Blustream Video Splitters

The Blustream SP12CS 2-Way HDMI Splitter allows a single HDMI source to be shared across two displays without any loss in video quality. Supporting HDMI 2.0 and HDCP 2.2, it handles 4K UHD at 60Hz with full 4:4:4 chroma and HDR content. Each output can adapt to the display's capability, downscaling if necessary, while maintaining maximum resolution on the other screen. Audio can be routed simultaneously via analogue L/R and optical outputs, giving flexibility for different audio setups. Advanced EDID management ensures compatibility with a wide range of devices, making this splitter suitable for both home and professional AV setups.

Key Features of BlueStream SP12CS Features 1x HDMI input that is replicated to 2x HDMI outputs
Supports HDMI 2.0 18Gbps specification including HDR
Supports up to 4K UHD 60Hz 4:4:4
Video down-conversion on outputs allowing a display only capable of supporting lower video resolutions (4K 60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on remaining video outputs
Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
Supports bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications
HDMI audio breakout to analogue L/R audio and optical digital outputs concurrently
CEC (Consumer Electronic Command) will only pass between the source device and the sink connected to output 1
Advanced EDID management
HDCP 2.2 Support
Video & Audio Compatibility Supports a wide range of video formats from VGA to 4K UHD, including HDR and all HDMI standard resolutions. Audio passthrough covers Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, and DTS-HD formats.

Physical & Connectivity Details Includes 1 HDMI input, 2 HDMI outputs, optical and analogue L/R audio outputs, and DIP switch EDID controls. Powered via 5V DC supply, with compact dimensions for easy installation in any AV setup.

The Blustream SP14CS 4-Way 4K HDMI 2.0 Splitter allows a single HDMI source to be shared across four displays simultaneously. Supporting 4K UHD 60Hz 4:4:4 video, HDR content, and HDCP 2.2, it also provides audio breakout and automatic down-conversion to accommodate displays with lower resolution capabilities.

Key Features of BlueStream SP14CS Features 1x HDMI input that is replicated to 4x HDMI outputs
Supports HDMI 2.0 18Gbps specification including HDR
Supports up to 4K UHD 60Hz 4:4:4
Video down-conversion on outputs allowing a display only capable of supporting lower video resolutions (4K 60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on remaining video outputs
Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
Supports bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications
HDMI audio breakout to analogue L/R audio and optical digital outputs concurrently
CEC (Consumer Electronic Command) will only pass between the source device and the sink connected to output 1
Advanced EDID management
HDCP 2.2 Support
Reliable Distribution The SP14CS ensures high-quality video and audio are delivered consistently to all connected displays, maintaining full 4K performance on compatible screens while adapting to lower-capability displays where needed.

Flexible Installation Compact and easy to integrate, this splitter is suitable for both home and commercial AV setups, providing a clean and simple way to distribute a single HDMI source across multiple displays.

The Blustream HD11CTRL-V2 HDMI 2.0 In-line Controller automates and manages HDMI signals in AV systems, providing reliable control over displays and connected devices. With multiple configuration options, this unit includes RS-232, IR or IP command triggers, display on / off control via CEC, and HDMI signal sensing. External relay inputs allow 3rd party triggers for integration with devices such as sensors or switches. The addition of a web-GUI allows for simple configuration and advanced management and distribution of 3rd party commands and automated processes.

The HD11CTRL-V2 will also help with HDMI compatibility, HDCP 2.2, clock stretching, EDID and handshaking issues that can cause problems when distributing HDMI signals, especially 4K. The HD11CTRL-V2 supports full HDMI 2.0 and HDCP 2.2, with video resolutions up to and including 4K @ 60Hz 4:4:4.

Key Features of BlueStream HD11CTRL-V2 Automated in-line HDMI control module supporting up to 10 macros, with up to 10 command functions per macro
Supports HDMI 2.0 18Gbps specification including HDR
Supports resolutions up to 4K UHD 60Hz 4:4:4
Supports bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications
Features Smart-Scale technology to convert 4K input signal to 1080p output (Note: 4:2:2 colour space not supported)
Can help to solve most HDMI EDID, HDCP, compatibility, and handshaking issues
Automatic display control via CEC, RS-232, IR or IP
IR learning up to 30 IR commands
Relay control for interface to third party devices such as projector screens
Signal sense input for connection from third party devices such as sensors or switches
HDCP 2.2 compliant with advanced EDID management
In-built web-GUI for configuration and control
Flexible Control The HD11CTRL-V2 allows seamless management of HDMI displays and devices, helping to address common EDID, HDCP, and compatibility issues while automating repetitive commands for convenience.

Discreet Integration Its compact design and multiple interfaces make it suitable for installations where equipment is hidden in cabinets or racks, keeping setups clean while maintaining full control over connected AV components.

The Blustream SP24AB-8K is a high-performance HDMI splitter designed to share two HDMI 2.1 sources across four displays simultaneously. It supports ultra-high resolutions, including 8K at 60Hz and 4K at 120Hz, along with HDR content. Each output adapts to the connected display, ensuring compatibility with lower-resolution devices without affecting the other outputs. The unit offers both automatic and manual source switching via the front panel or IR remote, while audio can be routed concurrently through analogue L/R and coaxial digital outputs. Advanced EDID management and HDCP 2.3 compliance ensure wide compatibility across devices.

Key Features of BlueStream SP24AB-8K Features 2 x selectable HDMI 2.1 inputs that are split to 4 x HDMI outputs
Supports HDMI 2.1 specification including HDR (40Gbps maximum)
Supports up to 8K 60Hz YCbCr 4:2:0 10bit, 8K 30Hz RGB/YCbCr 4:4:4 10bit, or 4K 120Hz RGB/YCbCr 4:4:4 10bit
Supports ALLM (Auto Low Latency Mode) & VRR (Variable Refresh Rate)
Supports bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications
Auto HDMI source switching via 5v and / or TMDS signal sensing
Manual HDMI source switching via front panel and IR
Audio breakout to analogue L/R audio and Coaxial (S/PDIF) digital outputs concurrently
5v / 12v IR Compatible
HDCP 2.3 compliant with advanced EDID management
Video & Audio Performance Supports high-resolution formats up to 8K 60Hz and 4K 120Hz with HDR. Audio passthrough includes multichannel and object-based formats, ensuring compatibility with the latest audio systems.

Connectivity & Controls Equipped with 2 HDMI inputs, 4 HDMI outputs, analogue and coaxial audio outputs, IR input, and Micro-USB firmware upgrade port. Both automatic and manual source selection are supported for flexible operation.

The Blustream SP18 8-Way 4K HDMI 2.0 Splitter allows a single HDMI source to be distributed across eight displays simultaneously. Supporting full 4K UHD 60Hz 4:4:4 video, HDR content, and HDCP 2.2, it provides consistent video quality across multiple endpoints and maintains compatibility with all standard HDMI resolutions.

Key Features of BlueStream SP18 Features 1 x HDMI input that is replicated to 8 x HDMI outputs
Supports HDMI 2.0 18Gbps specification including HDR
Supports up to 4K UHD 60Hz 4:4:4
Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
Supports bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications
Advanced EDID management
HDCP 2.2 Support
Reliable Distribution The SP18 ensures high-quality video and audio are delivered consistently to all connected displays, maintaining the full 4K UHD signal where supported while preserving compatibility across multiple devices.

Flexible Installation Compact and easy to integrate, this splitter is suitable for both home and commercial AV environments, providing a clean and straightforward way to distribute a single HDMI source across multiple displays.

The Blustream SP18CS 8-Way 4K HDMI 2.0 Splitter allows a single HDMI source to be shared across eight displays simultaneously. It supports 4K UHD 60Hz 4:4:4 video, HDR content, and HDCP 2.2, while providing automatic video down-conversion on outputs so screens with lower resolution capabilities can still display compatible video. Audio can be extracted via analogue or optical outputs for flexible integration.

Key Features of BlueStream SP18CS Features 1x HDMI input that is replicated to 8x HDMI outputs
Supports HDMI 2.0 18Gbps specification including HDR
Supports up to 4K UHD 60Hz 4:4:4
Video down-conversion on outputs allowing a display only capable of supporting lower video resolutions (4K 60Hz 4:2:0 or 1080p) to receive 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on remaining video outputs
Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
Supports bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications
HDMI audio breakout to analogue L/R audio and optical digital outputs concurrently
CEC (Consumer Electronic Command) will only pass between the source device and the sink connected to output 1
Advanced EDID management
HDCP 2.2 Support
Consistent Performance The SP18CS maintains high-quality video and audio delivery across all connected displays, allowing each output to show the best possible resolution for the connected screen without affecting other outputs.

Flexible Integration Compact and easy to install, this splitter is ideal for multi-screen setups in homes, offices, classrooms, or commercial AV environments, providing reliable signal distribution with flexible audio and video management.

The Blustream HD12DB-V2 is a 1×2 HDMI splitter and scaler with built-in DAC for audio down-mixing. It features a HDMI loop out to pass the original video and multi-channel embedded audio signal to compatible equipment, with a second HDMI output featuring video down-conversion of 4K 60Hz 4:4:4 video down to 1080p.

This provides the perfect cost effective solution for ensuring that 4K UHD video and multi-channel audio can be distributed around a multi-room system where there are a mixture of 2ch and 7.1ch zones with multiple output resolution requirements.

Key Features of BlueStream HD12DB-V2 Features an in-built DAC (Digital to Analogue Audio Converter) that converts 7.1ch Dolby Audio® or DTS Audio to a stereo 2ch signal available on HDMI, optical, and analogue audio outputs concurrently
Supports Dolby Audio® Technology
Supports multi-channel audio input formats up to Dolby Atmos® and DTS:X
Features 1 x HDMI input supporting 4K UHD video (4K 60Hz 4:4:4), including HDR / Dolby Vision at 60Hz, replicated to 2 x HDMI outputs
HDMI loop out replicates the HDMI input signal up to 4K 60Hz 4:4:4 and 7.1ch Dolby Audio® & DTS Audio
HDMI output 2 features a video downconversion from 4K down to 1080p
HDMI audio breakout to downmixed analogue L/R audio and downmixed optical digital outputs concurrently
HDCP 2.2 compliant with advanced EDID management
® Dolby Audio is a registered trademark of Dolby Laboratories Licensing Corporation.

Video Handling The unit supports high-resolution 4K UHD video at 60Hz with full 4:4:4 chroma and HDR or Dolby Vision, ensuring compatibility with modern displays. HDMI output 1 mirrors the source, while output 2 down-converts to 1080p for older displays or zones with lower resolution requirements.

Audio Conversion An integrated DAC converts multi-channel audio to stereo 2-channel, making it accessible via HDMI, optical, and analogue outputs simultaneously. This allows devices that cannot decode 7.1ch audio to still play audio without loss of clarity or synchronization.

The Blustream HSP14CS 4-Way HDBaseT™ CSC Splitter distributes a single HDMI 2.0 4K 60Hz 4:4:4 source to four simultaneous HDBaseT™ outputs with independent down-scaling of 4K video inputs to allow those displays only capable of supporting lower video resolutions to receive 4K video while still showing maximum original 4K UHD resolution on the higher-definition displays.

It transmits HDMI, Bi-directional IR and PoC (Power over Cable) up to lengths of 70m (40m 4K 60Hz 4:4:4) over a single CAT cable. The 4-Way splitter also features audio breakout, EDID management and HDMI loop out for integrating local displays or cascading to multiple devices.

Key Features of BlueStream Advanced HDBaseT™ technology offering distribution of video and audio over a single CAT cable
Advanced Colour Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR
1 x HDMI input replicated to 4 x HDBaseT™ outputs
1 x HDMI loop out for integrating local displays or cascading to multiple devices
Supports 4K 60Hz 4:4:4 UHD video up to 40m
Independent down-scaling of video input resolutions up to 4K 60Hz 4:4:4 to: 1080p 60Hz (for screens that do not support 4K)
4K 60Hz 4:2:0 (for screens that do not support full 4K 60Hz 4:4:4)

Extends HDMI 1080p up to a distance of 70m over single CAT cable
Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
Supports bitstream passthrough of multichannel surround sound including object-based audio formats in line with HDMI specifications
HDMI audio breakout to both analogue L/R audio and coaxial digital outputs concurrently
Supports PoC (Power over Cable) to power compatible HDBaseT™ receivers
Compatible with the following Blustream HDBaseT™ receivers: HEX70CS-RX (recommended for resolutions up to 4K 60Hz 4:4:4)
HEX70SL-RX (system limited to 4K 60Hz 4:2:0 8-bit maximum)

HDCP 2.2 support
Flexible Distribution The HSP14CS allows high-quality video and audio to be delivered to multiple displays while maintaining signal integrity, adapting to the capabilities of each screen with down-scaling and colour space conversion.

Professional Integration Compact yet versatile, the splitter is suitable for classrooms, conference rooms, retail environments, or any installation requiring multiple displays from a single HDMI source, with reliable control and signal management.
