Lindy HDMI Converters

Overview The Lindy Mini DisplayPort to HDMI and VGA Converter allows users to connect either a HDMI or VGA screen to a Mini Displayport source. Supporting 4K resolutions up to 3840x2160@60Hz on HDMI displays. VGA monitors and projectors are supported with up to 1920x1080@60Hz.

With its lightweight, low profile design, this converter easily fits into a notebook bag and simply expands available connectivity options, so users can connect to various digital and analogue video devices, without having to carry multiple adapters.

Product Details Converts a DisplayPort signal to HDMI or VGA


Supports HDMI resolutions up to 4K@60Hz and VGA up to Full HD


Easily connect with a single legacy or modern display at any one time


Compact, portable design


2 year warranty

VGA & Audio to HDMI Converter

Key Features:



Converts and combines VGA video and analogue audio signals into a HDMI signal
Supports resolutions up to 1920x1080/1080/1200@60Hz
Perfect for connecting older VGA computers to a HDMI display
Powered by USB, simple plug and play installation
2 Year Warranty


The Lindy VGA & Audio to HDMI Converter combines analogue video and stereo audio signals and converts them into a HDMI signal, perfect for using legacy PC and AV equipment with HDMI displays. It supports resolutions up to 1920x1080/1200. The integrated USB cable can be connected to a USB port or USB power supply to power the converter.

The converter is also ideally suited for travelling due to its compact, lightweight form factor and convenient Plug & Play installation.

Specifications:



AV Interface: VGA & Audio to HDMI
Interface Standard: HDMI 1.3, VGA
Supported Bandwidth: 4.4Gbps
Maximum Input Resolution: 1920x1080/1200@60Hz
Maximum  Output Resolution: 1920x1080/1200@60Hz
Chipset: MS9282
Supported Audio: Stereo Audio
Separate Audio Ports: 3.5mm Stereo Audio
Special Features: Powered by USB port
Input: VGA Male, 3.5mm Stereo Audio , USB Type A Male (for power)
Output: HDMI Type A Female
Dimensions (approx.) WxDxH: 78x37x15mm (3.07x1.46x0.59in) - Housing
Cable Length: VGA cable: 150mm (5.91in), USB cable: 250mm (9.84in),  Audio cable: 500mm (19.69in)
Housing Material:
VGA/USB/Audio: PVC
HDMI: ABS
Jacket Material:  Nickle plated
Jacket Diameter:
VGA: 5.5mm (0.22in)
Audio: 3mm (0.12in)
USB: 3mm (0.12in)
Minimum Bend Radius: 22mm (0.87in)
Net Weight: 0.09g (0.2lb)
Operating Temperature: 0°C - 70°C (32°F - 158°F)
Storage Temperature: 0°C - 60°C (32°F - 140°F)
Humidity: 10 - 85% RH (non-condensing)
Colour: Black
Packaging Type: Polybag
Packaging Dimensions: 176x194x35mm (6.93x7.64x1.38in)
Gross Weight: 0.104kg (0.23lb)
Warranty (Years): 2
Certified: CE, UKCA, FCC, RoHS & REACH


Package Contents:



VGA & Audio to HDMI Converter
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

Overview The Lindy Mini DisplayPort to HDMI, DVI and VGA Converter allows users to connect either a HDMI, DVI or VGA screen to a Mini Displayport source. Supporting 4K resolutions up to 3840x2160@30Hz on HDMI displays, content can be viewed with superior clarity and stunning accuracy. DVI monitors are supported with a maximum resolution of 1920x1200@60Hz, VGA monitors and projectors up to 1920x1080@60Hz.

With its lightweight, low profile design, this converter easily fits into a notebook bag and simply expands available connectivity options, so users can connect to the most commonly used digital and analogue video equipment, without having to carry multiple adapters - ideal for BYOD applications.

Product Details Converts a DisplayPort signal to HDMI, DVI or VGA


Supports HDMI resolutions up to 4K@30Hz, VGA up to Full HD and DVI up to and above Full HD


Easily connect with a single legacy or modern display at any one time


Compact, portable design


2 year warranty

Overview The Lindy USB 3.1 Type-C to HDMI Adapter Converter allows you to quickly add external video capabilities to devices featuring the USB 3.1 Type-C port with support for DisplayPort Alternate Mode. Installation is simple as no drivers are required and the Type-C's reversible design means that you do not have to pay attention to which way the cable is inserted into the port. Fully compatible with the latest (2016) MacBook Pro models.

The Lindy HDMI to VGA converter converts signals from a HDMI equipped source into a VGA signal. It supports resolutions up to 1920x1200@60Hz for VGA displays.This allows the connection of HDMI capable devices, such as PC’s, notebooks and ultrabooks, to an older VGA display or projector.

The converter can also be used to add another display to extend the available desktop workspace. It is also ideally suited for travelling due to its compact, lightweight form factor and convenient plug & play installation.

Specifications



Converts HDMI signals into VGA
Supports resolutions up to 1920x1200@60Hz
Add a VGA monitor as a secondary display
Quick and simple plug & play installation
2 year warranty

Overview The Lindy Mini DisplayPort 1.2 to HDMI Converter is ideal for connecting a Mini DisplayPort equipped source such as a PC or laptop to an HDMI monitor or TV. It supports resolutions up to 4K 3840x2160@30Hz and allows Audio pass-through if supported by the video source.

The converter can also be used to add another display to extend the available desktop workspace and increase productivity. It is also ideally suited for travelling due to its compact, lightweight form factor and convenient Plug & Play installation.

Product Details Converts a DisplayPort signal into HDMI


Supports resolutions up to 4K 3840x2160@30Hz


Audio pass-through if supported by the video source


Quick and simple Plug & Play installation


2 year warranty

Overview The Lindy Mini HDMI 1.3 to VGA Converter converts signals from an HDMI C equipped source into an analogue VGA signal. It supports resolutions up to 1080p and 1920x1200 for PC VGA displays. This allows the connection of modern HDMI capable devices, such as PC’s, notebooks and ultrabooks, to an older VGA display or projector.

The converter can also be used to add another display to extend the available desktop workspace. It is also ideally suited for travelling due to Its compact, lightweight form factor and convenient plug & play installation.

Product Details Connects an HDMI C equipped device to a VGA display


Supports resolutions up to 1920x1200 including 1080p


Direct signal conversion, without scaling


Quick and simple plug and play installation


2 year warranty

The Lindy HDMI 1.3 to VGA converter converts signals from an HDMI equipped source into an analogue VGA signal. It supports resolutions up to 1080p and 1920x1200 for PC VGA displays. This allows the connection of modern HDMI capable devices, such as PC’s, notebooks and ultrabooks, to an older VGA display or projector.

The converter can also be used to add another display to extend the available desktop workspace. It is also ideally suited for travelling due to its compact, lightweight form factor and convenient plug & play installation.

Specifications



Connects an HDMI equipped device to a VGA display
Supports resolutions up to 1920x1200 including 1080p
Direct signal conversion, without scaling
Quick and simple plug and play installation
2 year warranty

USB Type C to HDMI 4K60 Converter - Connect an HDMI display to your computers USB Type C port

Key Features:



Converts a USB Type C port to an HDMI port
Supports HDMI resolutions up to 4K 3840 x 2160 @ 60Hz 12bit 4:2:2 HDR
Requires DisplayPort Alternate Mode support by the USB Port/Bus
Plug & Play, no drivers required
2 year warranty


The Lindy USB Type C to HDMI Converter allows users to easily add external video capabilities to a computer featuring the USB Type C port with support for DisplayPort Alternate Mode. The converter is powered by the USB Bus, therefore no external power supply is needed, saving space and time when connecting.

With support for 4K UHD resolutions, content can be viewed with superior clarity and stunning accuracy, while the Type C connectors reversible design means a connection can be found regardless of which way the cable is inserted into the port of a laptop, notebook or Macbook.

With Plug and Play installation, this converter can be installed with minimum fuss, perfect for both professional and first time users.

Specifications:



AV Interface: USB Type C to HDMI
Interface Standard: HDMI 2.0
Maximum Input Resolution: 3840 x 2160 @ 60Hz 12bit 4:2:2 HDR
Maximum Output Resolution: 3840 x 2160 @ 60Hz 12bit 4:2:2 HDR
Chipset: RTD2172U
Compatibility: USB Type C or Thunderbolt 3 equipped computers with DisplayPort Alternate Mode support (incl. Apple M1)
HDCP Support: HDCP 1.4 & 2.2
Special Features: DisplayPort Alternate Mode
Inputs: 1 x USB Type C (Male)
Outputs: 1 x HDMI (Female)
Power: Bus-powered
Dimensions (approx.) WxDxH: 45 x 45 x 15mm (1.65 x 1.65 x 0.47in)
(Fixed) Cable Length: 100mm (3.94in)
Housing Material: Plastic
Net Weight: 0.023kg (0.05lb)
Operating Temperature: 0°C - 45°C (32°F - 113°F)
Storage Temperature: -10°C - 70°C (14°F - 158°F)
Humidity: 10 - 85% RH ( non-condensing)
Colour: White
Packaging Type: Polybag
Packaging Dimensions: 174 x 20 x 194mm (6.85 x 0.79 x 7.64in)
Gross Weight: 0.04kg (0.09lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS, REACH & California Proposition 65


Package contents:



USB Type C to HDMI 4K60 Converter
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

Overview The Lindy HDMI 1.3 to VGA and Audio Converter is ideal for connecting HDMI equipped sources such as laptops, ultrabooks and PCs to VGA displays. It converts the HDMI signal (along with the associated digital audio stream) into an analogue VGA signal.

Full HD signals are supported, including 1080p for HDTV connections and up to 1920x1080 for PC VGA monitors.

No external power source is required, which makes this converter the perfect tool for flexible working in different environments, whether it’s in the office, traveling to hold presentations or at home, as it also permits the use of older VGA monitors or projectors to display content.

Product Details Connects an HDMI equipped device to a VGA display and analogue speakers


Supports resolutions up to 1920x1200 including 1080p


Direct signal conversion, without scaling


Quick and simple plug and play installation


2 year warranty

Overview The Lindy Micro HDMI 1.3 to VGA Converter converts signals from an HDMI D equipped source into an analogue VGA signal. It supports resolutions up to 1080p and 1920x1200 for PC VGA displays. This allows the connection of modern HDMI capable devices, such as notebooks, ultrabooks, smartphones and tablets, to an older VGA display or projector.

The converter can also be used to add another display to extend the available desktop workspace. It is also ideally suited for travelling due to its compact, lightweight form factor and convenient plug & play installation.

Product Details Connects an HDMI D equipped device to a VGA display


Supports resolutions up to 1920x1200 including 1080p


Direct signal conversion, without scaling


Quick and simple plug and play installation


2 year warranty

Overview The Lindy Micro HDMI 1.3 to VGA and Audio Converter is ideal for connecting HDMI D equipped sources such as ultrabooks, smartphones and tablets to VGA displays. It converts the HDMI signal (along with the associated digital audio stream) into an analogue VGA signal.

Full HD signals are supported, including 1080p for HDTV connections and up to 1920x1080 for PC VGA monitors. No external power source is required, which makes this converter the perfect tool for flexible working in different environments, whether it’s in the office, traveling to hold presentations or at home, as it also permits the use of older VGA monitors or projectors to display content.

Product Details Connects an HDMI D equipped device to a VGA display and analogue speakers


Supports resolutions up to 1920x1200 including 1080p


Direct signal conversion, without scaling


Quick and simple plug and play installation


2 year warranty

Overview The Lindy Mini HDMI 1.3 to VGA and Audio Converter is ideal for connecting HDMI C equipped sources such as laptops, ultrabooks and PCs to VGA displays. It converts the HDMI signal (along with the associated digital audio stream) into an analogue VGA signal.

Full HD signals are supported, including 1080p for HDTV connections and up to 1920x1080 for PC VGA monitors. No external power source is required, which makes this converter the perfect tool for flexible working in different environments, whether it’s in the office, traveling to hold presentations or at home, as it also permits the use of older VGA monitors or projectors to display content.

Product Details Connects an HDMI C equipped device to a VGA display and analogue speakers


Supports resolutions up to 1920x1200 including 1080p


Direct signal conversion, without scaling


Quick and simple plug and play installation


2 year warranty

Overview The Lindy Mini DisplayPort to HDMI, DVI and VGA Converter allows users to connect either a HDMI, DVI or VGA screen to a Mini Displayport source.

Supporting Ultra HD 4K resolutions up to 3840x2160@60Hz on HDMI displays, content can be viewed with superior clarity and stunning accuracy. DVI monitors are supported with a maximum resolution of 1920x1200@60Hz, VGA monitors and projectors up to 1920x1080@60Hz.

With its lightweight, low profile design, this converter easily fits into a notebook bag and simply expands available connectivity options, so users can connect to the most commonly used digital and analogue video equipment, without having to carry multiple adapters - ideal for BYOD applications.

Product Details Connects a HDMI, DVI-D or VGA display to a Mini DisplayPort device


Supports HDMI resolutions up to 4K@60Hz, VGA up to 1920x1080@60Hz and DVI up to 1920x1200@60Hz


Easily connect with a single legacy or modern display at any one time


Compact, portable design


2 year warranty

USB 3.2 Type C to HDMI Converter with USB Type A port and Power Delivery - Connect an HDMI display, a USB device and a Type C power supply to a single USB Type C port

Key Features:



Adds an HDMI port, a USB Type A port and a Type C power supply port to your computer
Supports HDMI resolutions up to 4K 3840x2160@30Hz
Supports USB 3.2 / 3.1 Gen 1 / USB 3.0 standard (5Gbps)
Supports Power Delivery 3.0 up to 100W
2 year warranty


The Lindy USB 3.1 Type C to HDMI, USB & Power Delivery Converter allows users to maximise the functionality of a single USB 3.1 Type C port by connecting and simultaneously using an HDMI display and USB SuperSpeed peripheral as well as a USB Type C power supply to your MacBook, ultrabook or notebook. The only requirement is that the computer supports the DisplayPort Alternate Mode.

USB Power Delivery of up to 100W provides power to a notebook or ultrabook, simply connect a compatible USB power supply to the USB Type C socket of the converter.

With support for resolutions up to 3840x2160p 30Hz, the converter is ideal for use by designers and video editors.  Installation is simple as no drivers are required, while Type-C's reversible design has been developed to work regardless of which way the cable is inserted into the port.

Information about USB 3.0, 3.1 & 3.2



USB 3.0, USB 3.1 and USB 3.2 PCs, cables and devices are all compatible with each other, when using either a USB Type A or USB Type C host interface.
USB 3.0, USB 3.1 Gen 1 and USB 3.2 Gen 1 all support data transfer rates up to 5 Gbps.
USB 3.1 Gen 2 and USB 3.2 Gen 2 both support data transfer rates up to 10 Gbps.


Specifications:



AV Interface: USB Type C to HDMI
Interface Standard: HDMI 1.4
Maximum Input Resolution: 3840 x 2160 @ 30Hz
Maximum Output Resolution: 3840x2160 @ 30Hz
Chipset:  VL815, AG6311
Compatibility: USB Type C or Thunderbolt 3 equipped computers with DisplayPort Alternate Mode support (incl. Apple M1)
Power Delivery: PD 2.0 up to 60W (20V 3A)
HDCP Support: HDCP 1.4
Special Features: DisplayPort Alternate Mode
Inputs: 1 x USB Type C (Male)
Outputs: 1 x HDMI (Female), 1 x USB Type A (Female)
Power: Bus-powered
Dimensions (approx.) WxDxH: 75.5 x 38.4 x 15.3mm (2.97 x 1.51 x 0.6in)
(Fixed) Cable Length: 180mm (7.09in)
Housing Material: Plastic
Net Weight: 0.042kg (0.09lb)
Operating Temperature: -20°C - 40°C (-4°F - 104°F)
Storage Temperature: -40°C - 80°C (-40°F - 176°F)
Humidity: 5 - 90% RH ( non-condensing)
Power Requirements: -
Colour: White
Packaging Type: Polybag
Packaging Dimensions: 174 x 194mm (6.85 x 7.64in)
Gross Weight: 0.06kg (0.13lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS, REACH & California Proposition 65


Package contents:



USB 3.2 Type C to HDMI Converter
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

Overview The Lindy DisplayPort to HDMI, DVI and VGA Converter allows users to connect either a HDMI, DVI or VGA screen to a Displayport source

Supporting 4K resolutions up to 3840x2160@30Hz on HDMI displays, content can be viewed with superior clarity and stunning accuracy

DVI monitors are supported with a maximum resolution of 1920x1200@60Hz, VGA monitors and projectors up to 1920x1080@60Hz.

With its lightweight, low profile design, this converter easily fits into a notebook bag and simply expands available connectivity options, so users can connect to the most commonly used digital and analogue video equipment, without having to carry multiple adapters - ideal for BYOD applications.

Product Details Converts a DisplayPort signal to HDMI, DVI or VGA


Supports HDMI resolutions up to 4K@30Hz, VGA up to Full HD and DVI up to and above Full HD


Easily connect with a single legacy or modern display at any one time


Compact, portable design


2 year warranty

HDMI to USB Type C Converter with USB Power - Connects an HDMI source to a USB Type C equipped display

Key Features:



Connects an HDMI source to a USB Type C equipped display
Supports resolutions up to 4K UHD 3840x2160@60Hz
Supports 7.1 channel surround audio
Integrated USB Power cable for use with low power HDMI sources
2 year warranty


The Lindy HDMI to USB Type C Converter allows the connection of HDMI source devices, such as a PC, Blu-ray player or media player to USB Type C equipped monitors, digital signage panels and LFDs (Large Format Displays).

More and more displays are using the USB Type C connection, and this cable will allow you to harness the video capabilities from your HDMI source connection, to deliver astonishing quality to a range of displays such as ultra-thin monitors, portable screens, and touch panels as well as smartboards or portable projectors.

Supporting resolutions up to 3840 x 2160 @ 60Hz, this converter outputs content with superior clarity within innovative workspaces, engaging collaboration environments and educational setups. Immersive multi-channel audio is supported up to 7.1CH to compliment the video on screen.

For added convenience the converter features a USB power cable, allowing the converter to be externally powered when used with low power HDMI sources. It is also ideally suited for travelling due to its compact, lightweight form factor and convenient plug & play installation.

Specifications:



AV Interface: HDMI to USB Type C
Interface Standard: HDMI 2.0 / USB Type C with DisplayPort 1.2 Alternate Mode
Supported Bandwidth: 18Gbps
Maximum Input Resolution: 3840 x 2160 @ 60Hz 4.4:4 8bit SDR
Maximum  Output Resolution: 3840 x 2160 @ 60Hz 4.4:4 8bit SDR
Chipset: LTD6711A
HDCP Support: HDCP 1.4
Supported Audio: Supports 7.1 LPCM 192kHz 24bit
Special Features: Optional power via USB
Input: HDMI Type A Male, USB Type A Male for optional power
Output: USB Type C Female
Dimensions (approx.) WxDxH:
Housing: 54.5x42x13.6mm (2.15x1.65x0.54in)
HDMI: 23x19.1x8.5mm (0.9x0.75x0.33in)
USB: 18x13.6x6.72mm (0.7x0.54x0.26in)
Cable Length: USB: 300mm (11.81in); HDMI: 135mm (5.31in)
Housing Material: Aluminium
Jacket Material: PVC
Jacket Diameter: HDMI: 5.2mm (0.2in), USB: 3.5mm (0.14in)
Minimum Bend Radius: 48mm (1.89in)
Net Weight: 0.043kg (0.09lb)
Operating Temperature: 0°C to 45°C (32°F - 113°F)
Storage Temperature: -10°C to + 80°C (14°F - 176°F)
Humidity: 10 - 85% RH (non-condensing)
Colour: Grey
Packaging Type: Polybag
Packaging Dimensions: 174x20x194mm (6.3x0.79x7.64in)
Gross Weight: 0.07kg (0.15lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS & REACH, CP65


Package Contents:



HDMI to USB Type C Converter with USB Power
Lindy manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

The Lindy HDMI 1.4 to DisplayPort 1.1 Converter is ideal for connecting an HDMI equipped source such as a PC, laptop or Blu-ray player to a DisplayPort monitor. It supports video resolutions up to Ultra HD 4K as well as 7.1 channel surround audio.

The converter can also be used to add another display to extend the available desktop workspace and increase productivity. It is also ideally suited for travelling due to its compact, lightweight form factor and convenient Plug & Play installation.

Specifications



Converts an HDMI input into a DisplayPort signal
Supports resolutions up to 3840x2160@30Hz
Supports 7.1 channel surround audio
Quick and simple Plug & Play installation
2 year warranty

HDMI 18G to DisplayPort 1.2 Converter

Key Features:



Converts an HDMI input into a DisplayPort signal
Supports resolutions up to 3840x2160@60Hz
Supports 7.1 channel surround audio
Quick and simple Plug & Play installation
2-year warranty


A converter allows devices which use different interfaces e.g. HDMI and DisplayPort to connect to one another by converting one signal to the other.

The Lindy HDMI 18G to DisplayPort 1.2 Converter allows the connection of HDMI source devices, such as a PC, Blu-ray player or media player to DisplayPort monitors digital signage and LFDs (Large Format Displays). Supporting resolutions up to 3840x2160@60Hz 4:4:4 8bit or 2560x1440@120Hz, this converter ensures superior clarity content within innovative workspaces, engaging collaboration environments and educational setups. Immersive multi-channel audio is supported up to 7.1CH to compliment the video on screen.

The converter can also be used to add another display to extend the available desktop workspace and increase productivity. It is also ideally suited for travelling due to its compact, lightweight form factor and convenient Plug & Play installation.

Specifications:



AV Interface: HDMI to DisplayPort
Interface Standard: HDMI 2.0 / DisplayPort 1.2
Supported Bandwidth: 21.6Gbps
Maximum Input Resolution: 3840x2160@60Hz 4:4:4 8bit SDR
Maximum Output Resolution: 3840x2160@60Hz 4:4:4 8bit SDR
Chipset: LT6711A
HDCP Support: HDCP 2.2
Supported Audio: Supports 7.1 LPCM digital audio up to 192kHz 24bit
Special Features: 3.5/1.35mm DC power connector for optional 5V 1A PSU
Input: HDMI Type A Female
Output: DisplayPort Male
Dimensions (approx.) WxDxH:
40x45x15mm (1.57x1.77x0.59in)
20.5x16.5x3.5mm (0.81x0.65x0.14in) / DP
Cable Length: 95mm (3.74in)
Housing Material: ABS
Jacket Material: ABS
Net Weight: 0.025kg (0.06lb)
Operating Temperature: -20°C - 85°C (-4°F - 185°F)
Storage Temperature: -20°C - 85°C (-4°F - 185°F)
Humidity: 20 - 95% RH (non-condensing)
Colour: White
Packaging Type: Polybag
Packaging Dimensions: 174x194x20mm (6.85x7.64x0.79in)
Gross Weight: 0.030kg (0.07lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS & REACH, CP65


Package Contents:



HDMI 18G to DisplayPort 1.2 Converter


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

Overview The VGA & Audio to HDMI Converter is capable of combining analogue video and stereo audio signals and converting them into a HDMI signal, perfect for using legacy PC and AV equipment seamlessly with the latest LCD, LED and Plasma displays.

The VGA and Audio converter features simple plug and play installation, there is no configuration required as there is no scaling of the video signal, with the output resolution matching the input resolution.

Product Details Converts and combines VGA and analogue audio signals into an HDMI signal


Perfect for using older VGA equipment with a HDMI display


Supports resolutions up to 1080p


Simple plug and play installation


2 year warranty


Please Note: This product is a format converter, from analogue to digital, there is no resolution scaling.

Composite / S-Video to HDMI Converter with Audio - Converts S-Video, Composite and Stereo audio signals to HDMI

Key Features:

Easily connect legacy Composite, S-Video & Audio source devices to modern HDMI displays
Upscales low resolution video to crisp 720 or 1080p
Supports both PAL & NTSC input devices
Connects to external audio devices via a 3.5mm audio output
2 Year warranty
The Lindy Composite / S-Video to HDMI Converter with Audio is a compact device which allows the connection of legacy analogue AV equipment with modern HDMI displays or projectors.

The converter features a built in up-scaler which enhances low resolution video, providing the option to output both Standard, or High-definition HDMI signals, creating a high-quality viewing experience, perfect for home office, security, and CCTV applications.

Compatibility is maximised with support for both PAL & NTSC source devices while a low power requirement through USB creates greater flexibility with installation.

Please Note: Audio through the HDMI connection is not supported on HDMI 2.0 displays.

Specifications:

AV Interface: Composite / S-video / HDMI
Interface Standard: HDMI 1.4
Maximum Input Resolution: 576i
Maximum  Output Resolution: 1080p
Supported Audio: Pass-through
Separate Audio Ports: 3.5mm Stereo Audio
Input : 1 x Composite Video (Female) / 2 x Phono (Female) / 1 x S-Video
Output : 1 x HDMI Type A (Female)
Power : 3.5/1.35mm
Dimensions (approx.) WxDxH: 113x71x24mm (4.45x2.8x0.94in)
Housing Material: Plastic
Net Weight: 0.084kg (0.19lb)
Operating Temperature: 0°C - 70°C (32°F - 158°F)
Storage Temperature: -10°C - 80°C (14°F - 176°F)
Humidity: 10% to 85% RH (no condensation)
Power Requirements: 5VDC 1A
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 190 x 145 x 60mm (7.48 x 5.71 x 2.36in)
Gross Weight: 0.294kg (0.65lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS, REACH, California Proposition 65
Package Content:

HDMI to Composite / S-Video & Stereo Audio converter
Multi-country DC5V1A (UK, EU, US & AUS) Barrel: 3.5/1.35mm
Lindy manual
Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

Overview The Lindy HDMI to DisplayPort, DVI and VGA Converter allows users to connect either a DisplayPort, DVI or VGA screen to an HDMI source. Supporting 4K resolutions up to 3840x2160@30Hz on HDMI displays, content can be viewed with superior clarity and stunning accuracy. DVI and VGA monitors are supported with a maximum resolution of 1920x1200@60Hz.

The integrated USB cable can be connected to a USB port or USB power supply to power the converter.

With its lightweight, low profile design, this converter easily fits into a notebook bag and simply expands available connectivity options, so users can connect to the most commonly used digital and analogue video equipment, without having to carry multiple adapters - ideal for BYOD applications.

Product Details Converts HDMI signals into DisplayPort, DVI or VGA signals


Supports Ultra HD resolutions 3840x2160@30Hz for DisplayPort and Full HD 1920x1200@60Hz for DVI/VGA


Easily connect with a single legacy or modern display at any one time


Quick and simple plug & play installation


2 year warranty

HDMI to Composite & Stereo Audio Converter

Key Features:



Connects a digital HDMI source device to composite PAL or NTSC displays
Supports HDMI resolutions up to 1920x1080 @ 60Hz
Integrated switching controls allow the user to quickly alternate between output formats.
Professional compact design provides flexibility for installation.
2-year warranty


The Lindy HDMI to Composite & Stereo Audio Converter is a compact device which simply connects modern digital AV equipment, to analogue displays. Ideal for use in presentations, tradeshows, retail and entertainment when newer HDMI devices must be connected to legacy displays and projectors.

This easy to use, compact device supports Full HD input resolutions and audio from HDMI and converts this into Composite & Stereo audio signals. Simple, integrated controls allow the user to quickly switch between output video formats depending on the display.

Please note: The HDMI Standard does not allow analogue conversion of HDCP protected video content. For HDCP protected HDMI signals, no output on the analogue video or audio connectors will be generated.

Specifications:



AV Interface: HDMI / Composite / RCA Stereo Audio
Maximum Input Resolution: 1920x1080@60Hz
Maximum Output Resolution: PAL 480i / NTSC 576i
Supported Audio: Pass-through
Input: HDMI Type A (Female)
Output: 1x Composite Video (Female), 2 x Phono (Female)
Power: 5.5/2.1mm
Dimensions (approx.) WxDxH: 102x100x25mm (4.02x3.94x0.98in)
Housing Material: Metal
Net Weight: 0.295kg (0.65lb)
Operating Temperature: 0°C - 45°C (32°F - 113°F)
Storage Temperature: -10°C - 70°C (14°F - 158°F)
Humidity: 10% to 85% RH (no condensation)
Power Requirements: 5VDC 1A
Colour: Black
Packaging Type: Carton Box
Packaging Dimensions: 220x190x55mm (8.66x7.48x2.17in)
Gross Weight: 0.315kg (0.65lb)
Warranty (Years): 2
Certified: CE, UKCA, FCC, RoHS, REACH, California Proposition 65


Package content:



HDMI to Composite & Stereo Audio converter
USB to DC Cable 5.5/2.1mm
Lindy manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

USB 3.0 Type A and C to HDMI & VGA Converter - Connect an HDMI or VGA display to the USB 3.0 Type A or Type C port

Key Features:



Connects an HDMI and/or VGA display to the USB 3.0 Type A or Type C port
Supports resolutions up to 3840x2160@30Hz (HDMI) and 1080p 60Hz (VGA)
Software-based Silicon solution to connect any display to any computer that supports USB
Easy to install and bus-powered from the USB port
2 year warranty


The Lindy USB 3.0 Type A & C to HDMI & VGA Converter allows users to display 4K and/or Full HD 1080p video and graphics on your TV, monitor or projector via a computer's USB 3.0 Type A or Type C port. It is the ideal solution for computers, which do not support MST and require several video outputs.

Perfect for connecting a display to USB 3.0 Type A or C equipped computers, this converter is a simple, high performance alternative to installing a traditional graphics card. It can be used as a primary, mirrored or extended desktop and it also supports audio transmission via HDMI.

Specifications:



AV Interface: USB Type A and C to HDMIand VGA
Interface Standard: HDMI 1.4, USB 3.0
Maximum Input Resolution: 3840x2160 30Hz
Maximum Output Resolution: HDMI: 3840x2160P 30Hz, VGA: 1920x1080P 60Hz
Chipset: SM768GX
Compatibility: USB Type A and Type C equipped computers
Supported Audio: Stereo, Multi-Channel 5.1, LPCM 16bit, 32/44.1/48KHz
Special Features: Software-based Silicon solution to connect any display to any computer that supports USB, compatible with Windows and MacOS
Inputs: 1 x USB Type A and C (Male)
Outputs: 1 x HDMI (Female), 1x VGA (Female)
Power: Bus-powered
Dimensions (approx.) WxDxH: 105x43x14mm (4.13x1.69x0.55in)
(Fixed) Cable Length: 100mm (3.94in)
Housing Material: Plastic
Net Weight: 0.06kg (0.13lb)
Operating Temperature: -20°C - 40°C (-4°F - 104°F)
Storage Temperature: -40°C - 80°C (40°F - 176°F)
Humidity: 0 - 85% RH ( non-condensing)
Power Requirements: -
Colour: Black
Packaging Type: Polybag
Packaging Dimensions: 174x194mm (6.85x7.64in)
Gross Weight: 0.09kg (0.2lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS & REACH, CP65


Package Contents:



USB 3.0 to HDMI & VGA Converter
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

Overview The Lindy HDMI ARC Digital to Analog Converter is a perfect solution for converting HDMI audio signals from a TV’s ARC (Audio Return Channel) connection to an analog stereo output, for a high quality listening experience of movies, games and music.

With a single HDMI input, and L/R Phono outputs, this audio converter is the ideal solution for connecting ARC supported TV’s with no analog audio connections, to older audio amplifiers, receivers or 2-channel speaker systems, with no loss in audio quality for a superior 2-channel audio experience that enhances the impact of video or audio content

With support for a hi-res sampling frequency of up to 24 bit / 192kHz, music can be heard exactly how the artist and sound engineers intended, with greater detail and clarity, while also ensuring movies are heard with dynamic multi-channel audio, for a true home cinema experience.

Featuring a minimalist and stylish design, the converter can also be hidden out of sight to compliment the popular trend of discreet AV installations for both home users and professional installers

Installation is quick and hassle free.

Product Details Extracts HDMI audio from a TV’s ARC connection and converts it to an analog L/R output


Supports 2 channel analog stereo output


Supports audio sample rates up to 24bit/192kHz


Minimalistic, compact design and simple functionality


2 year warranty

USB Type C, mDP & DisplayPort to HDMI 18G Converter Tether

Key Features:



Connects a Type C, Mini-DP or DP source device to a securely fitted HDMI cable
High-quality stainless-steel ring with all connectivity options
Fitted with a cable clamp for securing the HDMI cable
Supports resolutions up to 4K@60Hz 4:4:4 8bit
2-Year Warranty


Converter tethers, or adapter rings, are compact, secure solutions for equipping the correct converter to a secure display cable, providing simple connectivity for different users and source devices.

The Lindy USB Type C, mDP & DisplayPort to HDMI 18G Converter Tether is a superior, multi-av solution with separate USB Type C, Mini DP and DisplayPort to HDMI converters, all fitted securely to a 15cm diameter stainless-steel tether for easy access when required. With a built-in clamp which fits around the displays HDMI cable*, this tether is perfect for presentation or collaborative environments where different users will have a variety of source devices and connections. This ensures the adapters are also fixed in place ready for the next user.

With active chipset conversion each converter provides enhanced compatibility with many different source connections and graphics cards including PCs, notebooks and tablets. Supporting resolutions up to 3840x2160@60Hz 4:4:4 8bit, each converter ensures a premium viewing experience, perfect for immersive learning experiences in classrooms, engaging conference room displays or field-based demonstrations and training.

*The HDMI cable clamp will fit cables up to approx. 8mm (0.31in) diameter

Specifications:



AV Interface: USB Type C, Mini DisplayPort, DisplayPort to HDMI
Interface Standard: DisplayPort 1.2, HDMI 2.0
Supported Bandwidth: 18Gbps
Maximum Input Resolution: 3840x2160@60Hz 4:4:4 8Bit
Maximum Output Resolution: 3840x2160@60Hz 4:4:4 8Bit
Chipset: DisplayPort : PS176, mDP: PS176, USB Type C: VL100 + PS176
HDCP Support: 2.2
Supported Audio: Digital Audio Pass-through
Input : USB Type C (Male), Mini DisplayPort (Male), DisplayPort (Male)
Output : HDMI Type A (Female)
Dimensions (approx.) WxDxH: USB Type C Connector: 7.6x25x6.6mm (0.3x0.98x0.26in) to HDMI: 37x42x12mm (1.46x1.65x0.47in)
Mini DP Connector: 20x26x9.5mm (0.79x1.02x0.37in) to HDMI: 45x45x15mm (1.77x1.77x0.59in)
DisplayPort Connector: 31.5x20x9mm (1.24x0.79x0.35in) to HDMI:45x45x15mm (1.77x1.77x0.59in)
Cable Length: USB Type C to HDMI: 125mm (4.92in), Mini DP to HDMI: 135mm (5.31in), DP to HDMI: 120mm (4.72in)
Housing Material: Plastic
Jacket Material: PVC
Jacket Diameter: DisplayPort & mDP: 5mm (0.2in), USB Type C: 4mm (0.16in)
Minimum Bend Radius: DisplayPort & mDP: 55mm (2.17in), USB Type C: 40mm (1.57in)
Net Weight: 0.08kg (0.18lb)
Operating Temperature: 0°C - 45°C (32°F - 113°F)
Storage Temperature: -10°C - 70°C (14°F - 158°F)
Humidity: 10 - 90% RH (non-condensing)
Colour: Black
Packaging Type: Polybag
Packaging Dimensions: 236x255mm (9.29x10.04in)
Gross Weight: 0.1kg (0.22lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS, REACH & California Proposition 65


Package Contents:



USB Type C, mDP & DisplayPort to HDMI 18G Converter Tether
PH0x75 Screwdriver


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

HDMI 18G to DisplayPort 1.2 Converter - Convert HDMI 18G signals to DisplayPort 1.2

Key Features:



Converts HDMI 2.0 18G to DisplayPort 1.2 signals
High quality digital and analogue audio extraction
EDID switches to provide specific source resolutions
Supports resolutions up to 4096x2160@60Hz 4:4:4 8bit
2 Year Warranty


The HDMI 18G to DisplayPort 1.2 Converter has been designed as a professional method to convert a 18G HDMI 2.0 signal to a DisplayPort 1.2 signal as well as supporting the separation of high quality stereo analogue audio and digital SPDIF audio. This is ideal for high end applications where a high bandwidth conversion is required such as gaming and pro AV, where the source device does not natively support a DisplayPort output.

The unit is capable of resolutions up to 4096x2160@60Hz, however with the included EDID management it provides the option for 3840x2160@60Hz and 30Hz as well as 1080p@60Hz for the source device, to avoid any compatibility issues, perfect for a hassle-free installation.

Please note: This is not a bi-directional converter, it only works from a HDMI source to a DisplayPort sink device.

Specification:



AV Interface: HDMI to DisplayPort
Interface Standard: HDMI 2.0, DisplayPort 1.2
Supported Bandwidth: 18Gbps
Maximum Input Resolution: 4096x2160@60Hz 4:4:4 8bit
Maximum Output Resolution: 4096x2160@60Hz 4:4:4 8bit
HDCP Support: 2.2
Supported Audio: PCM, Dolby, DTS
Separate Audio Ports: SPDIF (RCA), 3.5mm Stereo
Input: 1 x HDMI Female
Output: 1 x DisplayPort Female, 1 x 3.5mm Stereo Audio, 1 x SPDIF (RCA)
Power: 5.5/2.1mm
Dimensions (approx.) WxDxH: 112x92x23mm (4.41x3.62x0.91in)
Housing Material: Metal
Net Weight: 0.626kg (1.38lb)
Operating Temperature: 0°C - 40°C (32°F - 104°F)
Storage Temperature: -20°C - 60°C (-4°F - 140°F)
Humidity: 20-90% RH (non-condensing)
Power Requirements: 5VDC 2A
Colour: Black
Packaging Type: Carton
Packaging Dimensions: 198x137x74mm (7.8x5.39x2.91in)
Gross Weight: 0.23kg (0.51lb)
Warranty (Years): 2
Certificated: CE, FCC, REACH & RoHS
Package Contents:
HDMI 2.0 to DisplayPort 1.2 Converter
Multi-Country Power Supply  (US, UK, EU & AUS)
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

DisplayPort 1.4 to HDMI 8K Active Converter - Convert a DisplayPort signal to HDMI 8K

Key Features:



Connects a DisplayPort 1.4 computer to an HDMI 8K display
Supports resolutions up to 7680x4320@60Hz and 3840x2160 @120Hz
Audio pass-through if supported by the video source
Active chipset for enhanced compatibility with various graphic cards
2 year warranty


The Lindy DisplayPort 1.4 to HDMI 8K Converter is a high-performance solution that converts a DisplayPort 1.4 signal to HDMI with video resolutions of 8K 7680 x 4320 @ 60Hz and 4K120Hz*, making it the ideal tool for 8K game streaming or high-resolution 8K video editing. Additional support for High-Dynamic Range ensures video content can be seen with enhanced brightness, superior contrasts and a much wider colour gamut, for more lifelike colour. For best performance the use of Ultra High-Speed HDMI Cables is recommended.

HDCP 2.2 ensures issue-free playback of 8K Ultra HD movies and other 8K content. Active conversion guarantees compatibility with various graphics cards including AMD Eyefinity, NVIDIA surround and Intel Collage, great for an immersive gaming setup or a productive multi-screen working experience. The converter features a USB Type C port for power; please connect a 5VDC 1A power supply with USB Type C connector (not included).

* Please update your graphic drivers and make sure that DSC v1.2a is supported on your devices

Specifications:



AV Interface: DisplayPort to HDMI
Interface Standard: DisplayPort 1.4, HDMI 2.1
Supported Bandwidth: 48Gbps
Maximum Input Resolution: 7680 x 4320 @ 60Hz and 3840 x 2160 @ 120Hz
Maximum  Output Resolution: 7680 x 4320 @ 60Hz and 3840 x 2160 @ 120Hz
Chipset: RTD2173 (Realtek)
HDCP Support: HDCP 2.2
Supported Audio: Pass-through
Special Features: HDR support, DSC v1.2a support
Input: DisplayPort Male
Output: HDMI Type A Female
Dimensions (approx.) W x D x H: 60 x 31.5 x 14mm (2.36 x 1.24 x 0.55in)
Cable Length: 110mm (4.33in)
Housing Material: ABS and Aluminium
Jacket Material: PVC
Jacket Diameter: 4.8mm (0.19in)
Net Weight: 0.04kg (0.09lb)
Operating Temperature: -20°C - 40°C (-4°F - 104°F)
Storage Temperature: -40°C - 80°C (-40°F - 176°F)
Humidity: 0 - 85% RH (non-condensing)
Colour: Grey
Packaging Type: Polybag
Packaging Dimensions: 174 x 194mm (6.85 x 7.64in)
Gross Weight: 0.042kg (0.09lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS & REACH, California Proposition 65


Package Contents:



DisplayPort 1.4 to HDMI 8K Active Converter

VGA & Audio to HDMI Converter

Key Features:



Converts and combines VGA video and analogue audio signals into a HDMI signal
Supports resolutions up to 1920x1080@60Hz
Perfect for connecting older VGA computers to a HDMI display
Powered by USB, simple plug and play installation
2 Year Warranty


The Lindy VGA & Audio to HDMI Converter combines analogue video and stereo audio signals and converts them into a HDMI signal, perfect for using legacy PC and AV equipment with HDMI displays. It supports resolutions up to 1920x1080. The integrated USB cable can be connected to a USB port or USB power supply to power the converter.

The converter is also ideally suited for travelling due to its compact, lightweight form factor and convenient Plug & Play installation.

Specifications:



AV Interface: VGA & Audio to HDMI
Interface Standard: HDMI 1.3, VGA
Supported Bandwidth: 4.95Gbps
Maximum Input Resolution: 1920x1080@60Hz
Maximum Output Resolution: 1920x1080@60Hz
Chipset: AG02EX
Supported Audio: Stereo Audio
Special Features: Powered by USB port
Input: VGA Male, 3.5mm Stereo Audio , USB Type A Male (for power)
Output: HDMI Type A Female, 3.5mm Audio
Dimensions (approx.) WxDxH: 45x45x16mm (1.77x1.77x0.63in)
Cable Length: VGA cable: 140mm (5.51in), USB cable: 600mm (23.62in),  Audio cable: 565mm (22.24in)
Housing Material:
    VGA/USB/Audio: PVC
    HDMI: ABS
    Jacket Material: PVC
Jacket Diameter:
    VGA: 5.5mm (0.22in)
    Audio: 3mm (0.12in)
    USB: 3mm (0.12in)
Net Weight: 0.081g (0.18lb)
Operating Temperature: 0°C - 70°C (32°F - 158°F)
Storage Temperature: 0°C - 60°C  (32°F - 140°F)
Humidity: 10 - 85% RH (non-condensing)
Colour: Black
Packaging Type: Polybag
Packaging Dimensions: 176x194mm (6.93x7.64in)
Gross Weight: 0.12kg (0.26lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS & REACH, CP65


Package Contents:



VGA & Audio to HDMI Converter
Lindy Manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)

HDMI 18G to DisplayPort 1.2 Converter with USB Power

Key Features:



Connects an HDMI source to a DP display
Supports resolutions up to 4K UHD 3840x2160@60Hz
Integrated USB Power cable for use with low power HDMI sources
High Dynamic Range support provides deeper blacks, brighter whites and a wider colour gamut
2-year warranty


A converter allows devices which use different interfaces e.g. HDMI and DVI to connect to one another by converting one signal to the other.

The Lindy HDMI 18G to DisplayPort 1.2 Converter allows the connection of HDMI source devices, such as a PC, Blu-ray player or media player to DisplayPort monitors digital signage and LFDs (Large Format Displays). Supporting resolutions up to 3840x2160@60Hz 4:4:4 8bit, this converter ensures superior clarity content within innovative workspaces, engaging collaboration environments and educational setups. Immersive multi-channel audio is supported up to 7.1CH to compliment the video on screen.

For added convenience the converter features a USB power cable, allowing the converter to be externally powered when used with low power HDMI sources. The converter can also be used to add an additional display to extend the available desktop workspace. It is also ideally suited for travelling due to its compact, lightweight form factor and convenient plug & play installation.

Specifications:



AV Interface: HDMI to DisplayPort
Interface Standard: HDMI 2.0 / DisplayPort 1.2
Supported Bandwidth: 21.6Gbps
Maximum Input Resolution: 3840x2160@60Hz 4:4:4 8bit SDR
Maximum Output Resolution: 3840x2160@60Hz 4:4:4 8bit SDR
Chipset: LT6711A
HDCP Support: HDCP 1.4
Supported Audio: Supports 7.1 LPCM digital audio up to 192kHz 24bit
Special Features: Optional power via USB
Input: HDMI Type A Male / USB Type A Male for Optional Power
Output: DisplayPort Female
Dimensions (approx.) WxDxH:
48x11x20.7mm (1.89x0.43x0.81in) / HDMI
31.8x21x11.5mm (1.25x0.83x0.45in) / DP
7.9x16x21mm (0.31x0.63x0.83in) / USB
Cable Length: 180mm (7.09in)
Housing Material: plastic
Jacket Material: PVC
Jacket Diameter: 4.8mm (0.19in)
Minimum Bend Radius: 48mm (1.89in)
Net Weight: 0.053kg (0.12lb)
Operating Temperature: 0°C - 45°C (32°F - 113°F)
Storage Temperature: -10°C - 80°C (14°F - 176°F)
Humidity: 10 - 85% RH (non-condensing)
Colour: Black, red USB connector
Packaging Type: Polybag
Packaging Dimensions: 174x194x20mm (6.85x7.64x0.79in)
Gross Weight: 0.089kg (0.2lb)
Warranty (Years): 2
Certificated: CE, FCC, RoHS & REACH, California Proposition 65


Package Contents:



HDMI to DisplayPort Converter with USB Power
Lindy manual


Datasheets / User Manuals / Quick Start Guides/ Charts can be downloaded from our Documentation tab (above)
