Salicru's SPS 2200 SOHO+ IEC 2200VA UPS stands out for their Line-interactive technology, compatibility with APFC (active power factor correction) loads and their dual USB charger on the front.
Line-interactive systems use AVR (buck-boost) automatic voltage regulators to reduce possible fluctuations in input voltage, thereby lowering battery use, extending battery life and providing maximum backup if necessary.
Features
Applications
Salicru's SPS SOHO+ series UPS systems are ideal for the protection of computer/office environments from single-user management, design or communications stations to small networks composed of one server, various workstations and all associated peripherals. At the same time, they allow the charging of mobile devices through the two built-in USB ports. They are therefore suitable for shops, self-employed professionals, small offices, franchises, dealers, etc.
They also feature a USB interface with HID protocol for control, parameter setting and computer shutdown/hibernation. Also available is a software package for the management and monitoring of associated environments, including virtualised systems.
Display
Connections
Contents
Control Software
UPS monitoring and management software, allowing the orderly closing of files and programs in the event of prolonged power cuts. Valid for Windows, Unix, Linux and Mac.
The latest version of this software can be downloaded from the Salicru website.
Technical Specification
| MODEL | SPS 2200 SOHO+ IEC | |
| UPS Power (VA / W) | 2200 / 1200 | |
| Technology | Line-interactive | |
| Format | Compact Tower | |
| Ports | AC outlets | 4 x power IEC 60320 C13 (UPS) ¦ 2 x power IEC 60320 C13 (surge) |
| AC outlet type | IEC 60320 C13 | |
| Input | Rated voltage | 230 V |
| Voltage Range | 162 V - 290 V | |
| Nominal frequency | 50 / 60 Hz | |
| Input protection | Resettable thermal cutoff | |
| Stabilisation | AVR Buck / Boost | |
| Output | Voltage | 230 V |
| Voltage accuracy (Battery mode) | ±10% | |
| Waveform (Battery mode) | Pseudo sine wave | |
| Frequency | 50/60 Hz (same as input) | |
| APFC compatibility loads | Yes | |
| Batteries | Type | Pb-Ca sealed, AGM, maintenance-free |
| Recharging time | 2-4 hours to 90% capacity | |
| Protection | Against deep discharge, against short circuit by means of fuse | |
| Communication | Interface | USB (HID protocol) |
| Downloadable monitoring software | For Windows, Linux and Mac | |
| Display | LCD | Yes, multifunction |
| Displayed values | Input and output voltage / Input and output frequency / Battery voltage / % of load |
|
| Levels | Connected load / Overload / Battery / Low battery | |
| Operating modes | Normal / Stabilisation (AVR) / Battery / Fault | |
| Functions | Cold start (starting from batteries) | Yes |
| Automatic re-start | Yes, after the end of back up time | |
| USB Charger | Quantity | 2 Ports |
| Voltage | 5 Vdc | |
| Maximum current | 2.0 A | |
| General | Operating temperature | 0ºC - 40ºC |
| Relative humidity | Up to 90%, non-condensing | |
| Noise level at 1 metre | < 45 dB | |
| Dimensions (D x W x H mm) | 364 x 139 x 195 | |
| Weight | 11.00Kg | |
| Standards | Safety | EN 62040-1-1; EN-60950-1 |
| Electromagnetic compatibility (EMC) | EN 62040-2 | |
| Operation | EN 62040-3 | |
| Quality & Environmental Management | ISO-9001 and ISO-14001 | |
Salicru's SPS 2200 SOHO+ IEC 2200VA UPS stands out for their Line-interactive technology, compatibility with APFC (active power factor correction) loads and their dual USB charger on the front.
Line-interactive systems use AVR (buck-boost), automatic voltage regulators, to reduce possible fluctuations in input voltage, thereby lowering battery use, extending battery life and providing maximum backup if necessary.
Salicru's SPS SOHO+ series UPS systems are ideal for the protection of computer/office environments from single-user management, design or communications stations to small networks composed of one server, various workstations and all associated peripherals. At the same time, they allow the charging of mobile devices through the two built-in USB ports. They are therefore suitable for shops, self-employed professionals, small offices, franchises, dealers, etc.
They also feature a USB interface with HID protocol for control, parameter setting and computer shutdown/hibernation. Also available is a software package for the management and monitoring of associated environments, including virtualised systems.
UPS monitoring and management software, allowing the orderly closing of files and programs in the event of prolonged power cuts. Valid for Windows, Unix, Linux and Mac. The latest version of this software can be downloaded from the Salicru website.
