Cisco Meraki MX Modules and Transceivers: High-Performance Fiber & Copper Connectivity
Cisco Meraki MX Modules and Transceivers provide the critical link for high-speed network connectivity within your IT infrastructure. Specifically designed for MX Security Appliances, these accessories enable flexible uplink and stacking configurations. This category includes a comprehensive range of SFP and SFP+ modules, ranging from standard Gigabit Ethernet to high-bandwidth 10G Fiber options. Whether you require 10GBASE-SR for short-range multi-mode fiber or 10GBASE-LR for long-distance single-mode deployments, these transceivers ensure seamless integration with the Meraki dashboard.
In addition to fiber optic modules, we offer Twinax cables (Direct Attach Copper) for cost-effective, low-latency stacking and short-range connections between appliances. Every module is hot-swappable, allowing for "pay-as-you-populate" scalability without necessitating network downtime. By utilizing genuine Meraki hardware, administrators ensure maximum reliability, full cloud-managed visibility, and diagnostic monitoring (DOM) capabilities. Enhance your branch or campus network with reliable, high-density transceiver solutions designed to meet the throughput demands of modern enterprise security.
The Cisco Meraki MA-CBL-TA-1M is a passive Direct Attach Copper (DAC) cable designed for high-speed, short-distance 10GbE connectivity. It is commonly used for switch stacking or connecting servers to Top-of-Rack (ToR) switches.
Interface: SFP+ to SFP+
Cable Type: Passive Twinaxial Copper
Data Rate: 10 Gbps
Length: 1 meter (3.3 feet)
Wire Gauge: 30 AWG
Power Consumption: Near-zero (approx. 0.1W)
Hardware CompatibilityThis cable is widely compatible across the Meraki portfolio where 10G SFP+ ports are present, including:
MS Series Switches: MS125, MS225, MS250, MS350, MS355, MS390, MS410, MS425.
MX Security Appliances: MX95, MX105, MX250, MX450.
Stacking: Supports physical stacking for MS series switches that utilize SFP+ ports for their stacking fabric.
As per Cisco's UK policy we are unable to ship any Cisco products to any address other than a company registered address as shown on Companies House.
The Cisco Meraki MA-CBL-TA-3M is a passive Direct Attach Copper (DAC) cable designed for high-speed 10GbE links between adjacent racks or within the same enclosure.
Interface: SFP+ to SFP+
Cable Type: Passive Twinaxial Copper
Data Rate: 10 Gbps
Length: 3 meters (9.8 feet)
Wire Gauge: 30 AWG / 28 AWG (varies by revision)
Power Consumption: Near-zero (approx. 0.1W)
As per Cisco's UK policy we are unable to ship any Cisco products to any address other than a company registered address as shown on Companies House.
1 Gigabit 1000Base-T SFP Copper Module with a range of up to 100mt.
For Use in the MX84. MX100, MX250, MX400, MX450 and MX600 Security Appliances
All MS Series Switches
As per Cisco's UK policy we are unable to ship any Cisco products to any address other than a company registered address as shown on Companies House.
1 Gigabit 1000Base-T SFP SX Fibre Module.
For Use in the MX84. MX100, MX250, MX400, MX450 and MX600 Security Appliances
All MS Series Switches
Standard
Fibre Type
Fibre Description
Core/Diameter
Max Distance
Data Rate
1000BASE-SX
Multimode
OM1
62.5 μm / 125 μm
220m
Gigabit
1000BASE-SX
Multimode
OM2
50 μm / 125 μm
550m
Gigabit
1000BASE-SX
Multimode
OM3
50 μm / 125 μm
550m
Gigabit
1000BASE-SX
Multimode
OM4
50 μm / 125 μm
1km
Gigabit
As per Cisco's UK policy we are unable to ship any Cisco products to any address other than a company registered address as shown on Companies House.
10 Gigabit 10GBase-T SFP SR Fibre Module with a range of up to 400m
For Use in the MX250, MX400, MX450 and MX600 Security Appliances
For Use in the MS225, MS250, MS300, MS400 Series Switches
Standard
Fibre Type
Fibre Description
Core/Diameter
Max Distance
Data Rate
10GBASE-SR
Multimode
OM1
62.5 μm / 125 μm
26m
10 Gigabit
10GBASE-SR
Multimode
OM2
50 μm / 125 μm
82m
10 Gigabit
10GBASE-SR
Multimode
OM3
50 μm / 125 μm
300m
10 Gigabit
10GBASE-SR
Multimode
OM4
50 μm / 125 μm
400m
10 Gigabit
As per Cisco's UK policy we are unable to ship any Cisco products to any address other than a company registered address as shown on Companies House.
1 Gigabit 1000Base-T SFP LX Fibre Module.
For Use in the MX84. MX100, MX250, MX400, MX450 and MX600 Security Appliances
All MS Series Switches
Standard
Fibre Type
Fibre Description
Core/Diameter
Max Distance
Data Rate
1000BASE-LX10
Multimode
OS1/OS2
9 μm / 125 μm
10km
Gigabit
As per Cisco's UK policy we are unable to ship any Cisco products to any address other than a company registered address as shown on Companies House.
10 Gigabit 10GBase-T SFP+ LR Fibre Module.
For Use in the MX250, MX400, MX450 and MX600 Security Appliances
For Use in the MS225, MS250, MS300, MS400 Series Switches
Standard
Fibre Type
Fibre Description
Core/Diameter
Max Distance
Data Rate
10GBASE-LR
Singlemode
OS1/OS2
9 μm / 125 μm
10km
10 Gigabit
As per Cisco's UK policy we are unable to ship any Cisco products to any address other than a company registered address as shown on Companies House.
