| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
Colour: |
| Part No: | UTPS |
| Manufacturer No: | 100-065 |
| Delivery: | End of Life Product |
| Part No: | UTPS-CE |
| Delivery: | In Stock: Next Day |
 |
Excel Category 5e Unscreened PVC Cables are manufactured and tested to the ISO 11801, EN 50173 and ANSI/TIA-568-C standards for enhanced performance Category 5 cables. Each cable consists of 8 colour coded polyethylene insulated conductors. These are twisted together to form 4 pairs with varying lay lengths.
These pairs, together with a strong nylon rip cord are jacketed in a heat resistant PVC material. The printing detail on the sheath, includes the cables part number, specification details and a unique 305-0 metre marking within each box supplied, allowing for quick and easy measurement of cable installed and the amount remaining within the box.
A choice of jacket colour enables departmental or application identification where necessary.
| Conductor | Materials | Cu, bare |
| Size | 24 AWG | |
| Insulation | Materials | PE |
| Colour | Blue/White | |
| Orange/White | ||
| Green/White | ||
| Brown/White | ||
| Rip Cord | One Rip Cord | |
| Jacket | Materials | PVC |
| Diameter | Nominal 5.2 mm | |
| Colour | Grey | |
| Construction | U/UTP | |
| No. of Cores | 8 | |
| Conductor category | Class 1 = Solid | |
| Reaction-to-fire class according to EN 13501-6 | Eca | |
| Category | 5e | |
Accessories
(sold Separately)
Tools
 |
 |
| Universal Stripping Tool | IDC Punchdown Tool |
Networking
 |
 |
| Cat5e Patch Panels | Cat5e Modules |
Excel Category 5e Unscreened PVC Cables are manufactured and tested to the ISO 11801, EN 50173 and ANSI/TIA-568-C standards for enhanced performance Category 5 cables. Each cable consists of 8 colour coded polyethylene insulated conductors. These are twisted together to form 4 pairs with varying lay lengths.
These pairs, together with a strong nylon rip cord are jacketed in a heat resistant PVC material. The printing detail on the sheath, includes the cables part number, specification details and a unique 305-0 metre marking within each box supplied, allowing for quick and easy measurement of cable installed and the amount remaining within the box.
A choice of jacket colour enables departmental or application identification where necessary.
