Zyxel 5G LTE Routers

The Zyxel FWA-515-GB0102F is a 5G NR indoor router that combines high-speed mobile broadband with WiFi 7 connectivity for homes, offices, retail locations and other environments where fast internet access is required without relying solely on fixed-line services. Supporting 5G download speeds of up to 7.01 Gbps and WiFi 7 BE7200 wireless performance, it can connect multiple devices while maintaining high-speed wireless networking.

Key Features of Zyxel FWA-515-GB0102F 5G NR connectivity with download speeds of up to 7.01 Gbps
WiFi 7 BE7200 with wireless link rates up to 7,200 Mbps
Supports both 5G NSA and SA modes
Dual-band 2.4 GHz and 5 GHz WiFi with 4x4 + 4x4 MIMO
Multi-Link Operation (MLO) for WiFi 7 connectivity
Up to 64 connected WiFi devices
Two 2.5GbE RJ-45 ports, with the second port configurable for Ethernet WAN
Automatic failover between 5G and Ethernet WAN
4FF Nano SIM card slot
Two external TS9 antenna connectors with internal/external antenna selection
USB 2.0 Type-A port for file sharing
WPA2 and WPA3 wireless security
Nebula cloud management support
High-Speed 5G Connectivity With support for 5G NR and both standalone and non-standalone modes, the router provides a high-speed mobile broadband connection where traditional wired broadband may not be available or suitable. Zyxel specifies up to 7.01 Gbps downstream performance under 5G SA conditions, while 4G LTE connectivity is also supported for wider network compatibility.

WiFi 7 Wireless Networking The WiFi 7 BE7200 platform supports wireless link rates of up to 7,200 Mbps and uses concurrent 4x4 MIMO across the 2.4 GHz and 5 GHz bands. Multi-Link Operation helps compatible devices make use of multiple wireless links, providing a modern wireless platform for demanding connected environments.

Dual-WAN Flexibility Two 2.5GbE Ethernet ports provide high-speed wired connectivity, with the second port configurable for Ethernet WAN use. This allows the router to use a wired connection alongside its 5G connection and supports automatic failover between 5G and Ethernet WAN for greater connection continuity.

Flexible Antenna and Device Connectivity The router includes four embedded 5G and 4G omni-directional antennas, plus two TS9 connectors for external antennas when additional antenna flexibility is required. A Nano SIM slot provides cellular access, while the USB 2.0 Type-A port can be used for file sharing across the network.

Security and Cloud Management Wireless security includes WPA2-PSK and WPA3-SAE support, with MAC address filtering and multiple SSID options. The FWA515 also supports Zyxel Nebula cloud management, allowing configuration, monitoring and network administration through the Nebula platform.

The Zyxel FWA70-EU0202F is an outdoor 5G NR and 4G LTE router that provides high-speed mobile broadband for locations where fixed-line connectivity is unavailable, unreliable or requires a backup connection. Supporting 5G standalone and non-standalone modes with download speeds of up to 7.01 Gbps, it combines 4x4 MIMO with four integrated directional antennas for strong signal reception. Its IP55-rated enclosure, wide operating temperature range and pole-mounting support make it suitable for outdoor deployments.

Key Features of Zyxel FWA70-EU0202F 5G NR Sub-6 GHz connectivity with SA and NSA support
5G SA download speeds up to 7.01 Gbps
5G NSA download speeds up to 5.67 Gbps
4G LTE connectivity with download speeds up to 1.6 Gbps
4x4 MIMO support for 5G and 4G connectivity
Four integrated directional 5G/4G antennas with up to 9 dBi peak gain
2.5GbE RJ45 PoE LAN port for data and power through one cable
IEEE 802.3af/at 2.5G PoE support
Nano SIM card slot for mobile network connectivity
IP55-rated enclosure for outdoor installation
K.21 6 kV surge protection and Level 12 wind resistance
Router and Bridge IP pass-through modes
Integrated firewall with SPI and DoS attack detection
Remote management through Nebula and Zyxel One app support
High-Speed 5G Broadband The router supports 5G NR Sub-6 GHz connectivity in both standalone and non-standalone modes. 5G SA can provide theoretical download speeds of up to 7.01 Gbps and upload speeds of up to 2.5 Gbps, while 5G NSA supports download speeds up to 5.67 Gbps. 4G LTE support provides continued connectivity where 5G coverage is unavailable.

Directional Antenna System Four integrated directional 5G and 4G antennas support 4x4 MIMO and provide peak antenna gain of up to 9 dBi depending on the frequency band. The directional antenna configuration is suited to outdoor installations where positioning the router towards the strongest available mobile signal can help maximise connectivity.

Outdoor Connectivity The IP55-rated enclosure provides protection for outdoor installations, while the router operates across temperatures from -30°C to 55°C. It supports Level 12 wind resistance for pole mounting and includes K.21 6 kV surge protection, making it suitable for demanding outdoor connectivity deployments.

PoE Network Connection A 2.5GbE RJ45 PoE LAN port provides a high-speed wired network connection while allowing power and data to travel through a single Ethernet cable. The router supports IEEE 802.3af/at 2.5G PoE, helping simplify installation where the unit is positioned away from the main networking equipment.

Remote Management and Security Management options include local and remote Web GUI access, TR-069 remote management, CLI and SSH access, along with Zyxel One app support. Nebula provides cloud-assisted setup and centralised monitoring, while IPv4 and IPv6 networking, NAT/NAPT, VPN pass-through, SPI, DoS protection and application-level firewall functions provide a range of network management and security controls.

5G - Empower the Future

Unlock Broadband via 5G Fixed Wireless Access

The most powerful 5G NR indoor router ever is here. Unlock the speed with a professional 5G FWA router. Integrated design that's ready for the future. Get more done with pro-quality assistance!

Powerful Chip, 5G Unleashed

Thanks to the mind-blowingly fast chip, which is designed with an integrated quad-core Arm CPU, it provides 5G speeds of up to an impressive 5 Gbps* right out of the box. Along with the two integrated 2.5 Gbps Gigabit Ethernet interfaces, allowing it a wide range of LAN port configurations for ultra-fast speed for connection to servers, workstations, or high-end gaming devices.

Get groundbreaking performance in both speed and wide-spectrum bandwidth for multi-streaming data access and reduce network latency for premium and time-sensitive internet services now!

3.6 Gbps - Accelerate with WiFi 6

Fast and vast. When 5G meets WiFi 6, they can boost larger bandwidth and capacity than previous legacy solutions. The Nebula FWA510 offers speeds of up to 3.6 Gbps** on dual bands with the latest WiFi 6 (AX3600) standard. Nebula FWA510 can deliver an optimal seamless high-speed WiFi experience to 64 wireless devices simultaneously.

24/7 - Non-stop Connectivity

Nebula FWA510 ensures that you'll have internet access even during a fixed line network outage with the WAN failover capability, which allows Nebula FWA510 to either serve as a primary or backup option for internet access according to your needs. It is equipped with four external TS9 antenna ports***, allowing you to improve mobile broadband reception when you are in a weak-signal area.

Strong and stable connection work together to give you the power and flexibility to achieve greater productivity!

Security - Without Compromise

Nebula FWA510 is deployed with simple yet essential security and protection functions to help you reduce the risk of falling a victim of data theft and sabotage.

Multiple SSIDs/hide SSIDs
NAT/NAPT firewall
DoS attack detection
WPA2 and WPA3
URL filtering
Application-level firewall
LAN MAC filtering
IP filtering
WLAN MAC filtering
SPI (Stateful Packet Inspection)
  Nebula Cloud - Manage Devices Anywhere

Managing mobile routers behind carrier grade NAT can be challenging and expensive as you need to buy VPN service or lease extra landline from ISP. This is where Nebula Cloud comes to help!

Nebula Cloud platform provides real-time network management anytime anywhere with ease. Centrally provisioning and seamlessly manage all networking devices, including access points, switches and firewalls within your organization that are across distributed locations from the Nebula platform, while keeping your network aware of constantly changing devices.

Get the richest collaboration with everything you need on a simplified and unified Nebula Could platform. Get started now!

Flexible Subscription for Your Needs

Nebula Control Center (NCC) offers multiple subscription options to meet customers’ needs. Whether you are looking for a complimentary option giving you some peace of mind at no extra cost, more control over your network updates and visibility, or even the most advanced management of cloud networking, Nebula is here to help you.

The plan you choose will determine the service level of Nebula Cloud.

Zyxel Air - Network Management Just Got Easy

Our free and easy to use “Zyxel Air” mobile app provides you the assistance from device setup to routine management. Nebula FWA510‘s smooth, rubber exterior and discreet, sleek design make it both durable and stylish. Its plug-and-play capability, and intuitive LED indicators on the device makes your user experience more efficient and intelligent!

Take Your Business to the Next Level

In this era of everything being remote, digital transformation is deemed the key to long-term business success and could be seen as a necessary change for all businesses. From robotics to automation, machine learning to predictive analytics, current organizations are driven digitally. To make your businesses more agile and able to deal with major changes, it's time to get over the traditional form of operations and take your business to the next level.
Nebula FWA710 is an 5G outdoor router with Nebula Cloud platform built in. It is designed for business that require higher performance of 5G along with consistent high-quality network connectivity for business-critical digital operations. Let Nebula FWA710 be your backbone of your network to pave the way for your future business success!

Effortlessly Manage All Devices Anytime Anywhere at Any Scale

Nebula Cloud platform provides real-time network management anytime anywhere with ease. Centrally provisioning and seamlessly manage all networking devices, including access points, switches and firewalls within your organization that are across distributed locations from the Nebula platform, while keeping your network aware of constantly changing devices.
Get the richest collaboration with everything you need on a simplified and unified Nebula Could platform. Get started now!

5G, Innovation and Transformation Start Today

Speed is everything in business. Technology progresses at record pace, so companies must do whatever it takes to stay relevant. Nebula FWA710 has up to 5 Gbps data rates, which can provide your business an advantage by being faster than others. Take part in it now!

Be the Pioneer of Pioneers

Feeling the need to increase bandwidth and network speed at office? Want to help manufacturing production operations become more flexible and efficient with better precision and lower costs than human inspection? Get a head start on smart office or industry 5.0, it’s time to upgrade to 5G and empower your future. Nebula FWA710 is poised to be your backbone of your network to pave the way for your future business success.

Enterprise-class 5G Router, Always-on Network

Nebula FWA710 is not only a simple network router, but your multipurpose business partner. It can be deployed as part of a Fixed Wireless Access (FWA) without extra wire infrastructure. To set 5G as your primary connection or use it as a backup when the primary connection drops. Nebula FWA710 also supports bridge mode to connect multiple devices without the risk of performance issues. Nebula FWA710 offers more than just 5G, the variety of usage is entirely up to you!

Transforming Your Business Today

Four 9dBi long range directional antennas are built into the Nebula FWA710, providing more focus transmission beam for receiving better cellular signal strength and quality from operator base stations. Better donor signal quality, faster cellular data speed. Choose the Nebula FWA710, start business transformation today.

Strong Backbone, Stronger Connection

Nebula FWA710 has industrial-grade components with outdoor-friendly design making it possible to work in harsh environment conditions where desirable signal strength is difficult to achieve or having weather challenges including strong winds and rainstorms. Nebula FWA710 guarantees high-quality connections and a longer device life, which supports your business deployment in wide territorial scopes.

Network Slicing, Tailor Your Network

Nebula FWA710 is interoperable with both Standalone (SA) and Non-Standalone (NSA) deployments. Under SA mode, Nebula FWA710 can support network slicing function with tailored network capabilities that are essential to fulfil different business needs, like dealing complex environments with massed wired and wireless networks for separate factory and office connections, and handling of multiple-node WiFi infrastructure, which can be unstable. Customize network via Nebula FWA710 to keep ahead of industry and to ensure success!

Easy and Instant Installation

A remote and simple DIY for own installation costs less than fiber as no electrician is required! To find the best signal spot for installation, you just need to use a smartphone or tablet to connect to Nebula FWA710’s WiFi network and follow its configuration instruction on the free “Zyxel Air” app. Comes with flexible wall and pole mounting options, integrated Power over Ethernet (PoE) support makes power requirements a non-issue.
