Lindy HDMI Switches

2 Port HDMI 18G Bi-Directional Switch

Key Features:

Switches between two source devices to one output, or one source device to two outputs
Supports resolutions up to 4K 3840x2160 @60Hz
Supports HDMI audio pass-through
No external power supply required, for easy and discreet installation
2 year warranty


The Lindy HDMI 18G Bi-directional Switch allows the user to connect two 4K Ultra High Definition source devices such as Blu-Ray players or games consoles to a single 4K Ultra HD display or projector and easily switch between them at the push of a button. Alternatively, one 4K Ultra HD source can be connected to two 4K Ultra HD displays or projectors and switch between displays at the touch of a button.

With support for resolutions up to 4K 3840x2160 @60Hz, this switch ensures a superior visual experience within residential, education or conferencing installations.

The switch's minimalistic design, with no external power requirement, allows for a clean, discreet installation.

Specifications:

AV Interface: HDMI
Interface Standard: HDMI 2.0
Supports Bandwidth: 18Gbps
Maximum Resolution: 4096x2160@60Hz 4:4:4 8bit
HDCP Support: Pass-through
Supported Audio: Pass-through
CEC Support: Pass-through
Special Features: Bi-Directional Capability
Input: 2 x HDMI Type A (Female) Bi-Directional
Output: HDMI Type A (Female) Bi-Directional
Power: Powered via HDMI interface
Dimensions (approx.) WxDxH: 49x52x20mm (1.93x2.05x0.79in)
Housing Material: Metal
Net Weight: 0.7kg (1.54lb)
Operating Temperature: 0°C - 70°C (32°F - 158°F)
Storage Temperature: -10°C - 80°C (14°F - 176°F)
Humidity: 10% to 85% RH (no condensation)
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 63.5x80x28mm (2.5x3.15x1.1in)
Gross Weight: 0.84kg (1.85lb)
Warranty (Years): 2
Certified: CE, UKCA, FCC, RoHS, REACH & California Proposition 65


Package Contents:

2 Port HDMI 18G Bi-Directional Switch
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

3 Port HDMI 18G Switch

Key Features:



Switches between 3 HDMI source devices when connected to a single display
Supports 18G resolutions up to 4K@60Hz, with additional support for HDR
Flexible control via push button, IR remote and auto-switching
Compact, minimalist design to ensure no distraction from the display or installation
2-year warranty


HDMI switches are reliable solutions for controlling and switching multiple HDMI source devices and outputting to a single display.

The Lindy 3 Port HDMI 18G switch is a compact, high quality solution for effortlessly switching between 3 HDMI source devices when connected to a single display.

Supporting HDMI 18G signals, this switch allows for the transmission of detailed 4K Ultra HD resolutions, while additional support for HDR ensures video content features greater contrasts and a much wider colour gamut. This switch is perfect for a premium residential setup, eye-catching digital signage in retail settings or engaging presentations. HDCP 2.2 support ensures there are no compatibility issues with a variety of 4K content from source devices including set top boxes, Blu-Ray players and 4K HDR media players.

This switch also provides efficient, simple switching options for the user, via an included IR remote or push buttons on the main unit. The switch can also identify the active HDMI source device and automatically switch to this option, providing a useful solution for when the unit is required to be out of sight.

Specifications:



AV Interface: HDMI
Interface Standard: HDMI 2.0
Supports Bandwidth: 18Gbps
Maximum Resolution: 3840x2160@60Hz 4:4:4 8bit
HDCP Support: HDCP 2.2
Supported Audio: Audio Pass-through
IR Support: 38kHz
Input: 3 x HDMI Type A (Female)
Output: HDMI Type A (Female)
Power: 5.5/2.1mm
Dimensions (approx.) WxDxH: 80x20x51mm (3.15x0.79x2.01in)
Housing Material: Metal
Net Weight: 0.108kg (0.24lb)
Operating Temperature: 0°C - 45°C (32°F - 113°F)
Storage Temperature: -10°C - 80°C (14°F - 176°F)
Humidity: 10 - 85% RH (non-condensing)
Power Requirements: 5VDC 1A
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 170x60x120mm (6.69x2.36x4.72in)
Gross Weight: 0.405kg (0.89lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS, REACH & California Proposition 65


Package contents:



3 Port HDMI Switch
Multi-country Power Supply (UK, EU, US & AUS)
Remote Control and CR2025L Battery
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

3 Port HDMI 2.0 18G Switch - HDTV up to 4K 60Hz, HDCP 2.2 copy protection

Key Features:

Connect and switch up to 3 UHD HDMI devices to 1 UHD display or projector
Supports video resolutions up to 4K2K@60Hz 8 bit including 3D 1080p
Supports 7.1 channel of LPCM, Dolby TrueHD and DTS-HD Master Audio digital audio signals
HDCP 2.2 compliant for use with the latest AV equipment
2 year warranty


This state of the art 4K UHD HDMI 2.0 18G switch is capable of displaying resolutions up to 3840 x 2160 from 3 UHD signals in to 1 UHD signal out.

The Switch is also HDR (High Dynamic Range) compatible to reproduce a greater dynamic range of luminosity similar to that used in imaging and photography. HDR used on TV's allows a wider range of colours and greater contrast with whites and blacks, resulting in much higher definition pictures similar to ones seen by the human eye.

With full support for HDCP 2.2 and HDMI 2.0, you can be sure that this product is fully future proof and ready for the new and demanding audio and video signals on the market.

An RS232 port is included to allow switching via a PC or control software.

Specifications:

AV Interface: HDMI
Interface Standard: HDMI 2.0
Supports Bandwidth: 18 Gbps
Maximum Resolution: 3840x2160@60Hz 4:4:4 8bit
HDCP Support: 2.2
Supported Audio: Audio Pass-through
Separate Audio Ports: HDMI
IR Support: 38kHz
CEC Support: Pass-Through
Serial Interface: RS232
Input: 3 x HDMI (Female), 3.5mm (Female)
Output: HDMI (Female)
Control: RS232 Port
Power: 5.5/2.1mm DC socket
Dimensions WxDxH: 154x61x25mm (6.06x2.4x0.98in)
Housing Material: Metal
Net Weight: 0.275kg (0.61lb)
Operating Temperature: 0°C - 50°C (32°F - 122°F)
Storage Temperature: -10°C - 50°C (14°F - 122°F)
Humidity: 5 - 85% RH (non-condensing)
Power Requirements: 5VDC 1A
Colour: Black
Packaging Type: Carton box
Packaging Dimensions: 240x165x55mm (9.45x6.5x2.17in)
Gross Weight: 0.496kg (1.09lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS & REACH
Package Contents
3 Port 4K HDMI 2.0 4K 18G Switch
IR Remote Control (inc battery)
1.2m (3.94ft) IR receiver cable
Multi-Country Power Supply (EU, UK, US & AUS)
Lindy Manual


Package Contents:

3 Port HDMI 2.0 18G Switch
5V Multi Country PSU with UK, US, Australian and European adapters
Remote control inc battery
IR receiver cable ~1.2m
LINDY Manual
Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

HDMI 4K60 Audio Extractor

Key Features:



Extracts stereo or multi-channel audio from an HDMI source
4K@60Hz video pass-through, with additional support for HDR
Supports both stereo and multi-channel audio up to 7.1
CEC and High Bit Rate Audio Pass-through
2 year warranty


The Lindy HDMI 18G Audio Extractor allows the user to seamlessly extract both digital and analogue audio from an HDMI source and output to an audio device in either digital or analogue formats, while sending the video signal to a 4K UHD display or projector. This is a perfect solution for connecting non-HDMI AV receivers or analogue 2-channel speaker setups to an HDMI source device, while also being ideal for extracting audio and video to a display that requires separate speakers.

This extractor supports the full 18G HDMI 2.0 bandwidth to display 4K UHD 4096x2160@60Hz resolutions with additional pass-through support for the REC.2020 colour space that covers the wider colour gamut required for HDR (high dynamic range) content, for enhanced contrast and more lifelike colour. Featuring support for HDCP 2.2, this is ideal for use with the latest source devices including set-top boxes, games consoles and media players.

With support for multi-channel audio including Dolby Digital 5.1 via Optical and analogue stereo via RCA connections, this device will ensure an impressive three-dimensional surround sound performance to compliment films, games and music when connected to the audio device. HDMI High Bit Rate audio pass through also allows high-resolution audio files to playback without compression for a flawless music listening experience. The RCA analogue connections ensure 2-channel speaker set ups can also be connected to the extractor, providing a versatile solution for home AV installations as well as applications in retail stores and meeting rooms where separate non-HDMI audio systems are used.

The extractor also includes two mounting brackets, for fixing to surfaces to provide a secure, tidy installation.

Specifications:



Video Interface: HDMI
Interface Standard: 2.0
Supported Bandwidth: 18Gbps
Maximum Resolution:
3840x2160@60Hz 4:4:4 8bit
3840x2160@60Hz 4:2:2 12bit
HDCP Support: 2.2 / 1.4
Audio Interface: SPDIF, Analogue L/R
Chipset: IT66321
Supported Audio:
HDMI (Pass-Through): LPCM 5.1CH, Dolby Digital 2/5.1CH, DTS Audio 2/5.1CH, Dolby DigitalPlus, DTS-HD Master Audio, Dolby TrueHD
Optical: LPCM 2CH, Dolby Digital 2/5.1CH, DTS Audio 2/5.1CH, DTS Audio 2CH, Dolby Digital 2CH
Analogue L/R: LPCM 2CH, Analogue Stereo 2CH
Maximum Supported Audio Sample Rate: 24-bit/192kHz
Input Impedance: 1K?
Output Impedance: 10K?
Output Voltage: 5V 1A
Frequency Response: < 3db; 20h~20kh
Signal to Noise Ratio: 85db
Special Features: CEC Pass-through
Input: HDMI Type A (Female)
Output: HDMI Type A (Female), SPDIF (Female), Analogue L/R (Female), USB Micro-B (Female)
Power: 5.5/2.1mm
Dimensions (approx.) WxDxH: 104.4x64x28.3mm (4.11x2.52x1.11in)
Housing Material: Metal
Net Weight: 0.118kg (0.26lb)
Operating Temperature: -5°C - 35°C (23°F - 95°F)
Storage Temperature: -5°C - 35°C (23°F - 95°F)
Humidity: 5 - 90% RH (non-condensing)
Power Requirements: 5VDC 1A
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 257x56x150mm (10.12x2.2x5.91in)
Gross Weight: 0.357kg (0.79lb)
Warranty (Years): 2
Certified: CE, UKCA, FCC, RoHS, REACH & California Proposition 65


Package Contents:



HDMI 18G Audio Extractor
Multi-country Power Supply (UK, EU, US & AUS)
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

2x2 HDMI 18G Matrix

Key Features:



Switches between 2 HDMI source devices and 2 HDMI displays connected simultaneously
Supports resolutions up to 4K UHD 4096x2160@60Hz, with additional support for HDR
Extract audio from HDMI to Toslink (Optical) and 3.5mm audio
EDID Management system for controlling and ensuring the optimum resolution possible
2-year warranty


A matrix switch is a multi-port solution for distributing content from multiple sources to several displays in a variety of configurations.

The Lindy 2x2 HDMI 18G Matrix Switch is a premium, compact solution for distributing content from two devices to two displays. Dual HDMI inputs & outputs provide the ability to switch between 2 separate source devices or 2 connected HDMI displays, or output video simultaneously.

With support for HDMI 18G signals, this matrix allows for the transmission of high quality 4K UHD 4096x2160@60Hz resolutions, while additional support for HDR (High Dynamic Range) ensures video content can be viewed with enhanced brightness, greater contrasts and a much wider colour gamut, perfect for high quality residential setups or small-scale digital signage installations in retail.

HDCP 2.2 support ensures there are no compatibility issues with 4K content when connected to source devices including set top boxes, Blu-Ray players and 4K HDR media players. Simple EDID management via an integrated switch allows the user to control and ensure the optimum resolution based on their connected displays.

As well as HDMI audio pass-through, a 3.5mm audio port allows for a separate connection of both analogue speaker systems, and optical audio devices such as soundbars and amplifiers, for creating immersive audio experiences to compliment the video on screen.

This matrix can be easily controlled via push button switching on the unit, while the included remote control also allows the user to have better control over multiple videos and displays, great for trade shows, training presentations or sales demonstrations.

Specifications:



AV Interface: HDMI
Interface Standard: HDMI 2.0
Supported Bandwidth: 18Gbps
Maximum Resolution: 4096x2160@60Hz 4:4:4 8bit
HDCP Support: 2.2
Supported Audio: HDMI Audio Pass-through, TosLink (Optical): Up to 5.1CH, 3.5mm: LPCM 2CH
IR Support : 20 - 60 kHz
CEC Support: Input 1 - Output 1
Special Features: EDID Management
Input: 2 x HDMI (Female)
Output: 2 x HDMI (Female), TosLink (Optical) (Female), 3.5mm (Female)
Power : 5.5/2.1mm
Dimensions (approx.) WxDxH: 144x59.5x18mm (5.67x2.34x0.71in)
Housing Material: Metal
Net Weight: 0.208kg (0.46lb)
Operating Temperature : 0°C - 40°C (32°F - 104°F)
Storage Temperature: -20°C - 60°C (-4°F - 140°F)
Humidity: 20 - 90% (non-condensing)
Power Requirements: 5VDC 1A
Colour: Black
Packaging Type: Carton box
Packaging Dimensions: 200x113x70mm (7.87x4.45x2.76in)
Gross Weight: 0.328kg (0.72lb)
Warranty (Years): 2
Certified: CE, UKCA, FCC, RoHS, REACH & California Proposition 65


Package Contents:



2x2 HDMI 18G Matrix
IR Remote Control with CR2025 Battery
Multi-Country PSU (UK, EU, US & AUS)
Lindy Manual


EDID - Extended Display Identification Data.
It is a way for a video source to discover the capabilities of the sink (display device) it is connected to. EDID information resides in the sink and is made available through the connection to a source device via HDMI, DP, DVI etc. When a sink is connected to a source it receives power for its EDID circuit from the source.

Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

Overview This HDMI 4x1 Multi-View Switch is a high performance video switch which allows signals from four different Full HD sources to be integrated for simultaneous display on a single monitor. Featuring four different viewing modes (Quad-View, Full Screen, Picture and Picture & Dual Video) the Multi-view switch allows for the monitoring of multiple video sources in different viewing configurations to meet the requirements of standard installations.

To ensure optimal performance in mission critical environments the Switch provides seamless switching, ensuring that there is no frame loss whilst switching between the connected source devices or between different picture modes.

Full HD 1080p resolutions are supported on both the input and output for simple integration within typical business environments, whilst the output can be down-scaled to 720p for operation with legacy displays.

Switching between audio and video channels can be completed independently using either the supplied remote control or using the front panel buttons. This independent switching allows a single audio source to be used continuously whilst switching between the connected source devices or conversely a single video source to be monitored whilst the audio source is switched.

Product Details Integrates 4 Full HD 1080p signals for display on a single HDMI display


Supports 4 viewing modes; Quadview, Picture & Picture, Dual Video and Standard


Seamless switching between inputs/viewing modes


Independent switching of audio and video signals


2 Year warranty

6x2 HDMI 10.2G Matrix Switch with PiP

Key Features:

Switch between 6 HDMI source devices and output to 2 displays
Supports resolutions up to 4K 30Hz 4:4:4
PiP (Picture in Picture) allows for 1 main picture and 5 sub pictures on one display
IR remote for easily switching between devices and displays
2 year warranty


The Lindy 6x2 HDMI 10.2G Matrix Switch with PiP allows for simple switching between 6 HDMI source devices and distributing to 2 displays, while also providing the ability to display all 6 sources on a single display using the PiP function.

Supporting HDMI 10.2G signals, this matrix allows for the transmission of detailed 4K Ultra HD resolutions, while HDCP 2.2 on input 1 and both outputs ensures there are no issues with a variety of 4K content when connected to source devices including set top boxes, Blu-Ray players and 4K media players.

The matrix also features PiP mode, which allows the user to generate multiple pictures on one display from the connected source devices, perfect for use in security, presentations with supporting data or collaborative working environments.

Specifications:

AV Interface: HDMI
Interface Standard: HDMI 1.4
Supports Bandwidth: 10.2 Gbps
Maximum Resolution: 4096x2160@30Hz 4:4:4 8bit
HDCP Support: 2.2 (Input 1 and Output 1 & 2 Only)
Supported Audio:
Audio Pass-through
LPCM Audio Extraction
IR Support : 30-60kHz
CEC Support: Pass-Through (Port 1)
Control: IR
EDID Management
ARC Audio Extraction
Picture in Picture
MHL
Input: 6 x HDMI (Female)
Output: 2 x HDMI (Female), 3.5mm (Female), TOSLink Audio (Female)
Power: 5.5/2.1mm DC socket
Dimensions WxHxD: 260x120x30mm (10.24x4.72x1.18in)
Housing Material: Metal
Net Weight: 0.87kg (1.92lb)
Operating Temperature : 0°C - 40°C (32°F - 104°F)
Storage Temperature: -20°C - 60°C (-4°F - 140°F)
Humidity: 20 - 90% (non-condensing)
Power Requirements: 5VDC 2A
Colour: Black
Packaging Type: Carton box
Packaging Dimensions: 305x240x60mm (12.01x9.45x2.36in)
Gross Weight: 1.1kg (2.43lb)
Warranty (Years): 2
Certified: CE, UKCA, FCC, RoHS & REACH


Package Contents:

HDMI Matrix
IR Remote Control
Mounting Kit
Multi-Country Power Supply (EU, UK, US & AUS)
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

Overview DisplayPort MST Hubs allow for the connection of multiple displays to a single DP source, to create larger workstation setups or larger scale DP distribution.

The Lindy DisplayPort to Quad HDMI MST/SST Hub with Video Wall Processor is a high-performance DP 1.2 MST and SST hub, with Video Wall, Duplicate, Extended and Expander View / Eyefinity functions.

To create a wide variety of display solutions, this processor groups the displays connected to port 1 and 2 together to create 1 single output, and then also apply this to the displays connected to 3 and 4.

This allows for the use of 4 different modes as detailed below. Maximum supported resolution can depend on the windows configuration, graphics card and connected display.

Video Wall Mode: Supports resolutions up to 3840x2160@60Hz using 4 displays connected together to create a single display, visualised as a 2x2 video wall.


This is a great solution for digital signage in retail, transport hubs or trade shows.


For the System Requirements and set-up instructions of certain graphics cards please refer to the Lindy Manual Under the Spec Sheet page for this product

Duplicate Mode: Supports resolutions up to 1920x1080@60Hz per display, using up to 4 displays. This works similar to a standard DisplayPort splitter with SST functionality, duplicating the input signal onto each individual display. The processor can also split the signal across 2 individual 4K displays, with resolutions up to 3840x2160@60Hz.


Using the grouped layout, resolutions up to 3840x1080@60Hz can be supported, duplicating the signal across the 2 separate groups (1+2) and (3+4).


These modes are great for use in security, surveillance and control installations.

Extended Mode: This mode supports resolutions up to 3840x1080@60Hz per display by using the grouped layout of displays 1+2 and 3+4. Content can be then shared across the 2 layouts simply by dragging the mouse across the displays.


This is useful for creating a large-scale office setup, or in graphic designs installations where users want to easily transfer content to another display or user.

Expander / Eyefinity Mode: This mode allows for the connection of 4 displays to create a multi-display workstation, viewed as a single display with resolutions up to 7680x1080@60Hz, with each display showing Full HD signals. Alternatively using 2 4K displays viewed as a single display, 7680x2160@30Hz can be viewed. This allows for the creation of a premium office or home workstation, or high-performance control set-ups in broadcasting and surveillance.


Multiple MST/SST hubs can be used to create even larger display setups, providing this can be supported by the display driver and graphics card.

Please note: This active MST Hub requires the source or graphics card to support DP++ to provide dual-mode signals

This MST hub does not support output to 3 displays.

NVIDIA graphics cards require a display to be connected to the graphics card for control. Intel and AMD cards do not require this.

Product Details Creates a 2x2 4K Ultra HD video wall from a single DisplayPort 1.2 source


High performance DisplayPort 1.2 MST and SST Hub, with Video Wall, Duplicate, Extended & Expander View / Eyefinity functionality


Supports DisplayPort & HDMI resolutions up to 4K@60Hz 4:4:4


Supports DisplayPort MST and SST modes


2 year warranty

Overview Matrices are multi-port solutions for distributing content from multiple sources to several displays in a variety of configurations.

The Lindy 4x4 HDMI 10.2G Matrix is an effective solution for distributing 4K content from up to 4 HDMI source devices, including PCs and media players, to 4 displays.

Supporting 4K@30Hz resolutions, content can be viewed in excellent quality - great for use with digital signage in retail, information display setups in educational buildings or engaging conference installations.

The matrix can be easily controlled with a variety of simple, effective options including push buttons on the main unit, IR or via RS-232 for integration into professional control systems. A rack mounting kit is also provided with the matrix for a discreet and secure installation within an AV rack.

Product Details Connects up to 4 4K source devices to 4 4K displays or projectors in any combination


Supports video resolutions up to 4K@60Hz 4:2:0 8bit


ush buttons, IR remote and Web Gui options for simple, flexible control


Superior smart EDID management for ensuring optimum video performance


2 year warranty

Single Port HDMI 18G Output Board

Key Features:

Adds a single HDMI output connection to the 12 slot modular matrix chassis (38350)
Develop customised 12-slot configurations to suit any installation
Supports 18G resolutions up to 4k@60Hz 4:4:4 8bit
Digital & Analogue audio de-embedding
2 year warranty


The Lindy 12 Slot Seamless Modular Matrix is a powerful AV device that creates flexible, centralised installations in a variety of environments. With fully customisable configurations of HDMI and HDBaseT boards possible, from 1x11, 6x6, 8x4 and more, this solution can be tailored to meet the requirements of any installation within education, hospitality, corporate or government sectors.

This board can be combined with 38351, 38352 or 38354 to create a fully customised 12 slot solution that meets the requirements of any installation. This board includes an individual HDMI Type A Female port for connection to HDMI displays or projectors, or other HDMI AV solutions such as splitters, converters or extension systems.

Supporting resolutions up to 4K@60Hz 4:4:4 8bit, this board ensures content is shown in exceptional clarity, perfect for eye-catching digital signage in retail, clear & informative displays in transport hubs or immersive projection at large events.

Digital (SPDIF) and analogue audio ports also allow for extraction to separate speakers, soundbars or amplifiers, to add captivating dual-channel audio to the video content, providing an enhanced stereo experience.

If desired, Lindy can pre-install the required modular boards that have been purchased, providing a quick and simple installation for the user once the matrix has been received.

Specifications:

AV Interface: HDMI
Interface Standards: HDMI 2.0
Supported Bandwidth: 18Gbps
Maximum Resolution: HDMI: 3840x2160@60Hz 4:4:4 8bit
EDID Pass Through
EDID Management
HDCP Support: 2.2
Supported Audio:
HDMI Audio Pass-through
Digital & Analogue Extraction to LPCM2.0
Separate Audio Ports: SPDIF, Analogue L/R
IR Support: 38kHz
CEC support: Yes
Serial Interface: RS-232
Output: HDMI Type A (Female) Output Card, SPDIF (Female), Audio Terminal Blocks
Dimensions (approx.) WxDxH: 23.3x215x126.6mm (0.92x8.46x4.98in)
Housing Material: Metal
Net Weight: 0.222kg (0.49lb)
Operating Temperature: 0°C - 45°C (32°F - 113°F)
Storage Temperature: -20°C - 70°C (-4°F - 158°F)
Humidity: 10 - 90% RH (non-condensing)
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 310x52x180mm (12.2x2.05x7.09in)
Gross weight: 0.395kg (0.87lb)
Warranty (Years): 2
Certified: CE, UKCA, FCC, RoHS, REACH, California Proposition 65


Package Contents:

Single Port HDMI 18G Output Board


EDID - Extended Display Identification Data.
It is a way for a video source to discover the capabilities of the sink (display device) it is connected to. EDID information resides in the sink and is made available through the connection to a source device via HDMI, DP, DVI etc. When a sink is connected to a source it receives power for its EDID circuit from the source.

Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

Single Port HDMI 18G Input Board

Key Features:



Adds a single HDMI input connection to the 12 slot modular matrix chassis (38350)
Develop customised 12-slot configurations to suit any installation
Supports 18G resolutions up to 4k@60Hz 4:4:4 8bit
Analogue audio embedding
2-year warranty


The Lindy 12 Slot Seamless Modular Matrix is a powerful AV device that creates flexible, centralised installations in a variety of environments. With fully customisable configurations of HDMI and HDBaseT boards possible, from 1x11, 6x6, 8x4 and more, this solution can be tailored to meet the requirements of any installation within education, hospitality, corporate or government sectors.

This board can be combined with 38352, 38353 or 38354 to create a fully customised 12 slot solution that meets the requirements of any installation. This board includes an individual HDMI Type A Female port for connection to HDMI source devices including media players, PCs or other HDMI AV solutions such as splitters, converters or extension systems.

Supporting resolutions up to 4K@60Hz 4:4:4 8bit, this board ensures content is shown in exceptional clarity, while analogue audio connections allow amplifiers or external audio devices to be embedded into HDMI within the setup.

If desired, Lindy can pre-install the required modular boards that have been purchased, providing a quick and simple installation for the user once the matrix has been received.

Specifications:



AV Interface: HDMI
Interface Standards: HDMI 2.0
Supported Bandwidth: 18Gbps
Maximum Resolution: HDMI: 3840x2160@60Hz 4:4:4 8bit
EDID Pass Through: EDID Management
HDCP Support: 2.2
Supported Audio:
HDMI Audio Pass-through
Analogue Audio Embedding
Separate Audio Ports: Analogue L/R
IR Support: 38kHz
CEC Support: Yes
Serial Interface: RS-232
Input: HDMI Type A (Female) Input Card, Audio Terminal Blocks
Dimensions (approx.) WxDxH: 23.3x215x126.6mm (0.92x8.46x4.98in)
Housing Material: Metal
Net Weight: 0.222kg (0.49lb)
Operating Temperature: 0°C - 45°C (32°F - 113°F)
Storage Temperature: -20°C - 70°C (-4°F - 158°F)
Humidity: 10 - 90% RH (non-condensing)
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 310x52x180mm (12.2x2.05x7.09in)
Gross Weight: 0.386kg (0.85lb)
Warranty (Years): 2
Certified: CE, UKCA, FCC, RoHS, REACH, California Proposition 65


Package Contents:



Single Port HDMI 18G Input Board
5 slot terminal block
Mounting screw


EDID - Extended Display Identification Data.
It is a way for a video source to discover the capabilities of the sink (display device) it is connected to. EDID information resides in the sink and is made available through the connection to a source device via HDMI, DP, DVI etc. When a sink is connected to a source it receives power for its EDID circuit from the source.

Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

9 Port HDMI 4K30 Multi-View Switch

Key Features:

Connects 9 HDMI inputs and view on a single HDMI display
Supports resolutions up to 3840x2160@30Hz 4:4:4 8bit
Simple switching via push button, IR remote or RS-232
Seamless switching between sources
2-year warranty


HDMI Multi-view switches are professional solutions for showing one or more sources of HDMI content on a single display.

The Lindy HDMI 4K30 Multi-view Switch is a high-performance solution for switching between a single or multiple HDMI source devices and outputting to a single HDMI display or projector. As well as standard switching between up to 9 devices, content can be viewed from all connected devices in a variety of layouts in the display, ideal for a wide range of scenarios.

These scenarios include the connection of two source devices in split screen layouts, which provide a useful layout for small scale CCTV or supporting content in retail stores, to the connection of 9 inputs for use in traffic monitoring or TV broadcasting facilities.

Resolutions up to 4K UHD 3840x2160@30Hz are supported providing an optimum viewing experience in detailed digital signage, security or broadcasting installations.

Switching can be easily controlled by the user via the push button on the main unit, or using the IR remote control, which also allows for hassle free switching between layouts modes. The switch also allows for output resolution scaling to ensure a consistent image quality within a setup, as well as independent audio switching from the connected HDMI devices, great for adding music or alternative commentary to video content from a separate HDMI source. Both features can also be easily controlled using the IR remote. RS-232 serial switching can also be used for control via a PC connection.

Seamless switching guarantees there is almost no downtime when alternating between connections, ensuring there is no interruption of content, meaning nothing is missed by the viewer when experiencing live sports or breaking news headlines.

Specifications:

AV Interface: HDMI
Interface Standard: HDMI 1.4
Supports Bandwidth: 10.2Gbps
Maximum Resolution: 3840x2160@30Hz 4:4:4 8bit
HDCP Support: 1.4
Supported Audio: Audio Pass-through
IR Support: 38kHz
Serial Interface: RS232
Special Features: Seamless Switching
Input: 9 x HDMI Type A (Female)
Output: HDMI Type A (Female)
Control: RS232 Terminal Blocks (Female)
Power: 5.5/2.1mm DC Socket
Dimensions (approx.) WxDxH: 252x25x105mm (9.92x0.98x4.13in)
Housing Material: Metal
Net Weight: 1.1kg (2.43lb)
Operating Temperature: -15°C - 55°C (5°F - 131°F)
Storage Temperature: -15°C - 55°C (5°F - 131°F)
Humidity: 0 - 90% RH (non-condensing)
Power Requirements: 12VDC 2A
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 280x55x195mm (11.02x2.17x7.68in)
Gross Weight: 1.4kg (3.09lb)
Warranty (Years): 2
Certified: CE, UKCA, FCC, RoHS & REACH


Package contents:

9 Port HDMI 4K30 Multi-view Switch
Multi-country Power Supply (UK, EU, US & AUS)
4 x Screws
IR Remote Control with CR2025 Battery
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

Overview Matrices are multi-port solutions for distributing content from multiple sources to several displays in a variety of configurations.

The Lindy 6x2 HDMI 18G Matrix is a premium solution for distributing content from up to 6 HDMI source devices, including PCs and media players, to 2 displays.

With support for full 4K@60Hz resolutions and HDR, content can be viewed in superior quality with a wider colour gamut and greater contrast. The matrix is perfect for creating eye-catching digital signage in retail, hospitality, conference rooms or impressive residential installations. HDCP 2.2 support also ensures seamless playback of 4K and Full HD content including video games, Blu-rays and on-demand video.

The matrix can be easily controlled with a variety of simple, effective options including push buttons on the main unit, individual IR extension ports or via RS-232 and IP for integration into professional control systems.

A rack mounting kit is also provided with the matrix for a discreet and secure installation within an AV rack.

Product Details Connects up to 6 4K source devices to 2 4K displays or projectors in any combination


Supports video resolutions up to 4K@60Hz 4:4:4 8bit, with additional support for HDR


Push buttons, Individual IR ports, Web Gui and Telnet options for simple, flexible control


Superior smart EDID management for ensuring optimum video performance


2 year warranty

6 Port Multi AV to HDMI 18G Processor Switch with PiP6 - Scales up to 4 video signals across a single display

Key Features:

UHD Video Processor capable of scaling 4 video signals across a single display
Supports resolutions up to 4K 3840x2160 @60Hz
Allows complete control over each window position and size
Full scaling and signal conversion for the most common inputs and a second output for monitoring a single input
2 year warranty


The Lindy Ultra HD Multi-View Video Processor is a powerful solution that allows multiple sources to be shown on a single display along with a second output for monitoring a specific input. The Video Processor features full scaling abilities and signal conversion for complete flexibility.

Ideal for situations where multiple video signals must be constantly monitored, for example CCTV stations or statistic and performance monitoring applications in security, retail or corporate environments.

Featuring HDMI, DisplayPort and VGA inputs with HDMI and DisplayPort outputs the Video Processor can be combined with Lindy's range of high quality Extenders for HDMI, DisplayPort and VGA signals, allowing the Video Processor to be installed near the source or display equipment as required.

Screen Modes and Pre-set Layouts
PoP/PiP and Multi-View video modes can be configured by the unit. This provides complete control over where each input is displayed on a single screen using any combination of up to 4 video sources. 6 pre-set video layouts allow for simple, out of the box, setup and installation. These layouts can be selected using the front panel buttons or using the Web GUI tool.

Monitoring Output
A separate DisplayPort output is provided for full screen monitoring, ideal for close observation of a specific input signal.

Scaling and Signal Conversion
The Video Processor features scaling support which enables you to have different input resolutions and the ability to select the output resolution. Full signal flexibility is provided with integrated signal conversion across the unit, for example VGA signals can be converted to HDMI or DP signals.

Specifications:

AV Interface: HDMI, DisplayPort
Interface Standard: HDMI 2.0, DisplayPort 1.2
Supports Bandwidth: 18 Gbps
Maximum Resolution: 3840x2160@60Hz 4:4:4 8bit
HDCP Support: 2.2
Supported Audio: Audio Pass-through, Stereo Audio
Separate Audio Ports: Terminal Block
Serial Interface: RS232
Special Features: Pip, Multi-View, Scaling
Input: 4 x HDMI (Female), DisplayPort (Female), VGA (Female), 3.5mm (Female)
Output: HDMI (Female), DisplayPort (Female), 3 Pin Terminal Block
Control: RS232, RJ45 (IP)
Power: 5.5/2.1mm DC socket
Dimensions WxHxD: 440x230x45mm (17.32x9.05x1.77in)
Housing Material: Metal
Nett Weight: 2.72Kg (5.99lb)
Operating Temperature : 0°C - 45°C (32°F - 113°F)
Storage Temperature: -20°C - 60°C (-4°F - 140°F)
Humidity: 20 - 90% RH (non-condensing)
Power Requirements: 12VDC 2A
Colour: Black
Packaging Type: Carton box
Packaging Dimensions: 510x400x94mm (20.08x15.75x3.7in)
Gross Weight: 3.58Kg (7.89lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS & REACH
Package Contents:
Ultra HD Multi-View Video Processor
IR Remote Control
19” Rackmount Brackets
Multi-Country Power Supply (EU, UK, US, AUS)
Plastic Feet with screws
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

Overview Matrix Switches are premium solutions for distributing content from multiple source devices to multiple displays

e Lindy 4x4 HDMI Matrix Switch Pro supports HDMI 2.0 18G signals, allowing for the transmission of clear 4K Ultra HD 60Hz resolutions

Additional support for High Dynamic Range ensures video content is displayed with enhanced brightness, greater contrasts and a much wider colour gamut, perfect for digital signage displays in retail, creating informational multi-display setups in education, or distributing content in commercial installations such as cinemas

HDCP 2.2 support ensures there are no issues with a variety of 4K content when connected to source devices including set top boxes, Blu-Ray players and 4K HDR media players.

As well as HDMI audio pass-through, individual SPDIF ports allow for a separate connection of digital speaker systems and amplifiers, creating immersive audio experiences to compliment the video content.

This Matrix can be easily controlled via push button switching on the unit, while the included remote control and IR extension also allows the user to have better control over multiple videos and displays, great for trade shows, training presentations or sales demonstrations.

Product Details Switch between 4 HDMI source devices and 4 HDMI displays connected simultaneously


Supports resolutions up to 4K 60Hz, with additional support for HDR


Extract audio from HDMI to SPDIF for connection to amplifiers and speaker systems


EDID Management system for controlling and ensuring the optimum resolution possible


2 year warranty

70m Cat.6 4x4 HDMI 4K60 Matrix Extender

Key Features:



Distribute 4K HDMI signals to up to 4 displays in multiple locations from 4 different sources.
Supports resolutions up to 4K@60Hz, with additional support for HDR.
Features 4 HDMI outputs on the transmitter for local monitoring, which run simultaneously with the extension output.
Supports Power over Cable (PoC) to the receivers, only a single power supply is required for operation.
2-year warranty


The Lindy 70m Cat.6 4x4 HDMI 4K60 Matrix Extender is a high-performance, professional solution for distribution of 4K HDMI signals to multiple displays using standard Cat.6 network cables from 4 separate HDMI sources.

Professional HDMI Content Distribution
This 4x4 matrix allows for the distribution of HDMI content to 4 separate locations, using the included receivers, at up to 70m in distance, perfect for splitting or switching content to various displays in sports bars, events or residential home cinemas. Each Cat.6 extension output also has a simultaneous HDMI output for local monitoring for each zone, or for a larger install with closely located displays. Each port also support simple independent downscaling to 1920x1080, for consistently ensuring peak performance on a variety of displays. Professional EDID management ensures maximum compatibility with both the source devices and displays.

Eye-Catching 4K and HDR Support
With support for resolutions up to 3840x2160@60Hz, this matrix provides exceptional clarity of high-quality video, including movies, sports, games, or live monitoring. HDR support ensures a much wider colour gamut is supported, alongside higher peak brightnesses and deeper blacks for an enhanced dynamic contrast. This provides an engaging visual experience for the viewer in a variety of different applications including home cinema installations, larger distribution in educational buildings or commercial advertising and displays.

Flexible Control
The included IR cables allow for simple control via an IR remote from any of the receiver locations, removing the need to be situated at the source side on the setup, while push buttons on the main unit provide easy control at the transmitter side. RS-232 and Ethernet connections also provide the ability for integration into larger control systems. An in-built Web-Gui also ensures very simple management using a connected PC.

Simultaneous PoC Distribution
The Cat.6 HDMI 18G Matrix also supports PoC (Power over cable) allowing for power to be distributed alongside audio and video over the cat.6 cabling. This allows for only one power source being required at the transmitter side, ensuring a minimalist and time-saving setup at the receiver locations.

Please Note: The quoted resolutions are possible with a direct connection between transmitter and receiver using good quality Cat.6 solid core cable. Using a different cable type, introducing wall plates, couplers or patch panels will result in a reduction of maximum distances.

Specifications:



AV Interface: HDMI
Interface Standard: HDMI 2.0
Supported Bandwidth: 18Gbps
Maximum Distance: 70m (229.66ft)
Maximum Resolution: 3840x2160@60Hz 4:4:4 8bit
HDCP Support: 2.2
EDID Pass Through: Pass-through
Supported Audio: HDMI Audio Pass-through
IR Support: 20-60kHz
CEC Support: Pass-through
Serial Interface: RS-232
Transmission Medium: 1 x Cat.6 each port
Chipset: GSV
Special Features:
RS-232 & Telnet Control
Mirrored HDMI Outputs
Power over Cable
4K to 1080 Downscaling Per Port
Transmitter Input: 4 x HDMI Type A (Female)
Transmitter Output: 4 x HDMI Type A (Female), 4 x RJ-45 (Female), 4 x 3.5mm IR (Female), RJ-45 LAN Control (Female), 3-Pin Phoenix Connector (Female)
Receiver Input: RJ-45 (Female), 3.5mm IR (Female)
Receiver Output: HDMI Type A (Female)
Power: 5.5/2.1mm
Dimensions (approx.) WxDxH:
Matrix Extender: 320x100x36mm (12.6x3.94x1.42in)
Receiver: 61x88x18mm (2.4x3.46x0.71in)
Housing Material: Metal
Net Weight:
    Matrix Extender: 0.95kg (2.09lb)
    Receiver: 0.14kg (0.31lb)
Operating Temperature: 0°C - 40°C (32°F - 104°F)
Storage Temperature: -20°C - 60°C (-4°F - 140°F)
Humidity: 20 - 90% RH (non-condensation)
Power Requirements: 12VDC 2.5A
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 393x88x271mm (15.47x3.46x10.67in)
Gross Weight: 2.58kg (5.69lb)
Warranty (Years): 2
Certified: CE, UKCA, FCC, RoHS, REACH & California Proposition 65


Package Contents:



70m Cat.6 4x4 HDMI 4K60 Matrix Extender
4 x Cat.6 HDMI Receiver
Multi-country Power Supply (UK, EU, US & AUS)
IR Remote with CR2025 Battery
4 x IR Emitter Cable, 1.5m
4 x Receiver Cable, 1.5m
RS-232 Male to Female Cable, 1.5m
3-Pin Phoenix Connector
10 x Mounting Ears
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

Overview Thank you for purchasing from the Lindy Modular Matrix range of products

This range of products is designed to allow you to create a matrix with 8, 16 or 32 input and output ports

The input ports can be a choice of HDMI, DVI or VGA while the output ports can be HDMI, DVI or C6 HDBaseT

Any of the inputs can be combined with any of the outputs to create a UHD 4Kx2K@60Hz display over distances of up to 100m

The modular design provides the ultimate in flexibility for audio and video distribution as a matrix, convertor or an extender in retail product demonstration, training and public display application in schools, pubs etc.

The 8 Port 4K HDMI Input Modular Board is designed for use with 38250, 38251, 38252 Chassis systems and 38254, 38255, 38256, 38257 & 38259 range of modular boards.

Product Details 8 x HDMI Type A Female Connectors


Input and output modules can be mixed and added in increments of 8


Supports video resolutions up to 4kx2k@60Hz 8 bit 4:2:0


Supports multiple audio signals from Stereo audio to LPCM 7.1Ch & DTS-HD Master Audio Transmission


2 Year Warranty

Product Details Display up to 4 sources in multiple configurations on a single display


Allows 4 inputs to be displayed in multiple different modes including:

Picture in Picture (PiP)


3 different Multi-Window displays


Overlay (Chromakey)



Supports mirror and rotate/flip functions


Seamless switching between HDMI sources


User definable channel size and position adjustment


Independant Audio Channel Selection


Adjustable picture contrast, brightness, saturation and hue


Controlled via on-panel controls, IR Remote, RS-232, Telnet or web GUI


2 Year Warranty


Package Contents HDMI Video Wall 4x4 Matrix


IR Remote Control


Multi-Country 12V 3A Power Supply (UK/EU/US/AUS)


Driver CD


User Manual

Overview This very flexible Lindy 4 x4 HDMI Video Wall Matrix offers maximum convenience when connecting multiple HDMI sources and displays together in one of three output modes; Video Wall, Matrix and dual

It features 4 HDMI input source ports and 4 HDMI output display ports

Each of the 4 sources can be directed to any of the 4 displays using the supplied remote control

It's an ideal solution for multiple HDMI distribution in retail product demonstration, training and public display applications in schools, pubs etc.

Video Wall allows you to create one large display, perfect for use at an exhibition, in a reception or for advertising while Dual Mode means you can display the same combination of 4 sources in 2 room simultaneously, perfect for use in a hotel or university.

Product Details Allows 4 HDMI inputs to be displayed in 3 different modes across 4 HD displays:

Video Wall Mode – Display an HDMI source across a 2x2 video wall


Matrix Mode – Display any HDMI source on any HDMI display


Dual Mode – Display 2 sources on a single HDMI display



Seamless switching between HDMI sources


User definable output scaling


Controlled via On-panel controls, IR Remote, RS-232, Telnet and web GUI


Bezel correction to aide screen blending


Adjustable picture contrast, brightness, saturation and hue


Memory function to store 4 user determined configurations


2 Year Warranty

Overview Switch between 8 HDMI source devices and 8 HDMI displays connected simultaneously Supports resolutions up to 4K 60Hz, with additional support for HDR Extract audio from HDMI to SPDIF for connection to amplifiers and speaker systems EDID Management system for controlling and ensuring the optimum resolution possible 2 year warranty Matrix Switches are premium solutions for distributing content from multiple source devices to multiple displays

The Lindy 8x8 HDMI Matrix Switch Pro supports HDMI 2.0 18G signals, allowing for the transmission of clear 4K Ultra HD 60Hz resolutions

Additional support for High Dynamic Range ensures video content is displayed with enhanced brightness, greater contrasts and a much wider colour gamut, perfect for digital signage displays in retail, creating informational multi-display setups in education, or distributing content in commercial installations such as cinemas

HDCP 2.2 support ensures there are no issues with a variety of 4K content when connected to source devices including set top boxes, Blu-Ray players and 4K HDR media players

As well as HDMI audio pass-through, individual SPDIF ports allow for a separate connection of digital speaker systems and amplifiers, creating immersive audio experiences to compliment the video content

This Matrix can be easily controlled via push button switching on the unit, while the included remote control and IR extension also allows the user to have better control over multiple videos and displays, great for trade shows, training presentations or sales demonstrations.

8x8 HDMI 18G Matrix with Video Wall Scaling

Key Features:



Switches between 8 HDMI source devices and 8 HDMI displays as a professional matrix
Creates single video walls (up to 4x2) or multiple video walls (2x2)
Seamlessly switch between devices under 0.1ms
Control output scaling to ensure the optimum or consistent resolution is shown
2 year warranty


The Lindy 8x8 HDMI 18G Matrix with Video Wall Scaling is the professional solution for distributing content from several source devices to many HDMI displays, or for creating eye-catching video wall setups.

Supporting resolutions up to 4K@60Hz, content can be shown in excellent clarity, great for ensuring a high-quality video experience in sports bars, retail stores or multiple consecutive locations in larger installations. Resolutions can easily be scaled and controlled by the user to ensure the optimum, or consistent, resolution is always displayed.

As well as providing a professional 8x8 matrix switching function, this device can create customisable singular or dual video wall displays in a variety of layouts. This provides the user with a range of flexible display options for their installation and allows the device to be used in a range of specialised environments; including transport hubs, points of sale and hospitality. Analogue audio ports also allow for 2-channel audio extraction, to add immersive stereo audio to the content on screen.

The matrix also provides instant seamless switching between source devices and displays, a crucial feature for use in real time operation centre scenarios such as traffic monitoring, stock market floors or security setups. Controlled via independent IR as well as LAN and push button switching, this matrix ensures minimum effort is required of the user when creating their installation, while RS-232 control also allows for integration into larger control systems.

Professional EDID management ensures maximum compatibility with both the source devices and displays.

Specifications:



AV Interface: HDMI
Interface Standard: 2.0
Supported Bandwidth: 18Gbps
Maximum Resolution: 3840x2160@60Hz 4:4:4 8bit
HDCP Support: 2.2
Supported Audio
HDMI Audio Pass-through
2CH Analogue Audio
IR Support: 38kHz
Serial Interface: RS-232
LED / LCD Display: Yes
Control: IR, Push Button, RS-232, Telnet
Special Features:
Seamless Switching
Video Wall Creation
Independent Audio Extraction
Independent IR Matrix
Output Resolution Scaling
Connectors:
Input: 8 x HDMI Type A (Female), 8 x 3.5mm (Female)
Output: 8 x HDMI Type A (Female), 8 x 3.5mm (Female)
Control: RS-232 (Female), RJ-45 (Female), 8 x IR 3.5mm (Female)
Power: IEC C14 (Male)
Dimensions (approx.): WxDxH 430x300x44mm (16.93x11.81x1.73in)
Housing Material: Metal
Net Weight: 5.236kg (11.54lb)
Operating Temperature:  0°C - 40°C (32°F - 104°F)
Storage Temperature: -20°C - 70°C (-4°F - 158°F)
Humidity: 10-50% RH (non-condensing)
Power Requirements: 100W, 110-240VAC
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 550x120x36mm (21.65x4.72x14.17in)
Gross Weight: 6.26kg (13.8lb)
Warranty: (Years) 2
Certified: CE, UKCA, FCC, RoHS, REACH & California Proposition 65


Package Contents:



8x8 HDMI Matrix
Multi-country C13 Power Cables, 1.5m
8 x IR Emitter Cables
8 x IR Receiver Cables
IR Remote & CR2025 Battery
Lindy Manual


EDID - Extended Display Identification Data.
It is a way for a video source to discover the capabilities of the sink (display device) it is connected to. EDID information resides in the sink and is made available through the connection to a source device via HDMI, DP, DVI etc. When a sink is connected to a source it receives power for its EDID circuit from the source.

Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

5 Port HDMI 2.0 18G Switch

Key Features:



Connect and switch up to 5 UHD HDMI devices to 1 UHD display or projector
Supports video resolutions up to 4K2K@60Hz 8 bit including 3D 1080p
Supports 7.1 channel of LPCM, Dolby TrueHD and DTS-HD Master Audio digital audio signals
HDCP 2.2 compliant for use with the latest AV equipment
2-year warranty


This state-of-the-art 4K UHD HDMI 2.0 18G switch is capable of displaying resolutions up to 3840 x 2160 from 5 UHD signals in to 1 UHD signal out.

An RS232 port is included to allow switching via a PC or control software.

The Switch is also HDR (High Dynamic Range) compatible to reproduce a greater dynamic range of luminosity similar to that used in imaging and photography. HDR used on TVs allows a wider range of colours and greater contrast with whites and blacks, resulting in much higher definition pictures similar to ones seen by the human eye.

With full support for HDCP 2.2 and HDMI 2.0, you can be sure that this product is fully future proof and ready for the new and demanding audio and video signals on the market.

Specifications:



AV Interface: HDMI
Interface Standard: HDMI 2.0
Supports Bandwidth: 18 Gbps
Maximum Resolution: 3840x2160@60Hz 4:4:4 8bit
HDCP Support: 2.2
Supported Audio: Audio Pass-through
Separate Audio Ports: HDMI
IR Support: 38kHz
CEC Support: Pass-Through
Serial Interface: RS232
Input: 5 x HDMI (Female), 3.5mm (Female)
Output: HDMI (Female)
Control: RS232 Port
Power: 5.5/2.1mm DC socket
Dimensions WxDxH: 211x75x25mm (8.31x2.95x0.98in)
Housing Material: Metal
Net Weight: 0.43kg (0.95lb)
Operating Temperature: 0°C - 50°C (32°F - 122°F)
Storage Temperature: -10°C - 50°C (14°F - 122°F)
Humidity: 5 - 85% RH (non-condensing)
Power Requirements: 5VDC 1A
Colour: Black
Packaging Type: Carton box
Packaging Dimensions: 240x165x55mm (9.45x6.5x2.17in)
Gross Weight: 0.659kg (1.45lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS & REACH


Package Contents:



5 Port 4K HDMI 2.0 4K 18G Switch
IR Remote Control (inc battery)
1.2m (3.94ft) IR receiver cable
Multi-Country Power Supply (EU, UK, US & AUS)
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)
