FEED UNIT CE
Clean Earth Feed Unit – Female – for use with Powertrack system.
Key Features
• End cap keyed for Red Track
• Press fit clip from power track for excellent earth bond
• Requires Tool to remove from track
• Single 20mm knockout for power cable
• Twin earth (to ground) terminals
Code
UN3200
Pack
1
Colour
Silver
Version
Clean Earth
Variation
Feed Unit
Recycled PVC-U Content
N/A
Dimensions
81mm wide x 162mm long x 44mm high
Materials
Galvanised steel case, Copper bars, Flame retardant PC and PBT mouldings
Compliance / Standards
CE & UKCA Marked
Low Voltage Directive 2014/35/EU
The Electrical Equipment (Safety) Regulations 2016
BS 7671:2018
BS EN 61534-1:2011+A1:2014
BS EN 61534-22:2014
All Plastics are UL94-V0 rated and pass IEC
60695-2 glow wire test at 850°C
Rated voltage (Un)
230 volts
Operating voltage range
50 – 253V
Rated load current
63A Amps
Full specification and details can be found in the Product Datasheet PDF file
Additional details can be found in the Product Catalogue PDF file
TAP-OFF UNIT STD 32A
Standard Tap-off unit. Unfused 32Amp, Length 3m / 5m for use with Powertrack system.
Key Features
• Fused and unfused options
• Keyed to fit Grey power track only
• Press fit clip for excellent earth bond
• Requires Tool to remove from track
UN7113
UN7115
Version
Standard
Standard
Variation
Tap-off
Tap-off
Colour
Silver
Silver
Pack
1
1
Dimensions
Tap-off head 33mm high x 80mm long x 61mm wide
Tap-off head 33mm high x 80mm long x 61mm wide
Materials
Galvanised steel Conduit, PVC BASEC 4mm² cable, Copper Contacts and Polycarbonate Housing / Nylon 6 MT32
Galvanised steel Conduit, PVC BASEC 4mm² cable, Copper Contacts and Polycarbonate Housing / Nylon 6 MT32
Compliance / Standards
CE & UKCA Marked
Low Voltage Directive 2014/35/EU
The Electrical Equipment (Safety) Regulations 2016
BS 7671:2018
BS EN 61534-1:2011+A1:2014
BS EN 61534-22:2014
All Plastics are UL94-V0 rated and pass IEC
60695-2 glow wire test at 850°C
CE & UKCA Marked
Low Voltage Directive 2014/35/EU
The Electrical Equipment (Safety) Regulations 2016
BS 7671:2018
BS EN 61534-1:2011+A1:2014
BS EN 61534-22:2014
All Plastics are UL94-V0 rated and pass IEC
60695-2 glow wire test at 850°C
Rated voltage (Un)
230 volts
230 volts
Operating voltage range
50 – 253V
50 – 253V
Rated Current
63A
63A
Full specification and details can be found in the Product Datasheet PDF file
Additional details can be found in the Product Catalogue PDF file
Length: |
TAP-OFF UNIT STD FUSED 13A
Standard Tap-off unit. Fused 13Amp, Length 3m / 5m for use with Powertrack system.
Key Features
• Fused and unfused options
• Keyed to fit Grey power track only
• Press fit clip for excellent earth bond
• Requires Tool to remove from track
UN7123
UN7125
Version
Standard
Standard
Variation
Tap-off
Tap-off
Colour
Silver
Silver
Pack
1
1
Dimensions
Tap-off head 33mm high x 80mm long x 61mm wide
Tap-off head 33mm high x 80mm long x 61mm wide
Materials
Galvanised steel Conduit, PVC BASEC 4mm² cable, Copper Contacts and Polycarbonate Housing / Nylon 6 MT32
Galvanised steel Conduit, PVC BASEC 4mm² cable, Copper Contacts and Polycarbonate Housing / Nylon 6 MT32
Compliance / Standards
CE & UKCA Marked
Low Voltage Directive 2014/35/EU
The Electrical Equipment (Safety) Regulations 2016
BS 7671:2018
BS EN 61534-1:2011+A1:2014
BS EN 61534-22:2014
All Plastics are UL94-V0 rated and pass IEC
60695-2 glow wire test at 850°C
CE & UKCA Marked
Low Voltage Directive 2014/35/EU
The Electrical Equipment (Safety) Regulations 2016
BS 7671:2018
BS EN 61534-1:2011+A1:2014
BS EN 61534-22:2014
All Plastics are UL94-V0 rated and pass IEC
60695-2 glow wire test at 850°C
Rated voltage (Un)
230 volts
230 volts
Operating voltage range
50 – 253V
50 – 253V
Rated Current
63A
63A
Full specification and details can be found in the Product Datasheet PDF file
Additional details can be found in the Product Catalogue PDF file
Length: |
TAP-OFF UNIT CE 32A
Clean Earth Tap-off unit. Unfused 32Amp, Length 3m / 5m for use with Powertrack system.
Key Features
• Fused and unfused options
• Keyed to fit Grey power track only
• Press fit clip for excellent earth bond
• Requires Tool to remove from track
UN7213
UN7215
Version
Clean Earth
Clean Earth
Variation
Tap-off
Tap-off
Colour
Silver
Silver
Pack
1
1
Dimensions
Tap-off head 33mm high x 80mm long x 61mm wide
Tap-off head 33mm high x 80mm long x 61mm wide
Materials
Galvanised steel Conduit, PVC BASEC 4mm² cable, Copper Contacts and Polycarbonate Housing / Nylon 6 MT32
Galvanised steel Conduit, PVC BASEC 4mm² cable, Copper Contacts and Polycarbonate Housing / Nylon 6 MT32
Compliance / Standards
CE & UKCA Marked
Low Voltage Directive 2014/35/EU
The Electrical Equipment (Safety) Regulations 2016
BS 7671:2018
BS EN 61534-1:2011+A1:2014
BS EN 61534-22:2014
All Plastics are UL94-V0 rated and pass IEC
60695-2 glow wire test at 850°C
CE & UKCA Marked
Low Voltage Directive 2014/35/EU
The Electrical Equipment (Safety) Regulations 2016
BS 7671:2018
BS EN 61534-1:2011+A1:2014
BS EN 61534-22:2014
All Plastics are UL94-V0 rated and pass IEC
60695-2 glow wire test at 850°C
Rated voltage (Un)
230 volts
230 volts
Operating voltage range
50 – 253V
50 – 253V
Rated Current
32A (Unfused)
32A (Unfused)
Full specification and details can be found in the Product Datasheet PDF file
Additional details can be found in the Product Catalogue PDF file
Length: |
TAP-OFF UNIT CE FUSED 13A
Clean Earth Tap-off unit. Fused 13Amp, Length 3m / 5m for use with Powertrack system.
Key Features
• Fused and unfused options
• Keyed to fit Grey power track only
• Press fit clip for excellent earth bond
• Requires Tool to remove from track
UN7223
UN7225
Version
Clean Earth
Clean Earth
Variation
Tap-off
Tap-off
Colour
Silver
Silver
Pack
1
1
Dimensions
Tap-off head 33mm high x 80mm long x 61mm wide
Tap-off head 33mm high x 80mm long x 61mm wide
Materials
Galvanised steel Conduit, PVC BASEC 4mm² cable, Copper Contacts and Polycarbonate Housing / Nylon 6 MT32
Galvanised steel Conduit, PVC BASEC 4mm² cable, Copper Contacts and Polycarbonate Housing / Nylon 6 MT32
Compliance / Standards
CE & UKCA Marked
Low Voltage Directive 2014/35/EU
The Electrical Equipment (Safety) Regulations 2016
BS 7671:2018
BS EN 61534-1:2011+A1:2014
BS EN 61534-22:2014
All Plastics are UL94-V0 rated and pass IEC
60695-2 glow wire test at 850°C
CE & UKCA Marked
Low Voltage Directive 2014/35/EU
The Electrical Equipment (Safety) Regulations 2016
BS 7671:2018
BS EN 61534-1:2011+A1:2014
BS EN 61534-22:2014
All Plastics are UL94-V0 rated and pass IEC
60695-2 glow wire test at 850°C
Rated voltage (Un)
230 volts
230 volts
Operating voltage range
50 – 253V
50 – 253V
Rated Current
32A (Unfused)
32A (Unfused)
Full specification and details can be found in the Product Datasheet PDF file
Additional details can be found in the Product Catalogue PDF file
Length: |
Powertrack Interlink CE
Interlink Clean Earth – Length 1.2m / 2.4m for use with Powertrack system.
Key Features
• Keyed to fit Grey powertrack only
• Press fit clip for excellent earth bond
• Requires Tool to remove from track
UN5202
UN5204
Version
Clean Earth
Clean Earth
Variation
Interlink
Interlink
Colour
Silver
Silver
Pack
1
1
Dimensions
81mm wide x 162mm long x 44mm high
81mm wide x 162mm long x 44mm high
Materials
Galvanised steel Conduit, PVC BASEC 4mm² cable, Galvanised steel Case, Copper Contacts with PC & PBT mouldings
Galvanised steel Conduit, PVC BASEC 4mm² cable, Galvanised steel Case, Copper Contacts with PC & PBT mouldings
Compliance / Standards
CE & UKCA Marked
Low Voltage Directive 2014/35/EU
The Electrical Equipment (Safety) Regulations 2016
BS 7671:2018
BS EN 61534-1:2011+A1:2014
BS EN 61534-22:2014
All Plastics are UL94-V0 rated and pass IEC
60695-2 glow wire test at 850°C
CE & UKCA Marked
Low Voltage Directive 2014/35/EU
The Electrical Equipment (Safety) Regulations 2016
BS 7671:2018
BS EN 61534-1:2011+A1:2014
BS EN 61534-22:2014
All Plastics are UL94-V0 rated and pass IEC
60695-2 glow wire test at 850°C
Rated voltage (Un)
230 volts
230 volts
Operating voltage range
50 – 253V
50 – 253V
Rated Current
63A
63A
Full specification and details can be found in the Product Datasheet PDF file
Additional details can be found in the Product Catalogue PDF file
Length: |
Powertrack Interlink STD
Interlink Standard – Length 1.2m / 2.4m for use with Powertrack system.
Key Features
• Keyed to fit Grey powertrack only
• Press fit clip for excellent earth bond
• Requires Tool to remove from track
UN5102
UN5104
Version
Standard
Standard
Variation
Interlink
Interlink
Colour
Silver
Silver
Pack
1
1
Recycled PVC-U Content
N/A
N/A
Materials
Galvanised steel Conduit, PVC BASEC 4mm² cable, Galvanised steel Case, Copper Contacts with PC & PBT mouldings
Galvanised steel Conduit, PVC BASEC 4mm² cable, Galvanised steel Case, Copper Contacts with PC & PBT mouldings
Compliance / Standards
CE & UKCA Marked
Low Voltage Directive 2014/35/EU
The Electrical Equipment (Safety) Regulations 2016
BS 7671:2018
BS EN 61534-1:2011+A1:2014
BS EN 61534-22:2014
All Plastics are UL94-V0 rated and pass IEC
60695-2 glow wire test at 850°C
CE & UKCA Marked
Low Voltage Directive 2014/35/EU
The Electrical Equipment (Safety) Regulations 2016
BS 7671:2018
BS EN 61534-1:2011+A1:2014
BS EN 61534-22:2014
All Plastics are UL94-V0 rated and pass IEC
60695-2 glow wire test at 850°C
Rated voltage (Un)
230 volts
230 volts
Operating voltage range
50 – 253V
50 – 253V
Rated Current
63A
63A
Full specification and details can be found in the Product Datasheet PDF file
Additional details can be found in the Product Catalogue PDF file
Length: |
