Ubiquiti UniFi Outdoor Access Points

Incredibly compact, indoor/outdoor AP with versatile mounting options and long-range external antenna support.

Main Features

WiFi 5
4 spatial streams
115 m² (1,250 ft²) coverage with internal antenna
200+ connected devices
Powered using PoE
GbE uplink
Versatile wall, ceiling, and pole mounting
(2) RP-SMA connectors for optional external antennas*
Weatherproof (outdoor exposed)
*Omnidirectional and directional antenna accessories coming soon. Mechanical Specifications

Dimensions: 137 x 84 x 34 mm (5.4 x 3.3 x 1.3")
Weight: 173 g (6.1 oz)
Enclosure material: UV-stabilized polycarbonate
Mount material: Polycarbonate, SGCC steel, plastic
Pole mount diameter: 1~2" on pipe outer diameter
Wind survivability: 33.2 N at 200 km/h (7.5 lbf at 125 mph)
Weatherproofing: IPX6
*For complete specifications see the documentation tab above

The Ubiquiti UniFi UAP-AC-M Access Point features high-performance, wide-area WiFi with UniFi Mesh Technology. The UniFi AC Mesh is also weather resistant, fitting seamlessly into any indoor or outdoor environment. It includes adjustable, dual-band omni antennas for outdoor or indoor omnidirectional coverage. You can also use a 5 GHz omni antenna for spot-beam coverage in high-density locations with numerous access points and clients, or add a 5 GHz sector antenna for broad, outdoor coverage (see 'Available Options' above).

Ubiquiti UniFi UAP AC Mesh Access Point Key Features

Ideal for Indoor/Outdoor environment
2.4 GHz Speed* 300 Mbps
2.4 GHz MIMO 2x2
5 GHz Speed* 867 Mbps
183 m (600 ft) Range
Compact Form Factor
The UAP-AC-M discreetly integrates into any environment.

Weather-Resistant Enclosure
The UAP-AC-M can be used indoors or outdoors.

Versatile Mounting
The UniFi AC Mesh AP can be mounted on a wall, pole, or fast-mount of a Ubiquiti high-gain antenna.

Multiple Power Options
The UAP-AC-M is compatible with 802.3af PoE Alternative A and 24V passive PoE. You can power it with the included Gigabit PoE adapter or an 802.3af Alternative A compatible switch, such as the UniFi PoE Switch or EdgePoint EP-R6.

Antenna Options
Use the included omni antennas, or use the included fast-mount adapter to install the AP on an optional connectorised antenna for expanded range coverage and customised pattern shaping.



The UniFi AC Mesh AP provides simultaneous, dual-band, 2x2 MIMO technology

UniFi is the revolutionary Wi-Fi system that combines enterprise performance, unlimited scalability, and a central management controller. The UniFi AC Mesh APs have a refined industrial design and can be easily installed using the included mounting hardware.

High-Performance Wide-Area Wi-Fi with UniFi® Mesh Technology
Dual-Band performance with aggregate speeds of up to 1167 Mbps
802.3af PoE Compatibility
Need a five pack?

UAP-AC-M-5

Ubiquiti UniFi UAP AC M - 5 Pack

Buy





UniFi AC Mesh

802.11AC Indoor/Outdoor Wi-Fi Access Point with Plug and Play Mesh Technology



Antenna Versatility

Adjustable dual-band omni-directional antennas and Fast-Mount included for expanded range cover







Optimal Performance

Dual-Band performance with aggregate speeds of up to 1167 Mbps





Compact Form Factor

The UniFi AC Mesh base is just slightly larger than a standard pen, making it easy to deploy anywhere. Dimensions: 354x46x34mm (HxWxD)





Multiple Power Options

Power the UniFi AC Mesh with an 802.3af compatible switch, a UniFi PoE switch, or the included Gigabit PoE adapter





Mounting Flexibility

The UniFi AC Mesh can be mounted on a pole, wall or Ubiquiti high-gain antenna



Unified IT Management

UniFi creates a highly scalable, end-to-end system of devices spanning mulitple locations across the world - all controlled by a single interface accessed via the internet or local network





UAP-AC-MUAP-AC-M-PRO Environment Indoor/ Outdoor Outdoor Simultaneous Dual-Band 2.4 GHz Speed 300 Mbps 450 Mbps 2.4 GHz MIMO 2x2 3x3 5 GHz Speed 867 Mbps 1300 Mbps 5 GHz MIMO 32x2 3x3 Range 183 mt 122 mt Secondary Ethernet Port   PoE Mode 24V Passive PoE 802.3af PoE: Alternative A 802.3af PoE Dimensions 353 x 46 x 34 mm 343 x 181 x 60 mm Wall Mount Pole Mount Fast Mount

Conquer Large Outdoor Areas with Reliable WiFi: Ubiquiti UniFi AC Mesh Pro Outdoor Access Point (UAP-AC-M-PRO)

The Ubiquiti UniFi AC Mesh Pro Outdoor Access Point (UAP-AC-M-PRO) provides a powerful and weatherproof solution for extending high-performance WiFi to your outdoor spaces.

Featuring Wi-Fi 802.11ac, 3x3 MIMO technology and a sleek industrial design, the UniFi AP-AC is a Ubiquiti Networks Access Point (AP), ideal for deployment of high-performance wireless networks.


The UniFi AC Mesh AP provides simultaneous, dual-band, 3x3 MIMO technology

High-Performance Wide-Area Wi-Fi with UniFi® Mesh Technology
Breakthrough Speeds up to 1300 Mbps in the 5 GHz Band
802.3af PoE Compatibility

UniFi AC Mesh Pro

802.11AC Outdoor Wi-Fi Access Point with Plug and Play Mesh Technology

Powerful Coverage

Built in Dual-Band omni-directional antennas included for expanded range outdoors



Optimal Performance

Dual-Band Performance with aggregate speeds up to 1750 Mbps


Multiple Power Options

Power the UniFi AC Mesh Pro with an 802.3af compatible switch, a UniFi PoE switch, or the included Gigabit PoE adapter



Mounting Flexibility

The UniFi AC Mesh Pro can be mounted on a pole or to a wall

Weatherproof Form Factor

The UniFi AC Mesh Pro is designed to withstand the elements, making it ideal for outdoor deployment.
Dimensions: 343.2 x 181.2 x 60.2mm (HxWxD)

Unified IT Management

UniFi creates a highly scalable, end-to-end system of devices spanning mulitple locations across the world - all controlled by a single interface accessed via the internet or local network




UAP-AC-MUAP-AC-M-PRO Environment Indoor/ Outdoor Outdoor Simultaneous Dual-Band 2.4 GHz Speed 300 Mbps 450 Mbps 2.4 GHz MIMO 2x2 3x3 5 GHz Speed 867 Mbps 1300 Mbps 5 GHz MIMO 2x2 3x3 Range 183 mt 122 mt Secondary Ethernet Port   PoE Mode 24V Passive PoE 802.3af PoE: Alternative A 802.3af PoE Dimensions 353 x 46 x 34 mm 343 x 181 x 60 mm Wall Mount Pole Mount Fast Mount

Ubiquiti Extended Warranty

Ubiquiti currently offers 1 year standard manufacturer warranty on equipment purchased through official UK distributors.

In the unlikely event that you have any issues with your Ubiquiti product within the 1 year of manufacturer warranty, please contact your account manager in the first instance. Our technical team will do everything they can to find a resolution to your problem. If a fix cannot be provided, then an RMA will need to be registered via the Ubiquiti Reseller Portal.

On all purchases made through Comms Express, we offer our customers options to upgrade the standard manufacturer warranty to a 3 or 5 year advanced hardware replacement.

Available warranty options:







Expand Your Outdoor WiFi Horizons with the Ubiquiti UniFi AC Mesh Pro Outdoor Access Point (UAP-AC-M-PRO) 5-Pack (No PoE Injectors)
The Ubiquiti UniFi AC Mesh Pro Outdoor Access Point (UAP-AC-M-PRO) 5-Pack (No PoE Injectors) delivers a cost-effective solution for blanketing large outdoor areas with reliable and high-performance WiFi. This 5-pack equips you with multiple access points, ideal for:
Homes with expansive yards, patios, pool areas, or outdoor entertainment spaces
Businesses with outdoor seating areas, gardens, open-air work environments, or warehouses
Large outdoor venues like parks, sports complexes, or event spaces


Product Features
802.11ac Wave 1 WiFi technology

5 GHz (3x3 MIMO) band with a 1.3 Gbps throughput rate

2.4 GHz (802.11n) band with a 450 Mbps throughput rate

Powered with PoE*

(2) GbE RJ45 ports



Overview
Dual-band, 802.11ac Wave 1 access point with an omnidirectional super antenna and 3x3 MIMO functionality.

With its 5 GHz (3x3 MIMO) and 2.4 GHz (802.11n) bands, the Access Point AC Mesh Pro (UAP AC Mesh Pro) is a high-performance, outdoor-ready, dual-band, 802.11ac WiFi access point that can achieve a throughput rate of 1.75 Gbps.

Furthermore, the UAP AC Mesh Pro has a tailored omnidirectional super antenna that offers exceptional 360° coverage and symmetrical long-range transmission up to 183 metres.

In order to support numerous high-speed LAN connections, this access point has two GbE RJ45 ports and is powered by PoE.

With the UniFi Network web application or mobile app, the UAP AC Mesh Pro can be fully configured and managed in minutes.
