AXIS V5925 PTZ Network Camera
Broadcast-quality HDTV 1080p PTZ camera
• AXIS V5925 PTZ Network Camera
• Studio-grade audio with XLR inputs
• VISCA and VISCA over IP support
• Camstreamer 3-month trial included
• 3G-SDI and HDMI outputs
Ideal for auditoriums, classrooms, indoor sports events, and places of worship, AXIS V5925 offers excellent video quality and studio-grade audio for professional broadcasting and live streaming.
Professional results made simple
AXIS V5925 provides excellent image quality in HDTV 1080p at 60 fps and 30x optical zoom for all the details. It offers stage mode and sports mode, providing better PTZ control for the operator in different scenarios. Featuring professional balanced XLR inputs with 48V phantom power, it can be used with studio-grade microphones and 3,5 mm input/output for flexibility. Additionally, the powerful chipset allows for analytics to run directly on the camera.
Great compatibility
This highly versatile PTZ camera includes both HDMI and 3G-SDI outputs, allowing you to connect to most professional video switchers. With a VISCA RS-232 based control system, the camera can easily be integrated with your existing AV installations. And, VISCA over IP allows for remote control of multiple cameras via a LAN connection. Furthermore, for simple or mobile installations, the included 3-month Camstreamer trial license lets you live stream to streaming platforms such as YouTube and Facebook Live directly from the camera over an IP network. You can also use any major video management software or just connect it via a web browser.
Lower bandwidth and enhanced security
AXIS V5925 features Axis Zipstream technology with H.264 and H.265 to preserve all the important details while significantly reducing bandwidth and storage requirements. It's packed with advanced security functionality to prevent unauthorized access and safeguard your system. Signed firmware and secure boot guarantee that the firmware hasn't been compromised and ensure only authorized firmware is installed. And if needed, secure boot guarantees the camera is completely free of malware after a factory default.
Analytics
Make your network camera solution more intelligent with powerful analytics and functionality.
AXIS Video Motion Detection
Performance
Preset points
Yes
Infrared (IR) cut-off filter
Yes
Fog proof
Yes
Type
IP security camera
Connectivity technology
Wired
PTZ control
Yes
Placement supported
Indoor
Wide Dynamic Range (WDR)
Yes
Tour recording
Yes
Day/night mode
Yes
Design
Housing material
Plastic
Fog proof
Yes
Form factor
Dome
Product colour
Black, White
Mounting type
Ceiling/wall
Camera
Minimum illumination
0.003 lx
Viewing angle, horizontal
62°
Viewing angle, vertical
37°
Tilt angle range
-20 - 90°
Tilt speed
90 °/sec
Pan range
170 - 170°
Pan speed
100 °/sec
Camera shutter speed
1/10000 - 1 s
Progressive scan
Yes
Camera pan control
Yes
Camera tilt control
Yes
Image sensor
Sensor type
CMOS
Optical sensor size
25.4 / 2.8 mm (1 / 2.8")
Progressive scan
Yes
Number of sensors
1
Lens system
Number of lenses
1
Maximum aperture number
4.6
Auto focus
Yes
Minimum aperture number
1.4
Zoom capability
Yes
Optical zoom
30x
Digital zoom
12x
Focal length range
4.4 - 132 mm
Video
Image quality adjustment
Brightness, Saturation, Sharpness
Bit rate control
Variable Bit Rate (VBR)
Video compression formats
AVC, H.264, H.265, HEVC, M-JPEG, MPEG4
Maximum resolution
1920 x 1080 pixelss
Supported graphics resolutions
160 x 90, 1920 x 1080 (HD 1080)
Supported video modes
1080p
Frame rate
60 fps
Text caption overlay
Yes
Video streaming
Yes
Storage
Card reader integrated
Yes
Compatible memory card
MicroSD (TransFlash), MicroSDHC, MicroSDXC
Flash memory
512 MB
Power
Power source type
DC
Power consumption (max)
51 W
Power consumption (typical)
14 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 65 °C
Operating relative humidity (H-H)
10 - 85 %
Storage relative humidity (H-H)
10 - 85 %
Full specification and details can be found in the Product Datasheet PDF file
