5 Port Layer 2 Managed Switches

Flexible 5-port, Layer 2 PoE switch for indoor and outdoor use, that can be powered with PoE++

PoE Flexibility

The USW-Flex supports a maximum PoE output budget of 46W when powered by 60W 802.3bt PoE++. Four ports offer auto-sensing 802.3af PoE output to power multiple devices on the network.

Versatile Mounting

The USW-Flex can be installed horizontally or vertically making it ideal for desktop, magnetic wall-mount, and pole-mount installations.

Indoor/Outdoor Design

The USW-Flex is designed for indoor or outdoor use. With its weatherproof housing and versatile mounting options, the USW-Flex provides both flexibility and durability for environments with extreme temperature variations

Compatible Products

The USW-Flex powers a variety of products, including the UniFi Video Camera G3 Flex, UniFi Video Camera G4 Pro, and UniFi AC Mesh AP, which use 802.3af PoE. To enable its maximum power budget of 46W, the USW-Flex can be powered by the USW-Industrial switch, which provides 60W of 802.3bt PoE++.

Seamless Integration

A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.

Product Features

(4) GbE PoE+ ports
(1) GbE PoE++ input port for power
46W PoE availability* PoE++ input
20W PoE availability* PoE+ input
8W PoE availability* PoE input
Indoor/Outdoor
*When powered with a PoE++ switch or a 60W PoE adapter (sold separately). Ubiquiti Extended Warranty

Ubiquiti currently offers 1 year standard manufacturer warranty on equipment purchased through official UK distributors.

In the unlikely event that you have any issues with your Ubiquiti product within the 1 year of manufacturer warranty, please contact your account manager in the first instance. Our technical team will do everything they can to find a resolution to your problem. If a fix cannot be provided, then an RMA will need to be registered via the Ubiquiti Reseller Portal.

On all purchases made through Comms Express, we offer our customers options to upgrade the standard manufacturer warranty to a 3 or 5 year advanced hardware replacement.

Available warranty options:



The Ubiquiti UniFi Switch USW-FLEX is a configurable Layer 2 Gigabit switch with auto-sensing 802.3af PoE. It offers five RJ45 Gigabit Ethernet ports, providing 1 PoE input and 4 PoE output links to your devices.

Product Features (1) GbE, PoE++ RJ45 input

(4) GbE, PoE+ RJ45 ports

Up to a 46W total PoE supply*

Weatherproof design with multiple mounting options


Overview Flexible five-port, Layer 2 PoE switch that can be powered with PoE++.

Managed with the UniFi Network application: Version 5.10.3 and later

*When powered with a PoE++ switch or a 60W PoE adapter (sold separately).

TRENDnet's Industrial Gigabit L2 Managed DIN-Rail Switch series offers advanced layer 2 managed features with enhanced traffic controls to meet the evolving demands of today's SMB networks.

Each industrial layer 2 managed switch is equipped with an IP30 rated metal enclosure, designed to withstand a high degree of vibration and shock, while operating within a wide temperature range of -40°C to 75°C for industrial environments.


Key Features:

4 x Gigabit ports
2 x SFP slots
Supports 100/1000Base-FX fibre SFP modules
12Gbps switching capacity
Hardened IP30 rated metal housing
Includes DIN-rail mounting bracket
Operating temperature range of -40°C to 75°C
Supports LACP, STP/RSTP, VLAN, and IGMP Snooping
IEEE 802.1p QoS with queue scheduling support
Bandwidth control per port
Dual redundant power inputs with overload current protection
Alarm output triggered by power failure
Supports Ethernet Ring Protection Switching (ERPSv2)
Power supply sold separately (model: TI-M6024)

Our industrial layer 2 managed switch models feature copper Gigabit ports for high-speed device connections, and SFP slots that support both 100Base-FX and 1000Base-FX modules for long distance fibre networking applications.

These industrial layer 2 managed DIN-Rail switches provide an intuitive web-based management interface. Each TRENDnet industrial layer 2 managed switch supports advanced traffic management controls, troubleshooting, and SNMP monitoring.

Advanced managed switch features include LACP to group ports together to increase bandwidth between switches, VLANs for segmenting and isolating virtual LAN groups, QoS for traffic prioritization, port bandwidth controls, and SNMP monitoring making each TRENDnet industrial layer 2 managed switch a powerful solution for SMB networks.


Datasheets / User Manuals / Quick Start Guides can be downloaded from our Documentation tab (above)
