Axis M12 Lenses

Lens M12 Megapixel 6.0 mm, F1.6

Optional lens for narrower field of view for AXIS P39 MkII cameras



• HFoV: 51°

• Focal length: 6 mm

• F-number: 1.6

• IR-coated for optimal color reproduction

• Sold in packs of 10


Lens M12 Megapixel 6.0 mm, F1.6 is a fixed lens with a 51° horizontal field of view (HFoV). It is an optional lens for AXIS P3904-R MkII and P3905-R MkII network cameras. M12 lenses come in different focal lengths ranging from wide angle to tele angle.

Lens M12 Megapixel 8.0 mm, F1.6

Optional lens for narrower field of view for AXIS P39 MkII cameras



• HFoV: 39°

• Focal length: 8 mm

• F-number: 1.6

• IR-coated for optimal color reproduction

• Sold in packs of 10


Lens M12 Megapixel 8.0 mm, F1.6 is a fixed lens with a 39° horizontal field of view (HFoV). It is an optional lens for AXIS P3904-R MkII and P3905-R MkII network cameras. M12 lenses come in different focal lengths ranging from wide angle to tele angle.

Lens M12 3.6 mm, F2.0

Standard lens for AXIS P39 MkII cameras



• HFoV: 93°

• Focal length: 3.6 mm

• F-number: 2.0

• Sold in packs of 10


Lens M12 3.6 mm, F2.0 is a fixed lens with a 93° horizontal field of view (HFoV). It is the default lens for AXIS P3904-R MkII and P3905-R MkII network cameras. M12 lenses come in different focal lengths ranging from wide angle to tele angle.

Lens M12 2.1 mm, F2.2

Optional lens for wider field of view for AXIS P39 MkII cameras



• HFoV: 130°

• Focal length: 2.1 mm

• F-number: 2.2

• IR-coated for optimal color reproduction

• Sold in packs of 10


Lens M12 2.1 mm, F2.2 is a fixed lens with a 130° horizontal field of view (HFoV). It is an optional lens for AXIS P3904-R MkII and P3905-R MkII network cameras. M12 lenses come in different focal lengths ranging from wide angle to tele angle.

Lens M12 2.8 mm F1.2

Optional lens for wider field of view for AXIS P39 MkII cameras



• HFoV: 113°

• Focal length: 2.8 mm

• F-number: 1.2

• IR-coated for optimal color reproduction

• Sold in packs of 10


Lens M12 2.8 mm F1.2 is a fixed lens with a 113° horizontal field of view (HFoV). It is an optional lens for AXIS P3904-R MkII and P3905-R MkII network cameras. M12 lenses come in different focal lengths ranging from wide angle to tele angle.

Lens M12 2.8 mm F1.6 IR

Standard lens for advanced Axis onboard cameras



• HFoV: 113°

• Focal length: 2.8 mm

• F-number: 1.6

• Sold in packs of 10


Lens M12 2.8 mm F1.6 IR is a fixed lens with a 113° horizontal field of view (HFoV). It's the default lens for AXIS P3925-R and P3935-LR network cameras. M12 lenses for onboard cameras come in different focal lengths ranging from wide angle to tele angle.

Lens M12 2.8 mm, F2.0

Standard fixed lens for selected AXIS F/FA/P12 sensor units



• HFoV: 93°

• Focal length: 2.8 mm

• F-number: 2.0

• Sold in packs of 10


Lens M12 2.8 mm, F2.0 is a fixed lens with a 93° horizontal field of view (HFoV). It is the default lens for AXIS F1005-E, F4005-E and P1214-E Sensor Units. M12 lenses come in different focal lengths ranging from wide angle to tele angle.

Lens Pinhole M12 3.7 mm

Standard pinhole lens for AXIS F series sensor units



• HFoV: 85°

• Focal length: 3.7 mm

• F-number: 2.5

• Sold in packs of 10


Lens M12 3.7 mm is a pinhole lens with a 85° horizontal field of view (HFoV). It is the default lens for AXIS F1025 sensor unit.

Lens M12 2.8 - 6 mm

Standard varifocal lens for AXIS F series sensor units



• HFoV: 101° - 51°

• Focal length: 2.8–6 mmF-number: 2.0

• F-number: 2.0

• Sold in packs of five


Lens M12 2.8-6 mm is a varifocal lens with a 101°-51° horizontal field of view (HFoV). It is the default lens for AXIS F1015 sensor unit.
