Cat6 Cable – Solid conductor 4 pair UTP cable with low smoke zero halogen outer sheath, CRP Rating Class B2ca
Each cable consists of 8 colour coded polyethylene insulated conductors. These are twisted together to form 4 pairs with varying lay lengths. These pairs, together with a strong nylon rip cord are jacketed Purple low smoke zero halogen material, which complies with the requirements of IEC11801-1.
The printing detail on the sheath, includes the cables part number, specification details and a 305-0 reverse metre marking within each box supplied, allowing for quick and easy measurement of cable installed and the amount remaining within the box.
Product Features
305 metres in an easy to pull box
Available in Purple
CRP Compliant to B2ca Standard – Classification B2ca, s1a, d0, a1
Manufactured and tested to the ANSI/TIA, ISO/IEC, and EN Standards, ANSI/TIA-568.2-D, ISO/IEC 11801-1 Edition 1.0
Fire Test is according to IEC 60332-1-2 and EN 50399, EN 61034-2, EN 60754-2
Sequential reverse metre markings (305-0)
Solid Copper Cores
Outer Sheath: LS0H
Product Specification
Construction and Characteristics
Conductor
Material/Size
Bare Copper / 23AWG
Insulation
Material
PE
Thickness
Nominal: 0.385mm
Diameter
Nominal: 1.32mm
Colours
Blue/White
Orange/White
Green/White
Brown/White
Unaged Elongation
Min. 100%
Unaged Tensile Strength
Min.0.816 Kgf/mm²
Screen
Material
Individual Foil and without overall braid screened.
Material
Stranded tinned copper drain wire
Jacket
Material
LS0H
Thickness
Nominal: 0.5mm
Diameter
Nominal: 7.1mm
Colour
Purple
Unaged Elongation
Min. 125%
Unaged Tensile Strength
Min. 0.918Kgf/mm²
Aging at 100°C for 168hrs
Min. elongation retention: 70%
Min. tensile strength retention: 70%
Electrical Performances
Dielectric Strength of Insulation
1500 V dc/2 Seconds
Insulation Resistance Test
Min. 5000 M?/Km
Conductor Resistance
Max. 9.38 ?/100m at 20°C
Resistance Unbalance
Max. 2%
Capacitance Unbalance
Max. 160 pF/100m
Mutual Capacitance
Max. 5600 pF/100m
Impedance
1~100MHz
100? ± 15%
100~250MHz
100? ± 22%
251~500MHz
100? ± 25%
Attenuation & Near End Cross Talk
Frequency
(MHz)
Attenuation
(dB), Max.
NEXT
(dB), Min.
PSNEXT
(dB), Min.
1MHz
1.9*
65.0*
62.0*
10MHz
5.5*
57.8*
55.5*
100MHz
18.0*
41.8*
39.9*
200MHz
26.1*
36.9*
34.3*
250MHz
29.5*
35.3*
32.7*
300MHz
32.7*
34.0*
31.4*
400MHz
38.4*
29.9*
27.1*
500MHz
43.8*
26.7*
23.8*
