Excel 16 Port Patch Panel Cat5e - 1u RJ45 UTP complies with the current standards for enhanced Category 5. Each panel offers a choice of labelling with the option to use the screen printed fields on the panel fascia or the slide label system or pre printed 1-96 labelling scheme which is enclosed with each panel. Ease of installation is assured with ample rear cable management positions and LSA IDC blocks. Cage nuts and mini cable ties are included with each panel.
Key Features of Excel 16 Port Cat5e Patch Panel - 1u RJ45 UTP:
Category 5e compliant
Supports Gigabit Ethernet
Cage nuts and mini cable ties included
LSA Style Termination Blocks
T568A/B Wiring Configuration
Pre Printed 1-96 Self Adhesive Labelling included
Performance Overview
Excel Category 5e Patch Panels are manufactured to and tested to the current Category 5 enhanced standards as defined by the TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications.
Accessories
(Sold Separately)
Cat5e Patch Leads
IDC Punchdown Tool
Cat5e Solid Cable
Cat5e Modules
Colour: |
24 Port 1U Excel Category 5e Patch Panels comply with the current standards for enhanced Category 5. Each panel offers a choice of labelling with the option to use the screen printed fields on the panel facia or the slide label system or pre printed 1-96 labelling scheme which is enclosed with each panel. Ease of installation is assured with ample rear cable management positions and LSA IDC blocks. Each panel is available in a choice of colours to allow identification of either applications, departments or services. Cage nuts and mini cable ties are included with each panel.
Key Features of Excel 24 Port Cat5e Patch Panel - 1u RJ45 UTP:
Category 5e compliant
Choice of Colours
Supports Gigabit Ethernet
Cage nuts and mini cable ties included
LSA Style Termination Blocks
T568A/B Wiring Configuration
Pre Printed 1-96 Self Adhesive Labelling included
Performance Overview
Excel Category 5e Patch Panels are manufactured to and tested to the current Category 5 enhanced standards as defined by the TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications.
Accessories
(Sold Separately)
Cat5e Patch Leads
IDC Punchdown Tool
Cat5e Solid Cable
Cat5e Modules
Colour: |
Excel Category 5e Patch Panels comply with the currrent standards for enhanced Category 5. Ease of installation is assured with built in rear cable management at a 90 degree angle to the panel facia.
The 48 Port Patch Panel features a removable 'upper deck' arrangement to ensure ease of termination of the cables. This tray also holds the LSA termination blocks. Cage nuts and mini cable ties are included with each panel.
Features and Benefits
Category 5e
Supports Gigabit Ethernet
Cage nuts and mini cable ties included
LSA Style Termination Blocks
T568A/B Wiring Configuration
25 Year system warranty
Product specifications for these products can be found in the Documentation tab
Excel 48-Port 2U Category 5e Patch Panel | High-Density Gigabit Solution
The Excel Category 5e Patch Panel is a professional-grade 2U solution engineered to exceed "Enhanced Category 5" standards. Designed for high-demand networking environments, this panel supports Gigabit Ethernet with significant performance headroom, ensuring reliable data transmission for critical enterprise applications.
Performance & Testing Rigor
Exceeds Industry Standards: Rigorously tested to TIA and ISO Category 5e specifications.
Advanced Frequency Analysis: Every panel undergoes swept frequency testing for critical characteristics, including Near-End Crosstalk (NEXT) and Far-End Crosstalk (FEXT).
Power Sum Certified: Verified using both Worst Case and Power Sum test methods to ensure maximum signal integrity and reduced interference.
Installation & Versatile Labeling
LSA Style Termination: Features industry-standard LSA IDC blocks for fast, reliable punchdown termination.
Dual Wiring: Supports both T568A and T568B wiring configurations for global compatibility.
Advanced Labeling System: Offers three distinct labeling methods to suit any workflow:
Screen-printed fields on the panel fascia.
An integrated slide label system.
Included pre-printed 1-96 self-adhesive labels.
Design & Included Hardware
High-Capacity 2U Form Factor: Provides 48 ports in a standard 19-inch 2U footprint, perfect for high-density rack setups.
Enhanced Cable Management: Designed with ample rear positions to ensure neat cable dressing and strain relief.
Complete Kit: Ships with cage nuts and mini cable ties included, making it ready for immediate deployment.
Technical Specifications
Feature
Specification Details
Category
Category 5e (Enhanced)
Performance
Supports Gigabit Ethernet (1000Base-T)
Port Count
48-Port RJ45
Rack Height
2U (19-inch Rackmount)
Termination Type
LSA Style IDC
Wiring Standard
T568A / T568B
Testing Standards
TIA/EIA-568-B.2-2001, ISO/IEC 11801:2002
Expert Note: The Excel 2U design provides extra vertical space between ports compared to 1U high-density panels, making it easier to manage patch cords in high-traffic cabinets.
Accessories
(Sold Separately)
Cat5e Patch Leads
IDC Punchdown Tool
Cat5e Solid Cable
Cat5e Modules
24 Port 1U Excel Category 5e Through Coupler Patch Panels offers RJ45 to RJ45 jack connectivity between the front and rear of the patch panel. The patch panel is ideal for providing a cross connect for network equipment with the simple fitting of patch cords rather than switch link looms. Each panel has the port number screen printed below the port with an area to add the port identification above. The design lends itself for the easy application of a bespoke engraved label above and below the ports to suit the installation requirement.
Key Features of Excel 24 Port Cat5e Patch Panel - 1u RJ45 Through Coupler:
Category 5e compliant
Through Coupler
Supports Gigabit Ethernet
RJ45 Ports Front & Rear
Pre Printed 1-96 Self Adhesive Labelling included
Performance Overview
Excel Category 5e Data Outlets are manufactured and tested to the current Category 5 enhanced standards as defined by the TIA and ISO standards’ bodies. Swept frequency tests are applied to each critical performance characteristic, such as near end cross talk (NEXT) and far end cross talk (FEXT). Both Worst Case and Power Sum Test methods are applied. Actual performance exceeds the required standard by a considerable margin ensuring sufficient headroom for even the most demanding applications.
Accessories
(Sold Separately)
Cat5e Patch Leads
Cat5e Modules
Excel Category 5e Patch Panels comply with the currrent standards for enhanced Category 5. Ease of installation is assured with built in rear cable management at a 90 degree angle to the panel facia.
The 48 Port Patch Panel features a removable 'upper deck' arrangement to ensure ease of termination of the cables. This tray also holds the LSA termination blocks. Cage nuts and mini cable ties are included with each panel.
Features and Benefits
Category 5e
Supports Gigabit Ethernet
Cage nuts and mini cable ties included
LSA Style Termination Blocks
T568A/B Wiring Configuration
25 Year system warranty
