Reliable protection in tower format for computer rooms
Salicru's SPS ADVANCE T series offers, as a UPS solution, optimum levels of efficiency and reliability for all critical devices that require power supply continuity and dependability. They come in a very compact tower format to save space in server and computer rooms. They also feature line-interactive technology to combat any fluctuations in the mains supply together with an output voltage that is always sine-wave, the highest quality possible to power all sensitive loads.
For easier and more convenient use, they feature a display that shows all necessary information on the operation of the device and power supply (input/output voltage, % load, % battery, etc.) and a wide range of communication options through the USB interface with HID protocol, monitoring and management software (downloadable) and integrated smart slot (SNMP).
Also noteworthy is their compatibility with current APFC (active power factor correction) power supplies.
Features
1000 VA of Power
6 x IEC C13 Outlet Sockets
Line-interactive technology with sine-wave output.
Permanent AVR stabilisation (buck-boost).
Compact tower format.
RS-232 and USB-HID communication interfaces.
Monitoring and management software for Windows, Linux and Mac.
Smart slot for SNMP adapter.
Compatible with APFC power supplies.
Possibility of backup extension.
(Through additional modules, except for 850 VA model)
Complete display showing all operating information.
IEC output sockets.
Automatic battery test on each start-up.
Cold-start function for start-up from batteries.
SLC Greenergy solution.
Application
Salicru's SPS ADVANCE T series UPSs provide an optimum combination of features to protect all computer room equipment, from entry-level servers, through routers, switches, hubs, network devices and access points, to backup systems.
Display
Level of battery available.
Values for input/battery/backup.
Values for output/charging.
Level of load connected.
Normal operation.
Battery operation (power cut).
Device fault.
Audible alarm and alarm cancellation.
Communication Options
USB interface with HID protocol: Parameter configuration, UPS control and computer shutdown/hibernation through the USB port. Available for Windows, Linux and Mac.
UPS management and monitoring software for closing files/applications for Windows, Linux, Unix and Mac. Free and downloadable from www.salicru.com.
Smart slot for the connection of SNMP environment integration cards and signal cards via potential-free contacts or Modbus protocol.
Comparison Chart
Technical Specification
MODEL
SPS 1000 ADVANCE T
UPS Power (VA / W)
1000 / 700
Technology
Line-interactive
Format
Tower
Ports
AC outlets
6 x power IEC 60320 C13
AC outlet type
IEC 60320 C13
Input
Rated Voltage
230 V
Voltage range
165 - 290 V
Stabiliser
AVR (buck-boost)
Frequency
50 / 60 Hz ±10%
Input protection
Resettable breaker
Output
Rated voltage
230V
Voltage accuracy (battery mode)
±10%
Waveform
Pure sine wave
Total harmonic distortion (THDv)
≤5%
Frequency
50/60 Hz (same as input)
Frequency accuracy (battery mode)
±1 Hz
Compatible with APFC loads
Yes (1)
Admissible overload
Line mode
110% permanent
Battery mode
110% for 1 min / >130% immediate
Socket type
IEC
Protection
Overloads, short circuit and over discharge and battery charging
Efficiency
On-line mode
>98%
Stabiliser mode (AVR)
>92%
Battery mode
>80%
Battery
Battery type
Pb-Ca sealed, AGM, maintenance-free
Protection
Internal current limitation
Battery test
Automatic on each start-up + manual
Charging
Charge type
I/U (constant current/constant voltage)
Recharge time
4 hours to 90%
Communication
Interface
RS-232 / USB (HID)
Slot for SNMP/potential-free contacts/MODBUS
Yes
Downloadable monitoring software
For Windows, Linux and Mac
Warnings
LCD + keypad
Yes, multifunction screen
Displayed values
Input and output voltage / % load / % battery / backup
Levels
Connected load / overload / battery / low battery
Alarm
Battery / low battery / overload / failure
Other Functions
Cold start (start-up from batteries)
Yes
Emergency power off (EPO)
Yes
General
Operating temperature
0ºC - 40ºC
Relative humidity
Up to 95%, non-condensing
Noise level at 1 metre
Less than 45 dB
Dimensions (D x W x H mm)
327 x 140 x 191
Weight
13.50Kg
Standards
Safety
EN 62040-1
Electromagnetic compatibility (EMC)
EN 62040-2
Operation
EN 62040-3
Quality & Environmental Management
ISO-9001 and ISO-14001
(1) Power degradation of 20%
