| Product Code: | |
| Options: | |
| Qty: | |
| Unit Price: | £ |
| Part No: | FTPSLS6 |
| Manufacturer No: | 100-076 |
| Delivery: | In Stock: Next Day |
 |
Excel Excel Cat6 Cable F/UTP Shielded LSOH 4 Pair - 305mt Reel foil screened cables are manufactured and tested to the TIA-568-C.2, EN50173-1 and ISO/IEC 11801
Category 6 specifications. Each cable consists of 8 colour coded 23AWG polyethylene insulated, solid bare copper, conductors. These are twisted together to form 4 pairs with varying lay lengths. These pairs are then formed around a central ‘X’ shaped polyethylene filler. This filler assists in maintaining and enhancing the cables performance. A clear Mylar tape is then wrapped around this unit and a foil tape screen with 24AWG drain wire applied. The foil screen provides protection from Electromagnetic Interference (EMI) which can occur when data is transmitted at high frequencies| Conductor | Materials | Cu, bare |
| Size | 23 AWG | |
| Insulation | Materials | PE |
| Colour | Blue/White | |
| Orange/White | ||
| Green/White | ||
| Brown/White | ||
| Overall Screening | Foil | |
| Jacket | Materials | LSOH |
| Diameter | Nominal 7.2 mm | |
| Colour | Violet | |
| Construction | F/UTP | |
| No. of Cores | 8 | |
| Conductor category | Class 1 = Solid | |
| Reaction-to-fire class according to EN 13501-6 | Dca | |
| Category | 6 | |
Accessories
(sold Separately)
Tools
 |
 |
| Universal Stripping Tool | IDC Punchdown Tool |
Networking
 |
 |
| Cat6 Patch Panels | Cat6 Modules |
Category 6 specifications. Each cable consists of 8 colour coded 23AWG polyethylene insulated, solid bare copper, conductors. These are twisted together to form 4 pairs with varying lay lengths. These pairs are then formed around a central ‘X’ shaped polyethylene filler. This filler assists in maintaining and enhancing the cables performance. A clear Mylar tape is then wrapped around this unit and a foil tape screen with 24AWG drain wire applied. The foil screen provides protection from Electromagnetic Interference (EMI) which can occur when data is transmitted at high frequencies
| Conductor | |
|---|---|
| Materials | Cu, bare |
| Size | 23 AWG |
| Insulation | |
| Materials | PE |
| Colour | Blue/White Orange/White Green/White Brown/White |
| Jacket | |
| Materials | LSOH |
| Diameter | Nominal 7.2mm |
| Colours | Violet |
| Other Features | |
| Overall Screening | Foil |
| Construction | F/UTP |
| No. of Cores | 8 |
| Conductor category | Class 1 = Solid |
| Reaction-to-fire class according to EN 13501-6 | Dca |
| Category | 6 |
