Mellanox Compatible 100G LR4 (singlemode) Transceiver
The 100G QSFP LR4-S is a transceiver module designed for 10km optical communication applications.
The QSFP-100G-LR4-S is designed with form factor, optical/electrical connection and digital diagnostic interface according to the QSFP28 MultiSource Agreement (MSA). It has been designed to meet the harshest external operating conditions including temperature, humidity and EMI interference. The module offers very high functionality and feature integration, accessible via a two-wire serial interface.
Features:
Hot Pluggable, Duplex LC Connector, 3.3V, SMF 10KM DDM
4 lanes MUX/DEMUX design
Integrated LAN WDM TOSA / ROSA for up to 10 km reach over SMF28
Support 100GBASE-LR4 for line rate of 103.125Gbps and OTU4 for line rate of 111.81 Gbps
Aggregate bandwidth of >100Gbps
Duplex LC connector
Compliant with IEEE 802.3-2012 Clause 88 standard IEEE 802.3bm CAUl-4 chip to module electrical standard ITU-T G.959.1-2012-02 standard
Single 3.3V power supply
Built-in digital diagnostic functions
Temperature range 0°C to 70°C
RoHS Compliant Part
Applications:
Local Area Network (LAN)
Wide Area Network (WAN)
Ethernet switches and router applications
The design is compliant to 100GbASE-LR4 of the IEEE 802.3-2012 Clause 88 standard IEEE 802.3bm CAUl-4 chip to module electrical standard ITU-T G.959.1-2012-02 standard . The module converts 4 inputs channels (ch) of 25.78 Gbps to 27.95Gbps electrical data to 4 lanes optical signals, and multiplexes them into a single channel for 100Gb/s optical transmission. Reversely, on the receiver side, the module optically demultiplexes a 100Gb/s input into 4 lanes signals, and converts them to 4 lanes output electrical data.
The central wavelengths of the 4 lanes are 1296 nm, 1300 nm, 1305nm and 1309nm. It contains a duplex LC connector for the optical interface and a 38- pin connector for the electrical interface. To minimize the optical dispersion in the long-haul system, single-mode fiber (SMF) has to be applied in this module.
The module operates from a single +3.3V power supply and LVCMOS/LVTTL global control signals such as Module Present, Reset, Interrupt and Low Power Mode are available with the modules. A 2-wire serial interface is available to send and receive more complex control signals and to obtain digital diagnostic information. Individual channels can be addressed and unused channels can be shut down for maximum design flexibility.
