Businesses need to be ready for future expansion: with incoming new multispeed devices, their wired network needs to expand its reach and scope to support speeds greater than 1 Gigabit. The IEEE 802.3bz standard paved the way for new 2.5 Gigabit and 5 Gigabit speeds in addition to legacy 1 Gigabit and 10 Gigabit per second. New servers, workstations, storage devices, and motherboards are coming with 802.3bz (NBASE-T) Multi-Gigabit Ethernet for 2.5X to 5X faster speeds up to 100 meters (323 feet) on legacy Cat5E / Cat6 cables.
With 10G Copper/Fibre Uplinks

Plenty of headroom with 1G, 2.5G, 5G and even 10G!

Businesses need to be ready for future expansion: with incoming new multispeed devices, their wired network needs to expand its reach and scope to support speeds greater than 1 Gigabit. The IEEE 802.3bz standard paved the way for new 2.5 Gigabit and 5 Gigabit speeds in addition to legacy 1 Gigabit and 10 Gigabit per second. New servers, workstations, storage devices and motherboards are coming with 802.3bz (NBASE-T) Multi-Gigabit Ethernet for 2.5X to 5X faster speeds up to 100 metres (323 feet) on legacy Cat5E / Cat6 cables. Hardware Features:

Multi-Gigabit to connect any type of device to a single switch 2-port RJ-45 Multi-Gigabit Ethernet IEEE 802.3bz (NBASE-T) 100M/1G/2.5G/5G
2-port RJ-45 Multi-Gigabit Ethernet IEEE 802.3bz (NBASE-T) 100M/1G/2.5G
4-port RJ-45 Gigabit Ethernet 10M/100M/1G
1-port RJ-45 10 Gigabit Ethernet Copper (100M/1G/2.5G/5G/10GBASE-T)
1-port SFP+ 10 Gigabit Ethernet Fibre (1G/10GBASE-X SFP+)
Fan-speed control with max 21dB at 25°C (77°F) ambient
Each port automatically detects which speed is needed by the connected device and provides the adequate speed. As opposed to regular 10-Gigabit switches that will only provide 1-Gigabit connectivity to any device that require less than 10-Gigabit, the MS510TX gives the exact speed required, with no downgrade. Also, the new NETGEAR Multi-speed switch ports can connect regular CAT5e Ethernet cables, without the need to upgrade to CAT6 wiring, therefore reducing wiring costs and hassle.
Desktop Switch with 10G Uplinks - Application 1

Collapse Core for Advanced Small Businesses

Desktop Switch with 10G Uplinks - Application 2

Department / Relay IP Surveillance Switch
Local Government, Hospitalities, Industry

Desktop Switch with 10G Uplinks - Application 3

IDF / Distribution Switch for Wireless LAN Access in K12


*Switch shown in example applications is a MS510TXPP
Access, Aggregation or Collapsed Core

You can now have your PCs, printers and routers/firewalls connected at 1G and aggregate Multi-Gigabit Ethernet new devices on the same switch, all line-rate. 10G copper and fibre ports are ready for local servers and storage, or high-speed aggregation to your network core. Comprehensive L2+/Layer 3 Lite Features

NETGEAR Smart Managed Pro Switches offer powerful L2+ and Layer 3 Lite features, enhanced performance and usability. They are purposely designed for converged networks where voice, video, data are all carried on a single network platform. These switches are optimised for network efficiency, operational cost savings, and ease of management. Advanced features such as IPv4/IPv6 Layer 3 static routing, DiffServ QoS, LACP link aggregation and Spanning Tree will satisfy even the most advanced small business networks. Multi-Gigabit for Future-Proof Deployments

With or without PoE, the switches provide two Multi-Gigabit RJ-45 ports that support 5G, 2.5G, and 1G; another two Multi-Gigabit RJ-45 ports that support 2.5G and 1G; four 1G RJ-45 ports; one dedicated 10G RJ-45 uplink port (which also supports 5G, 2.5G and 1G); and one dedicated SFP+ fibre uplink port that supports 10G and 1G. Smart IT, not Big IT

No need for an IT expert or a complicated user manual, just configure your network with the user-friendly NETGEAR Smart Managed Pro Web browser-based management GUI. The MS510TX and MS510TXPP are backed by NETGEAR ProSAFE Lifetime Limited Warranty and 24/7 support including lifetime chat.

Smart IT, not Big IT

No need for an IT expert or a complicated user manual, just configure your network with the user-friendly NETGEAR Smart Managed Pro Web browser-based management GUI. The MS510TX and MS510TXPP are backed by NETGEAR ProSAFE Lifetime Limited Warranty and 24/7 support including lifetime chat. MS510TX MS510TXPP Form Factor Desktop (Rackmount Kit) Desktop (Rackmount Kit) Ports 8 8 Management Smart Managed Pro 10M/100M/1G Copper Ports 4 4 PoE+ 100M/1G 2.5G Copper Ports 2 2 PoE+ 100M/1G/2.5G/5G Copper Ports 2 2 PoE+ 100M/1G/2.5G/5G/10G Copper Ports 1 (dedicated) 1 (dedicated) 1G/10G SFP+ Fibre Ports 1 (dedicated) 1 (dedicated) PoE 802.3at Ports N/A 8 Total PoE Power budget (Watts) N/A 180W Dimensions (WxDxH) mm 328 x 169 x 43 mm  328 x 169 x 43 mm  Power Supply Internal Internal Fans 1 1 Max MAC entries 16K 16K VLAN (Number Supported) 256 256

View More
In Stock: Next Day
£210.56
£252.67 Inc Vat.
Qty:
With 10G Copper/Fibre Uplinks

Plenty of headroom with 1G, 2.5G, 5G and even 10G!

Businesses need to be ready for future expansion: with incoming new multispeed devices, their wired network needs to expand its reach and scope to support speeds greater than 1 Gigabit. The IEEE 802.3bz standard paved the way for new 2.5 Gigabit and 5 Gigabit speeds in addition to legacy 1 Gigabit and 10 Gigabit per second. New servers, workstations, storage devices and motherboards are coming with 802.3bz (NBASE-T) Multi-Gigabit Ethernet for 2.5X to 5X faster speeds up to 100 metres (323 feet) on legacy Cat5E / Cat6 cables. Hardware Features:

Multi-Gigabit to connect any type of device to a single switch 2-port RJ-45 Multi-Gigabit Ethernet IEEE 802.3bz (NBASE-T) 100M/1G/2.5G/5G
2-port RJ-45 Multi-Gigabit Ethernet IEEE 802.3bz (NBASE-T) 100M/1G/2.5G
4-port RJ-45 Gigabit Ethernet 10M/100M/1G
1-port RJ-45 10 Gigabit Ethernet Copper (100M/1G/2.5G/5G/10GBASE-T)
1-port SFP+ 10 Gigabit Ethernet Fibre (1G/10GBASE-X SFP+)
180W PoE budget available across 8 Gigabit and Multi-Gigabit PoE+ ports (802.3at)
Fan-speed control with max 21dB at 25°C (77°F) ambient
Each port automatically detects which speed is needed by the connected device and provides the adequate speed. As opposed to regular 10-Gigabit switches that will only provide 1-Gigabit connectivity to any device that require less than 10-Gigabit, the MS510TXPP gives the exact speed required, with no downgrade. Also, the new NETGEAR Multi-speed switch ports can connect regular CAT5e Ethernet cables, without the need to upgrade to CAT6 wiring, therefore reducing wiring costs and hassle.
Desktop Switch with 10G Uplinks - Application 1

Collapse Core for Advanced Small Businesses

Desktop Switch with 10G Uplinks - Application 2

Department / Relay IP Surveillance Switch
Local Government, Hospitalities, Industry

Desktop Switch with 10G Uplinks - Application 3

IDF / Distribution Switch for Wireless LAN Access in K12

Access, Aggregation or Collapsed Core

You can now have your PCs, printers and routers/firewalls connected at 1G and aggregate Multi-Gigabit Ethernet new devices on the same switch, all line-rate. 10G copper and fibre ports are ready for local servers and storage, or high-speed aggregation to your network core. Comprehensive L2+/Layer 3 Lite Features

NETGEAR Smart Managed Pro Switches offer powerful L2+ and Layer 3 Lite features, enhanced performance and usability. They are purposely designed for converged networks where voice, video, data are all carried on a single network platform. These switches are optimised for network efficiency, operational cost savings, and ease of management. Advanced features such as IPv4/IPv6 Layer 3 static routing, DiffServ QoS, LACP link aggregation and Spanning Tree will satisfy even the most advanced small business networks. Multi-Gigabit for Future-Proof Deployments

With or without PoE, the switches provide two Multi-Gigabit RJ-45 ports that support 5G, 2.5G, and 1G; another two Multi-Gigabit RJ-45 ports that support 2.5G and 1G; four 1G RJ-45 ports; one dedicated 10G RJ-45 uplink port (which also supports 5G, 2.5G and 1G); and one dedicated SFP+ fibre uplink port that supports 10G and 1G.

Smart IT, not Big IT

No need for an IT expert or a complicated user manual, just configure your network with the user-friendly NETGEAR Smart Managed Pro Web browser-based management GUI. The MS510TX and MS510TXPP are backed by NETGEAR ProSAFE Lifetime Limited Warranty and 24/7 support including lifetime chat. MS510TX MS510TXPP Form Factor Desktop (Rackmount Kit) Desktop (Rackmount Kit) Ports 8 8 Management Smart Managed Pro 10M/100M/1G Copper Ports 4 4 PoE+ 100M/1G 2.5G Copper Ports 2 2 PoE+ 100M/1G/2.5G/5G Copper Ports 2 2 PoE+ 100M/1G/2.5G/5G/10G Copper Ports 1 (dedicated) 1 (dedicated) 1G/10G SFP+ Fibre Ports 1 (dedicated) 1 (dedicated) PoE 802.3at Ports N/A 8 Total PoE Power budget (Watts) N/A 180W Dimensions (WxDxH) mm 328 x 169 x 43 mm  328 x 169 x 43 mm  Power Supply Internal Internal Fans 1 1 Max MAC entries 16K 16K VLAN (Number Supported) 256 256

View More
In Stock: Next Day
£250.98
£301.18 Inc Vat.
Qty:
