Netgear Auxilliary Power Supply and RPS Unit

NETGEAR ProSAFE Modular Power Supply Unit 150W AC (APS150W) is compatible with select Managed Switches such as M4300-28G (GSM4328S) and M4300-52G (GSM4352S). These M4300 series switches come with one PSU pre-installed. These M4300 series switches come with one PSU pre-installed. Another APS150W in second PSU bay can be combined for 1+1 power redundancy or 1+1 power expansion. Features: Additional PSU for M4300-28G and M4300-52G
C14 connector
Capacity: 110V-240V AC power input. Up to 150W output power at 110/220V AC

NETGEAR ProSAFE Modular Power Supply Unit 250W AC (APS250W) is compatible with select Managed Switches such as M4300-8X8F (XSM4316S), M4300-12X12F (XSM4324S) and M4300-24X24F (XSM4348S). These M4300 series switches come with one PSU pre-installed. Another APS250W in full-width models second PSU bay can be combined for 1+1 power redundancy or 1+1 power expansion. Features: Additional PSU for M4300-8X8F, M4300-12X12F and M4300-24X24F
C14 connector
Capacity: 110V-240V AC power input
Up to 250W output power at 110/220V AC

Provides a second power supply to M4300 series (1G PoE models), and additional power modules to M6100 Chassis Switches and RPS4000 external RPS/EPS unit.
Additional PSU for M4300-28G-PoE+ (GSM4328PB) and M4300-52G-PoE+ (GSM4352PB)
Additional PSU for M6100 Chassis switches
Power module for RPS4000 and RPS4000v2 external RPS/EPS units
C15 connector
Capacity:
110V-240V AC power input
Up to 640W output power at 110V AC
Up to 910W output power at 220V AC

Additional 1U power shelf (RPS/EPS unit with four open power supply slots)

Compatible with M4300-96X models (XSM4396K0, XSM4396K1). The NETGEAR M4300-96X is a 2RU modular switch that comes either empty or pre-populated with 48 SFP+ ports and supporting up to 96-port 10GBASE-T copper (RJ-45) with first 48 ports capable of PoE+, 96-port 10GBASE-X fiber (SFP+), 24-port 40GBASE-X fiber (QSFP+), or a combination. The M4300 family provides world-class services for server and storage interconnect, mid-enterprise edge and SMB core. SDVoE-Ready, M4300 switches streamline AV-over-IP deployments with Zero Touch multicast. Layer 3 feature set includes static, policy-based and dynamic routing as standard.

NETGEAR ProSAFE Modular Power Supply Unit 550W AC (APS550W) is compatible with select Managed Switches such as M4300-28G-PoE+ (GSM4328PA) and M4300-52G-PoE+ (GSM4352PA). These M4300 series switches come with one PSU pre-installed. Another APS550W in second PSU bay can be combined for 1+1 power redundancy or 1+1 power expansion. Features: Additional PSU for M4300-28G-PoE+ (GSM4328PA) and M4300-52G-PoE+ (GSM4352PA)
C14 connector
Capacity: 110V-240V AC power input
Up to 575W output power at 110/220V AC

Compatible with M4300-96X models (XSM4396K0, XSM4396K1). The NETGEAR M4300-96X is a 2RU modular switch that comes either empty or pre-populated with 48 SFP+ ports and supporting up to 96-port 10GBASE-T copper (RJ-45) with first 48 ports capable of PoE+, 96-port 10GBASE-X fiber (SFP+), 24-port 40GBASE-X fiber (QSFP+), or a combination. The M4300 family provides world-class services for server and storage interconnect, mid-enterprise edge and SMB core. SDVoE-Ready, M4300 switches streamline AV-over-IP deployments with Zero Touch multicast. Layer 3 feature set includes static, policy-based and dynamic routing as standard.

Powered by the industry’s first flexible PoE+ integrated technology, you can increase or decrease the PoE budget by simply buying a new power supply, effectively future proofing small business networks and budgets. Reliable power adapter with 90W
Compatible with NETGEAR products for GS108LP, GS108PP, GS116LP and GS116PP
Power Input: 110V-240V ~ 50/60Hz
Power Output: 54V @ 1.66A
DC Connector
OVP, OCP, SCP Protection (OVP: Over Voltage output Protection. OCP: Over Current output Protection. SCP: Short Circuit output Protection) Green design to meets LV6 Energy Star ratings
UL /FCC, RCM, CE EMC, PSE, CB, KCC, BIS, BSMI certified
This product is backed by a NETGEAR limited 2-year Hardware Warranty. 24/7 basic technical support provided for 90 days from purchase date, when purchased from Comms-Express
Switch Model Power Adapter Model Power Adapter Wattage PoE+ Power Wattage GS108LP
(comes w/ 67.5 W PA) EPS90W
EPS130W 90W
130W 83W
123W GS108PP
(comes w/ 130 W PA) EPS90W
EPS130W 90W
130W 83W
123W GS116LP
(comes w/ 90 W PA) EPS90W
EPS130W
EPS200W 90W
130W
200W 76W
115W
183W GS116PP
(comes w/ 200 W PA) EPS90W
EPS130W
EPS200W 90W
130W
200W 76W
115W
183W

Powered by the industry’s first flexible PoE+ integrated technology, you can increase or decrease the PoE budget by simply buying a new power supply, effectively future proofing small business networks and budgets. Reliable power adapter with 130W
Compatible with NETGEAR products for GS108LP, GS108PP, GS116LP and GS116PP
Power Input: 110V-240V ~ 50/60Hz
Power Output: 54V @ 2.4A
DC Connector
OVP, OCP, SCP Protection (OVP: Over Voltage output Protection. OCP: Over Current output Protection. SCP: Short Circuit output Protection) Green design to meets LV6 Energy Star ratings
UL /FCC, RCM, CE EMC, PSE, CB, KCC, BIS, BSMI certified
This product is backed by a NETGEAR limited 2-year Hardware Warranty. 24/7 basic technical support provided for 90 days from purchase date, when purchased from Comms-Express
Switch Model Power Adapter Model Power Adapter Wattage PoE+ Power Wattage GS108LP
(comes w/ 67.5 W PA) EPS90W
EPS130W 90W
130W 83W
123W GS108PP
(comes w/ 130 W PA) EPS90W
EPS130W 90W
130W 83W
123W GS116LP
(comes w/ 90 W PA) EPS90W
EPS130W
EPS200W 90W
130W
200W 76W
115W
183W GS116PP
(comes w/ 200 W PA) EPS90W
EPS130W
EPS200W 90W
130W
200W 76W
115W
183W

Powered by the industry’s first flexible PoE+ integrated technology, you can increase or decrease the PoE budget by simply buying a new power supply, effectively future proofing small business networks and budgets. Reliable power adapter with 200W
Compatible with NETGEAR products for GS116LP and GS116PP
Power Input: 110V-240V ~ 50/60Hz
Power Output: 54V @ 3.7A
DC Connector
OVP, OCP, SCP Protection (OVP: Over Voltage output Protection. OCP: Over Current output Protection. SCP: Short Circuit output Protection) Green design to meets LV6 Energy Star ratings
UL /FCC, RCM, CE EMC, PSE, CB, KCC, BIS, BSMI certified
This product is backed by a NETGEAR limited 2-year Hardware Warranty. 24/7 basic technical support provided for 90 days from purchase date, when purchased from Comms-Express
Switch Model Power Adapter Model Power Adapter Wattage PoE+ Power Wattage GS108LP
(comes w/ 67.5 W PA) EPS90W
EPS130W 90W
130W 83W
123W GS108PP
(comes w/ 130 W PA) EPS90W
EPS130W 90W
130W 83W
123W GS116LP
(comes w/ 90 W PA) EPS90W
EPS130W
EPS200W 90W
130W
200W 76W
115W
183W GS116PP
(comes w/ 200 W PA) EPS90W
EPS130W
EPS200W 90W
130W
200W 76W
115W
183W
