MikroTik RouterBoards and Enclosures

A black aluminium indoor case with installation kit.

Compatible with the RB450, RB450G, RB450Gx4 and RB850Gx2

Product specifications:

Product code: CA150
Material: Aluminium
Color: Black
Purpose: Indoor

Image showing Routerboard in the case is for illustration purposed only, Routerboard is not included

The MikroTik CA411-711 is new indoor case for RB411, RB711 and RB911/2 series RouterBoards.

It has changeable front panels, so you can choose one that fits the product that you actually use. Also, case is taller to accommodate high-power wireless cards and has wall mounting holes on the back.



Dimensions: 18cm x 12cm x 4cm

Small Outdoor case (one Ethernet insulator)

Mounting set included.



Internal Dimensions: 175mm x 141mm x 35mm
Fits RB411 and RB711 series products

The MikroTik RBM33G is a fully featured RouterBOARD device perfect for use in your own custom solution/installation. The RBM33G uses the same PCB form factor and mounting points as its predecessors the RB433 and RB953 series RouterBOARDs.

The RBM33G features a brand new dual-core CPU running at 880 MHz and 256 MB of DDR3 RAM, along with three gigabit ethernet ports. The M33G is specially designed for setups that require multiple 3G/LTE modems. The additional miniPCIe and USB slots gives added flexibility allowing scenarios like the following:

Running two miniPCIe 3G/LTE modems (two SIM slots provided)
Using one miniPCIe and One USB 3G/LTE modem leaving other miniPCIe slot available for an 802.11 wireless card
The USB 2.0/3.0 port can even be used for an external hard drive. To expand storage, microSD and PCIe M.2 slots are also provided. The 33G comes fitted with a RS232 serial port for console access and can be powered by 24V passive PoE through its gigabit ethernet port or with a DC PSU through the DC power jack.



MikroTik RBM33G Specifications:

Product code: RBM33G
Architecture: MMIPS
CPU: MT7621A
CPU core count: 2
CPU nominal frequency: 880 MHz
CPU Threads count: 4
License level: 4
RAM: 256 MB
Storage size: 16 MB
Storage type: FLASH
Max Power consumption: 19W
Number of DC inputs: 2 (DC jack, PoE-IN)
PoE in: Passive PoE
DC jack input Voltage: 11-30 V
PoE in input Voltage: 11-30 V
10/100/1000 Ethernet ports: 3
Number of SIM slots: 2 Modem (Mini SIM)
M.2 slots: 1
MiniPCI-e slots: 2
Number of USB ports: 1
Serial port: RS232
USB Power Reset: Yes
USB slot type: USB 3.0 type A
PCB temperature monitor: Yes
Voltage Monitor: Yes

911 Lite5 dual - 600Mhz CPU, 64MB RAM, 1xEthernet, onboard 5Ghz Dual chain wireless, RouterOS L3

Perfect for building low cost CPE devices. The RB911-5Hn is a small CPE type RouterBOARD wireless router with an integrated 5Ghz single cahin wireless card. It's equipped with powerful 600Mhz CPU, providing superb value for money.


MikroTik RB911-5Hn Specifications:



10/100 Ethernet ports: 1
10/100/1000 Ethernet ports: None
Antenna gain: No
Architecture: MIPSBE
CPU: AR9344
CPU core count: 1
CPU nominal frequency: 600 MHz
Dimensions: 105x105mm
Ethernet Combo ports: 0
License level: 3
Max power consumption: 5W
Number of DC inputs: 1
Number of SIM slots: 0
Number of USB ports: 0
Operating System: RouterOS
PoE in: Passive PoE
PoE in input Voltage: 8-30 V
SFP ports: None
SFP+ ports: None
RAM: 64 MB
Storage size: 16 MB
Wireless 1 band: 5 GHz
Wireless 1 Number of chains: 1

The RB911G-2HPnD is a small wireless router with an integrated high power 2.4GHz wireless card. The Gigabit port helps to utilise the full potential of 802.11n wireless speeds.

The integrated wireless card is capable of up to 1000mW output power. It has built in 16kV ESD protection on both the Ethernet and the MMCX ports.

MikroTik RB911G-2HPnD Specifications:



10/100 Ethernet ports: None
10/100/1000 Ethernet ports: 1
Antenna gain: No
Architecture: MIPSBE
CPU: AR9342
CPU core count: 1
CPU nominal frequency: 600 MHz
DC jack input Voltage: 6-30 V
Dimensions: 105x105mm
Ethernet Combo ports: 0
License level: 3
Max power consumption: 10W
Number of DC inputs: 2
Number of SIM slots: 0
Number of USB ports: 0
Operating System: RouterOS
PoE in: Passive PoE
PoE in input Voltage: 6-30 V
SFP ports: None
SFP+ ports: None
RAM: 64 MB
Storage size: 128 MB
Wireless 1 band: 2.4 GHz
Wireless 1 Number of chains: 2

The RB911 is a small wireless router with an integrated 5Ghz high power wireless card. The Gigabit port helps to utilise the full potential of 802.11n wireless speeds.

The integrated wireless card is capable of up to 1000mW output power. It has built in 16kV ESD protection on both the Ethernet and the MMCX ports.

Specifications:



Product code: RB911G-5HPnD
CPU speed: 600MHz
CPU cores: 1
RAM: 32MB
LAN ports: 1
Gigabit: Yes
MiniPCI: 0
Integrated Wireless: yes
Wireless standards: 802.11an
Power Jack: Yes
PoE: Yes
Dimensions: 105x105mm
Operating System: RouterOS
Temperature range: -35C to +65C
RouterOS License: L3
TX power: 30dBm
CPU: AR9342
Max Power consumption: 11W at 24V

MikroTik RouterBoard 911 Lite 2 Board Only - RB911-2Hn

The RB911-2Hn is a small CPE type RouterBOARD wireless router with an integrated 2Ghz single chain wireless card. It's equipped with powerful 600Mhz CPU, providing superb value for money.

Specifications:



Product code: RB911-2Hn
Architecture: MIPSBE
CPU: AR9344
CPU core count: 1
CPU nominal frequency: 600 MHz
Dimensions: 105mm x 105mm
Operating System: RouterOS - Licence Level 3
RAM: 64 MB
Storage size: 16 MB
Storage type: FLASH
MTBF: Approximately 100'000 hours at 25°C
Tested ambient temperature: -40°C to +70°C
Max power consumption: 4 W
FAN: Passive
Number of DC inputs: 1 (PoE-IN)
PoE input Voltage:  10-30V
PoE in: Passive PoE

The RB912UAG-2HPnD is very versatile device. It's small wireless router with an integrated 2.4GHz high power wireless card and an additional miniPCIe slot for 802.11 wireless, or 3G card. The Gigabit port helps to utilise the full potential of 802.11n wireless speeds.

The integrated wireless card is capable of up to 1000mW output power. It has built in 16kV ESD protection on both the Ethernet and the MMCX ports

MikroTik RB912UAG-2HPnD Specifications:



10/100 Ethernet ports: None
10/100/1000 Ethernet ports: 1
Antenna gain: No
Architecture: None
CPU: AR9342
CPU core count: 1
CPU nominal frequency: 600 MHz
DC jack input Voltage: 8-30 V
Dimensions: 105mm x 105mm
Ethernet Combo ports: 0
License level: 4
Max power consumption: 13.5 W
Number of DC inputs: 2
Number of SIM slots: 1
Number of USB ports: 1
Operating System: RouterOS
PoE in: Passive PoE
PoE in input Voltage: 8-30V
SFP ports: None
SFP+ ports: None
RAM: 64 MB
Storage size: 128 MB
USB slot type: USB type A
Wireless 1 band: 2.4 GHz
Wireless 1 Number of chains: 2

The RB912UAG-5HPnD is a very versatile device. It's a small wireless router with an integrated high power wireless card and an additional miniPCIe slot for 802.11 wireless, or 3G card. The Gigabit port helps to utilise the full potential of 802.11n wireless speeds.

The integrated wireless card is capable of up to 1000mW output power. It has built in 16kV ESD protection on both the Ethernet and the MMCX ports.

MikroTik RB912UAG-5HPnD Specifications:



Architecture: MIPSBE
Boot Loader: RouterBOOT
CPU core count: 1
CPU nominal frequency: 600 MHz
CPU: AR9342
Data Storage: onboard NAND memory chip
DC jack input Voltage: 8-30V
Dimensions: 105 x 105mm
Ethernet: One Gigabit port with Auto-MDI/X
Expansion: miniPCIe slot for 802.11 or 3G (using 3G disables the USB port), USB 2.0 port
Extras: reset, beeper, signal and status LEDs, SIM slot (requires 3g miniPCIe card)
LED's: Power, NAND Activity, 5 Ethernet LED's
Operating System: RouterOS
License level: 4
Max power consumption: 12 W
Memory Cards: No
Number of DC inputs: 2
Number of SIM slots: 1
Number of USB ports: 1
PoE in Passive PoE
Power Consumption: Up to 14W at 24V
Power over Ethernet: 8-30V DC on Ether1 (Non 802.3af)
RAM: 64 MB
Storage size: 128 MB
Transmit Power: up to +30dBm (1W)
USB slot type: USB type A
Wireless 1 band: 5 GHz
Wireless 1 Number of chains: 2
Wireless: Built in 5GHz 802.11a/n, 2x MMCX connectors

The RouterBOARD RB922UAGS-5HPacD is a very versatile wireless router, perfect for assembling your own solution. It supports the new 802.11ac standard for high speed wireless (up to 866Mbit data rate and 20/40/80MHz channels).

The device has ports and slots for many uses: 1x SFP cage, miniPCIe slot with SIM for 3G/4G modem or another wireless card, USB port, Gigabit Ethernet port and two MMCX connectors for the built in powerful 1300mW 802.11ac 2x2 radio. Comes with RouterOS L4 (AP) licence.

MikroTik RB922UAGS-5HPacD Specifications:

10/100/1000 Ethernet ports: 1
Architecture: MIPSBE
CPU core count: 1
CPU nominal frequency: 720 MHz
CPU: QCA9557-AT4A-R
DC jack input Voltage: 8-30V
Dimensions: 105mm x 105mm
Max power consumption: 17 W
MiniPCI-e slots: 1
Number of chains: 2
Number of DC inputs: 2
Number of SIM slots: 1
Number of USB ports: 1
Operating System: RouterOS - License level 4
Operating temperature range: -40°C to +70°C tested
PCB temperature monitor: Yes
PoE in input Voltage: 8-30V
PoE in: Passive PoE
PoE out: No
Power Jack: 1
RAM: 128 MB
SFP DDMI: yes
SFP ports: 1
SFP+ ports: None
USB slot type: USB type A
Voltage Monitor: Yes
Wireless 1 band: 5 GHz
Wireless 1 Number of chains: 2
Wireless chip model: QCA9882-BR4A-R
Wireless standards: 802.11a/n/ac

The MikroTik RBM11G is a fully featured RouterBOARD device. Perfect for use with existing enclosures or building a custom solution. The M11G uses the same square PCB and mounting holes as its predecessors so you can simply swap out older models with the brand new RBM11G.

The M11 features a brand new MediaTek dual core CPU running at an impressive 880MHz, and a miniPCIe slot for use with a WiFi module of your choice, or with a 3G/ LTE modem (SIM slot provided). The 11G can be powered by 24V passive PoE through its gigabit ethernet port or through the DC power jack.

MikroTik RBM11G Specifications:



10/100/1000 Ethernet ports: 1
Architecture: MMIPS
CPU: MT7621A
CPU core count: 2
CPU nominal frequency: 880 MHz
DC jack input Voltage: 10 - 30V
Dimensions: 105mm x 110mm
Ethernet Combo ports: 0
Licence level: 4
Max power consumption: 11 W
Number of DC inputs: 2
Number of SIM slots: 1
Number of USB ports: 0
Operating System: RouterOS
PoE in: Passive PoE
PoE in input Voltage: 10V - 30V
SFP ports: None
SFP+ ports: None
RAM: 256 MB
Storage size: 16 MB
Wireless 1 Number of chains: 0

The new MikroTik SXT LTE Kit is a device designed for remote locations with limited connectivity but are within mobile network coverage. Thanks to its professional LTE chip design and high-gain antenna, it can provide stable connectivity for your building even where mobile phones can't.

The MikroTik SXT LTE Kit is powered by a faster CPU than its predecessor, it supports not only LTE with more speeds, but also 2G and 3G, as well as much wider band range.

The SXT LTE Kit is equipped with two Ethernet ports (the second port has PoE-out functionality), so you can use it to power up another device, ideal for dog-leg connections.

The LTE Kit is shipped with a 24V power supply, but can support a wide input range from 18-57V and is 802.3af/at compliant.

MikroTiks SXT LTE Kit has a built in high quality 2G/3G/4G/LTE Category 4 modem for speeds of up to 150 Mbit/s downlink and 50 Mbit/s uplink, as well as two Micro SIM slots for fail-over. The LTE modem supports International LTE bands 1, 2, 3, 7, 8, 20, 38 and 40.


MikroTik RBSXTR&R11e-LTE Specifications:

Architecture: MIPSBE
CPU: QCA9531
CPU core count: 1
CPU nominal frequency: 650 MHz
Dimensions: 140mm x 140mm x 103mm
License level: 3
Operating System: RouterOS
RAM: 64 MB
Storage: 16 MB
Storage type: FLASH
Tested ambient temperature: -40°C to +60°C
Max Power consumption: 6W
PoE in: 802.3af/at
PoE out: Passive PoE up to 57V
PoE in: input Voltage 18-57 V
Number of DC inputs: 1 (PoE-IN)
2G Category: Class 12
3G Category: R7 (21Mbps Downlinks, 5.76Mbps Uplink)
LTE Category: 4 (150Mbps Downlink, 50Mbps Uplink)
LTE FDD bands: 1 (2100MHz) / 2 (1900MHz) / 3 (1800MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz)
LTE TDD bands: 38 (2600MHz) / 40 (2300MHz)
LTE Antenna Gain: 9 dBi
10/100 Ethernet ports: 2
Number of SIM slots: 2 Modem (Micro SIM)
MiniPCI-e slots: 1

Thanks to its advanced LTE chip design and high gain antenna, the LTE6 Kit can capably provide connectivity for your home, business or even vehicle, where mobile phones and 4G dongles fail. The MikroTik SXT LTE6 kit is a CAT6 LTE device for remote/rural locations that are still within mobile network coverage.

The SXT LTE6 features a CAT6 LTE modem, allowing much higher speeds utilising mobile carrier aggregation. Carrier aggregation means the SXT can use multiple mobile bands at the same time. This also provides better responsiveness in a crowded environment and higher efficiency for weaker signal situations in the countryside.

LTE CAT6 can achieve speeds of up to 300 Mbps downlink and 50 Mbps uplink compared to a maximum of 150 Mbps downlink, 50 Mbps uplink on previous CAT4 devices.

Mikrotiks SXT LTE6 is equipped with two Ethernet ports. The secondary port features PoE-out functionality and can be used to power up other PoE compatible device. The unit also features two Micro SIM slots for fail-over. Shipped with a 24V UK power supply, it can support a wide voltage range from 18 to 57V and is 802.3af/at compliant.


MikroTik SXT LTE6 kit Specifications:



Architecture: MIPSBE
CPU: QCA9531
CPU core count: 1
CPU nominal frequency: 650 MHz
License level: 3
RAM: 64 MB
Storage: 16 MB
Storage type: FLASH
Tested ambient temperature: -30°C to +60°C
PoE in: 802.3af/at
PoE in: input Voltage 12-57 V
PoE out: Passive PoE up to 57V
PoE-out ports: Ether2
Number of DC inputs: 1 (PoE-IN)
Max out per port output (input > 30 V): 400 mA
Max out per port output (input < 30 V): 600 mA
Max total out: 600 mA
2G Category: Class12
3G Category: R7 (21Mbps Downlinks, 5.76Mbps Uplink) / R8 (42.2Mbps Downlink, 5.76Mbps Uplink)
LTE Category: 6 (300Mbit/s Downlink, 50Mbit/s Uplink)
LTE FDD bands: 1 (2100MHz) / 2 (1900MHz) / 3 (1800MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) /
5 (850MHz) / 12 (700MHz) / 17 (700MHz) / 25 (1900MHz) / 26 (850MHz)
LTE TDD bands: 38 (2600MHz) / 40 (2300MHz) / 39 (1900MHz) / 41n (2500MHz)
2G bands: 2 (1900MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)
3G bands: 1 (2100MHz) / 2 (1900MHz) / 5 (850MHz) / 8 (900MHz)
10/100 Ethernet ports: 2
Number of SIM slots: 2 Modem (Micro SIM)
MiniPCI-e slots: 1
Certification: CE/RED, EAC, ROHS

Radome Cover Kit is now available for our mANT 30dBi parabolic antennas!

It reduces wind load, protects reflector surfaces from harsh environment, protects the antenna feed from falling objects, as well as positively affects the antenna sustainability and operational life.

It's made from a special material that has a low dielectric constant. Wide range of temperature and direct sunlight won't affect it.

- Wind Load (125 mph) 50 kg at 40 m/s, 28 kg at 30 m/s
