Juniper Networks EX3400 Optics

EX-SFP-10GE-DAC-1M 1m Twinax Copper Cable

SFP+ 10-Gigabit Ethernet Direct Attach Copper

Small form-factor pluggable plus transceiver (SFP+) direct attach copper (DAC) cables, also known as Twinax cables, are suitable for in-rack connections between servers and switches. They are suitable for short distances, making them ideal for highly cost-effective networking connectivity within a rack and between adjacent racks.

The cables are hot-removable and hot-insertable: You can remove and replace them without powering off the switch or disrupting switch functions. A cable comprises a low-voltage cable assembly that connects directly into two 10-Gigabit Ethernet (GbE) ports, one at each end of the cable. The cables use high-performance integrated duplex serial data links for bidirectional communication and are designed for data rates of up to 10 Gbps.

EX-SFP-10GE-DAC-3M 3m Twinax Copper Cable

SFP+ 10-Gigabit Ethernet Direct Attach Copper

Small form-factor pluggable plus transceiver (SFP+) direct attach copper (DAC) cables, also known as Twinax cables, are suitable for in-rack connections between servers and switches. They are suitable for short distances, making them ideal for highly cost-effective networking connectivity within a rack and between adjacent racks.

The cables are hot-removable and hot-insertable: You can remove and replace them without powering off the switch or disrupting switch functions. A cable comprises a low-voltage cable assembly that connects directly into two 10-Gigabit Ethernet (GbE) ports, one at each end of the cable. The cables use high-performance integrated duplex serial data links for bidirectional communication and are designed for data rates of up to 10 Gbps.

EX-SFP-10GE-DAC-5M 5m Twinax Copper Cable

SFP+ 10-Gigabit Ethernet Direct Attach Copper

Small form-factor pluggable plus transceiver (SFP+) direct attach copper (DAC) cables, also known as Twinax cables, are suitable for in-rack connections between servers and switches. They are suitable for short distances, making them ideal for highly cost-effective networking connectivity within a rack and between adjacent racks.

The cables are hot-removable and hot-insertable: You can remove and replace them without powering off the switch or disrupting switch functions. A cable comprises a low-voltage cable assembly that connects directly into two 10-Gigabit Ethernet (GbE) ports, one at each end of the cable. The cables use high-performance integrated duplex serial data links for bidirectional communication and are designed for data rates of up to 10 Gbps.

EX-SFP-10GE-DAC-7M 7m Twinax Copper Cable

SFP+ 10-Gigabit Ethernet Direct Attach Copper

Small form-factor pluggable plus transceiver (SFP+) direct attach copper (DAC) cables, also known as Twinax cables, are suitable for in-rack connections between servers and switches. They are suitable for short distances, making them ideal for highly cost-effective networking connectivity within a rack and between adjacent racks.

The cables are hot-removable and hot-insertable: You can remove and replace them without powering off the switch or disrupting switch functions. A cable comprises a low-voltage cable assembly that connects directly into two 10-Gigabit Ethernet (GbE) ports, one at each end of the cable. The cables use high-performance integrated duplex serial data links for bidirectional communication and are designed for data rates of up to 10 Gbps.

EX-SFP-1GE-LX40K Gigabit Ethernet Optics

SFP 1000BASE-LX, 1310 nm for 40 km transmission on SMF

Juniper Networks devices support a variety of fixed and pluggable transceivers and network cable, including multimode and single-mode fiber-optic cable. We strongly recommend that only transceivers qualified for Juniper Networks be used on Juniper Networks devices. Different transceiver types (long-range, short-range, copper, and others) can be used together on multiport interface modules as long as they are qualified by Juniper Networks. We cannot guarantee that the interface module will operate correctly if third-party transceivers are used.

EX-SFP-GE10KT13R15 Gigabit Ethernet Optics

SFP 1000BASE-BX, Tx 1310 nm/Rx 1550 nm for 10 km transmission on single strand of SMF

Juniper EX-SFP-GE10KT13R15. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Certification: MSA

EX-SFP-GE10KT13R14 Gigabit Ethernet Optics

SFP 1000BASE-BX, Tx 1310 nm/Rx 1490 nm for 10 km transmission on single strand of SMF

Juniper EX-SFP-GE10KT13R14. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Compatible products: Juniper EX4200, Certification: MSA. Input voltage: 3.3 V. Width: 13.4 mm, Depth: 56.5 mm, Height: 8.5 mm

EX-SFP-GE10KT14R13 Gigabit Ethernet Optics

SFP 1000BASE-BX, Tx 1490 nm/Rx 1310 nm for 10 km transmission on single strand of SMF

Juniper EX-SFP-GE10KT14R13. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Certification: MSA

EX-SFP-GE10KT15R13 Gigabit Ethernet Optics

SFP 1000BASE-BX, Tx 1550 nm/Rx 1310 nm for 10 km transmission on single strand of SMF

Juniper EX-SFP-GE10KT15R13. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Certification: MSA

EX-SFP-GE80KCW1610 LC connector

SFP Gigabit Ethernet CWDM, 1610 nm, 80 km reach on single-mode fiber

Juniper EX-SFP-GE80KCW1610. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Compatible products: Juniper EX4200, Certification: MSA. Input voltage: 3.3 V

EX-SFP-GE80KCW1490 LC connector

SFP Gigabit Ethernet CWDM, 1490 nm, 80 km reach on single-mode fiber

Juniper EX-SFP-GE80KCW1490. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Compatible products: Juniper EX4200, Certification: MSa. Input voltage: 3.3 V

EX-SFP-GE80KCW1510 LC connector

SFP Gigabit Ethernet CWDM, 1510 nm, 80 km reach on single-mode fiber

Juniper EX-SFP-GE80KCW1510. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Compatible products: Juniper EX4200, Certification: MSA. Input voltage: 3.3 V

EX-SFP-GE80KCW1530 LC connector

SFP Gigabit Ethernet CWDM, 1510 nm, 80 km reach on single-mode fiber

Juniper EX-SFP-GE80KCW1530. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Compatible products: Juniper EX4200, Certification: MSA. Input voltage: 3.3 V

EX-SFP-GE80KCW1550 LC connector

SFP Gigabit Ethernet CWDM, 1550 nm, 80 km reach on single-mode fiber

Juniper EX-SFP-GE80KCW1550. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Compatible products: Juniper EX4200, Certification: MSA. Input voltage: 3.3 V. Width: 13.4 mm, Depth: 56.5 mm, Height: 8.5 mm

EX-SFP-GE80KCW1570 LC connector

SFP Gigabit Ethernet CWDM, 1550 nm, 80 km reach on single-mode fiber

Juniper EX-SFP-GE80KCW1570. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Compatible products: Juniper EX4200, Certification: MSA. Input voltage: 3.3 V

EX-SFP-GE80KCW1470 LC connector

SFP Gigabit Ethernet CWDM, 1470 nm, 80 km reach on single-mode fiber

Juniper EX-SFP-GE80KCW1470. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Compatible products: Juniper EX4200, Certification: MSA. Input voltage: 3.3 V. Width: 13.4 mm, Depth: 56.5 mm, Height: 8.5 mm

EX-SFP-GE80KCW1590 LC connector

SFP Gigabit Ethernet CWDM, 1590 nm, 80 km reach on single-mode fiber

Juniper EX-SFP-GE80KCW1590. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Compatible products: Juniper EX4200, Certification: MSA. Input voltage: 3.3 V. Width: 13.4 mm, Depth: 56.5 mm, Height: 8.5 mm

EX-SFP-GE40KT13R15 Gigabit Ethernet Optics

SFP 1000BASE-BX, Tx 1310 nm/Rx 1550 nm for 40 km transmission on single strand of SMF

Juniper EX-SFP-GE40KT13R15. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Compatible products: Juniper EX4200, Certification: MSA. Input voltage: 3.3 V. Width: 13.4 mm, Depth: 56.5 mm, Height: 8.5 mm

EX-SFP-GE40KT15R13 Gigabit Ethernet Optics

SFP 1000BASE-BX, Tx 1550 nm/Rx 1310 nm for 40 km transmission on single strand of SMF

Juniper EX-SFP-GE40KT15R13. SFP transceiver type: Fiber optic, Maximum data transfer rate: 1000 Mbit/s, Interface type: SFP. Certification: MSA

EX-SFP-1GE-LH Gigabit Ethernet Optics

SFP 1000BASE-LH, 1550 nm for 70 km transmission on SMF

Juniper Networks devices support a variety of fixed and pluggable transceivers and network cable, including multimode and single-mode fiber-optic cable. We strongly recommend that only transceivers qualified for Juniper Networks be used on Juniper Networks devices. Different transceiver types (long-range, short-range, copper, and others) can be used together on multiport interface modules as long as they are qualified by Juniper Networks. We cannot guarantee that the interface module will operate correctly if third-party transceivers are used.

EX-SFP-10GE-ZR LC connector

SFP+ 10GBASE-ZRr; 1550 nm; 80 km reach on single-mode fiber

This is an optional uplink module for EX4200 switches support SFP, SFP+, or XFP transceivers. The Gigabit Ethernet SFP, SFP+, or XFP transceivers installed in EX4200 switches support digital optical monitoring (DOM). Use only optical transceivers and optical connectors purchased from Juniper Networks for your EX Series switches.
