When maintaining operating uptime in a data center or server room, sustainable energy efficiency can make all the difference. The ATEN PG5308 Intelligent PDU is a high-performance, eco-friendly solution engineered to meet the growing power demands of modern IT infrastructure. Designed with a 1U rack housing and equipped with IEC socket configurations, the PG5308 offers advanced power distribution, precise monitoring, and efficient management capabilities to ensure consistent uptime and optimized energy use.
Key Features of ATEN PG5308 PDU
Accurate kWh Energy Data (+/-1%) for reliable tracking and energy analysis
8 Port Outlets powered up within 10 seconds of connection
Real-Time Power Monitoring via intuitive LCD display
Dual LAN Ports supporting 1G Ethernet for scalable network setups
Support for up to 8 Environmental Sensors via RJ-45 daisy-chain connection
WiFi Network Capability through USB dongle for flexible monitoring and configuration
Integrated DCIM Monitoring via ATEN’s eco DC software
1U Rack Housing designed for high-density IT environments
Powerful ARM-Cortex A8 Processor
The PG5308 is powered by an ARM-Cortex A8 processor, delivering fast, stable control and energy data calculations. It ensures all connected devices receive power in under 10 seconds after startup, minimizing downtime and streamlining power delivery across connected IT systems.
Real-Time Alerts via LCD Display
The front-panel LCD provides key electrical readings such as Aggregate Current (A), Voltage (V), Power (W), and Power Consumption (kWh). The display automatically changes color to red during critical or warning events, alerting administrators to irregular power conditions that require immediate attention.
Environmental Sensor Integration
Equipped with a Sensor port for RJ-45 connections, the PG5308 supports up to eight environmental sensors (EA1640 series, sold separately). These sensors enable real-time monitoring of temperature, humidity, airflow, air pressure, and potential leaks, providing proactive management of environmental conditions in server rooms.
RS-232 Serial Communication
The built-in COM port allows for direct communication via RS-232 protocol. This provides administrators with command-line interface (CLI) control for flexible and efficient configuration, diagnostics, and management of the PDU.
Network Connectivity via WiFi
The PG5308 supports wireless connectivity through an optional USB WiFi dongle. This capability enables firmware updates, log exports, and DCIM integration over wireless networks, simplifying deployment and remote management tasks.
Dual LAN Ports for Scalable Expansion
Featuring dual LAN ports for Internet and Intranet connectivity, the PG5308 supports up to 1G Ethernet and allows cascading of up to 64 PDUs. This design eliminates the need for additional network switches, reducing costs while optimizing rack space utilization.
DCIM Integration for Smart Management
Through ATEN’s eco DC software, the PG5308 provides seamless integration into Data Center Infrastructure Management (DCIM) systems. Users can monitor and analyze power, energy, and environmental data through an intuitive web interface to maintain efficient operations and sustainability goals.
Applications
The ATEN PG5308 PDU is ideal for server rooms, data centers, and IT racks that require precise, energy-efficient power distribution to high-density equipment. It enhances operational visibility, sustainability, and scalability for modern network environments.
Package Contents
1 x 8-Outlet 1U eco PDU
1 x Rack Mount Kit
1 x Foot Pad Set (4 pcs)
1 x RJ-45 to DB-9 Cable
1 x Full-Panel Colored Sticker
1 x User Instructions
The Aten PE8208G Eco PDU is designed for IT environments that demand intelligent power management. With real-time monitoring, remote access, and secure outlet-level control, it brings efficiency and reliability to data centers, server rooms, and network racks. This 1U rack-mountable PDU offers both versatility and stability, helping administrators manage energy use with confidence.
• 8 outlets
• 20A (UL derated 16A) / 16A
• Outlet Power Measurement
The PE8208 eco PDU is intelligent PDUs that contains 8 AC outlets and is available in various IEC or NEMA socket configurations. It provides secure, centralized, intelligent, power management (power on, off, cycle) of data center IT equipment (servers, storage systems, KVM switches, network devices, serial data devices, etc.), as well as the ability to monitor the center's health environment via sensors*.
The eco PDUs offer remote power control combined with real-time power measurement - allowing you to control and monitor the power status of devices attached to the PDUs, either at the PDU device or outlet level, from practically any location via a TCP/IP connection.
eco PDU supports any 3rd party v3 SNMP Manager Software and eco DC (Energy Management Web GUI). eco DC provides you with an easy method for managing multiple devices, offering an intuitive and user friendly Graphical User Interface that allows you to configure a PDU device and monitor power status of the equipment connected to it. With eco DC, the Sensor-enabled eco PDU also offers comprehensive power analysis reports which can separate by departments and locations, providing precise measurements of current, voltage, power and watt-hour in a real-time display.
With its advanced security features and ease of operation, the eco PDU is the most convenient, most reliable, and most cost effective way to remotely manage power access for multiple computer installations and allocate power resources in the most efficient way possible.
Note: Sensors are optional accessories. A sensor-enabled installation is required to generate a more complete energy-efficient data and chart. Higher sensor installation density is helpful to generate more accurate data.
Key Features
Power Distribution
Space saving 1U rack mount design with rear mounting
IEC or NEMA outlet models
3 digit 7-segment front panel LED shows Current / IP Address
Remote users can monitor outlet status via web pages on their browsers
Safe shutdown support
Separate power for the unit's own power and its power outlets. The user interface is still accessible even when an overload condition trips the devices' circuit breaker
Remote Access
Remote power control via TCP/IP and a built in 10/100 Ethernet port
Network Interfaces: TCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, DHCP, NTP, DNS, 10Base-T/100Base-TX, auto sense, Ping, Telnet
eco PDU Power Management software – eco DC
Supports SNMP Manager V3
Operation
Remote power outlet control (On, Off, Power Cycle) by individual outlets
Power-on sequencing – users can set the power on sequence and delay time for each port to allow equipment to be turned on in the proper order
Easy setup and operation via a browser-based user interface
Multibrowser support (IE, Firefox, Chrome, Safari)
RTC support to keep the timer running during times of no power.
Supports up to 8 user and 1 administrator accounts
Proactive Overload Protection (POP) – automatically powers off outlets when current overloads to protect operating devices
Management
Power status measurement at the PDU or Outlet level
LED indicators for current and IP address at Outlet level
Real-time current, voltage, and kWH displayed in a browsed-based UI for monitoring at the outlet level
Current and voltage threshold setting
Naming support for outlets
User outlet access assignment on an outlet-by-outlet basis.
Event logging and syslog support
Upgradeable firmware
Multilanguage support: English, German, Traditional Chinese, Simplified Chinese, Japanese, French, Spanish, Italian
Security
Two-level password security
Strong security features include password protection and advanced encryption technologies – 128 bit SSL
Remote authentication support: RADIUS
eco DC Energy Management Software
Automatic discovery of all PE devices within the same intranet
Remote real-time power measurement and monitoring
Remote real-time power outlet management*
Remote real-time environment sensor monitoring
Plotting/Monitoring of all PE devices
Exceed threshold alert through SMTP and Syslog
Power Analysis Report
Features available only on firmware-upgraded models with -ATB part number
Supports SMPTS, IPv6, Modbus (Over TCP/IP), Auto Ping, TLS1.2, SSH
Supports IEEE 802.1X
Authentication: LDAP, TACACS+
UI – heartbeat,schedule control, mail control, and setting rule
ECO DC Included free with Aten PDUs
The Eco DC energy tracking and reporting program is included at no additional cost with every ATEN PDU, providing users with valuable insights into energy consumption. This program enables real-time monitoring, detailed reporting, and efficient management of power usage, helping organizations optimize performance and reduce unnecessary energy waste—all without requiring extra investment.
Download ECO DC For Free Here
*Contact ATEN UK support for Serial Number to activate, via
[email protected]
The ATEN PE8108G Eco PDU is a 1U rack-mountable intelligent power distribution unit designed for precise energy management. It provides real-time monitoring, remote outlet control, and secure user access, making it well suited for professional IT environments where efficiency and control are priorities.
• 8 outlets
• 15A (UL derated 12A) / 10A
• Outlet Power Measurement
The PE8108 eco PDU is intelligent PDUs that contains 8 AC outlets and is available in various IEC or NEMA socket configurations. It provides secure, centralized, intelligent, power management (power on, off, cycle) of data center IT equipment (servers, storage systems, KVM switches, network devices, serial data devices, etc.), as well as the ability to monitor the center's health environment via sensors*.
The eco PDUs offer remote power control combined with real-time power measurement - allowing you to control and monitor the power status of devices attached to the PDUs at outlet level from practically any location via a TCP/IP connection.
eco PDU supports any 3rd party v3 SNMP Manager Software and eco DC (Energy Management Web GUI). eco DC provides you with an easy method for managing multiple devices, offering an intuitive and user friendly Graphical User Interface that allows you to configure a PDU device and monitor power status of the equipment connected to it. With eco DC, the Sensor-enabled eco PDU also offers comprehensive power analysis reports which can separate by departments and locations, providing precise measurements of current, voltage, power and watt-hour in a real-time display.
With its advanced security features and ease of operation, the eco PDU is the most convenient, most reliable, and most cost effective way to remotely manage power access for multiple computer installations and allocate power resources in the most efficient way possible.
Note: Sensors are optional accessories. A sensor-enabled installation is required to generate a more complete energy-efficient data and chart. Higher sensor installation density is helpful to generate more accurate data.
Key Features
Power Distribution
Space saving 1U rack mount design with rear mounting
IEC or NEMA outlet models
3 digit 7-segment front panel LED shows Current / IP Address
Remote users can monitor outlet status via web pages on their browsers
Safe shutdown support
Separate power for the unit's own power and its power outlets. The user interface is still accessible even when an overload condition trips the devices' circuit breaker
Remote Access
Remote power control via TCP/IP and a built in 10/100 Ethernet port
Network Interfaces: TCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, DHCP, NTP, DNS, 10Base-T/100Base-TX, auto sense, Ping, Telnet
eco PDU Power Management software – eco DC
Supports SNMP Manager V3
Operation
Remote power outlet control (On, Off, Power Cycle) by individual outlets
Power-on sequencing – users can set the power on sequence and delay time for each port to allow equipment to be turned on in the proper order
Easy setup and operation via a browser-based user interface
Multibrowser support (IE, Firefox, Chrome, Safari)
RTC support to keep the timer running during times of no power.
Supports up to 8 user and 1 administrator accounts
Proactive Overload Protection (POP) – automatically powers off outlets when current overloads to protect operating devices
Management
Power status measurement at the PDU or Outlet level
LED indicators for current and IP address at Outlet levels
Real-time current, voltage, and kWH displayed in a browsed-based UI for monitoring at the outlet level (PE8108 / PE8208)
Current and voltage threshold setting
Naming support for outlets
User outlet access assignment on an outlet-by-outlet basis.
Event logging and syslog support
Upgradeable firmware
Multilanguage support: English, German, Traditional Chinese, Simplified Chinese, Japanese, French, Spanish, Italian
Security
Two-level password security
Strong security features include password protection and advanced encryption technologies – 128 bit SSL
Remote authentication support: RADIUS
eco DC Energy Management Software
Automatic discovery of all PE devices within the same intranet
Remote real-time power measurement and monitoring
Remote real-time power outlet management*
Remote real-time environment sensor monitoring
Plotting/Monitoring of all PE devices
Exceed threshold alert through SMTP and Syslog
Power Analysis Report
Features available only on firmware-upgraded models with -ATB part number
Supports SMPTS, IPv6, Modbus (Over TCP/IP), Auto Ping, TLS1.2, SSH
Supports IEEE 802.1X
Authentication: LDAP, TACACS+
UI – heartbeat,schedule control, mail control, and setting rule
ECO DC Included free with Aten PDUs
The Eco DC energy tracking and reporting program is included at no additional cost with every ATEN PDU, providing users with valuable insights into energy consumption. This program enables real-time monitoring, detailed reporting, and efficient management of power usage, helping organizations optimize performance and reduce unnecessary energy waste—all without requiring extra investment.
Download ECO DC For Free Here
*Contact ATEN UK support for Serial Number to activate, via
[email protected]
The ATEN PE8216G Eco PDU is a zero-U, rack-mountable power distribution unit designed for efficient energy management in modern data centers. With real-time monitoring, outlet-level control, and environmental sensing support, it provides greater oversight and reliability for mission-critical equipment.
ATEN's NRGence line-up is a new generation of green energy power distribution units (eco PDUs) that optimize the efficiency of data center power usage. The PE8216 eco PDUs are intelligent PDUs that contain 16 AC outlets and are available in various IEC / NEMA socket configurations. These models feature proactive overload protection to automatically power off the last outlet that causes the current overload while allowing users to set shutdown priority.
The eco PDUs provide secure, centralized and intelligent power management (power on, off, and cycle) of data center IT equipment (servers, storage systems, KVM switches, network devices, serial data devices, and more), as well as the ability to monitor the center's health environment via sensors.*These PDUs offer remote power control combined with real-time power measurement, allowing users to control and monitor the power status of devices attached to the PDUs, either at the PDU device, bank, or outlet level, depending on the model, from practically any location via a TCP / IP connection.
The power status of each outlet can be set individually, allowing users to switch each device on / off. The eco PDU also offers comprehensive power analysis reports which can separate departments and locations, providing precise measurements of current, voltage, power and watt-hour in a real-time display. Installation and operation are made fast and easy by simply plugging cables into their appropriate ports, and users get to enjoy the intuitive browser-based configuration and management. The eco PDU firmware is upgradeable over the Net, meaning users can download updates from ATEN's website to ensure that their eco PDU is equipped with the latest functionalities and improvements.
The series also supports the 3rd party V3 SNMP manager software and NRGence eco DC (Energy & DCIM Management Web GUI). The eco DC makes it easy when it comes to the management for multiple devices by allowing users to configure eco PDU setting and monitor the power status of the equipment connected to the PDU through a user friendly interface. Along with its set of features, the PE8216 series has become a convenient, reliable and cost-effective solution to help remotely manage power access for multiple computer installations and allocate power resources with efficiency.
* Note:
1. Sensors are optional accessories. A sensor-enabled installation is required to generate more complete energy-efficient data and charts. The higher the sensor installation density is, the more accurate the data generated will be.
2. eco PDUs are primarily designed for access via Intranet; extra network security protection is suggested for Internet access usage.
Key Features
Connections
Supports 10 / 100M bit Ethernet interface
Supports TCP / IP, UDP, HTTP, HTTPS, SSL, DHCP, ARP, NTP, DNS, Telnet, Auto Sense, Ping, SNMP V1,V2 and V3
Supports three-level account / password security, IP / MAC filter, 128 bit SSL, and RADIUS
Supports CC2000, eco DC, multiple browsers (IE, Firefox, Chrome, and Safari)
Metering
PDU and outlet level power metering and monitoring
Environment monitoring – supports external temperature / temperature and humidity sensors for rack temperature and humidity monitoring
Current, voltage, power, power dissipation, temperature, and humidity metering and threshold level setting
Supports door sensor
Outlet Switch Control
Remote power outlet control (On/Off, Power Cycle) by individual outlets and outlet groups
Outlet group support at the PDU level
On / Off scheduling for individual outlet and outlet groups. Power management tasks can be scheduled on a daily, weekly, or user-specifi ed time basis
Supports multiple power control methods – Wake on LAN, System After AC Back, Kill the Power
Power-On sequencing – users can set the power-on sequence and delay time for each outlet to allow equipment to be powered on in the correct order
Proactive overload protection (POP) – automatically powers off the last outlet that causes the current overload while allowing users to set shutdown priority
ECO DC Included free with Aten PDUs
The Eco DC energy tracking and reporting program is included at no additional cost with every ATEN PDU, providing users with valuable insights into energy consumption. This program enables real-time monitoring, detailed reporting, and efficient management of power usage, helping organizations optimize performance and reduce unnecessary energy waste—all without requiring extra investment.
Download ECO DC For Free Here
*Contact ATEN UK support for Serial Number to activate, via
[email protected]
Overview
As part of its NRGence line, ATEN has developed a new generation of green energy power distribution units (eco PDUs) to effectively increase the efficiency of data center power usage. The NRGence PE8324 eco PDUs are intelligent PDUs that contain 24 AC outlets and are available in various IEC socket configurations. Models in the advanced PE8 ranges feature NRGence´s proactive overload protection, which automatically powers off the last outlet that caused the current overload.
NRGence eco PDUs provide secure, centralized, intelligent, power management (power on, off, cycle) of data center IT equipment (servers, storage systems, KVM switches, network devices, serial data devices, etc.), as well as the ability to monitor the center´s health environment via sensors.
NRGence eco PDUs offer remote power control combined with real-time power measurement — allowing you to control and monitor the power status of devices attached to the PDUs, either at the PDU device, bank, or outlet level, depending on the model, from practically any location via a TCP/IP connection.
The power status of each outlet can be set individually, allowing users to switch each device On/Off. The eco PDU also offers comprehensive power analysis reports which can separate departments and locations, providing precise measurements of current, voltage, power and watt-hour in a real-time display. Installation and operation is fast and easy: plugging cables into their appropriate ports and user-friendly browser-based configuration and management is all that is entailed. Since the eco PDU firmware is upgradeable over the Net, you can stay current with the latest functionality improvements simply by downloading updates from our website as they become available.
NRGence eco PDU supports any 3rd party V3 SNMP Manager Software and NRGence eco Sensors (eco PDU Manager Software). eco Sensors provides you with an easy method for managing multiple devices, offering an intuitive and user-friendly Graphical User Interface that allows you to configure a PDU device and monitor power status of the equipment connected to it.
With its advanced security features and ease of operation, the eco PDU is the most convenient, most reliable, and most cost effective way to remotely manage power access for multiple computer installations and allocate power resources in the most efficient way possible.
Package Contents
1x PE8324 eco PDU
1x Rack Mount Kit
1x CD-ROM (Manual, eco Sensors Software)
1x User Instructions
Features
Connections
Support 10/100Mbit Ethernet Interface
Support TCP/IP, UDP, HTTP, HTTPS, SSL, DHCP, SMTP, NTP, DNS, Auto Sense, Ping, Telnet, and SNMP V1,V2&V3
Support 2-level account/password security, IP/MAC filter, 128 bit SSL, RADIOUS
Support : eco Sensors, Browser ( IE, Firefox, Chrome, Safari )
Metering
PDU and outlet level power metering and monitoring
Environment monitoring — supports external temperature/temperature & humidity sensors for rack temperature and humidity monitoring
Current, voltage, power, power dissipation, temperature, and humidity metering and threshold level setting
Support door sensor
Outlet Switch Control
Remote power outlet control (On/Off, Power Cycle) by individual outlets and outlet groups
Outlet group support at the PDU
Supports multiple power control methods — Wake on LAN, System After AC Back, Kill the Power
Power-On sequencing — users can set the power-on sequence and delay time for each outlet to allow equipment to be powered on in the correct order
Proactive overload protection(POP) — automatically powers off the last outlet that caused the current overload
The ATEN PE8324G Eco PDU is a reliable power distribution unit designed for modern data centers and server rooms. Built with intelligent monitoring and switching functions, it provides efficient control of connected devices while maintaining flexibility through its 0U vertical design. With advanced network management and environmental awareness features, it helps maintain stable and secure operations in demanding IT environments.
ATEN's NRGence line-up is a new generation of green energy power distribution units (eco PDUs) that optimize the efficiency of data center power usage. The PE8324 eco PDUs are intelligent PDUs that contain 24 AC outlets and are available in various IEC / NEMA socket configurations. These models feature proactive overload protection to automatically power off the last outlet that causes the current overload while allowing users to set shutdown priority.
The eco PDUs provide secure, centralized and intelligent power management (power on, off, and cycle) of data center IT equipment (servers, storage systems, KVM switches, network devices, serial data devices, and more), as well as the ability to monitor the center's health environment via sensors.*These PDUs offer remote power control combined with real-time power measurement, allowing users to control and monitor the power status of devices attached to the PDUs, either at the PDU device, bank, or outlet level, depending on the model, from practically any location via a TCP / IP connection.
The power status of each outlet can be set individually, allowing users to switch each device on / off. The eco PDU also offers comprehensive power analysis reports which can separate departments and locations, providing precise measurements of current, voltage, power and watt-hour in a real-time display. Installation and operation are made fast and easy by simply plugging cables into their appropriate ports, and users get to enjoy the intuitive browser-based configuration and management. The eco PDU firmware is upgradeable over the Net, meaning users can download updates from ATEN's website to ensure that their eco PDU is equipped with the latest functionalities and improvements.
The series also supports the 3rd party V3 SNMP manager software and NRGence eco DC (Energy & DCIM Management Web GUI). The eco DC makes it easy when it comes to the management for multiple devices by allowing users to configure eco PDU setting and monitor the power status of the equipment connected to the PDU through a user friendly interface. Along with its set of features, the PE8324 series has become a convenient, reliable and cost-effective solution to help remotely manage power access for multiple computer installations and allocate power resources with efficiency.
* Note:
1. Sensors are optional accessories. A sensor-enabled installation is required to generate more complete energy-efficient data and charts. The higher the sensor installation density is, the more accurate the data generated will be.
2. eco PDUs are primarily designed for access via Intranet; extra network security protection is suggested for Internet access usage.
Key Features
Connections
Supports 10 / 100M bit Ethernet interface
Supports TCP / IP, UDP, HTTP, HTTPS, SSL,SMTP, DHCP, ARP, NTP, DNS, Telnet, Auto Sense, Ping, SNMP V1,V2 and V3
Supports three-level account / password security, IP / MAC filter, 128 bit SSL, and RADIUS
Supports CC2000, eco DC, multiple browsers (IE, Firefox, Chrome, and Safari)
Metering
PDU and outlet level power metering and monitoring
Environment monitoring – supports external temperature / temperature and humidity sensors for rack temperature and humidity monitoring
Current, voltage, power, power dissipation, temperature, and humidity metering and threshold level setting
Supports door sensor
Outlet Switch Control
Remote power outlet control (On/Off, Power Cycle) by individual outlets and outlet groups
Outlet group support at the PDU level
On / Off scheduling for individual outlet and outlet groups. Power management tasks can be scheduled on a daily, weekly, or user-specifi ed time basis
Supports multiple power control methods – Wake on LAN, System After AC Back, Kill the Power
Power-On sequencing – users can set the power-on sequence and delay time for each outlet to allow equipment to be powered on in the correct order
Proactive overload protection (POP) – automatically powers off the last outlet that causes the current overload while allowing users to set shutdown priority
ECO DC Included free with Aten PDUs
The Eco DC energy tracking and reporting program is included at no additional cost with every ATEN PDU, providing users with valuable insights into energy consumption. This program enables real-time monitoring, detailed reporting, and efficient management of power usage, helping organizations optimize performance and reduce unnecessary energy waste—all without requiring extra investment.
Download ECO DC For Free Here
*Contact ATEN UK support for Serial Number to activate, via
[email protected]
Aten PG6308G 30A/32A 8-Outlet 1U Switched eco PDU
ATEN's PG6308 switched series intelligent PDU features 8 outlets* housed in a compact 1U rack enclosure.
Dual 1G Ethernet ports support cascading up to 64 PDUs
Environment sensor port enables RJ-45 connectivity to connect or daisy-chain up to 8 ATEN EA1640 environment sensors for monitoring and management of temperature, humidity, airflow, differential air pressure, and leaks, featuring alerts for potential threats (sold separately)
Precise kWh metering (+/-1% ) for better power consumption habits, baselines, and initiative tracking
With an ARM Cortex-A8 processor, these PDUs provide advanced control options through USB, COM, environmental sensors, and dual Gigabit LAN ports
With an ARM Cortex-A8 processor, these PDUs provide advanced control options through USB, COM, environmental sensors, and dual Gigabit LAN ports.
Designed for rapid deployment, PG series PDUs can power all connected equipment within just 10 seconds of being plugged in. For enhanced cost efficiency and space optimization, these intelligent PDUs can be cascaded, allowing interconnection of up to 64 units.
The PG series PDUs are equipped with RJ-45 sensor ports to connect with EA1640 that monitor the health of the data center environment, ensuring optimal operating conditions. They offer secure, centralized, and intelligent power management capabilities, allowing users to power on, off, or cycle data center IT equipment such as servers, storage systems, KVM switches, network devices, and serial data devices.
With the integration of remote power control and real-time power measurement, users can manage and monitor the power status of devices connected to the PG series PDUs from virtually anywhere with an IP connection. This functionality is accessible at the PDU device, bank, or outlet level, depending on the specific model.
These intelligent PDUs are capable of handling high voltage ranges of 100V to 240V. Additionally, they provide precise kWh energy usage data with an accuracy of ±1%. This level of precision enhances the monitoring of power consumption, aids in the establishment of baseline energy usage, and supports the tracking of energy efficiency initiatives.
In terms of hardware design, the PG series PDUs incorporate built-in energy-saving relays – subtypes of electromagnetic switches – to manage large current flows more efficiently, resulting in lower energy consumption compared to non-relay models. The PG series models are equipped with circuit breakers that support 30A or 32A currents, automatically disconnect the power supply to prevent overloads, and protect connected devices from damage.
The firmware of the PG series is upgradeable via web GUI or USB, allowing users to conveniently download updates from ATEN's website, ensuring access to the latest functionalities and improvements for practical use.
Green LCD console panel sticker is included for users, with additional options in blue, yellow, red, and purple available for purchase. This color-coding system enhances the ability to differentiate between power feed settings and facilitates more efficient troubleshooting.
The PG series intelligent PDUs are ideally suited for enterprise server rooms, network closets, and data centers, providing an intelligent power distribution and management solution that meets the demands of high-density IT applications while optimizing overall costs.
Note:
1. PG6308A contains 8 x NEMA 5-20R socket configurations
2. PG6308B / PG6308G contains 6 x IEC60320 C13 and 2 x IEC60320 C19 socket configurations
Features
Metering
Secure locking enhancement prevents power cords from becoming unplugged due to vibration or human error
Metering and monitoring of power at the PDU and outlet levels
Measuring and establishing threshold levels for current, voltage, power, power dissipation, temperature, and humidity
Precise kWh metering (+/-1% ) for better power consumption habits, baselines, and initiative tracking
Real-time alerts via LCD display notify users of unusual power states:
– Home Screen Readings: A (aggregate Current), V (voltage), W (power), kWh (power consumption)
– Types of Alerts: Critical, Alert (value exceeds a predefined threshold), Warning (value approaches alert threshold)
Network
Dual Ethernet ports support cascading up to 64 PDUs
Daisy chaining functions support SNMP & Modbus protocols and TC / IP protocols (web page)
Supports ATEN’s eco DC (Energy & DCIM Management Web GUI) for monitoring power distribution, energy, and environmental data from PDUs and connected devices
Outlet Switch Control
Remote power outlet control (On/Off, Power Cycle) by individual outlets and outlet groups
Outlet group support at the PDU level
Supports multiple power control methods – Wake on LAN, System After AC Back, Kill the Power
Power-On/Off sequencing – users can set the power-on sequence and delay time for each outlet to allow equipment to be powered on in the correct order
Proactive overload protection (POP) – automatically powers off the last outlet, causing the current overload, while allowing users to set shutdown priority
Schedule Control
When the temperature or humidity sensor value reaches the predetermined threshold, the PDU can turn on, off, or reboot a particular outlet
Energy-efficient relays allow operators to control large amounts of current flow for lower energy consumption
Package Content
1 x 8-Outlet 1U eco PDU
1 x rack mount kit
1 x foot pad set (4 pcs)
1 x RJ-45 to DB-9 cable
1 x full-panel colored sticker
1 x user instructions
ECO DC Included free with Aten PDUs
The Eco DC energy tracking and reporting program is included at no additional cost with every ATEN PDU, providing users with valuable insights into energy consumption. This program enables real-time monitoring, detailed reporting, and efficient management of power usage, helping organizations optimize performance and reduce unnecessary energy waste—all without requiring extra investment.
Download ECO DC For Free Here
*Contact ATEN UK support for Serial Number to activate, via
[email protected]
Aten PG8308G 30A/32A 8-Outlet 1U Outlet-Metered & Switched eco PDU
ATEN's PG8308 outlet-metered & switched series intelligent PDU features 8 outlets* housed in a compact 1U rack enclosure.
Dual 1G Ethernet ports support cascading up to 64 PDUs
Environment sensor port enables RJ-45 connectivity to connect or daisy-chain up to 8 ATEN EA1640 environment sensors for monitoring and management of temperature, humidity, airflow, differential air pressure, and leaks, featuring alerts for potential threats (sold separately)
Precise kWh metering (+/-1% ) for better power consumption habits, baselines, and initiative tracking
With an ARM Cortex-A8 processor, these PDUs provide advanced control options through USB, COM, environmental sensors, and dual Gigabit LAN ports
With an ARM Cortex-A8 processor, these PDUs provide advanced control options through USB, COM, environmental sensors, and dual Gigabit LAN ports.
Designed for rapid deployment, PG series PDUs can power all connected equipment within just 10 seconds of being plugged in. For enhanced cost efficiency and space optimization, these intelligent PDUs can be cascaded, allowing interconnection of up to 64 units.
The PG series PDUs are equipped with RJ-45 sensor ports to connect with EA1640 that monitor the health of the data center environment, ensuring optimal operating conditions. They offer secure, centralized, and intelligent power management capabilities, allowing users to power on, off, or cycle data center IT equipment such as servers, storage systems, KVM switches, network devices, and serial data devices.
With the integration of remote power control and real-time power measurement, users can manage and monitor the power status of devices connected to the PG series PDUs from virtually anywhere with an IP connection. This functionality is accessible at the PDU device, bank, or outlet level, depending on the specific model.
These intelligent PDUs are capable of handling high voltage ranges of 100V to 240V. Additionally, they provide precise kWh energy usage data with an accuracy of ±1%. This level of precision enhances the monitoring of power consumption, aids in the establishment of baseline energy usage, and supports the tracking of energy efficiency initiatives.
In terms of hardware design, the PG series PDUs incorporate built-in energy-saving relays – subtypes of electromagnetic switches – to manage large current flows more efficiently, resulting in lower energy consumption compared to non-relay models. The built-in circuit breaker on the PG series models support current flows of 30A or 32A, automatically disconnecting the power supply to prevent overloads and protect connected devices from damage.
The firmware of the PG series is upgradeable via web GUI or USB, allowing users to conveniently download updates from ATEN's website, ensuring access to the latest functionalities and improvements for practical use.
Green LCD console panel sticker is included for users, with additional options in blue, yellow, red, and purple available for purchase. This color-coding system enhances the ability to differentiate between power feed settings and facilitates more efficient troubleshooting.
The PG series intelligent PDUs are ideally suited for enterprise server rooms, network closets, and data centers, providing an intelligent power distribution and management solution that meets the demands of high-density IT applications while optimizing overall costs.
Note: 1. PG8308A contains 8 x NEMA 5-20R socket configurations
2. PG8308B / PG8308G contains 6 x IEC60320 C13 and 2 x IEC60320 C19 socket configurations
Connections
Supports 1Gbps Ethernet Interface
Remote Management Protocols – TCP/IP, UDP, HTTP, HTTPS, SSL, DHCP, SMTP (TLS 1.2), ARP, NTP, DNS, Auto Sense, Ping, SNMP V1, V2, and V3, Telnet, Modbus (over TCP/IP), Wi-Fi, and IPv6
Scripting – JSON-RPC (Remote Procedure Call) protocol and Python scripting to control specified PDU units
Security – 2-level account/password login access, and IP/MAC filter, 128 bit SSL
Authentication – RADIUS, LDAP, TACACS
Supports eco DC and multiple browsers (IE, Firefox, Chrome, and Safari)
Supports RS-232 and RS-485 communication ports
Auto Ping & Reboot
Environment sensor port enables RJ-45 connectivity to connect or daisy-chain up to 8 ATEN EA1640 environment sensors for monitoring and management of temperature, humidity, airflow, differential air pressure, and leaks, featuring alerts for potential threats (sold separately)
Rotatable LCD Screen – capable of 180-degree rotation, delivering flexible in-rack installation
Metering
Secure locking enhancement prevents power cords from becoming unplugged due to vibration or human error
Metering and monitoring of power at the PDU and outlet levels
Measuring and establishing threshold levels for current, voltage, power, power dissipation, temperature, and humidity
Precise kWh metering (+/-1% ) for better power consumption habits, baselines, and initiative tracking
Real-time alerts via LCD display notify users of unusual power states:
– Home Screen Readings: A (aggregate Current), V (voltage), W (power), kWh (power consumption)
– Types of Alerts: Critical, Alert (value exceeds a predefined threshold), Warning (value approaches alert threshold)
Network
Dual Ethernet ports support cascading up to 64 PDUs
Daisy chaining functions support SNMP & Modbus protocols and TC / IP protocols (web page)
Supports ATEN’s eco DC (Energy & DCIM Management Web GUI) for monitoring power distribution, energy, and environmental data from PDUs and connected devices
Outlet Switch Control
Remote power outlet control (On/Off, Power Cycle) by individual outlets and outlet groups
Outlet group support at the PDU level
Supports multiple power control methods – Wake on LAN, System After AC Back, Kill the Power
Power-On/Off sequencing – users can set the power-on sequence and delay time for each outlet to allow equipment to be powered on in the correct order
Proactive overload protection (POP) – automatically powers off the last outlet, causing the current overload, while allowing users to set shutdown priority
Schedule Control
When the temperature or humidity sensor value reaches the predetermined threshold, the PDU can turn on, off, or reboot a particular outlet
Energy-efficient relays allow operators to control large amounts of current flow for lower energy consumption
Package Content
1x 8-Outlet 1U eco PDU
1x rack mount kit
1x foot pad set (4 pcs)
1x RJ-45 to DB-9 cable
1x full-panel colored sticker
1x user instructions
ECO DC Included free with Aten PDUs
The Eco DC energy tracking and reporting program is included at no additional cost with every ATEN PDU, providing users with valuable insights into energy consumption. This program enables real-time monitoring, detailed reporting, and efficient management of power usage, helping organizations optimize performance and reduce unnecessary energy waste—all without requiring extra investment.
Download ECO DC For Free Here
*Contact ATEN UK support for Serial Number to activate, via
[email protected]
The PE4102G Eco PDU Power Controller is designed to deliver precise, remote-controlled power distribution in compact
IT environments. Built for efficiency and reliability, it enables administrators to manage connected devices
intelligently, reduce downtime, and maintain system stability across edge deployments, retail setups, and data
centres.
Key Features of PE4102G Eco PDU Power
Controller
2 IEC outlets with intelligent power distribution
Remote power control via TCP/IP connection
Built-in 10/100 Ethernet port for network access
Power sequencing to prevent inrush damage
Auto ping and auto reboot for device recovery
Web-based eco DC software support
Email-based outlet control (IMAP & POP3)
Compact design with multiple mounting options
Advanced security with TLS encryption and RADIUS support
Intelligent Remote Power Management
Control connected devices from virtually anywhere using TCP/IP connectivity. The PE4102G allows administrators to
switch outlets on or off, reboot equipment, and manage power states remotely, reducing the need for on-site
intervention and improving operational efficiency.
Reliable Power Sequencing
The integrated power sequencing function helps prevent electrical surges during startup by allowing users to
define startup order and delay intervals. This ensures stable system performance while protecting sensitive IT
equipment from inrush current damage.
Automated Device Recovery
With auto ping and auto reboot capabilities, the unit continuously monitors device connectivity. If a failure is
detected, the system automatically reboots the affected outlet, helping maintain uptime and reducing manual
troubleshooting.
Flexible Control Options
Manage power locally via the device interface or remotely through a browser-based GUI. Additional control is
available through scheduled operations and even email commands, giving administrators multiple ways to maintain
control over connected equipment.
Robust Network Compatibility
The PE4102G supports a wide range of network protocols including HTTP, HTTPS, SNMP, Modbus over TCP/IP, and more.
This ensures seamless integration into existing IT infrastructures while maintaining compatibility with enterprise
monitoring systems.
Enhanced Security Framework
Security is reinforced through two-level password protection, TLS 1.2 and 1.3 encryption, and RADIUS
authentication support. These features help safeguard access and maintain secure control over critical power
systems.
Compact and Versatile Installation
The slim form factor allows for flexible deployment, whether desk-mounted, wall-mounted, or rack-mounted. This
makes it ideal for space-constrained environments such as retail installations, digital signage setups, or edge
computing locations.
Continuous System Accessibility
The design separates the unit’s operational power from its outlets, ensuring the user interface remains
accessible even if a circuit breaker trips due to overload. This enables faster recovery and uninterrupted
management access.
Optimised for Edge and Commercial Use
Well-suited for hospitality, retail, and distributed IT environments, the PE4102G provides reliable power control
for routers, servers, cameras, and digital displays where continuous uptime and remote accessibility are
essential.
I/O Diagram
What's in the Box
1x PE4102G 2-Outlet Eco PDU Power Controller
1x Power Cord
1x User Instructions
