StarTech MSA Uncoded SFP to RJ45 Cat6/Cat5e Transceivers

MSA Uncoded SFP Module - 1000BASE-TX - SFP to RJ45 Cat6/Cat5e - 1GE Gigabit Ethernet SFP - RJ-45 100m

1000 Mbps (1 Gbps) | Copper | RJ45 | 100 m (328 ft) | Lifetime Warranty

The SFP1000TXST is an MSA compliant copper SFP transceiver that’s designed, programmed and tested to work with 1000BASE-TX compatible MSA switches and routers. The SFP transceiver module supports a maximum distance of up to 100 m (328 ft) and delivers dependable 1 GbE connectivity over copper cabling.

This SFP copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.












Applications:

Replace defective or damaged SFP modules
Expand your network to remote segments







Features:

100% MSA UNCODED SFP TRANSCEIVER: Designed, programmed and tested to work with compatible MSA Compliant switches and routers to deliver dependable 1GbE connectivity
TECHNICAL SPECS: 1000BASE-TX 1Gbps Copper RJ-45 Connector Distances up to 100m (328ft)
USES A COST-EFFECTIVE CABLING ALTERNATIVE TO FIBER-OPTIC SET UPS
TESTED FOR COMPATIBILITY: Hot-swappable in MSA Compliant routers and switches
LIFETIME WARRANTY: Backed by a lifetime warranty on the life of the module itself and not the life of your switch; our modules won't void your OEM warranty and supported by our Tech Advisors 5/24
WORKS WITH MSA COMPLIANT SWITCHES: Works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules







StarTech.com SFPs: All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.




Technical Specifications:

Maximum Data Transfer Rate: 1000 Mbps
Type: Copper
Connection Type: RJ45 Connector
Maximum Transfer Distance: 100 m (328 ft)
Power Consumption: Less than 1.3 Watt
Digital Diagnostics Monitoring (DDM): No







Network SFP transceiver type Copper Maximum data transfer rate 1000 Mbit/s Interface type SFP+ Ethernet LAN (RJ-45) ports 1

Performance Product colour Silver Housing material Aluminium Hot-Plug support Yes Digital Diagnostics Monitoring (DDM) No SFP transceiver type Copper Maximum transfer distance 100 m Maximum data transfer rate 1000 Mbit/s SFP transceiver standard TX

Operational conditions Operating temperature (T-T) 0 - 70 °C Storage temperature (T-T) -40 - 85 °C Operating relative humidity (H-H) 5 - 95%

Weight & dimensions Width 13.9 mm Depth 58.4 mm Height 12.6 mm Weight 25 g

Logistics data Master (outer) case width 31 cm Master (outer) case length 40 cm Master (outer) case height 32 cm Quantity per master (outer) case 70 pc(s) Full specification and details can be found in the

MSA Uncoded SFP+ Module - 10GBASE-T - SFP to RJ45 Cat6/Cat5e - 10GE Gigabit Ethernet SFP+ - RJ-45 30m

10 Gbps | Copper | RJ45 | 30 m (98.4 ft) | Lifetime Warranty

The SFP10GBTST is an MSA compliant copper SFP transceiver that’s designed, programmed and tested to work with 10GBASE-T compatible switchess and routers. The SFP+ transceiver module supports a maximum distance of up to 30 m (98.4 ft.) and delivers dependable 10 GbE connectivity over copper cabling, which is a cost-effective alternative to fiber-optic cable setups.

This SFP+ copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.












Applications:

Replace defective or damaged SFP+ modules
Expand your network to remote segments







Features:

100% MSA UNCODED SFP+ TRANSCEIVER: Designed, programmed and tested to work with compatible MSA Compliant switches and routers to deliver dependable 10GbE connectivity
TESTED FOR COMPATIBILITY: Hot-swappable in MSA Compliant routers and switches
LIFETIME WARRANTY: Backed by a lifetime warranty on the life of the module itself and not the life of your switch; our modules won't void your OEM warranty and supported by our Tech Advisors 5/24
WORKS WITH MSA COMPLIANT SWITCHES: Works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules







StarTech.com SFPs: All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.




Technical Specifications:

Maximum Data Transfer Rate: 10 Gbps
Type: Copper
Connection Type: RJ45 Connector
Maximum Transfer Distance: 30 m (98.4 ft.)
MTBF: 4,598,430 hours
Digital Diagnostics Monitoring (DDM): No







Network SFP transceiver type Copper Maximum data transfer rate 10000 Mbit/s Interface type SFP+ Ethernet LAN (RJ-45) ports 1

Performance Product colour Silver Housing material Zinc steel Hot-Plug support Yes Digital Diagnostics Monitoring (DDM) No Brand compatibility MSA Compliant Maximum transfer distance 30 m Maximum data transfer rate 10000 Mbit/s

Operational conditions Operating temperature (T-T) 0 - 70 °C Storage temperature (T-T) -40 - 85 °C Operating relative humidity (H-H) 5 - 95%

Weight & dimensions Width 13.9 mm Depth 70 mm Height 12.6 mm Weight 28 g

Logistics data Master (outer) case width 34.5 cm Master (outer) case length 38.5 cm Master (outer) case height 30.5 cm Quantity per master (outer) case 100 pc(s) Full specification and details can be found in the
