger local network.
A Bridge Between Two Generations
The DMS-1100-10TP is a future-ready solution, designed for the upcoming years of connectivity. As more businesses replace older Ethernet with 2.5G to support increasingly powerful access points, you can rest assured this switch will keep on serving you well. It is also a big deal for your CAPEX thanks to backwards compatibility. It can push Cat 5e cabling to its limit, allowing 2.5 Gigabit connectivity over it, so you get the absolute most out of your existing cabling.
Even Safer Surveillance
If you have surveillance cameras or related devices attached to your network, putting them onto their own VLAN keeps surveillance footage running seamlessly. The DMS-1100 Series intelligently sorts surveillance traffic automatically into a separate VLAN. It can also head off a variety of malicious attacks by isolating sensitive areas of the network.
PoE for a Rapid Rollout
The DMS-1100-10TP is PoE-ready, with a hefty 240W power budget, allowing for a rapid rollout of supported access points. No need to connect your APs to power supplies, simply connect via Ethernet cable and they have all the power they need.
Rich Layer 2 Features
• STP, RSTP, MSTP, ERPS
802.1Q/Port/Asymmetric VLAN
Port mirroring
IGMP/MLD Snooping
LACP
D-Link Safeguard Engine
DoS attack prevention
Intuitive Management
D-Link Network Assistant (DNA) utility
Web-based GUI
Built-in SNMP MIB for remote NMS (D-View/DNA)
Advanced Features
Auto Surveillance VLAN
Auto Voice VLAN
Loopback detection
Cable diagnostics
LLDP/LLDP-MED
Green Technology
Power saving features: LED shutof & IEEE 802.3az Energy-Efficient Ethernet (EEE)
Fast Data, Fast Business
When data is running smoothly, so does your business.
The DMS-1100 Series is packed with Layer 2 features for a more efficient network and rapid troubleshooting abilities.
Physical
Standby Power Consumption
PoE on: 293.4 W / PoE off: 38.1 W
AC Input
100 to 240 VAC
Operating Temperature
-5 to 50 °C / 23 to 122 °F
Temperature (Storage)
-40 to 70 °C / -40 to 158 °F
Humidity (Operating)
0% to 95% non-condensing
Humidity (Storage)
0% to 95% non-condensing
Dimensions
440 x 250 x 44 mm / 17.32 x 9.84 x 1.73 in
Weight
3.43 kg / 7.56 lbs
General
Interfaces
8 x 100/1000/2.5GBASE-T PoE ports / 2 x SFP+ ports
Port Standard & Functions
IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T, IEEE 802.3z 1000BASE-X, IEEE 802.3bz 2.5GBASE-T, IEEE 802.3ae 10G over fiber, IEEE 802.3az, IEEE 802.3af/at (DMS-1100-10TP)
