Ubiquiti Security

Product Features Customized encasing for G4 Doorbell.




Blends seamlessly into a variety of backgrounds


Compatible with the G4 Doorbell

The UVC-G4-Doorbell-PS-UK is an optional power adapter for the UVC-G4-Doorbell-UK.

Instead of using existing electrical wiring, one end connects to the doorbell and the other end plugs into a standard EU electrical outlet. Maximum distance: 6 m (19' 8").

EU PSU. Circular EU-UK converter/adaptor required. (Ui currently only produce an EU and US variant of this unit).

Features

Plugs into standard (EU) electrical outlet UK Converter/Adaptor provided
Input: 110VAC, 60 Hz, 1A
Output: 20VAC, 0.7A
Cable length: 6 m (19' 8")
(2) Spade wire connectors

UniFi Protect G4 Doorbell is a WiFi video doorbell with a built-in display and real-time two-way audio communication.

The camera features a high-quality 5MP sensor with enhanced night vision. Image streams can be viewed in up to 1600x1200 (2MP) HD at 30 FPS. UniFi Protect G4 Doorbell includes a PIR sensor for instant motion detection alerts. Integration with UniFi Protect provides an easy-to-use interface.

Features

1600x1200 (2MP) HD stream with night vision
Integrated entrance lighting
Real-time two-way audio with echo cancellation
Built-in display
Dual-band 802.11ac WiFi
PIR motion detection sensor
Weather-resistant
UniFi Protect integration
Ubiquiti Extended Warranty

Ubiquiti currently offers 1 year standard manufacturer warranty on equipment purchased through official UK distributors.

In the unlikely event that you have any issues with your Ubiquiti product within the 1 year of manufacturer warranty, please contact your account manager in the first instance. Our technical team will do everything they can to find a resolution to your problem. If a fix cannot be provided, then an RMA will need to be registered via the Ubiquiti Reseller Portal.

On all purchases made through Comms Express, we offer our customers options to upgrade the standard manufacturer warranty to a 3 or 5 year advanced hardware replacement.

Available warranty options:



WiFi-connected video doorbell with a primary 5MP night vision camera, secondary 8 MP package camera, programmable display, and porch light.

The G4 Doorbell Pro is a WiFi-enabled video doorbell equipped with a primary 5MP camera and a secondary 8MP package camera. The doorbell's main camera is equipped with IR LED to provide enhanced night vision that, when combined with the built-in porch light, ensures a reliably clear surveillance feed around the clock.

The G4 Doorbell Pro also features echo-cancelling, two-way audio so you can interact with visitors, and its programmable display allows you to give alerts or delivery instructions to couriers. Designed to be a powerful, plug-and-play security tool, the G4 Doorbell Pro can be set up and configured in minutes with the UniFi Protect application.

Product Features

Improved HDR and low-light performance
Programmable welcome display and secondary package-detection camera
20 ft IR night vision
AI event detections
Wirelessly connected (auto-connect to UniFi WiFi)
Integrated 2-way audio
Weather-resistant (outdoor covered)
Build Features

Ubiquiti Extended Warranty

Ubiquiti currently offers 1 year standard manufacturer warranty on equipment purchased through official UK distributors.

In the unlikely event that you have any issues with your Ubiquiti product within the 1 year of manufacturer warranty, please contact your account manager in the first instance. Our technical team will do everything they can to find a resolution to your problem. If a fix cannot be provided, then an RMA will need to be registered via the Ubiquiti Reseller Portal.

On all purchases made through Comms Express, we offer our customers options to upgrade the standard manufacturer warranty to a 3 or 5 year advanced hardware replacement.

Available warranty options:



UACC-G4 Doorbell Pro Cover available in a variety of colours/textures Specifications



Dimensions:
Cover: 164 x 55 x 21 mm (6.5 x 2.2 x 0.8")
Wedge mount cover: 164 x 55 x 26 mm (6.5 x 2.2 x 1")
Weight:
Cover: 17.3 g (0.6 oz)
Wedge mount cover: 13.7 g (0.5 oz)
Enclosure material: Polycarbonate
Colours/Textures:
Brick
Concrete
Silver
White
Wood
Compatability:
UVC-G4 Doorbell Pro
UVC-G4 Doorbell Pro UVC-G4 Doorbell Pro PoE

Premium UniFi doorbell with integrated PoE and included PoE chime for plug-and-play installation. Features

Improved HDR and low-light performance
Programmable welcome display and secondary package-detection camera
AI event detections
Connect and power using PoE
Integrated 2-way audio
Includes PoE Chime
Weather-resistant (outdoor covered)
Specifications

Mechanical

Dimensions (UVC-G4 Doorbell Pro): Device: 160.6 x 51.7 x 35.1 mm (6.3 x 2 x 1.4")
Wall mount: 159.3 x 50.3 x 17.5 mm (6.3 x 1.9 x 0.7")
Wedge: 161.1 x 52.1 x 25.7 mm (6.3 x 2.1 x 1")
On-wall mount: 161.1 x 52.1 x 25.75 mm (6.3 x 2.1 x 1")

Dimensions (UP-Chime PoE): Device: Ø62 x 54 mm (Ø2.5 x 2.1")
In-wall mount: Ø89 x 63.1 mm (Ø3.5 x 2.5")
On-wall mount: Ø62 x 20.2 mm (Ø2.5 x 0.8")

Weight (UVC-G4 Doorbell Pro):
Device: 264 g (9.3 oz)
Wall mount: 56 g (2 oz)
Wedge: 33 g (1.2 oz)
On-wall mount: 53 g (1.9 oz)
Weight (UP-Chime PoE):
Device: 158 g (5.6 oz)
In-wall mount: 91 g (3.2 oz)
On-wall mount: 28 g (1 oz)
Enclosure Material: Aluminum alloy, polycarbonate
Mount Material:
Wall mount: aluminum alloy
Wedge: polycarbonate
On-wall mount: polycarbonate
Chime mount: polycarbonate, zinc alloy
Wetherproofing: IPX4 (UVC-G4 Doorbell Pro)
Optic

Sensor:
Main camera: 5MP CMOS
Package camera: 8MP CMOS
Lens: Fixed focal length
View Angle:
Main camera: H: 138°, V: 114°, D: 155° (LDC On)
Main camera: H: 160°, V: 117°, D: 160° (LDC Off)
Package camera: H: 97.5°, V: 79.4°, D: 118.2°
Night Mode: Built-in IR LED illumination and IR cut filter
Video and Audio

Video compression: H.264
Resolution:
Main camera: 2MP 1600 x 1200 (4:3)
Package camera: 2MP 1600 x 1200 (4:3)
Max. frame rate: 30 FPS
Microphone: Yes (Can be disabled for the Doorbell)
Speaker: Yes
Buzzer: Yes (UP-Chime PoE)
System

Processor: Quad-core Arm® Cortex®-A53 based chip
Networking interface: UVC-G4 Doorbell Pro: GbE RJ45 port. UP-Chime PoE: 10/100 MbE port
Max. power consumption: UVC-G4 Doorbell Pro: 7W. UP-Chime PoE: 3.5W
Power method: PoE
Supported voltage range: UVC-G4 Doorbell Pro: 37—57V DC. UP-Chime PoE: 44–57V DC
Ambient operating temperature: UVC-G4 Doorbell Pro: -30 to 40º C (-22 to 104º F). UP-Chime PoE: 0 to 40° C (32 to 104° F)
Ambient operating humidity: UVC-G4 Doorbell Pro: 0 to 90% noncondensing. UP-Chime PoE: 10 to 90% noncondensing

Indoor/outdoor intercom terminal for managing residential and commercial building entry requests. Features

Unlock using an NFC card, UniFi Identity mobile app, PIN code or QR code
Directory and doorbell to request entry
Pairs with multiple UniFi Intercom Viewers for remote access control
Connects to UniFi Access Hub series using PoE
Weatherproof (outdoor exposed -30 to 60° C)
Specifications

Mechanical

Dimensions: 324.8 x 113.7 x 28.3 mm (12.8 x 4.5 x 1.1")
Weight:
Device: 965 g (2.1 lb)
Bracket: 445 g (1 lb)
Enclosure material:Aluminum alloy, UV-stabilized polycarbonate, glass
Mount material: Powder-coated stainless steel
Mounting:
Wall mount, adapter to the gooseneck pedestal (Included)
Surface angle mount, flush mount (Optional)
Sunshield kit (Optional)
Weatherproofing: IP65
Hardware

Networking interface: (1) GbE RJ45 port
Connectivity: Bluetooth 4.2 , NFC
Power method PoE
Supported voltage range: 48V DC
Max. power consumption: 13W
ESD/EMP protection: Air: ±15kV, Contact: ±8kV
Sensors: Proximity sensor, ALS sensor
Camera: 3264 x 2448, 8 MP. H: 79.4°, V: 97.5°, D: 118.2°
Display: 177 mm (7") diagonal
Resolution 1024 x 600 (16:9)
Display luminance Max. 1000 nits (typical)
Touch screen technology Capacitive multi-touch
Microphone Yes
Speaker (1) 4 ohm, 2W
Ambient operating temperature Device: -30 to 60° C (-22 to 140°F). Display:* -25 to 60° C (-13 to 140° F)
Ambient operating humidity 5 to 90% noncondensing
*The display will turn off when the ambient temperature is above/below the display operation temperature, but other functions will remain functional. (Effective after firmware v 1.0.66)

Display that pairs with the Access Intercom for visitor screening and remote access control, to mount in multiple locations throughout your building.

Features

Two-way audio
Instant live view
5" touch display
Connect and power using a PoE switch
Specifications

Mechanical

Dimensions: 135 x 72 x 31.8 mm (5.3 x 2.8 x 1.3")
Weight: 168 g (5.9 oz)
Enclosure material: Glass, polycarbonate
Mount material: Aluminum alloy
Mounting: Wall (Included), Gang box mount (Gang box not included)
Weatherproofing: IP65
Hardware

Networking interface: (1) 10/100 Mbps RJ45 port
Management interface: Ethernet
Power method PoE
Supported voltage range: 48V DC
Max. power consumption: 13W
Display: 127 mm (5") diagonal
Resolution 720 x 1280 (9:16)
Display luminance 300 nits (typical)
Touch screen technology Capacitive multi-touch
Microphone Yes
Speaker (1) 4 ohm, 2W
Ambient operating temperature -10 to 40° C (14 to 104° F)
Ambient operating humidity 5 to 95% noncondensing

Four-and-a-half-meter USB cable that connects a Camera G4 Instant to a PoE source.

Connects a Camera G4 Instant to a PoE source*
GbE connectivity
Cable length 4.5 m
*PoE to USB-C Adapter sold separately.

Specifications

Weight: 117 g (4.1 oz)
Cable length: 4.5 m (14.76 ft)
Cable color: White
Shielding type: Shielded twisted pair (STP)
Conductor wire gauge: (2) 24 AWG + (3) 30 AWG
Conductor type: Stranded copper
Jacket material: Thermoplastic elastomer (TPE)
Jacket diameter: 3.5 mm (0.14 in)
Bend radius: Min. 14 mm (0.55 in)
Anti-crosstalk divider: No
Flam rating: VW-1 (UL1581)
Storage temperature: -40 to 85° C (-40 to 185° F)
Ambient operating temperature: -20 to 60° C (-4 to 140° F)

Seven-meter-long power adapter that connects the G4 Doorbell Pro to a standard AC outlet.

Plugs into standard electrical outlet
100—240V AC, 50/60 Hz, 0.3A input and 5V DC, 2A output
Cable length 7 m
Specifications

Mechanical

Jacket enclosure dimensions: Without prong - Ø51.6 x 23 mm (Ø2 x 0.9")
Jacket enclosure material: Polycarbonate
Cable length: 7 m (23 ft)
Cable diameter: 4.8 mm
Cable jacket material: Thermoplastic elastomer
Weight: 394 g (13.9 oz)
Connector type: USB-C
Hardware

Input rating: 100–240V AC, 50/60 Hz, 0.3A
Output rating: 5V DC, 2A
Ambient operating temperature: -10 to 40° C (14 to 104° F)
Ambient operating humidity: 10 to 95% noncondensing
