High-density security in 1U rack format
Salicru's SPS Advance R series UPSs feature line-interactive technology (AVR stabilisation with buck-boost regulation) and pure sine-wave output to power all kinds of critical load.
This technology enables a high level of efficiency to be achieved, providing significant savings in the total consumption of the rack. Also noteworthy is their compatibility with current APFC (active power factor correction) power supplies.
In terms of communications, the options are through the RS-232 interface and management and monitoring software for Windows, Linux and Mac systems, or through the available adapters (SNMP/Web adapter) to be inserted into the smart slot that the devices incorporate.
Features
Line-interactive technology with AVR stabilisation(buck-boost).
Pure sine wave.
Ultra-compact 1U rack format.
Efficiency of up to 98%.
Compatible with APFC power supplies.
LCD display + keys for operation and information.
Smart slot for SNMP/potential-free contacts/Modbus.
RS-232 communication interface.
Downloadable monitoring and management software for Windows, Linux and Mac.
IEC output sockets.
Automatic battery test on each start-up.
Cold-start function for start-up from batteries.
SLC Greenergy solution.
Display
Level of battery available.
Values for input/battery/backup.
Values for output/charging.
Level of load connected.
Normal operation.
Battery operation (AC power outage).
Device fault.
Audible alarm and alarm cancellation.
Applications
Specially designed for installation on racks with high occupancy density, Salicru’s SPS ADVANCE R series UPSs, thanks to their height of only one U, enable space to be freed up for other devices. In addition, their IEC sockets facilitate the connection of all computing environment elements.
Connections
Input socket with fuse.
Output sockets (4 x IEC13).
Intelligent slot for SNMP/web adapter.
RS-232 interface.
Emergency power off (EPO).
Software
UPS monitoring and management software for closing files and applications. Compatible with Windows, Linux and Mac.
Technical Specification
MODEL
SPS 750 ADVANCE R
UPS Power (VA / W)
750 / 450
Technology
Line-interactive
Format
1U rack
Outlets
AC outlets
4 x power IEC 60320 C13
AC outlet type
IEC 60320 C13
Input
Rated Voltage
230 V
Voltage range
165 - 290 V up to 100% load
Stabiliser
AVR (buck-boost)
Frequency
50 / 60 Hz ±5%
Input protection
Fuse
Output
Rated voltage
230 V
Voltage accuracy (battery mode)
±10%
Waveform
Pure sine wave
Total harmonic distortion (THDv)
≤5% linear load;
≤10% non-linear load
Admissible overload
Line mode
110% for 1 min / 130% immediate
Battery mode
110% for 1 min / 130% immediate
Compatible with APFC loads
Yes (1)
Protection
Overload, short circuit and over discharge and battery charging
Efficiency
On-line mode
>95%
Stabiliser mode (AVR)
>92%
Battery mode
>80%
Battery
Battery type
Pb-Ca sealed, AGM, maintenance-free
Protection
Internal current limitation
Battery test
Automatic on each start-up + manual
Battery replacement by the user
Yes
Charging
Charge type
I/U (constant current/constant voltage)
Recharge time
4 hours to 90%
Communication
Interface
RS-232
Smart slot for SNMP / potential-free contacts / MODBUS
Yes
Downloadable monitoring software
For Windows, Linux and Mac
Warnings
LCD + keypad
Yes, multifunction screen
Displayed values
Input and output voltage / % load / % battery / backup
Levels
Connected load / overload / battery / low battery
Alarm
Battery / low battery / overload / failure
Other Functions
Cold start (start-up from batteries)
Yes
Emergency power off (EPO)
Yes
General
Operating temperature
0ºC - 40ºC
Relative humidity
Up to 95%, non-condensing
Noise level at 1 metre
Less 40 dB
Dimensions (D x W x H mm)
216 x 433 x 44
Weight
8.60Kg
Standards
Safety
EN 62040-1
Electromagnetic compatibility (EMC)
EN 62040-3
Operation
EN 62040-3:2011
Quality & Environmental Management
ISO-9001 and ISO-14001
(1)Power degradation of 20%
