The HPE ProLiant DL20 Gen11 powered by the Intel Xeon E-2434 processor brings focused performance to compact deployments. With a 1U rack design and 4-core, 3.4 GHz base frequency (boosting up to 5 GHz), this server is purpose-built for secure, high-efficiency computing in edge and remote environments. Outfitted with 32 GB of DDR5 memory and a hybrid 4 TB storage setup, it balances speed, reliability, and storage flexibility—making it ideal for branch offices, retail operations, and space-sensitive installations across commercial and government sectors.
Key Features:
Intel Xeon E-2434 processor with 4 performance cores and 12 MB cache
Clock speed up to 5 GHz for responsive workload execution
32 GB DDR5-SDRAM (4800 MHz) for faster throughput and power efficiency
4 TB total storage: 2 TB SATA HDD and dual SSD configuration
1U short-depth rack chassis ideal for space-constrained installations
Four Gigabit Ethernet LAN ports for high-availability networking
Redundant Power Supply support and 290W PSU for operational resilience
Integrated with HPE InfoSight and optional HPE iLO port for secure, predictive system monitoring
PCIe Gen5 and OCP slots offer scalable I/O expansion
Compact Performance for Edge Applications
Equipped with the Intel Xeon E-2434, the DL20 Gen11 delivers a solid foundation for edge computing, POS platforms, and localized data tasks. Its 1U form factor fits seamlessly into tight IT closets, branch setups, and mobile deployments where full-size servers are impractical.
Speed and Flexibility in Memory and Storage
With a single 32 GB DDR5 module running at 4800 MHz, the system supports next-gen performance and energy efficiency. A combined 4 TB storage configuration—split between SATA HDD and solid-state drives—offers balanced capacity and fast data access to support both transactional and read-heavy workloads.
Enterprise Networking in a 1U Frame
Boasting four Gigabit Ethernet ports and one dedicated LAN controller, the DL20 Gen11 is designed for high-uptime networking in environments that demand constant connectivity. Whether in retail, transport, or public sector applications, this server keeps systems live and responsive.
Ready for Expansion and Remote Management
Support for PCIe Gen5 and an OCP slot offers future-ready expansion for additional I/O needs. Optional HPE iLO management provides remote control and enhanced security, while HPE InfoSight integration enables predictive analytics that reduce downtime and manual oversight.
I/O Diagram (Front)
Key
Component
1
Access Panel
2
Optical drive bay
3
Serial number/iLO information pull tab
4
iLO Service Port (USB)
5
System Power button/LED
6
NS204i-u device bay (optional)
7
Front Fan Assembly
8
Health LED
9
NIC Status LED1
10
UID button/LED
11
USB 3.2 Gen 1 Port
12
Four-bay SFF hot-plug drive bays
1. Front NIC LED display doesn’t support NIC LED ACT/LINK indication from ALOM/PCIE/FLOM NIC's
I/O Diagram (Side)
Key
Component
1
Power Supply (1x500W shown)
2
M.2 Slot (Supports the iLO/M.2 Cable Kit option)
3
PCIe Riser
4
4-pin processor power connector
5
4 DDR5 DIMM slots
6
Processor shown with heatsink
7
Chassis intrusion detection switch connector
8
SlimSAS x8 port
9
Front I/O & USB 3.2 Gen 1 & iLO service port connector
10
Fan cage shown with 2 fans
11
Central fan assembly (3rd fan)
I/O Diagram (Back)
Key
Component
1
NIC ports (1Gb) NIC port 1 - iLO and production data shared port
2
Serial Port (optional)
3
Slot 1 PCIe 5.0
4
Redundant Power Supplies (2nd power supply not shown)
5
OCP 3.0 Slot
6
iLO dedicated network port (optional)
7
Display Port
8
VGA Port
9
USB 3.2 Gen1 ports
1. Front NIC LED display doesn’t support NIC LED ACT/LINK indication from ALOM/PCIE/FLOM NIC's
The HPE ProLiant DL20 Gen11 (Model:P78087-425) features a powerful Intel Xeon E-2434 processor running at 3.4 GHz with a boost frequency up to 5 GHz, delivering 4 high-performance cores and 12 MB of cache for efficient multitasking and processing power. Equipped with 32 GB of DDR5 memory clocked at 4800 MHz in a single slot, this server supports fast, reliable data handling suited for demanding edge workloads.
Key Features:
Intel Xeon E-2434 processor with 4 performance cores and 12 MB cache
32 GB DDR5-SDRAM memory at 4800 MHz for high-speed operation
960 GB total storage via dual 480 GB SATA SSDs (2.5") with RAID support
Broadcom BCM5719 Gigabit Ethernet controller with 4 RJ-45 LAN ports
Compact 1U rack chassis with standard rack mounting
Trusted Platform Module (TPM) for enhanced hardware security
800 W single power supply ensuring reliable power delivery
Processor and Memory Performance
Powered by the Intel Xeon E-2434 processor, this DL20 Gen11 server delivers strong single-thread and multi-thread performance with 4 cores and up to 5 GHz turbo frequency. Its 32 GB DDR5 memory ensures fast data throughput, enabling smooth execution of business-critical edge applications.
Storage and Data Security
The server includes two 480 GB SATA SSDs configured with RAID support for redundancy and improved data protection. The Trusted Platform Module (TPM) enhances security by safeguarding cryptographic keys and system integrity.
Connectivity and Design
With four Gigabit Ethernet LAN ports powered by the Broadcom BCM5719 controller, the DL20 Gen11 ensures robust network connectivity. Its compact 1U rack chassis fits standard racks, making it ideal for space-constrained environments.
I/O Diagram (Front)
Key
Component
1
Access Panel
2
Optical drive bay
3
Serial number/iLO information pull tab
4
iLO Service Port (USB)
5
System Power button/LED
6
NS204i-u device bay (optional)
7
Front Fan Assembly
8
Health LED
9
NIC Status LED1
10
UID button/LED
11
USB 3.2 Gen 1 Port
12
Four-bay SFF hot-plug drive bays
1. Front NIC LED display doesn’t support NIC LED ACT/LINK indication from ALOM/PCIE/FLOM NIC's
I/O Diagram (Side)
Key
Component
1
Power Supply (1x500W shown)
2
M.2 Slot (Supports the iLO/M.2 Cable Kit option)
3
PCIe Riser
4
4-pin processor power connector
5
4 DDR5 DIMM slots
6
Processor shown with heatsink
7
Chassis intrusion detection switch connector
8
SlimSAS x8 port
9
Front I/O & USB 3.2 Gen 1 & iLO service port connector
10
Fan cage shown with 2 fans
11
Central fan assembly (3rd fan)
I/O Diagram (Back)
Key
Component
1
NIC ports (1Gb) NIC port 1 - iLO and production data shared port
2
Serial Port (optional)
3
Slot 1 PCIe 5.0
4
Redundant Power Supplies (2nd power supply not shown)
5
OCP 3.0 Slot
6
iLO dedicated network port (optional)
7
Display Port
8
VGA Port
9
USB 3.2 Gen1 ports
1. Front NIC LED display doesn’t support NIC LED ACT/LINK indication from ALOM/PCIE/FLOM NIC's
The HPE ProLiant DL20 Gen11 E-2436 server delivers enterprise-grade performance in a space-saving 1U chassis. Featuring the Intel Xeon E-2436 processor, 32 GB DDR5 ECC memory, and dual 480 GB SATA SSDs, it is tailored for small to medium-sized businesses seeking reliability, scalability, and efficient manageability.
Key Features
Intel Xeon E-2436 processor with 6 cores and 12 threads, operating at 2.9 GHz (up to 4.5 GHz with Turbo Boost).
32 GB DDR5 ECC memory, expandable up to 128 GB, ensuring data integrity and high-speed performance.
Two 480 GB SATA SSDs configured via Intel VROC for enhanced storage performance and reliability.
Support for up to four Small Form Factor (SFF) drives, providing flexible storage options.
Integrated HPE iLO 6 for advanced remote management and monitoring capabilities.
800W redundant power supply, ensuring continuous operation and energy efficiency.
What's New
Introduction of the Intel Xeon E-2436 processor, offering improved performance for entry-level server workloads.
Enhanced memory support with DDR5 ECC technology, reducing the risk of data corruption.
Updated HPE iLO 6 management engine, providing more robust remote management features.
Improved energy efficiency with an 800W redundant power supply, suitable for various deployment scenarios.
Performance and Scalability
The DL20 Gen11 E-2436 is designed to handle a variety of workloads, from file and print services to more demanding applications. Its support for ECC memory and the latest Intel Xeon E-series processors ensures reliable performance and data integrity.
Deployment Flexibility
With its compact 1U rack design, the DL20 Gen11 fits easily into space-constrained environments. Its flexible storage options and scalable memory make it adaptable to evolving business needs.
Enhanced Security and Manageability
Security features like TPM 2.0 and HPE iLO 6 provide robust protection against unauthorized access and simplify server management tasks, ensuring that your IT infrastructure remains secure and manageable.
I/O Diagram (Front)
Key
Component
1
Access Panel
2
Optical drive bay
3
Serial number/iLO information pull tab
4
iLO Service Port (USB)
5
System Power button/LED
6
NS204i-u device bay (optional)
7
Front Fan Assembly
8
Health LED
9
NIC Status LED1
10
UID button/LED
11
USB 3.2 Gen 1 Port
12
Four-bay SFF hot-plug drive bays
1. Front NIC LED display doesn’t support NIC LED ACT/LINK indication from ALOM/PCIE/FLOM NIC's
I/O Diagram (Side)
Key
Component
1
Power Supply (1x500W shown)
2
M.2 Slot (Supports the iLO/M.2 Cable Kit option)
3
PCIe Riser
4
4-pin processor power connector
5
4 DDR5 DIMM slots
6
Processor shown with heatsink
7
Chassis intrusion detection switch connector
8
SlimSAS x8 port
9
Front I/O & USB 3.2 Gen 1 & iLO service port connector
10
Fan cage shown with 2 fans
11
Central fan assembly (3rd fan)
I/O Diagram (Back)
Key
Component
1
NIC ports (1Gb) NIC port 1 - iLO and production data shared port
2
Serial Port (optional)
3
Slot 1 PCIe 5.0
4
Redundant Power Supplies (2nd power supply not shown)
5
OCP 3.0 Slot
6
iLO dedicated network port (optional)
7
Display Port
8
VGA Port
9
USB 3.2 Gen1 ports
1. Front NIC LED display doesn’t support NIC LED ACT/LINK indication from ALOM/PCIE/FLOM NIC's
Compact Powerhouse for Edge and SMB Deployments
The HPE ProLiant DL20 Gen11 Server combines enterprise-grade performance with a compact form factor, making it an ideal choice for small to medium-sized businesses and edge computing environments. Equipped with the Intel Xeon E-2434 processor, this 1U rack server delivers robust computing capabilities while maintaining energy efficiency and scalability.
Key Features
Intel Xeon E-2434 processor with 4 cores and 8 threads, operating at 3.4 GHz (up to 4.7 GHz with Turbo Boost).
16 GB DDR4 ECC memory, expandable up to 64 GB, ensuring data integrity and reliability.
Support for up to two Large Form Factor (LFF) drives, providing flexible storage options.
Integrated HPE iLO 6 for advanced remote management and monitoring capabilities.
Trusted Platform Module (TPM) 2.0 for enhanced hardware-based security.
290W power supply, balancing performance with energy efficiency.
What's New
Introduction of the Intel Xeon E-2434 processor, offering improved performance for entry-level server workloads.
Enhanced memory support with ECC technology, reducing the risk of data corruption.
Updated HPE iLO 6 management engine, providing more robust remote management features.
Improved energy efficiency with a 290W power supply, suitable for various deployment scenarios.
Performance and Scalability
The DL20 Gen11 is designed to handle a variety of workloads, from file and print services to more demanding applications. Its support for ECC memory and the latest Intel Xeon E-series processors ensures reliable performance and data integrity.
Deployment Flexibility
With its compact 1U rack design, the DL20 Gen11 fits easily into space-constrained environments. Its flexible storage options and scalable memory make it adaptable to evolving business needs.
Enhanced Security and Manageability
Security features like TPM 2.0 and HPE iLO 6 provide robust protection against unauthorized access and simplify server management tasks, ensuring that your IT infrastructure remains secure and manageable.
I/O Diagram (Front)
Key
Component
1
Access Panel
2
Optical drive bay
3
Serial number/iLO information pull tab
4
iLO Service Port (USB)
5
System Power button/LED
6
NS204i-u device bay (optional)
7
Front Fan Assembly
8
Health LED
9
NIC Status LED1
10
UID button/LED
11
USB 3.2 Gen 1 Port
12
Four-bay SFF hot-plug drive bays
1. Front NIC LED display doesn’t support NIC LED ACT/LINK indication from ALOM/PCIE/FLOM NIC's
I/O Diagram (Side)
Key
Component
1
Power Supply (1x500W shown)
2
M.2 Slot (Supports the iLO/M.2 Cable Kit option)
3
PCIe Riser
4
4-pin processor power connector
5
4 DDR5 DIMM slots
6
Processor shown with heatsink
7
Chassis intrusion detection switch connector
8
SlimSAS x8 port
9
Front I/O & USB 3.2 Gen 1 & iLO service port connector
10
Fan cage shown with 2 fans
11
Central fan assembly (3rd fan)
I/O Diagram (Back)
Key
Component
1
NIC ports (1Gb) NIC port 1 - iLO and production data shared port
2
Serial Port (optional)
3
Slot 1 PCIe 5.0
4
Redundant Power Supplies (2nd power supply not shown)
5
OCP 3.0 Slot
6
iLO dedicated network port (optional)
7
Display Port
8
VGA Port
9
USB 3.2 Gen1 ports
1. Front NIC LED display doesn’t support NIC LED ACT/LINK indication from ALOM/PCIE/FLOM NIC's
The HPE ProLiant DL20 Gen11 Server, equipped with the Intel Xeon E-2414 processor, offers a blend of performance, reliability, and manageability in a compact 1U rack-mountable form factor. Designed for small to medium-sized businesses and edge computing environments, this server delivers enterprise-class capabilities at an affordable price point.
Key Features
Intel Xeon E-2414 processor with 4 cores and 8 threads, operating at 2.6 GHz (up to 4.5 GHz with Turbo Boost).
16 GB DDR5 ECC memory, expandable up to 128 GB, ensuring data integrity and reliability.
Support for up to two Large Form Factor (LFF) drives, providing flexible storage options.
Integrated HPE iLO 6 for advanced remote management and monitoring capabilities.
Trusted Platform Module (TPM) 2.0 for enhanced hardware-based security.
290W power supply, balancing performance with energy efficiency.
What's New
Introduction of the Intel Xeon E-2414 processor, offering improved performance for entry-level server workloads.
Enhanced memory support with DDR5 ECC technology, reducing the risk of data corruption.
Updated HPE iLO 6 management engine, providing more robust remote management features.
Improved energy efficiency with a 290W power supply, suitable for various deployment scenarios.
Performance and Scalability
The DL20 Gen11 is designed to handle a variety of workloads, from file and print services to more demanding applications. Its support for ECC memory and the latest Intel Xeon E-series processors ensures reliable performance and data integrity.
Deployment Flexibility
With its compact 1U rack design, the DL20 Gen11 fits easily into space-constrained environments. Its flexible storage options and scalable memory make it adaptable to evolving business needs.
Enhanced Security and Manageability
Security features like TPM 2.0 and HPE iLO 6 provide robust protection against unauthorized access and simplify server management tasks, ensuring that your IT infrastructure remains secure and manageable.
I/O Diagram (Front)
Key
Component
1
Access Panel
2
Optical drive bay
3
Serial number/iLO information pull tab
4
iLO Service Port (USB)
5
System Power button/LED
6
NS204i-u device bay (optional)
7
Front Fan Assembly
8
Health LED
9
NIC Status LED1
10
UID button/LED
11
USB 3.2 Gen 1 Port
12
Four-bay SFF hot-plug drive bays
1. Front NIC LED display doesn’t support NIC LED ACT/LINK indication from ALOM/PCIE/FLOM NIC's
I/O Diagram (Side)
Key
Component
1
Power Supply (1x500W shown)
2
M.2 Slot (Supports the iLO/M.2 Cable Kit option)
3
PCIe Riser
4
4-pin processor power connector
5
4 DDR5 DIMM slots
6
Processor shown with heatsink
7
Chassis intrusion detection switch connector
8
SlimSAS x8 port
9
Front I/O & USB 3.2 Gen 1 & iLO service port connector
10
Fan cage shown with 2 fans
11
Central fan assembly (3rd fan)
I/O Diagram (Back)
Key
Component
1
NIC ports (1Gb) NIC port 1 - iLO and production data shared port
2
Serial Port (optional)
3
Slot 1 PCIe 5.0
4
Redundant Power Supplies (2nd power supply not shown)
5
OCP 3.0 Slot
6
iLO dedicated network port (optional)
7
Display Port
8
VGA Port
9
USB 3.2 Gen1 ports
1. Front NIC LED display doesn’t support NIC LED ACT/LINK indication from ALOM/PCIE/FLOM NIC's
