Salicru's SPS 500 SOHO+ IEC 500VA UPS stand out for their Line-interactive technology, compatibility with APFC (active power factor correction) loads and their dual USB charger on the front.
Line-interactive systems use AVR (buck-boost) automatic voltage regulators to reduce possible fluctuations in input voltage, thereby lowering battery use, extending battery life and providing maximum backup if necessary.
Features
500 VA of Power
4 x IEC Outlet Sockets
Line-interactive technology.
Dual USB charger on the front (max. 2 Amp).
Compatible with APFC (active power factor correction) loads.
Complete LCD display with all information.
Permanent stabilisation (AVR).
USB communication interface with HID protocol.
Monitoring software for Windows, Linux and Mac.
Resettable input thermal protection.
Cold start function for start-up without mains.
Automatic restart when power restored.
Automatic frequency detector 50 or 60 Hz.
Protection against overloads and short circuits.
SLC Greenergy solution.
Applications
Salicru's SPS SOHO+ series UPS systems are ideal for the protection of computer/office environments from single-user management, design or communications stations to small networks composed of one server, various workstations and all associated peripherals. At the same time, they allow the charging of mobile devices through the two built-in USB ports. They are therefore suitable for shops, self-employed professionals, small offices, franchises, dealers, etc.
They also feature a USB interface with HID protocol for control, parameter setting and computer shutdown/hibernation. Also available is a software package for the management and monitoring of associated environments, including virtualised systems.
Display
Battery level available (25-50-75-100% and end of backup).
Connected load level (25-50-75-100% and overload).
Input voltage.
Output voltage.
Normal operation.
AVR operation (stabilisation).
Battery operation (power cut CA).
Device fault.
Connections
AC input.
UPS sockets.
Sockets with surge protection.
USB port.
Thermal rearmable input.
Contents
UPS SPS 500 SOHO+ IEC
UPS / PC USB communication cable.
Telephone / data / modem cable.
Start-up guide.
Warranty certificate.
Control Software
UPS monitoring and management software, allowing the orderly closing of files and programs in the event of prolonged power cuts. Valid for Windows, Unix, Linux and Mac.
The latest version of this software can be downloaded from the Salicru website.
Technical Specification
MODEL
SPS 500 SOHO+ IEC
UPS Power (VA / W)
500 / 300
Technology
Line-interactive
Format
Compact Tower
Ports
AC outlets
3 x power IEC 60320 C13 (UPS) ¦ 1 x power IEC 60320 C13 (surge)
AC outlet type
IEC 60320 C13
Input
Rated voltage
230 V
Voltage Range
162 V - 290 V
Nominal frequency
50 / 60 Hz
Input protection
Resettable thermal cutoff
Stabilisation
AVR Buck / Boost
Output
Voltage
230 V
Voltage accuracy (Battery mode)
±10%
Waveform (Battery mode)
Pseudo sine wave
Frequency
50/60 Hz (same as input)
APFC compatibility loads
Yes
Batteries
Type
Pb-Ca sealed, AGM, maintenance-free
Recharging time
2-4 hours to 90% capacity
Protection
Against deep discharge, against short circuit by means of fuse
Communication
Interface
USB (HID protocol)
Downloadable monitoring software
For Windows, Linux and Mac
Display
LCD
Yes, multifunction
Displayed values
Input and output voltage / Input and output frequency /
Battery voltage / % of load
Levels
Connected load / Overload / Battery / Low battery
Operating modes
Normal / Stabilisation (AVR) / Battery / Fault
Functions
Cold start (starting from batteries)
Yes
Automatic re-start
Yes, after the end of back up time
USB Charger
Quantity
2 Ports
Voltage
5 Vdc
Maximum current
2.0 A
General
Operating temperature
0ºC - 40ºC
Relative humidity
Up to 90%, non-condensing
Noise level at 1 metre
< 40 dB
Dimensions (D x W x H mm)
290 x 100 x 143
Weight
4.40Kg
Standards
Safety
EN 62040-1-1; EN-60950-1
Electromagnetic compatibility (EMC)
EN 62040-2
Operation
EN 62040-3
Quality & Environmental Management
ISO-9001 and ISO-14001
