The LanTEK IV-L is a state-of-the-art copper certifier designed to optimize network testing efficiency with rapid 10-second test times and comprehensive diagnostic capabilities.
Features
The LanTEK IV-L can test and save a Cat6A cable in just 10 seconds, including measurements for DC resistance unbalance (DCRU) and transverse conversion loss (TCL).
The innovative VisiLINQ™ permanent link adapters enhance productivity by providing all necessary operations and result verifications in the palm of your hand.
The Saphire Care plan ensures minimal downtime, reduces ownership costs, and protects against unexpected repair bills.
The device is ETL Verified to TIA 1152-A/IEC 61935-1 Level IIIe standards, ensuring precise performance measurements up to 500 MHz.
The LanTEK IV-L performs length and wiremap tests with Time Domain Reflectometry (TDR) fault location, and offers Main/Remote NEXT, PSNEXT, Return Loss, PSACR-F, ACR-N certification.
It includes Main/Remote TCL/ELTCTL noise immunity certification.
The certifier assesses resistance unbalance for PoE++ applications.
It simplifies troubleshooting by providing distance-to-fault locations for NEXT and Return Loss issues.
What's in the box?
LanTEK IV-L 500MHz Cable Certifier (TIA Category 6A/ISO Class EA),
LanTEK IV-L Display/Remote Handsets, 2 Li-ion Batteries,
2 Universal Power Adapters, 2 Hanging Straps,
Quick Reference Guide, Carry Case,
2 CAT6A RJ45 VisiLINQ Permanent Link Adapters,
And 2 CAT6A Channel Adapters.
*For complete specifications see the documentation tab above.
