Marshall Tufflex In-screed Flooring System

SCREED FLOOR DUCTING 75X25MM

Twin section PVC-U duct (three ducts required per run) for use with In-Screed Flooring System.

A range of floor outlet boxes, fittings and plates in galvanised steel, with choice of PVC-U or steel ducting designed to be positioned within screed flooring.

Code MTU125 Size 75 x 25mm Pack 8 x 3m Recycled PVC-U Content N/A
Full specification and details can be found in the Product Datasheet PDF file

POWERTRACK STD 300P

Powertrack Standard for use with Powertrack range. To calculate Powertrack lengths required for different floor layouts refer to the brochure. We recommend that no single run of Powertrack exceeds 20 metres.

A range of 63Amp powertrack complete with integral mounting brackets and pre-assembled end caps and couplers for ease of installation.


Product information Each length of track comes complete with pre-assembled coupler, end cap and floor mounting brackets.

Maximum 63Amp rating

Tap-offs are key and colour coded for Standard and CE (Clean Earth)

Tap-offs are 32Amp rated or fused at 13Amp

Adhesive dust covers protect outlets

Compatible with MT32 pre-wired floor boxes


UN1112 UN1118 UN1114 UN1116 Version Standard Standard Standard Standard Length 1.2m 1.8m 2.4m 3.6m Colour Silver Silver Silver Silver Material Galvanised Steel Galvanised Steel Galvanised Steel Galvanised Steel Pack 2 2 2 2 Recycled PVC-U Content N/A N/A N/A N/A
Full specification and details can be found in the Product Datasheet PDF file

POWERTRACK CE 300P

STEEL DUCT 3 COMP 2.5M

3 compartment steel duct for use with In-Screed Flooring System.

A range of floor outlet boxes, fittings and plates in galvanised steel, with choice of PVC-U or steel ducting designed to be positioned within screed flooring.


Code USFT25 Size 225 x 25mm Pack 1 x 2.5m Recycled PVC-U Content N/A
Full specification and details can be found in the Product Datasheet PDF file
