MikroTik Routers

The MikroTik L009UIGS-2HAXD-IN is a high-performance 8-Port PoE WiFi 6 router, combining advanced technology for enhanced wireless connectivity. With eight PoE ports, it streamlines device deployment, ensuring optimal performance through dual-band connectivity and robust security features.

Features

Raw Power and Performance: L009 features a powerful dual-core ARM CPU, providing substantial improvements in routing, filtering, firewall rules, IPsec hardware encryption, and advanced RouterOS features. Modern ARM CPU architecture offers advantages over older MIPS-based devices, enabling the use of the latest Linux Kernel features and the implementation of custom container projects. Up to 4 times faster than RB2011 in most scenarios, with IPsec hardware encryption ensuring lower CPU usage without performance degradation. Expect 60-90 Mbps throughput using a 1400-byte packet size.
Connectivity and Ports: All ports are now Gigabit Ethernet ports, with PoE-In on the first port for powering the unit and PoE-Out on the last port for powering other devices. SFP cage supports both Gigabit and 2.5 Gigabit connectivity, offering versatility and compatibility with higher-speed MikroTik SFP modules and cables. Speedy Marvell Peridot Switchchip provides an impressive 2.5 Gigabit full duplex connection to the CPU, minimizing bottlenecks.
Wireless Connectivity: 2.4 GHz dual-chain wireless connectivity, based on the Generation 6 or the ax standard, offers up to 90% higher speed in the 2.4 GHz spectrum. Improved signal stability allows the router to handle more clients with better responsiveness.
Innovative Enclosure: The new enclosure, similar to the RB5009 devices, acts as a massive heat sink, preventing overheating and ensuring reliability. Accessories enable the fitting of up to four routers in a single 1U rackmount space, providing efficient space management.
Space-Efficient Rackmount Configuration: MikroTik suggests a space-saving configuration: Combine an RB5009 with PoE-Out ports and seven L009 routers in just two 1U rackmount spaces for efficient space management and reliable powering. A cost-effective alternative is the L009UiGS-RM, lacking 2.4 GHz wireless but retaining all other features and mounting accessories.
Specifications

Processing Power: ARM CPU, IPQ-5018, 2 cores, 800 MHz
Memory and Storage: 512 MB RAM, 128 MB NAND Storage
Wireless Connectivity: 574 Mbit/s 2.4 GHz, 802.11b/g/n/ax, AX600
Wired Networking: 8 Ethernet Ports (10/100/1000), 1 PoE-Out Port (1G)
Power and Consumption: 2 DC Inputs (DC jack, PoE-IN), 24-56 V Input Voltage, 47 W Max Power Consumption
Power over Ethernet (PoE): Ether8 PoE-Out Ports, 1.0 A Max Total Output
Certifications and Approvals: CE, FCC, IC, EAC, ROHS; IP 20
Operating System: RouterOS v7
Fiber Connectivity: 1 SFP Port (2.5G supported)
Peripherals: RJ45 Serial Console Port, 1 USB Port (USB 3.0 Type A)
*For complete specifications see the documentation tab above.

The MikroTik hAP AX lite LTE6 WiFi 6 Modem Router (L41G-2axD+FG621-EA) combines WiFi 6 technology with LTE6 connectivity for high-speed internet on the go, all within a compact and sleek design. Enjoy efficient processing, versatile wired networking, and easy setup, making it an ideal solution for modern connectivity needs.

Features

Built-in LTE Modem: The inclusion of a built-in LTE modem provides the freedom of mobile internet, allowing users to stay connected wherever they go. With consistent speeds of up to 300 Mbps and carrier aggregation support, it ensures reliable and high-speed connectivity.
Four Gigabit Ethernet Ports: The device comes equipped with four Gigabit Ethernet ports, making it suitable for Small Office/Home Office (SOHO) setups. This feature enables fast and stable wired connections for various devices.
Dual-Core ARM CPU and 256 MB RAM: The hAP ax lite LTE6 is powered by a speedy dual-core ARM CPU and 256 MB of RAM, providing a solid foundation for efficient data processing and improved overall performance.
2.4 GHz Wi-Fi 6 (802.11ax): The inclusion of 2.4 GHz Wi-Fi 6 with a dual-chain antenna (4.3 dBi) enhances wireless connectivity. The latest wireless chips optimize the 2.4 GHz spectrum, potentially increasing wireless speed by up to 90% depending on the overall setup.
LTE Freedom: The built-in CAT6 modem supports carrier aggregation, allowing devices to utilize multiple bands simultaneously. This feature is advantageous in areas with many LTE users, providing better responsiveness in crowded environments and higher efficiency in weaker signal situations, such as rural areas.
Project Discounts and Custom Branding: Volume orders are eligible for significant project discounts, and custom branding options are available. This makes the hAP ax lite LTE6 an even more cost-effective solution for large-scale deployments.
RouterOS 7: The device comes with all the extensive features of RouterOS 7, offering advanced capabilities such as secure VPN tunneling, bandwidth shaping, firewall, and user access control. Users have the flexibility to customize and optimize their network according to their specific needs.
Cost-Effective: Despite its affordable price, the hAP ax lite LTE6 is designed with high-quality features, making it a cost-effective solution for users who want a reliable and feature-rich router without compromising on performance.
Versatile Use Cases: The router is suitable for various use cases, from home networks to small businesses. Its versatility allows users to tailor the network setup according to their requirements.
Specifications

Processing Power: ARM, IPQ-5010 (2 cores), 2 CPU core count, 800 MHz CPU nominal frequency, MT7531BE switch chip model
Memory and Storage: 256 MB RAM, 128 MB storage size, NAND storage type
Wireless Connectivity: 574 Mbit/s max data rate, 2 chains, 802.11b/g/n/ax standards, 4.3 dBi antenna gain, IPQ-5010 chip model, Wi-Fi 6 generation, AX600 WiFi speed
Wired Networking: 10/100/1000 Ethernet ports, 4 ports
Power and Consumption: 1 DC input (USB-C), 5 V supported voltage, 12 W max power consumption, Passive cooling type
Power over Ethernet (PoE): No information provided about PoE capabilities
Certifications and Approvals: CE, EAC, ROHS certification, IP 20 rating
Operating System: RouterOS: RouterOS v7
Fiber Connectivity: No information provided about fiber connectivity
Peripherals: 1 SIM slot (Micro SIM)
*For complete specifications see the documentation tab above.

MikroTik 4G GPS Enabled Mobile Router LtAP LTE Kit - RBLtAP-2HnD&R11e-LTE

A rugged, heavy-duty 2.4GHz access point with GPS support, extra miniPCI-e slot, three SIM slots, GNSS support (GPS, GLONASS, BeiDou, Galileo) and LTE modem for International bands 1,2,3,7,8,20,38 and 40

The LtAP LTE kit is compact and capable, with its weatherproof enclosure, high-power wireless and flawless 4G performance, it's perfect for busy urban environments, off-grid outdoors networking and automotive applications. It features a built-in cellular modem that supports 4G (LTE) connectivity - so there's no need for additional devices.

Its high power 2.4 GHz 802.11b/g/n wireless capability provides secure access to LTE network from your phone or any other wireless device with up to 150 Mbps download speed. You can also use a Gigabit Ethernet LAN port for your wired devices. There are several power options - DC jack, POE-in and automotive.

The rugged and extremely durable case with a special wall mounting kit will be perfect for almost any challenge: from public transportation, food trucks or logistics to harsh winter and stormy desert environment. LtAP can handle any temperature from -40°C to +70°C. It is a perfect solution for tracking vehicles in real time. We have provided a simple tracking application example in the RouterOS documentation to help you get started. LtAP even has 3 Mini-SIM slots for easy roaming management. Saves your time and money worldwide!

The unit comes with an extra miniPCIe slot, offering many expansion options. For example, you can install a second LTE modem for redundancy or a 5GHz interface to have dual concurrent 2.4 GHz / 5GHz AP + LTE. The other miniPCIe slot is already populated with the LTE modem.

LtAP has a RS232 serial port, which gives you console access for debugging, as well as full size USB for other devices.


The new LtAP LTE kit is more than an access point -
it's what you need it to be wherever you need it to be.


RBLtAP-2HnD&R11e-LTE Specifications:

Architecture: MMIPS
CPU: MT7621A
CPU core count: 2
CPU nominal frequency: 880 MHz
CPU Threads count: 4
Licence level: 4
RAM: 128 MB
Storage size: 16 MB
Storage type: FLASH
Tested ambient temperature: -40°C to 70°C
Power:
PoE in: Passive PoE
PoE in input Voltage: 12-30 V
Number of DC inputs: 3 (DC jack, PoE-IN, Automotive)
DC jack input Voltage: 12-30 V
Automotive input Voltage: 12-30 V
Max power consumption: 24 W
Max power consumption without attachments: 12 W
Mobile:
LTE (FDD) bands: 1(2100)/2(1900)/3(1800)/7(2600)/8(900)/20(800)
LTE (TDD) bands: 38(2600)/40(2300)
3G bands: 1(2100)/2(1900)/5(850)/8(900)
2G bands: 2(1900)/3(1800)/5(850)/8(900)
Wireless:
Wi-Fi generation: 4
Ethernet:
10/100/1000 Ethernet ports: 1
Peripherals:
Number of SIM slots: 3 Modem (Mini SIM)
MiniPCI-e slots: 2
Serial port: RS232
Number of USB ports: 1
USB Power Reset: Yes
USB slot type: USB type A
Max USB current: 1A
PCB temperature monitor: Yes
Voltage Monitor: Yes

PowerBox - 650MHz CPU, 64MB RAM, 5xEthernet with PoE output for four ports, RouterOS L4, outdoor case, PSU

The PowerBox is an outdoor five Ethernet port router with PoE output on four ports. You can use this device to supply power to four PoE capable devices such as our SXT, or others.

Since the device has a waterproof outdoor case, you can mount it on a tower, or in other outdoor locations.

The unit has five shielded Ethernet ports, four of which can power other PoE capable devices with the same voltage as applied to the unit (max current out is 1A per port, max total out is 2A). Less power adapters and cables to worry about!

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..


RB750P-PBR2 Specifications:



10/100 Ethernet ports: 5
10/100/1000 Ethernet ports: None
Architecture: MIPSBE
CPU: QCA9533
CPU core count: 1
CPU nominal frequency: 650 MHz
DC jack input Voltage: 8-30 V
Dimensions: 125 x 178 x 48mm
Ethernet Combo ports: 0
License level: 4
Max Power consumption: 2W
Number of DC inputs: 2
Number of SIM slots: 0
Number of USB ports: 0
Operating System: RouterOS
PoE in: Passive PoE
PoE in input Voltage: 8-30 V
SFP ports: None
SFP+ ports: None
RAM: 64 MB
Storage size: 16 MB
Wireless 1 Number of chains: 0

The MikroTik RouterBoard hEX PoE lite is a small five port ethernet router in a plastic case, it has a USB 2.0 port and PoE output for four ports, 650MHz CPU, 64MB RAM, RouterOS L4

Ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. Less power adapters and cables to worry about! Max current is 1A per port, Ethernet ports are shielded.

It is affordable, small and easy to use. With it's compact design and clean looks, it will fit perfectly into any SOHO* environment.

* small office or home office

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..


RB750UPr2 Specifications:

10/100 Ethernet ports: 5
10/100/1000 Ethernet ports: None
Architecture: MIPSBE
CPU: QCA9531
CPU core count: 1
CPU nominal frequency: 650 MHz
DC jack input Voltage: 8-30 V
Dimensions: 113 x 89 x 28mm
Ethernet Combo ports: 0
License level: 4
Max Power consumption: 3W
Number of DC inputs: 2
Number of SIM slots: 0
Number of USB ports: 1
Operating System: RouterOS
PoE in: Passive PoE
PoE in input Voltage: 8-30 V
SFP ports: None
SFP+ ports: None
RAM: 64 MB
Storage size: 16 MB
USB slot type: USB type A
Wireless 1 Number of chains: 0

The MikroTik RouterBoard hEX S is a 5 port Gigabit Ethernet router for applications where integrated wireless connectivity is not required.

5x Gigabit Ethernet, SFP, Dual Core 880MHz CPU, 256MB RAM, USB, microSD, RouterOS L4, IPsec hardware encryption support and The Dude server package hEX S is a five port Gigabit Ethernet router for locations where wireless connectivity is not required. Compared to the hEX, the hEX S also features an SFP port and PoE output on the last port.

It is affordable, small and easy to use, but at the same time comes with a very powerful dual core 880 MHz CPU and 256 MB RAM, capable of all the advanced configurations that RouterOS supports. The device has a USB 2.0, PoE output for Ethernet port #5 and a 1.25Gbit/s SFP cage. The port #5 can power other passive PoE capable devices with the same voltage as applied to the unit.

IPsec hardware encryption (~470 Mbps) and The Dude server package is supported, microSD slot provides improved r/w speed for file storage and Dude.

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..


hEX S RB760iGS Specifications:

10/100 Ethernet ports: None
10/100/1000 Ethernet ports: 5
Architecture: MMIPS
CPU: MT7621A
CPU core count: 2
CPU nominal frequency: 880 MHz
DC jack input Voltage: 12-57V
Dimensions: 113 x 89 x 28mm
Ethernet Combo ports: 0
License level: 4
Max Power consumption without attachments: 6W
Max power consumption: 24W
Memory Cards: 1
Number of DC inputs: 2
Number of SIM slots: 0
Number of USB ports: 1
Operating System: RouterOS
PoE in: 802.3af/at
PoE in input Voltage: 12-57V
SFP ports: 1
SFP+ ports: None
RAM: 256 MB
Storage size: 16 MB
USB slot type: USB type A
Wireless 1 Number of chains: 0

MikroTik RouterBoard 5 Port Router 2.4GHz AP with five Ethernet ports and PoE output on port 5. It has a 600MHz CPU, 128MB RAM and a USB port.

The RB951Ui-2HnD is a wireless SOHO* AP with a new generation Atheros CPU and more processing power. It has five Ethernet ports, one USB 2.0 port and a high power 2.4GHz 802.11b/g/n wireless AP with antennas built in.

It has a 600MHz CPU,128MB of RAM and PoE output on port #5 - it can power other PoE capable devices with the same voltage as applied to the unit. Maximum load on the port is 500mA.

* small office or home office

Package contains RouterBOARD 951Ui-2HnD in a plastic case and power adapter.

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..


RB951Ui-2HnD Specifications:

Product code: RB951Ui-2HnD
CPU nominal frequency: 600 MHz
CPU core count: 1
RAM: 128 MB
10/100 Ethernet ports: 5
Wireless chip model: R9344
Wireless standards: 802.11b/g/n
Number of USB ports: 1
Power Jack: 1
PoE ou: Yes
Supported input voltage: 7V - 31V
PoE in: Yes
Dimensions: 113 x 138 x 29mm
Operating System: RouterOS
Tested ambient temperature: -20°C to +50°C
License level: 4
Antenna gain DBI: 2.5
CPU: AR9344
Max Power consumption: Up to 7W
USB slot type: USB type A
Number of chains: 2
Storage type: NAND
Storage size: 128 MB

hAP ac lite - Dual-Concurrent 2.4/5GHz AP, 802.11ac, Five Ethernet ports, PoE-out on port 5, USB for 3G/4G support. The hAP ac lite is a Dual-concurrent Access Point, that provides WiFi coverage for 2.4GHz and 5GHz frequencies at the same time

The hAP AC Lite offers two power options - using the included power adapter or using passive PoE from a compatible PoE injector. The RB952UI-5AC2ND provides PoE on port 5, which uses the same voltage provided to power other capable devices - maximum load is 500mA.

This MikroTik Routerboard comes pre-configured, offering plug and play set up - simply plug in power and Ethernet, then connect your device to your network and you're ready to go online instantly. You also have the added option of connecting a 3G/4G modem via the USB port to give even more connectivity.

Unit is equipped with a 650MHz CPU, 64MB RAM, five 10/100Mbps Ethernet ports (PoE output on port #5), dual-chain 802.11b/g/n 2.4GHz wireless, single chain 802.11a/n/ac 5GHz wireless, USB port for 3G/4G modem and a RouterOS L4 license.

RB952Ui-5ac2nD (International) supports 2412-2484MHz and 5150MHz - 5875MHz range (Specific frequency range can be limited by country regulations).


MikroTik RB952Ui-5ac2nD Specifications:



10/100 Ethernet ports: 5
10/100/1000 Ethernet ports: None
Antenna gain: 2
Antenna gain dBi for Wireless 2: 2
Architecture: MIPSBE
CPU: QCA9531
CPU core count: 1
CPU nominal frequency: 650 MHz
DC jack input Voltage: 10-30V
Dimensions: 113 x 89 x 28mm
Ethernet Combo ports: 0
License level: 4
Max power consumption: 8W
Number of DC inputs: 2
Number of SIM slots: 0
Number of USB ports: 1
Operating System: RouterOS
PoE in: Passive PoE
PoE in input Voltage: 12-30V
SFP ports: None
SFP+ ports: None
RAM: 64 MB
Storage size: 16 MB
USB slot type: USB type A
Wireless 1 band: 2.4 GHz
Wireless 1 Number of chains: 2
Wireless 2 band: 5 GHz
Wireless 2 Number of chains: 1

hEX PoE - 5x Gigabit Ethernet with PoE output for four ports, SFP, USB 2.0 port, 800MHz CPU, 128MB RAM, RouterOS L4 and SFP port for optical fiber connectivity

USB 2.0 port and a SFP port for adding optical fiber connectivityhEX PoE is a five port Gigabit Ethernet router for locations where wireless connectivity is not required. The device has a USB 2.0 port and a SFP port for adding optical fiber connectivity. The ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit.

It is affordable, small and easy to use, but at the same time comes with a very powerful 800MHz CPU, capable of all the advanced configurations that RouterOS supports.

It also supports passive PoE input and passive or 802.3af/at PoE output. On the MikroTik RB960PGS, ports 2-5 support PoE (power other Ethernet) supplying whatever voltage the router is powered with, ranging from 12-57V. This method of PoE pass-through negates the need for any additional power adaptors. Each shielded Gigabit port is capable of delivering up to 1Amp. A 24V 2.5A Power adapter is included.


hEX PoE RB960PGS Specifications:

10/100 Ethernet ports: None
10/100/1000 Ethernet ports: 5
Architecture: MIPSBE
CPU: QCA9557
CPU core count: 1
CPU nominal frequency: 800 MHz
DC jack input Voltage: 12-57V
Ethernet Combo ports: 0
License level: 4
Max Power consumption without attachments: 6W
Max power consumption: 54W
Number of DC inputs: 2
Number of SIM slots: 0
Number of USB ports: 1
Operating System: RouterOS
PoE in: Passive PoE
PoE in input Voltage: 2-57V
SFP ports: 1
SFP+ ports: None
RAM: 128 MB
Storage size: 16 MB
USB slot type: USB type A
Wireless 1 Number of chains: 0

PowerBox Pro - Five Gigabit Ethernet Router with 4xPoE-out ports, SFP cage and outdoor enclosure

The PowerBox supports passive or standard 802.3at/af PoE input/output. Ethernet ports 2-5 can power other PoE capable devices with the same voltage as applied to the unit. Less power adapters and cables to worry about! It can power 802.3at and af mode B compatible devices, if 48-57 input voltage is used.

The device has a SFP port for adding optical fibre connectivity. It is affordable, small and easy to use, but at the same time comes with a very powerful 800MHz CPU, capable of all the advanced configurations that RouterOS supports.


RB960PGS-PB PowerBox Pro Specifications:



10/100 Ethernet ports: None
10/100/1000 Ethernet ports: 5
Architecture: MIPSBE
CPU: QCA9557
CPU core count: 1
CPU nominal frequency: 800 MHz
DC jack input Voltage: 12-57V
Dimensions: 125 x 52 x 225mm
Ethernet Combo ports: 0
Licence level: 4
Max Power consumption without attachments: 6W
Max power consumption: 54W
Number of DC inputs: 2
Number of SIM slots: 0
Number of USB port: s0
Operating System: RouterOS
PoE in: Passive PoE
PoE in input Voltage: 12-57 V
SFP ports: 1
SFP+ ports: None
RAM: 128 MB
Storage size: 16 MB
Wireless 1 Number of chains: 0
Tested ambient temperature: -40°C to +70°C

RB450Gx4 - Four core 716MHz CPU, 1GB RAM, 5xGigabit Ethernet, PoE out on port #5, RouterOS L5

The RB450Gx4 is an Ethernet router with five Gigabit Ethernet ports, a serial port, 512 MB NAND memory and a microSD card slot. In addition, it supports full 10V - 57V input by two power jacks or PoE (802.3af/ at or passive PoE) and can provide PoE output for Ethernet port #5.

It is powered by MikroTik RouterOS. It comes without an enclosure, you are free to use it in your own. The device form factor is identical to our previous RB850 and RB450 series, so you can even use the same enclosure (CA/150).

The device is powered by a quad core ARM CPU, has 1 GB of RAM and supports hardware IPsec encryption. The device is powered by RouterOS - the operating system, which will turn this powerful system into a highly sophisticated router, firewall or bandwidth manager.

If you wish to purchase this Routerboard with a case, this is available as part number RB450GX4/CASED


MikroTik Router RB450Gx4 Specifications:

10/100/1000 Ethernet ports: 5
Architecture: ARM 32bit
CPU: IPQ-4019
CPU core count: 4
CPU nominal frequency: 716 MHz
Number of DC inputs: 3 (DC jack, PoE-IN)
DC jack input Voltage: 10-57 V
Dimensions: 90 x 115 mm
Ethernet Combo ports: 0
Licence level: 5
Max Power consumption without attachments: 5W
Max power consumption: 16W
Number of DC inputs: 3
Number of SIM slots: 0
Number of USB ports: 0
Operating System: RouterOS
PoE in: 802.3af/at
PoE in input Voltage: 12-57 V
PoE out: Passive PoE
SFP ports: None
SFP+ ports: None
RAM: 1 GB
Storage size: 512 MB
Wireless 1 Number of chains: 0
Storage type: NAND
Tested ambient temperature: -40°C to +70°C
Memory card type: microSD
Serial port: RS232
PCB temperature monitor: Yes
Voltage Monitor: Yes

RB4011iGS+RM - Powerful 10xGigabit port router with a Quad-core 1.4Ghz CPU, 1GB RAM, SFP+ 10Gbps cage and desktop case with rack ears

The RB4011 from MikroTik is the latest and greatest addition to MikroTik's *011 series, offering amazing processing performance along with ten Gigabit ports, an SFP+ 10Gbps interface, IPsec hardware acceleration and impressive dual-band wireless in a desktop case, all for an incredibly low price.

The RB4011 uses a quad core Cortex A15 CPU, same as in MikroTik's carrier grade RB1100AHX4 unit. The unit is equipped with 1GB of RAM, can provide PoE output on port #10 and comes with a compact and professional looking solid metal enclosure in matte black.


The RB4011iGS+RM (Ethernet model) includes two rackmount ears that will securely fasten the unit in a standard 1U rack space.

Note: Passive DAC (MikroTik S+DA0001/S+DA0003) are not supported.


RB4011iGS+RM Ethernet Router Specifications:



10/100/1000 Ethernet ports: 10
Antenna gain: 3
Antenna gain dBi for Wireless 2: 3
Architecture: ARM 32bit
CPU: AL21400
CPU core count: 4
CPU nominal frequency: 1.4 GHz
DC jack input Voltage: 12-57 V
Dimensions: 228 x 120 x 30 mm
Ethernet Combo ports: 0
SFP ports: None
SFP+ ports: 1
Licence level: 5
Max Power consumption without attachments: 23 W
Max power consumption: 44 W
Number of DC inputs: 2
Number of SIM slots: 0
Number of USB ports: 0
Operating System: RouterOS
PoE in: Passive PoE
PoE in input Voltage: 18-57 V
RAM: 1 GB
Storage size: 512 MB
Wireless 1 Number of chains: 0

CCR2004-1G-12S+2XS - The Connectivity Router - your best companion when it comes to SFP, SFP+ and SFP28 management! 1G, 10G and 25G ports all in a single device to make your life easier!

The CCR2004-1G-12S+2XS allows you to forget about all connectivity troubles and expand your setup in any way you please. This handy router features 12 x 10G SFP+,  2 x 25G SFP28 and 1 x 1G 10/100/1000 ports.

MikroTik's CCR2004-1G-12S+2XS features their most powerful single-core performance so far. It provides incredible IPSec throughput* (up to 3.4 Gbps), whilst offering BGP feed processing**

Be prepared for anything, the Cloud Core CCR2004 router also offers sublime performance with 2 x 25G SFP28 ports, this puts it on a similar level to the renowned CCR1009 / CCR1016 routers.

If you're worried about unexpected downtime, MikroTik has you covered with its dual redundant power supplies - no more stress over loss of service. Catering to more advanced network configurations, the new CCR2004-1G-12S+2XS is the perfect addition to any professional networking setup.

The Cloud Core routers are powered by RouterOS, a fully-featured routing operating system which has been continuously updated and improved for fifteen years. Dynamic routing, hotspot, firewalls, MPLS, VPN, advanced quality of service, load balancing and bonding, real-time configuration and monitoring - just a few of the vast number of features supported by RouterOS.


NB: RAM with RouterOS level 6 is 1792 MB ECC / RAM with RouterOS level 7 is 4 GB ECC.

* Internet Protocol Security

** Border Gateway Protocol (BGP) Feeds deliver real time threat intelligence, allowing you to block connections from malicious IP addresses at the network edge, utilizing your existing BGP routers. This provides an additional layer of protection for your network without capital expenditure.


CCR2004-1G-12S+2XS Features:

12 x 10G SFP+ ports
2 x 25G SFP28 ports
1 x Gigabit Ethernet port
1 x RJ45 serial port
ARM 64bit 1700 MHz Quad core CPU
4GB RAM
128MB Internal Storage
Dual redundant power supplies

CCR2004-1G-12S+2XS Specifications:

Architecture: ARM 64bit
CPU: AL32400
CPU core count: 4
CPU nominal frequency: 1700 MHz
Dimensions: 443 x 224 x 44mm
Licence level: 6
Operating System: RouterOS
RAM 4 GB in RouterOS lvel 7 (only 1792 MB RAM is usable with RouterOS level 6)
Storage size: 128 MB
Storage type: NAND
Tested ambient temperature: -20°C to 60°C
Number of AC inputs: 2
AC input range: 100V - 240V
Max power consumption: 49 W
Max power consumption without attachments: 32 W
10/100/1000 (1G) Ethernet ports: 1
SFP+ (10G) ports: 12
SFP28 (25G) ports: 2
Serial port: RJ45
CPU temperature monitor: Yes
PCB temperature monitor: Yes
Voltage Monitor: Yes
Certification: CE/RED, EAC, ROHS

MikroTik CCR2004-16G-2S+ Cloud Core Router - 16 Port Firewall VPN Dual 10Gb SFP+ (RouterOS Level 6)

The CCR2004-16G-2S+ is designed with single-core performance in mind. 16x Gigabit Ethernet ports, 2x10G SFP+ cages and active cooling; it comes equipped with the Annapurna Labs Alpine v2 CPU with 4x 64-bit ARMv8-A Cortex-A57 cores running at 1.7GHz, and surpasses all previous CCR models when it comes to single-core tasks based on per-connection processing such as queues.

Despite this large performance boost the CCR2004-16G-2S+ is also extremely efficient; with the best single-core performance and overall performance per watt of any CCR currently available, and that is the most important aspect when it comes to heavy operations based on per-connection processing. Better for the planet, better for the bills, it's a win-win!

The new router has 18 wired ports, including 16x Gigabit Ethernet ports and two 10G SFP+ cages. It also has a full-size USB and RJ-45 console port on the front panel. Built-in dual redundant power supplies are included, so you have one less thing to worry about. And, of course, there is active cooling to keep things nice and cool.

Each group of 8 Gigabit Ethernet ports is connected to a separate Marvell Amethyst family switch-chip. Each switch chip has a 10 Gbps full-duplex line connected to the CPU. The same goes for each SFP+ cage - a separate 10 Gbps full-duplex line. Boards come with 4GB of DDR4 RAM and 128MB of NAND storage.

So as you can see - no bottlenecks. As long as the CPU can handle the processing, all ports can reach wire speed. And this CPU is a beast that can handle a lot!

The best part? This brand new CCR is among the most affordable options out there - not only within the CCR series, but on the market in general. One of the most common ways to use this device would be: Gigabit Ethernet ports for the internal network; SFP+ ports for downlink and uplink. The perfect all-in-one solution for small and medium-sized businesses. Easy and efficient.

With the new CCR2004, you can take your office network to the next level. Without breaking the bank.


CCR2004-16G-2S+ Insane Single-Core Performance:




MikroTik CCR2004-16G-2S+ Specifications:

10/100 Ethernet ports: None
10/100/1000 Ethernet ports: 16
Architecture: ARM 64bit
CPU: AL32400
CPU core count: 4
CPU nominal frequency: 1700 MHz
Ethernet Combo ports: 0
Licence level: 6
Max Power consumption without attachments: 35 W
Max power consumption: 48 W
Number of DC inputs: 0
Number of SIM slots: 0
Number of USB ports: 1
Operating System: RouterOS
PoE in: No
SFP+ ports: 2
SFP ports: None
RAM: 4 GB
Storage size: 128 MB
USB slot type: USB 3.0 type A
Wireless 1 Number of chains: 0
If we look at the performance, you can see that it is trading blows with our CCR1009. Even surpassing it in CPU-heavy configurations! And if that wasn't enough - it can even reach the performance of CCR1016.

The Cloud Core routers are powered by RouterOS, a fully-featured routing operating system which has been continuously updated and improved for fifteen years. Dynamic routing, hotspot, firewalls, MPLS, VPN, advanced quality of service, load balancing and bonding, real-time configuration and monitoring - just a few of the vast number of features supported by RouterOS.
