FEED UNIT CE
Clean Earth Feed Unit – Female – for use with Powertrack system.
• End cap keyed for Red Track
• Press fit clip from power track for excellent earth bond
• Requires Tool to remove from track
• Single 20mm knockout for power cable
• Twin earth (to ground) terminals
Code | UN3200 |
Pack | 1 |
Colour | Silver |
Version | Clean Earth |
Variation | Feed Unit |
Recycled PVC-U Content | N/A |
Dimensions | 81mm wide x 162mm long x 44mm high |
Materials | Galvanised steel case, Copper bars, Flame retardant PC and PBT mouldings |
Compliance / Standards | CE & UKCA Marked Low Voltage Directive 2014/35/EU The Electrical Equipment (Safety) Regulations 2016 BS 7671:2018 BS EN 61534-1:2011+A1:2014 BS EN 61534-22:2014 All Plastics are UL94-V0 rated and pass IEC 60695-2 glow wire test at 850°C |
Rated voltage (Un) | 230 volts |
Operating voltage range | 50 – 253V |
Rated load current | 63A Amps |
Full specification and details can be found in the Product Datasheet PDF file
Additional details can be found in the Product Catalogue PDF file
