Solid Core Cable

Solid conductor 4 pair Cat5e U/UTP cable with PVC Grey outer sheath.

Each cable consists of 8 colour coded polyethylene insulated conductors. These are twisted together to form 4 pairs with varying lay lengths. These pairs, together with a strong nylon rip cord are jacketed in a heat resistant PVC material.

The printing detail on the sheath, includes the cables part number, specification details and a 305-0 reverse metre marking within each box supplied, allowing for quick and easy measurement of cable installed and the amount remaining within the box.

Key Features: 305 metres in an easy to pull box
Cat5e 4 pair UTP solid cable with 8 colour coded polyethylene insulated conductors.
Rip cord for ease of stripping outer sheath.
Supports Gigabit Ethernet
CPR Compliant to Eca Standard
Manufactured and tested to the ISO 11801, EN 50173 & ANSI/TIA-568-C standards
Sequential reverse metre markings (305-0)
Material & Construction Conductor Materials Soft & annealed copper   Size 24 AWG Insulation Materials HDPE Colour Blue/White (Blue stripe-2line) Orange/White (Orange stripe-2line) Green/White (Green stripe-2line) Brown/White (Brown stripe-2line) Rip Cord One Rip Cord Jacket Materials Flame Retardent PVC   Diameter Nominal 5.0 mm Colour Grey RAL 7035 Construction U/UTP   No. of Pairs 4 Category 5e Number of Cores 8 Length 305 Metres Reaction to fire class EN 13501-6 Eca

Accessories
(Sold Separately)

Tools

Universal Stripping Tool IDC Punchdown Tool Networking

Cat5e Patch Panels Cat5e Modules

*While we are transitioning over to eco packaging you may receive products in the existing packaging or the recyclable eco packaging or a combination of both.

Cat6 Cable - Solid conductor 4 pair UTP cable with low smoke zero halogen outer sheath.

Each cable consists of 8 colour coded polyethylene insulated conductors. These are twisted together to form 4 pairs with varying lay lengths. These pairs, together with a strong nylon rip cord are jacketed in either Purple, Orange Grey or Blue low smoke zero halogen material, which complies with the requirements of IEC332-1. The printing detail on the sheath, includes the cables part number, specification details and a 305-0 reverse metre marking within each box supplied, allowing for quick and easy measurement of cable installed and the amount remaining within the box.

Features:

305 metres in an easy to pull box
Available in a Orange, Purple, Grey or Blue LSOH Sheath
Cat6 4 pair UTP solid cable with 8 colour coded polyethylene insulated conductors.
Rip cord for ease of stripping outer sheath.
CPR Compliant to Dca Standard
Manufactured and tested to the ISO 11801, EN 50288-3-1 & ANSI/TIA-568-C standards
Sequential reverse metre markings (305-0)


Material & Construction Conductor Materials Soft & annealed copper   Size 24 AWG Insulation Materials HDPE Colour Blue/White (Blue stripe-2line) Orange/White (Orange stripe-2line) Green/White (Green stripe-2line) Brown/White (Brown stripe-2line) Rip Cord One Rip Cord Jacket Materials LSOH   Diameter Nominal 5.9 mm Colour Orange RAL 2004 Purple RAL 4005 Blue RAL 5015 Grey RAL 7035 Construction U/UTP   No. of Pairs 4 Category 6 Number of Cores 8 Length 305 Metres Reaction to fire class EN 13501-6 Dca

Accessories
(Sold Separately)

Tools

Universal Stripping Tool IDC Punchdown Tool Networking

Cat6 Patch Panels Cat6 Modules

*While we are transitioning over to eco packaging you may receive products in the existing packaging or the recyclable eco packaging or a combination of both.

Solid conductor 4 pair U/UTP Cat6 cable with LS0H Grey outer sheath. Supplied as convenient 100m reels

Each cable consists of 8 colour coded polyethylene insulated conductors. These are twisted together to form 4 pairs with varying lay lengths. These pairs, together with a strong nylon rip cord are jacketed in an LS0H material. Tested to 100 MHz, the guaranteed performance of this cable meets the ANSI/TIA 568C.2 and ISO/IEC 11801 requirements for PS-NEXT, attenuation, return loss, attenuation-to-crosstalk ratio (ACR)and impedance, making it ideal for high-end transmission links supporting today’s networking protocols..

Features: Supplied as 100 metre reels for the smaller job
Cat6 4 pair UTP solid cable with 8 colour coded polyethylene insulated conductors.
Rip cord for ease of stripping outer sheath.
CPR Compliant to Dca Standard
Manufactured and tested to the ISO 11801, EN 50173 & ANSI/TIA-568-C standards
Benefits

Reliably supports today’s network protocols
Reduced installation costs and maintenance
Lower Bit Error Rates, increases network efficiency and uptime
Material & Construction Conductor Materials Soft & annealed copper   Size 23 AWG Insulation Materials HDPE Colour Blue/White (Blue stripe-2line) Orange/White (Orange stripe-2line) Green/White (Green stripe-2line) Brown/White (Brown stripe-2line) Rip Cord One Rip Cord Jacket Materials LS0H   Diameter Nominal 6.0mm Colour Grey RAL 7035 Construction U/UTP   No. of Pairs 4 Category 6 Number of Cores 8 Length 100 Metres Reaction to fire class EN 13501-6 Dca

Accessories
(Sold Separately)

Tools

Universal Stripping Tool IDC Punchdown Tool Networking

Cat6 Patch Panels Cat6 Modules

Solid conductor 4 pair U/UTP Cat5e cable with PVC Grey outer sheath Supplied on convenient 100m reels.

Each cable consists of 8 colour coded polyethylene insulated conductors. These are twisted together to form 4 pairs with varying lay lengths. These pairs, together with a strong nylon rip cord are jacketed in a heat resistant PVC material.

Tested to 100 MHz, the guaranteed performance of this cable meets the ANSI/TIA 568C.2 and ISO/IEC 11801 requirements for PS-NEXT, attenuation, return loss, attenuation-to-crosstalk ratio (ACR)and impedance, making it ideal for high-end transmission links supporting today’s networking protocols.

Key Features: Supplied as 100 metre reels for the smaller job
Cat5e 4 pair UTP solid cable with 8 colour coded polyethylene insulated conductors
Rip cord for ease of stripping outer sheath
CPR Compliant to Eca Standard
Supports Gigabit Ethernet
Manufactured and tested to the ISO 11801, EN 50173 & ANSI/TIA-568-C standards
Material & Construction Conductor Materials Soft & annealed copper   Size 24 AWG Insulation Materials HDPE Colour Blue/White (Blue stripe-2line) Orange/White (Orange stripe-2line) Green/White (Green stripe-2line) Brown/White (Brown stripe-2line) Rip Cord One Rip Cord Jacket Materials Flame Retardent PVC   Diameter Nominal 5.0 mm Colour Grey RAL 7035 Construction U/UTP   No. of Pairs 4 Category 5e Number of Cores 8 Length 100 Metres Reaction to fire class EN 13501-6 Eca

Accessories
(Sold Separately)

Tools

Universal Stripping Tool IDC Punchdown Tool Networking

Cat5e Patch Panels Cat5e Modules

Excel Excel Cat6 Cable F/UTP Shielded LSOH 4 Pair - 305mt Reel foil screened cables are manufactured and tested to the TIA-568-C.2, EN50173-1 and ISO/IEC 11801

Category 6 specifications. Each cable consists of 8 colour coded 23AWG polyethylene insulated, solid bare copper, conductors. These are twisted together to form 4 pairs with varying lay lengths. These pairs are then formed around a central ‘X’ shaped polyethylene filler. This filler assists in maintaining and enhancing the cables performance. A clear Mylar tape is then wrapped around this unit and a foil tape screen with 24AWG drain wire applied. The foil screen provides protection from Electromagnetic Interference (EMI) which can occur when data is transmitted at high frequencies

Features
Central 'X' Filler
23 AWG Conductor
305-0 Metre Marked
LSOH Outer Sheath
Overall Foil Tape Screen
Supplied on a Reel
Material & Construction Conductor Materials Cu, bare Size 23 AWG Insulation Materials PE Colour Blue/White Orange/White Green/White Brown/White Overall Screening Foil Jacket Materials LSOH Diameter Nominal 7.2 mm Colour Violet Construction F/UTP No. of Cores 8 Conductor category Class 1 = Solid Reaction-to-fire class according to EN 13501-6 Dca Category 6 Accessories
(sold Separately)

Tools

Universal Stripping Tool IDC Punchdown Tool Networking

Cat6 Patch Panels Cat6 Modules

The PowerCat 6A Shielded Cable is a key component of the PowerCat 6A end-to-end solution. Molex PowerCat 6A U/FTP Cable is specifically designed to support high speed data network applications such as 10-Gigabyte Ethernet (10GBASE-T). The cable is constructed of 4 screened pairs and a drain wire. This cable minimizes alien crosstalk, provides excellent signal isolation and provides superior electromagnetic interference (EMI) protection.

Molex recommends that the full range of PowerCat 6A Shielded products be used in a system to maximize cabling performance. This system is compliant with the latest ISO/IEC 11801 2nd Ed 2.2:2011 and ratified TIA 568-C.2 for the support of cat. 6A and 10GBASE-T.

Features & Advantages

Reaction to Fire Euroclass - B2ca -s1a d1 a1
Outstanding signal isolation
The cable is compliant with ISO/IEC 11801 Ed 2.2:2011 and TIA 568-C.2 and EN 50173:2011
Enhanced performance 4 pair U/FTP LS0H Cable
Resistant to alien crosstalk (Alien NEXT) and crosstalk (PS NEXT)
Color coded for ease of termination
RoHS Compliant
Technical Information

Mechanical

Conductor Size [mm]: 23 AWG (0.570±0,005)
Insulated conductor diameter [mm]: 1.350 ?0,05
Color code: Blue x White/Orange x White/Green x White/Brown x White
Pair number: 4
Outside cable diameter [mm]: 7.4?0,5
Individual pair shield: Aluminium foil, providing 100% coverage, foil face out
Drain Wire: Yes
Overall shield: No
Pulling force: 100N max
Sheath: LS0H
Flame test: IEC 60332-1
Gas & smoke test: IEC 60754 (halogen & acid gas) and IEC 61034 (dense smoke)
Sheath color LSZH: Violet RAL4005
Shipping weight [kg]: 28.5
Cable length tolerance: +/- 5%
Electrical

Characteristic Impedance [Ohm]: 100?15 @ 1-250 MHz / 100?20 @ 250-500 MHz
DC Resistance [Ohm/100m]: 9,38 max
Resistance unbalance [%]: 2% max
Capacitance [nF/100m]: ?5.6
Voltage rating [Vdc]: 72 max
NVP: 74% - printed on a jacket
Delay Skew [nS/100m]: ?45
Insulation Resistance [MegaOhm•Km]: 5000 min. @ 500 Vdc

Product Features Category 6 Ethernet cable for high-speed, indoor deployments.




Category 6 UTP communications multipurpose cable


Riser (CMR)-rated, fire-resistant jacket


Anti-crosstalk divider


Cable length 305 m

Excel screened Cat6a cable S/FTP LSOH CPR Euroclass Dca with individual foil wrapped pairs and overall foil wrap and braided screening supplied on 500m Reel. Excel Cat 6A fully screened (S/FTP) Cable takes the performance capabilities of copper infrastructure to new levels. This delivers Class EA/ Augmented Category 6 link performance over distances of up 90 metres which supports the applications including 10GBASE-T, 10 Gigabit Ethernet.

Each cable consists of four pairs which are individually wrapped with a high quality, strong, aluminium/polyester foil tape providing screening for each pair. The individual pairs are set to different lay lengths to ensure optimum performance. These are then wrapped in another, overall foil and an overall braid screening.

Features and Benefits

Cat6A solid copper cable
S/FTP Overall Screening
Foil Screen per pair
Reaction-to-fire class according to EN 13501-6: Dca
Smoke development class according to EN 13501-6: s2
Product specifications for these products can be found in the Documentation tab
